  • Page 1 User Manual Ver1.0 eBOX-3000-ETC Fanless Industrial Computer...
  • Page 2 Copyright Copyright notice The information in this document is subject to change without prior notice in order to improve reliability, design and function and doesn’t represent a commitment on the part of manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damage arising out of the use or inability to use the product or documentation, even if advised of possibility of such damages.
  • Page 3 Manual conventions WARNING: Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION: Cautionary messages should be heeled to help reduce the chance of losing data or damaging the product. NOTE: These messages inform the reader of essential but non-critical information.
  • Page 4 Declaration of Conformity This restriction is subject to provide protection for system operation in business environment, which will produce, use and transmit radio frequency energy. Without notice of the instructions of the correct installation and use, it may cause harmful interference to radio communication.
  • Page 5 Technical Support and Service Please visit the Nodka website http://en.nodka.com to get more details. If you need additional assistance, please contact your system reseller or vendor. Please have the following information ready before you call: 1. Product name and serial number 2.
  • Page 6 Ordering Information Product code Description EBOX-3000-ETC No CPU/No memory/No hard disk/4*RS232/ 2* LAN/8*USB2.0（4 of them support USB3.0）/DVI/VGA//HDMI/PS2/Audio card/AC96~264Vinput /Two-year warranty Optional equipment: Name Description Power cable L= 1.8M+ external PSU Power cable Hard disk Support 2.5", MSATA Memory Support DDR4 2400, 2 x 260-pin, SO-DIMM Slot, Up to 32 GB Memory Size Optional Intel®...

  • Page 7: Table Of Contents

    Content Chapter 1 Overview ......................1 1.1 Introductions ........................ 2 1.2 Key Features ....................... 2 1.3 External Overview ....................... 3 1.4 Specifications ......................3 1.5 Dimensions........................4 1.6 Assembly and disassembly ..................5 Chapter 2 System installation ..................... 6 2.1 Connectors Definition ....................7 2.2 BIOS Setup .......................

  • Page 8: Chapter 1 Overview

    Chapter 1 Overview...

  • Page 9: Introductions

    1.1 Introductions eBOX-3000-ETC is a fanless mini PC based on Intel® Core™ i3/i5/i7/Celeron high performance processor, impact and with large aluminum fin radiator, with no cable inside. The performance has increased 30% than the 6th/7th generation Intel® Core™ processor. It uses dual channel DDR4 SODIMM, up to 32GB. There are 2 Intel210AT Ethernet slots, and can be extended to 6 groups.

  • Page 10: External Overview

    1.3 External Overview Figure 1-1 Front and rear overview of eBOX-3000-ETC 1.4 Specifications SYSTEM eBOX-3000-ETC Intel® Core™ 6th / 7th generation i7 / i5 / i3 / Pentium / Celeron Processor Chipset Intel H110 Express Chipset BIOS AMI EFI 64Mbit...

  • Page 11: Dimensions

    5~95% (Non condensation) Shake SSD applied: 1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis Shock SSD applied: 10 G, IEC 60068-2-64, Half-sine wave, 11ms duration CE/FCC Class A Safety Certification 1.5 Dimensions Unit: mm Figure 1-2 Dimensions of eBOX-3000-ETC...

  • Page 12: Assembly And Disassembly

    1.6 Assembly and disassembly eBOX-3000- ETC has a unique structure design which makes COM port settings easily and quickly as well as the replacement of the hard disk. 1.6.1 Hard disk replacement Step1. Find the orange HDD cover. Step 2. Pull out the blue sign. Step 3.

  • Page 13: Chapter 2 System Installation

    Chapter 2 System installation...

  • Page 14: Connectors Definition

    2.1 Connectors Definition Figure 2-1 Definition of connectors 2.1.1 COM Ports eBOX-3000-ETC has 4 COMs, which can be extended to 8 COMs. COM 1~4 are R232 type DB9 connector. PIN9 on DB9 defaults RI. The definitions are as follows: SIGNAL...
  • Page 15 2.1.2 USB We provide 2 X 2 standard double-deck USB port in front panel and 2 x 2 standard double-deck USB interface on I/O interfaces; you can use the 8 USB interfaces at the same time. SIGNAL Date- Date+ 2.1.3 Audio interface (LINE_OUT) We provide a standard Ø3.
  • Page 16 Indicators of LAN connector. Network Left (LILED) double colors Right (ACTLED) single color status (Orange / Green) (Yellow) 1000M Constant ON FLASH 100M Constant ON FLASH FLASH Data No Data Active GREEN ORANGE Transferring Transferring description Linking indicator Active status indicator 2.1.5 PS2 Keyboard/Mouse Connector Definition Slot...
  • Page 17 2.1.7 DVI interface We provide a DVI-D interface in the rear panel which makes double display with VGA possible. The definition is as below. 2.1.8 Switch button (PWR) On rear panel, we provide an ATX power touch switch button (PWR) to power up. 2.1.9 Power connector PRODUCT offers a 2-pins power input.
  • Page 18 2.1.11DIO interface SIGNAL SIGNAL SIGNAL R0_NO R4_NO R6_NO R4_COM R0_COM R1_NO DI.COM or DI.GND R7_NO R2_NO R1_COM R6_COM R5_NO R2_COM R7_COM R5_COM R3_NO R3_COM...

