PS392e
SAS Expansion Enclosure
Hardware Installation Manual
1st Edition
February 2017

Advertisement

Table of Contents
loading

Related Manuals for Rasilient PS392e

Summary of Contents for Rasilient PS392e

  • Page 1 PS392e SAS Expansion Enclosure Hardware Installation Manual 1st Edition February 2017...
  • Page 2 All rights, including copyright, in the content of this manual are owned or controlled by RASILIENT and protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of RASILIENT Systems, Inc.

  • Page 3: Table Of Contents

    Fan Modules 60 2.4.4 Control Panel 2.4.5 Drive Carrier 64 2.4.6 SEM Card Support Matrix........................73 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 4 Supported physical disk drives ..................73 Supported system connections ..................73 3.4.1 Single port configuration 3.4.2 Redundant configuration Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 5 About This Manual Conventions Safety Symbols Safety Precautions Regulatory and Integration Information Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 6: Conventions

    WARNING: Indicates a potential for property damage, personal injury, or death. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 7: Safety Precautions

    Before picking it up again, touch the antistatic bag and the metal frame of the system unit at the same time. Rack Warnings If you plan to rack mount the PS392e, please follow the rack manufacturer’s safety instructions. ...
  • Page 8 Pay particular attention to the plug, electrical outlet, and the point where the cords exit from the product. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 9: Regulatory And Integration Information

    FCC 47 CFR Part 15 Class A VCCI VCCI V-32014.4 Class A ICES ICES-003, Issue-004 Class A Approvals Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 10 NOTICE: Any modifications made to this device that are not approved by Rasilient may void the authority granted to the user by the FCC to operate this equipment.
  • Page 11 この装置は、情報処理装置等電波障害自主規制協議会(VCCI)の基準に基づくクラス A 情報技術装 置です。 この装置を家庭環境で使用すると電波妨害を引き起こすことがあります。この場合には使用者が 適切な対策を講ずるよう要求されることがあります。 中国环保使用期限标志 此产品环保使用期限是 年，在此期限内可安全放心使用，到期后必须进入回收环节。 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 12 Chapter 1 Introduction Audience Assumptions About This Guide Packing Checklist Specifications System Overview Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 13: Introduction

    PS392e SAS expansion enclosure hardware. This guide also includes information on its use and maintenance. Once the PS392e hardware is ready, you will need to refer to the PS5012 documentation (included with that system) to provision the storage and set up host access.

  • Page 14: Specifications

    950m altitude. 1.5 System Overview The PS392e product is a high availability, 5U high density enterprise-class JBOD storage enclosure for up to 92 Drives, which supports 3.5 inch 12Gbps SAS3.0 disk drives that fits within a 1000mm rack including space for cable management.
  • Page 15  Fan module Four (4) Hot-pluggable Fan Modules in chassis Each fan module contains two 92mm fans (dual-rotor) Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 16: Product Appearance

    Figure 1-1 below, is a trimetric view of the chassis. Figure 1-1 PS392e Chassis Trimetric View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 17 Figure 1-3 below, is a rear view of the chassis, showing Fan Modules and ESM canisters. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 18 Figure 1-3 PS392e System Rear View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 19 Enclosure Fault LED (Amber) Off – Normal Table 1-1 Indicator information on the front of PS392e Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 20 Figure 1-5 Indicator on the top of PS392e without top cover Indicator information Description Fan 1~ Fan 4: Fan indicators. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 21 Drive Row 1~ Drive Row 14: Row number of Drive. Lock (on top cover): Toggle left, lock the cover. Unlock (on top cover): Toggle right, unlock the cover. Table 1-2 Indicator information on the top of PS392e without top cover Figure 1-6 Indicator on the rear of PS392e Indicator Description ESM Canister 1: Canister indicator 1.
  • Page 22 Drive 77 Drive 63 Drive 51 Drive 39 Drive 27 Drive 13 Figure 1-7: PS392e Drive Numbering Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 23: Product Exploded View

    1.7 Product Exploded View Figure 1-8 Trimetric View of PS392e Exploded Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 24 Chapter 2 Hardware Installation Safety Instructions Equipment Installation Cabling / Electricity Hardware Element Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 25: Hardware Installation

    Do not use household extension cords with your product. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 26: Electro-Static Discharge (Esd) Caution And Warnings

    CAUTION: Keep fingers and other body parts away from the moving blade,Failure to take this precaution may result in personal injury. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 27: Rack System Instructions

    A third person may be required to help align the storage if the server is installed higher than chest level. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 28: System Warnings

    We recommend the users to prepare and use the following tools for equipment installation: ESD Protection: the users can wrap them around the wrist. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 29 Figure 2-2: ESD Protection Protective gloves: Figure 2-3: Protective gloves Screw driver: Figure 2-4: Screw drive Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 30: Equipment Installation

    Take all items out of the package and check whether any item is in poor condition. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 31: Rail Kit Installation

    The rail kit sample from the package is as below. The middle rail and external rail are shipped as a combination part. Figure 2-7: Slide Rail Sample Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 32 Remove the inner member. Push (a) and slide middle member back. Figure 2-8: Remove the inner Rail Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 33 The inner rail fixed on chassis by 8 pcs screw, on each side 4 pcs screw (M4xL6). Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 34 Step 3: Install the outer member/bracket assembly to the Rack. Figure 2-11 Rail Assembly on Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 35 Figure 2-12: Fixing rail on Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 36 Pull/push release tab to unlock and retract chassis into rack. Tighten chassis with shipping screws before rack ship. Figure 2-13 Push Chassis into Rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 37: Rail Kit Removal

