PS390e
SAS Expansion Enclosure
User Manual
3/9/2022
RASILIENT CONFIDENTIAL PROPRIETARY INFORMATION
This document contains confidential information that is proprietary to Rasilient or confidential information which
Rasilient has a legal duty to protect from disclosure. The information contained in this document may not be
disclosed without the express written permission of Rasilient Systems Inc.

Advertisement

Table of Contents
loading

Related Manuals for Rasilient PS390e

Summary of Contents for Rasilient PS390e

  • Page 1 This document contains confidential information that is proprietary to Rasilient or confidential information which Rasilient has a legal duty to protect from disclosure. The information contained in this document may not be disclosed without the express written permission of Rasilient Systems Inc.
  • Page 2 This document contains confidential information that is proprietary to Rasilient or confidential information which Rasilient has a legal duty to protect from disclosure. The information contained in this document may not be disclosed without the express written permission of Rasilient Systems Inc.
  • Page 3 Manufacturer of this product has the right to change specifications and product descriptions at any time without notice. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page - 3 -...
  • Page 4 About This Manual Safety Symbols Environmental Specifications Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page - 4 - of this document.

  • Page 5: About This Manual

    Fill in the content > Menu links at all levels Bold Menu, Button, Options Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page - 5 - of this document.

  • Page 6: Cooling Specification

    The system can operate during a PSU replacement service interval of 10 minutes without experiencing an over temperature condition in the canister. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 7: Table Of Contents

    Push Chassis into Rack ..............................52 HARDWARE OVERVIEW ............................53 ESM C ....................... 53 ANISTER XPANDER TORAGE ODULE ANISTER Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 8 ................................ 73 ONNECT THE ENCLOSURE PORT CONFIGURATION ..............................75 ..............................75 INGLE PORT CONFIGURATION ..............................75 EDUNDANT CONFIGURATION Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 9 Figure 32: Or other top cover ......................47 Figure 33: Locker ..........................48 Figure 34: Assemble HDD into Chassis ..................... 50 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 10 Figure 63: Single Port Configuration ....................75 Figure 64: Redundant Configuration ....................76 Figure 65: PS7012 to PS390e SAS connections ................76 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 11: General Overview

    1100 mm rack (not include door space) including space for cable management. The PS390e product pictures are as shown below: PS390e Front PS390e Rear 1 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 12 Hot-pluggable service from rear of chassis, AC power cord on the rear of the chassis 73.5mm(W) x 40 mm (H) x 185 mm (L) ● Fan module Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 13: Feature Summary

    Power control for 12Gb/s SAS drive via pin3  Power Supply Four 1200W PSU support redundant 2+2 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 14 One passive Power Interconnect Board (PIB) to provide system power rail(12V and 12VSB) from PSU and connect to 5V DC-DC board for providing disk’s Power rail(5V)  Front Bezel Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 15: Product Appearance

    Figure below, is a trimetric view of the chassis. Figure 1: PS390e System Trimetric View Figure 2: PS390e Front View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 16: Figure 3: Ps390E Rear View

    Figure below, is a rear view of the chassis, showing PSU, DC-DC and ESM canisters. Figure 3: PS390e Rear View Figures below, show the indicator information on PS390E JBOD. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 17: Figure 4: Ps390E Front Indicators

    Enclosure Identify LED- UID (BLUE) Off – Normal operation Table 1-1 Indicator information on the front of PS390E Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 18: Figure 5: Indicators On Top Of Ps390E

    Fan 1~ Fan 5: Fan fault indicators. Table 1-2 Indicator information on the top of PS390E cover Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 19: Figure 6: Indicators On Rear Of Ps390E

    ① PSU1 PSU 2 ② PSU2 DC-DC Module 1 ③ DC1 ESM Canister A ④ ESM1 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 20 PSU 4 ESM Canister B ⑧ ESM2 Table 1-3 Indicator information on the rear of PS390E Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 21: Product Exploded View

    At Minimum 15 drives need to be installed. Product Exploded View Figure 8: PS390e Exploded View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 22: Storage Enclosure Installation

     While shipping the product, pack it inside of the qualified package and ship with pallet. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 23: Power Cord Connection