  • Page 19: Bios Setup

    2.2 BIOS Setup The BIOS is programmed onto the BIOS chip, the BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may very throughout the life cycle of the product and are subject to change without prior notice.
  • Page 20 General help, only for the status page setup menu and option page setup menu Previous value Optimized defaults Save all the CMOS changes and reset The menu bar which is anchored to the top of the BIOS screen has the following main items: ...
  • Page 21 The Main menu has two user configurable fields. System Time: Set the system time, the time format is HH: MM: SS System Date: Set the system date, the date format is MM/DD/YY Day: Note that the ‘Day’ automatically changes when you set the date. 2.2.4 Advanced setting The Advanced BIOS Setup screen is shown as below.
  • Page 22 a. Advance - CPU Configuration Choose CPU configuration menu in Advanced menu to view detailed CPU specifications or enable the Intel Virtualization Technology. b. Advance - ACPI Configuration...
  • Page 23 c. SATA Configuration d. Display Configuration...
  • Page 24 e. AC Power Loss f. Wake up Settings...
  • Page 25 g. Super IO Configuration h. USB Configuration...
  • Page 26 2.2.5 Chipset configuration...
  • Page 27 2.2.6 BOOT Configuration 2.2.7 Security settings...
  • Page 28 2.2.8 Save & Exit Option a. Save Changes and Exit When you have completed system configuration, select this option to save your changes, exit BIOS setup and reboot the computer. So the new system configuration parameters can take effect. 1. Select Exit Saving Changes from the Exit menu and press Enter. The following message appears: Save Configuration Changes and Exit Now? [Ok] [Cancel] 2.

  • Page 29: Driver Installation

    2.3 Driver installation NOTE: Please Install Operating system first. All drivers of eBOX-3000-ETC are under the Windows XP. When first using the system, users need to set up corresponding drivers to make sure all functions are normal. To install the drivers, please follow the steps below: Step 1.
  • Page 30 2.3.1 Chipset driver To install the chipset diver, please follow the steps below. Step 1. Right select management into the computer management window. Then right click to update SM bus controller as shown in the figure below. Step 2. Double-click Chipset. Step 3.
  • Page 31 Step 4. Click Next. Step 5. Read the license agreement. Click Accept.
  • Page 32 Step 6. Click Restart Now. 2.3.2 Graphics driver To install graphics diver, please follow the steps below. Steps 1. Select the application of graphics driver.
  • Page 33 Step 2. Click Automatically run WinSAT and enable the Windows Aero desktop theme (if supported). Click Next. Step 3. Read license agreement. Click Yes.
  • Page 34 Step 4. Click NEXT to continue. Step 5. Click Next.
  • Page 35 Step 6. Select Yes, I want to restart this computer now.. Click Finish to complete the installation. 2.3.3 Audio driver To install audio diver, please follow the steps below. Step1. Double click the folder of audio driver.
  • Page 36 Step 2. Click Setup Step 3. Click Next to continue...
  • Page 37 Step 4. Click Finish 2.3.4 LAN driver To install LAN driver, please follow the steps below. Step 1. Right select management into the computer management window. Then right click to update Intel(R) I210 Gigabit Network Connection#2 as shown in the figure below.
  • Page 38 Step 2. Choose Browse my computer for diver software. Step 3. Wait for the installation process to complete. 2.3.5 Me diver To install ME driver, please follow the steps below. Step 1. Click SetupME...
  • Page 39 Step 2. Click Next Step 3. Click Next.
  • Page 40 Step 4. Read license agreement. Choose I accept the terms in the License Agreement., Click Next. Step 5. Click Finish.

  • Page 41: Appendix A Safety Precautions

    Appendix A Safety Precautions CAURION: The precautions outlined in this chapter should be strictly followed. Failure to do so may cause permanent damage to the product. A.1 General Safety Precautions Please read the following safety precautions carefully. Make sure you always follow the precautions.

  • Page 42: Anti-Static Precautions

    A.2 Anti-static Precautions WARNING: During the installation of the product, failure to take ESD precautions may result in permanent damage to the device and cause severe injury to the user. Electrostatic discharge (ESD) may cause severe damage to electronic components of product, especially during dry weather.

  • Page 43: Disposing Of The Equipment

    A.3 Disposing of the Equipment CAURION: If the battery is replaced with the wrong type, there might be a risk of a battery explosion. Only certified engineers can replace the on-board battery. NOTE: Disposal of used batteries must be in accordance with local environmental regulations.

  • Page 44: Maintenance And Cleaning Precautions

    A.4 Maintenance and Cleaning Precautions When maintaining or cleaning the product, please follow the guidelines below. A.4.1. Maintenance and Cleaning Prior to cleaning any part or component of the product, please read the details below. 1. Except for the LCD panel, never spray or squirt liquids directly onto any other components.
  • Page 45 5. Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas. 6. Foam swabs - Whenever possible, it is best to use lint free swabs such as foam swabs for cleaning.

  • Page 46: Compliant Under 2002/95/Ec Without Mercury

    Appendix B B.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC without Mercury The details provided in Appendix B are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 47 B-1 Poisonous or hazardous substances or element in products Toxic or Hazardous Substances and Elements Component Hexavalent Chromium Polybrominated Biphenyls Polybrominated Diphenyl Ethers Lead (Pb) Mercury (Hg) Cadmium(Cd) (Cr(VI)) (PBB) (PBDE) Housing Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Battery O: The quantity of poisonous or hazardous substances or elements found in each of the component's parts is below the SJ/T 11363-2006-stipulated requirement.