    Pull the disconnect tab forward to remove chassis. Figure 2-15 Pull Chassis from Rack Step 2: Remove the bracket. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 38: Cable Management Assembly (Cma)

    Figure 2-17: CMA Sample Pictures below demonstrate the steps to install CMA with slide rail rear ending. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 39 Figure 2-18: CMA Step 1: Install the inner member. Install (A) onto (B). Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 40 Figure 2-20: Step 2 Step3: Install the outer member. Install (E) onto (F). Figure 2-21: Step 3 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 41: Drive

    When the equipment is put on the plane, install hard drive randomly on drive slot, but all empty slot must be filled with dummy carrier. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 42: Drive Installation

    These methods must be followed or failure could occur to the isolator if not properly installed. Figure 2-25: Drive Carrier Kit for 3.5 inch Drive Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 43 Figure 2-26: Install grommets Figure 2-26: Install grommets Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 44 NOTE: Please make sure the drives have been installed correctly and tightly, otherwise will affect the use. 2.2.7.2 Install Drives into chassis Step 1: Open the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 45 Figure 2-28: Release Button (lock) Figure 2-29: Open Cover Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 46 Step 2: Pull out / install the Drive carrier. Pictures below will show the details for proper drive installation and removal process. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 47 Figure 2-30: Installing and Removing Drive Carriers into the Chassis Step 3: Close the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 48: Push Chassis Into Rack

    Figure 2-31: Close Chassis 2.2.8 Push Chassis into Rack Figure 2-32 Push chassis into rack Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 49: Bezel

    NOTE: Top bezel is assembled with top cover as one assembly. User need to install the front bezel and the PSU bezel. Secure the bezel with screws provided. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 50: Cabling And Access To Electricity

    NOTE: Turn on your enclosure, check all the LEDs are lighting normally and there are no fault conditions. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 51: Securing The Power Cords

    To remove the SAS cable, pull the pull-tab to release the cable from the connector on the ESM and the PS5012HD system. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 52 For more information about LED indicators, see 2.4. Hardware Element Overview; for more information about cabling your enclosure, see 3.4 Supported system connections Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 53: Hardware Element Overview

    Two LEDs are for each Mini-SAS HD port active status identification. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 54 Green Off – Loss of link on all of the SAS ports within the connector 2.4.1.3 Mini-SAS HD port There are six Mini-SAS HD ports on PS392e system, each canister has three ports. Three Mini-SAS HD port for JBOD upstream/downstream connection. Only one is used for connection to PS5012HD chassis.
  • Page 55 Click the handle lock and rotate the handle then pull the canister out of the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 56: Psu-Power Supply Unit

    Figure 2-41: ESM Canister Removal 2.4.2 PSU-Power Supply Unit The PS392e storage enclosure is powered by two 2400 watt redundant Power Supply Units with following features:  2400w N+1 Redundant (80Plus Gold Level)  Input:180-264VAC via IEC C-20 inlet on the system rear 2.4.2.1 PSU LED...
  • Page 57 Rotate the PSU handle with a stop angle and push the PSU into the chassis. Then rotate the PSU handle to close. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 58 Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 59 Click the handle lock and rotate the handle then pull the PSU out of the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 60: Fan Modules

    Figure 2-46: PSU Removal 2.4.3 Fan Modules The PS392e enclosure houses four fan modules in the rear of the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 61 Align the fan module with the fan slot, then insert fan module in the system. Listen for “Click. The installation is finished. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 62: Control Panel

    Control Panel front view refers to the picture below. It is located on the front side of the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 63 Align the control panel module and control panel slot, then insert control panel module in the system. Listen for “Click” the installation is finished. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 64: Drive Carrier

    For Detail drive assembly refers to section 2.2.7 of this user guide. Figure 2-54: Drive Carrier Side View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 65: Sem Card

    The SEM provides SAS connectivity between the drives and ESM and enclosure management within the PS392e system. The SEM has a custom form factor located in the drive bay area. One or both SEM cards must be installed in PS392e chassis depending upon single or redundant configuration.
  • Page 66 SEM card front view refers to the picture below. There are two LEDs on the SEM card face. One is power LED, the other is Fault LED. Figure 2-57: SEM card Front View Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 67 NOTE:2 SEM cards have been installed when users unpack. Step 1: Pull out Chassis from Rack. See 2.2.6.1. Step 2: Open the chassis cover. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 68 Figure 2-60: Open Chassis Cover Step 3: Install/ pull out the SEM card from / into the chassis. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 69 Figure 2-61 Install the SEM card Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 70 Figure 2-62: Pull out SEM Card from Chassis Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 71 Step 4: Close the chassis cover. Figure 2-63: Close Chassis Cover Step 6: Push Chassis into Rack. See 2.2.8. Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 72 Chapter 3 Support Matrix Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.

  • Page 73: Support Matrix

    3 Support Matrix This document provides information about supported software, firmware and hardware for PS392e. 3.1 PS392e Storage enclosure rules This section contains consideration rules for the PS392e Storage Enclosures. Components PS392e Maximum Supported SAS cable length (Mini-SAS-HDD) Maximum number of Supported Drives Maximum HDD Power Consumption 13.5w...
  • Page 74 In Redundant configuration, ESM 2 is connected to PS5012HD's Controller 0 (bottom) and ESM 1 is connected to Controller 1 (top) controller. Figure 3-2 Redundant configuration Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
  • Page 75 ─── END OF DOCUMENT ─── Rasilient Confidential - Use or disclosure of data contained on this page is subject to the restriction on the title page of this document.