    Do not use household extension cords with your product. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 24: Electro-Static Discharge (Esd) Caution And Warnings

    Rack System Instructions The following or similar rack-mount instructions are included with the installation instructions: Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 25 Reduced Air Flow – Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the equipment is not compromised. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 26: Others Warnings And Cautions

    A third person may be required to help align the storage if the server is installed higher than chest level. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 27: Regulatory Information Fcc (Us)

    NOTICE: Any modifications made to this device that are not approved by Rasilient may void the authority granted to the user by the FCC to operate this equipment. ICES-003 (Canada) Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 28: Ce (European Community)

    This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 29 この装置は、情報処理装置等電波障害自主規制協議会(VCCI)の基準に基づくクラス A 情報技術装置です。 この装置を家庭環境で使用すると電波妨害を引き起こすことがあります。この場合には使用者が適切な対策を 講ずるよう要求されることがあります。 中国环保使用期限标志 此产品环保使用期限是 年，在此期限内可安全放心使用，到期后必须进入回收环节。 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 30: Necessary Tools

    Figure 10: ESD Protection 2) Protective gloves: Figure 11: Protective Gloves 3) Screwdriver: Figure 12: Screw Driver Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 31: Check The Installation Environment

    Follow the following steps to unpack the product: 1) Inspect the package to make sure that it has not been damaged. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 32: Rail Kit

    Figure 14: Slide Rails Step 1: 1) Remove the inner rail. 2) Push (a) and slide middle rail back. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 33: Figure 15: Remove The Inner Rail

    Step 2: Install the inner member onto the chassis. Figure 16: Install the inner member onto the chassis Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 34: Figure 17: Fix Inner Rail To Chassis

    The inner rail fixed on chassis by 8 pcs screw, on each side 4 pcs screw (M4xL6). Figure 17: Fix Inner Rail to Chassis Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 35: Figure 18: Install Cma Bracket

    Step 4: Install the outer rail onto the rack post. Figure 19: Rail Assembled on Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 36: Figure 20: Fixing Rail On Rack

    4) &5)When the chassis is locked, push release blue tab on both sides and continue sliding the chassis to the rack. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 37: Figure 21: Push Chassis Into Rack

    6) Tighten chassis with rack by thumb screw on chassis ear during normal operating, and the shipping screw is tightened during rack shipment only. Figure 21: Push Chassis into Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 38: Figure 22: Front Bezel Screw

    Figure 22: Front Bezel Screw Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 39: Rail Kit Removal

    1) Loosen shipping screw to pull out chassis. 2) Pull the disconnect tab forward to remove chassis. Figure 23: Pull Chassis from Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 40: Drive

    Figure 25: Drive Assembly Flow Chart ● Pull out Chassis from Rack ● Push Chassis into Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 41: Figure 26: Service Label

    When the equipment is putted on the plane, install hard drive inorder on drive slot, but all empty slot must be filled with HDD carrier. Figure 26: Service Label Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 42: Pull Out Chassis From Rack

    These methods must be followed or failure could occur to the isolator if not properly installed. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 43: Figure 28: Drive Carrier Kit For 3.5" Drive

    Screw torque: 6 +/- 0.5 kgf.cm(5 lbf.inch) Step 1: Put hard disk into carrier. Step 2: Fixed hard disk by screws. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 44: Figure 29: 3.5" Drive Assembly Sequence

    Figure 29: 3.5" Drive Assembly Sequence Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 45: Figure 30: Drive Carrier Kit For 2.5" Drive

    Screw torque: 4.5 +/- 0.5kgf.cm(4 lbf.inch) Step 1: Place hard disk into carrier by locating four holes. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 46: Figure 31: 2.5" Drive Assembly Sequence

    Step 2: Fixed hard disk by screws. Figure 31: 2.5" Drive Assembly Sequence Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 47: Figure 32: Or Other Top Cover

    Install Drives into chassis Step 1: Open the chassis top cover. Figure 32: Or other top cover Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 48: Figure 33: Locker

    Aligning the HDD and HDD slot then push HDD down until the latch top toe touches the partition. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 49 Rotate the handle down to lock the HDD into the chassis. The bottom toe will engage on the first step. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 50: Figure 34: Assemble Hdd Into Chassis

