ORTILEB BACK-ROLLER PRO PLUS Quick Start Manual

PRODUCT INFO

BACK-ROLLER PRO PLUS
XLtouring pannier with roll closure and QL2.1 system
Carrying handle for mounting and releasing
Automatically closing 16mm QL2.1 hooks
Exchangeablehook inserts with anti-scratch
function (8, 10, 12 mm)
Adjustable and rotatable mounting hook
(in 15° steps) withanti-scratchfunction
Semi-elliptical hook rail madeof two-component
synthetic with anti-scratch function
Edgeprotector with slots for mounting the
Carrying SystemBike Pannier
height cm/in width cm/in.
45/17.7 36/24 14.1/9.4

SPECIFICATIONS:

SPECIFICATIONS:
+ XLrear pannier (single) with roll closure for extendedtouring with lots of equipment
+ Outerfront pocket (4 L) folds flat, with reflective thread, ideal for damp clothing
+ Material: PU-laminated Cordura
+ Integrated inner pocket and shoulder strap
+ Easyto clean inside
+Twostrong 3M Scotchlite reflectors
+ QL2.1 mounting system for racks with tube diameter max.16 mm
+ hook available as accessory (e.g. for e-bikes)
18 mm & 20 mm
+ Reductioninserts for tube diameters 8, 10 und 12 mmwith anti-scratch-function protecting the rack from abrasions
+ Upper QL-hooksand lower hook adjustable without requiring any tools
+ Lowerhook with anti-scratch function protecting the rack from abrasions
+ Symmetrical shape allows use on right or left side
+ Canbecombined on the rack with ORTLIEBRack-Packsize24 Lor 31 L
Contents: Pannierpair with 2 shoulder straps, reducting inserts 8, 10 und 12 mm (2 pairs per size)
Optional accessories: Packing Cubes/Commuter Insert for Panniers, Carrying SystemBike Pannier, Anti-Theft-Device (E125), Outer Pocket2,1 L, Mesh-Pocket,Bottle-Cage, QL2.1 hook
18mm (E211) & 20mm (E193)
Attention: Maximumload per pannier is 9kg / 20 lbs. Werecommendweighingeach loaded pannier to confirm that the maximumallowance of the pannier fixation is not exceeded.
This practice is advised for both rear and front panniers. CAUTION:Themaximumweightcapacity of every carrier model is different. Please observe the maximumweight allowance of
the carrier fitted to your bicycle. Note: Sometimes the maximumcapacity of the panniers fixing system can exceed the maximum capacity of the carrier. DONOT exceed the maximum
capacity of the carrier! Note, that the use of panniers will significantly influence the handling properties of yourbicycle.
Attention: Asabrasion cannot be ruled out, we recommendthat all points wherethe mounting system contacts the bicycle rack or frame be protected by scratch protection film.
Note: In order to meet standard IP64 (6=dustproof, 4=protected against splash watercomingfrom all directions) the roll closure must be rolled at least 3-4 times.
ORTLIEBSport art ikel GmbH · Rainstrasse 6 · 91560 · Heilsbronn, Germany· T +49 9872 800-0 · F +49 9872 800-266 · E info@ortlieb.com · www.ortlieb.com
the QL2.1 system
depth cm/in.
26/10.2
Additional closure with buckle (when the bag
is carried with the shoulder strap)
Roll closure
Front pocket with reflective thread
Bucklesfor fixing roll closure or
shoulder strap
Shoulder strap with padding for comfortable
carrying or for fixing to the hook
Lateral 3M Scotchlite reflector on
both sides
vol. Ltr. weight gr.
35+4 1004
PVC
free IP 64
QL2.1
A n t i
system
scratch
PS36C
max. capacity kgs.
9
