HearthSong Air Rider Assembly And Installation Instructions

Air Rider Swing
Safety Assembly and Installation Instructions
Includes:
1 Fully assembled swing
Safety Checklist: Read the Instructions Before Use
1. Choose an outdoor site free of sharp objects: select a flat surface free of depressions, holes, or raised spots, and away from,
walls, garden equipment, pools, or other objects for at least 6 feet in every direction.
2. Ideally, the swing should be hung over grass, sand, wood chips, or other soft surfaces. Under no circumstances should it be hung
over concrete, asphalt, or other hard surfaces.
3. Inspect all components for wear. Do not use if damaged.
Installation:
1. Can be hung on an A-frame or swing set or on a tree limb of at
least 10"-12" diameter.
2. Swing should be hung equal distances from the ground to the
branch and from deck of the swing to the trunk of the tree. For
example, if the supporting branch is 10' from the ground, the
swing needs to be 10' from the trunk of the tree. (See diagram)
3. Connect the swing to a tree branch using two Mega Multi-
Use Hanging Straps (731926)*. Place the hangers on the
tree branch 33½" apart (the length of the seat). Connect each
hanger and carabiner attached to the top of each rope.
4. Swing deck should be at least 15" from the ground, and no
more than 18" from the ground.
5. Ropes should be adjusted to a minimum of 9' and a maximum
of 14'.
*Hanging hardware not included and available at HearthSong.com.
USE:
• DO NOT ALLOW ANYONE UNDER THE AGE OF 5 TO USE THIS TOY.
• The swing is intended solely for family and domestic use, not for a commercial playground or daycare.
• Children must not use the swing until it has been properly installed.
CARE:
• Please be sure to regularly examine all components for wear.
• If damage is found, discontinue use and replace the spinning ring.
#732431 Conforms to ASTM F1148 Made in China. ©HearthSong 2020. Madison, VA 22727. 1-800-533-4397 HearthSong.com
®
Adult installation and supervision required.
Seat: 33½"L x 12"W; Ropes: 9'-14'L; Handles: 16"L
Equal distance
15"-18"
to height
#732431 | Ages 5+
Takes 1 adult to install.
Weight Limit: 200 lbs.