    The second stage will engage to fully close. Figure 34: Assemble HDD into Chassis Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 51: Figure 35: Installing And Remove Drive Carriers Into Chassis

    Step 2: The handle will open automatically. Pull the drive out of the chassis. Figure 35: Installing and remove Drive Carriers into Chassis Step 3: Close the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 52: Push Chassis Into Rack

    Figure 36: Close Chassis Push Chassis into Rack Figure 37: Push Chassis into Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 53: Hardware Overview

    Three LEDs are for canister power, locate and fault identification. Two LEDs are for each Mini-SAS HD port active status identification. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 54: Mini-Sas Hd Port

    3.5mm Audio Jack connector. Following is a list of commands for ESM console (only for reference purpose): Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 55 Show/Set status of various LED indicators Display/Program various VPD spin Drive spin up control PHY enable/disable/reset flash Toggle the boot selection Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 56: Esm Canister

    Press the latch and rotate the ESM Canister handle with a stop angle and push it into the chassis. Then rotate the ESM Canister handle to close. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 57: Figure 39: Esm Canister Installation

    Press the latch and rotate the ESM Canister handle then pull the canister out of the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 58: Psu- Power Supply Unit

    Refer to the picture below for the PSU front view. There is one indicator LED located on the front faceplate. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 59: Ac Power Cord

    Rasilient for other options if want to use other types of power cord. NOTE: The PSU AC input range: 180 to 264V rms. Figure 42: AC Power Cord Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 60: Psu

    Rotate the PSU handle with a suitable angle and push the PSU into the chassis. Then rotate the PSU handle to close. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 61: Figure 44: Psu Installation

    Rotate the handle and then pull the PSU out of the chassis. Figure 45: PSU Removal Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 62: Fan Modules

    Figure 47: Fan Module Assembly Top View ● Fan Fault LED (Amber) On –FAN fault Off – Normal Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 63: Fan Modules

    Pull the latch and the handle will open automatically then pull out fan module from the system. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 64: Figure 49: Fan Module Removal

    Figure 49: Fan Module Removal Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 65: Dc To Dc

    NOTE: Users should not disassemble the fan module without Rasilient engineer authority. DC to DC Figure 50: DC-DC Module View Figure 51: DC-DC Front View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 66: Figure 52: Assemble Dc-Dc Into Chassis

    Assemble into chassis Figure 52: Assemble DC-DC into Chassis Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 67: Drive Carrier

    The drive carrier side view refers to below. It is designed to support both 2.5 inch and 3.5 inch drive. Figure 54: Drive Carrier Side View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 68: Drive Led

    On – Drive fault 2nd priority Blink @ 1Hz – Reb 3rd priority uild Off – Normal operation Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 69: Cabling And Power

    1) Connect the system’s power cable(s) to the rear side of system. 2) Connect power cord to the power source. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 70: Securing The Power Cable(S)

    Securing the power cable(s) After connecting the power cable(s), as shown in the illustration, attach to the cable strap. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 71: Figure 58:Bottom Layer Cma

    Figure 57: Securing Power Cables Open Status of Routing the cables. Figure 58:Bottom Layer CMA Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 72: Figure 59: Top Layer Cma

    Figure 59: Top Layer CMA Figure 60: Open Status of Routing the cables Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 73: Connect The Enclosure

    PS7012 or PS5012 Raid Application Controllers. Push the cable into the connector until it clicks into place. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 74: Figure 62: Connecting Sas Cables

    For more information about LED indicators, see the 4.Hardware Element Overview; for more information about cabling your enclosure, see the Port configuration. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 75: Port Configuration

    Configuration Port Configuration PS390e can be used in a dual-controller configuration (for SAS drives). It only supports single controller configuration for SATA drives. Single port configuration Single Port configuration the enclosures are daisy-chained with one of the ESMs connected to a single port on the controller card.

  • Page 76: Figure 64: Redundant Configuration

    Figure 64: Redundant Configuration Figure 65: PS7012 to PS390e SAS connections ─── END OF DOCUMENT ─── Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
