Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property and other rights in or to the information contained herein, and such
information may only be used in connection with the operation of your GAI-Tronics product or system.
This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
General Information
®
The 751-001 Page/Party
important component of the 700 Series Page/Party
system. It mates directly with the 701 and 751 Series
Enclosures and broadcasts page announcements over
®
the Page/Party
system speakers.
The 751-001 is constructed of 16-gauge cold-rolled
steel and is suitable for either indoor or outdoor use.
Installation
CAUTION
Do not install this equipment in hazardous areas or
areas other than those on the equipment approval list
in the Specifications section. Such installation may
cause a safety hazard and consequent injury or
property damage.
To install, plug the 751-001 Speaker Amplifier into the appropriate enclosure, and tighten the four screws
in the corners of the front panel. Refer to Figure 1 for typical installation details.
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
V
ISIT WWW
G A I - T R O N I C S ®
A H U B B E L L C O M P A N Y
751-001 Page/Party
Speaker Amplifier
Speaker Amplifier is an
®
610-777-1374
800-492-1212
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
®
Figure 1. 751-001 Speaker Amplifier
(shown with an indoor enclosure)
Fax: 610-796-5954
Pub. 42004-210B
Advertisement
Table of Contents
Related Manuals for Hubbel GAI-TRONICS Page/Party 700 Series
Summary of Contents for Hubbel GAI-TRONICS Page/Party 700 Series
- Page 1 Pub. 42004-210B G A I - T R O N I C S ® A H U B B E L L C O M P A N Y 751-001 Page/Party ® Speaker Amplifier Confidentiality Notice This manual is provided solely as an operational, installation, and maintenance guide and contains sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
- Page 2 Pub. 42004-210B ® 2 of 3 751-001 Page/Party Speaker Amplifier Page: Adjustment The 751-001 Speaker Amplifier mates with an enclosure wired directly to a speaker. The speaker volume adjustment is located under the GAI-Tronics nameplate on the front panel. Refer to Figure 1. Use a small flat-blade screwdriver to adjust the speaker sound volume.
- Page 3 Pub. 42004-210B ® 3 of 3 751-001 Page/Party Speaker Amplifier Page: Approvals NRTL Listed for USA and Canada ..........Class I, Div. 2, Groups A, B, C, D when used with listed GAI-Tronics 702 or 703 120 V ac series enclosures Class I, Div.
- Page 4 Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
