MRD-60 Marine AM / FM / CD / MP3 Receiver
Installation and Operation Manual
Poly Planar Group LLC 520 McCormick Dr. Glen Burnie MD 21061 PH: 410-761-4000
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRD-60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for poly-planar MRD-60

Summary of Contents for poly-planar MRD-60

  • Page 1 MRD-60 Marine AM / FM / CD / MP3 Receiver Installation and Operation Manual Poly Planar Group LLC 520 McCormick Dr. Glen Burnie MD 21061 PH: 410-761-4000...

  • Page 2: Table Of Contents

    MRD-60 Audio System Features: Plays CD, CDR,CDR-W, MP3, WMA discs Waterproof Front Panel Stainless Steel Chassis Conformal coated circuitry Audio Expansion Port™ for easy system expansion Stereo Auxiliary inputs (for TV , MP3 etc.) Highly visible back lighted display Ergonomic controls...

  • Page 3: Front Panel Functions

    Front Panel Functions 1. Power ON/OFF 2. Mute 3. Source 4. Volume 5. IR port 6. Intro /Station Presets (6-11) 7. Random play Display 8. Repeat 9. Pause / Play (Preset # 4) Disc- (Changer, Prev. Disc) 11.Disc+ ( Changer, Next Disc) 12.

  • Page 4: Connections

    MRD-60, Rear Chassis Connections Aux In 1 Aux In 2 Auxiliary Input connections (2) for MP3 Players , TV audio, Sat- ellite radio or other Audio device with Audio output See page 10 for connection details DIN Port for CD Changer or IP100 MP3 dock Main Connector for Radio.

  • Page 5: Schematic

    Power & Speaker Harness Connections Important! Disconnect power before installation. If you are not familiar with this type of installation seek professional assistance To Radio Use the wired plug end (Pig tail) provided to make power and speaker connections according to the diagram on the right.

  • Page 6: Mounting Instructions

    Mounting Instructions: Optional Mounting IMPORTANT! Before mounting be sure there is sufficient room to accommodate the unit and that Techniques there is sufficient ventilation. Disconnect power before installation. Receiver should be mounted within 30º (+ or— 15º)from Horizontal Use the template provided to make the cutout. For blind installations (no rear access) the center screw will hold the mounting blocks/brackets in place while the radio is mounted.

  • Page 7: Getting Started

    Getting Started…. Power On / Off Push (1)to power on unit , Push again to turn unit off. Adjusting the Volume Rotate Volume knob (4) to increase or decrease volume level. Current setting is displayed for a few seconds. Mute Push (2) to mute sound, push again to resume Program Selection Press the Source button (3) to cycle through the available program...

  • Page 8: Cd / Mp3 Player

    To program a preset, tune in the desired station. Push and hold the desired button for at least 2 seconds. PRESET Seek & Manual Tune: Press the button (15) once to auto-matically tune to the TUNE/SEEK-UP next higher station. Press the button (14) once to automatically tune to TUNE/SEEK-DOWN the next lower station...

  • Page 9: Troubleshooting

    INTRO, SCAN CD: Press the INTRO button (6) to enter into Scan Mode, SCN will appear in the left side of the display. In this mode the first 10 seconds of each track will play. MP3 Disc: If the disc is an MP3 the first 10 seconds of each track will play and then advance to the next directory.

  • Page 10: Auxiliary Inputs

    The Variable level outputs (Front & Rear , Right &Left) mimic the output of the tuner. These outputs are generally used to feed a 2 or 4 channel Amplifier where the volume is controlled by the MRD-60 Receiver. For more information see the instructional material included with the IMR Control Modules for Spa Applications: The MRD60 expansion port can support control modules for full spa control applications.

  • Page 11: Specifications

    90dB 30dB 30uV 44.1kHz Poly-Planar products are warranted to be free of defects in materials and work- 80dB manship for a period of two years. No finished goods or parts may be returned 90dBA for repair or replacement without a Poly-Planar RMA (Return Merchandise 20-20kHz Authorization) number.
