poly-planar MA-9020 Specifications

Gunwale-Mount Speakers
Mount these full-sized speakers out of the way under the gunwale, where they're
protected from the elements, yet close enough to deliver rich, full sound. The
molded, one-piece plastic grill protects the speaker components from splash and
spray. The two-way vented port design offers full range response. Peak power 200
watts/pair.
Specifications:
• Impedence _____________________________________________ 4 ohms
• Configuration ____________________________________________2 way
• Max RMS Power per Speaker _________________________60 watts
• Max Peak Power per Speaker ______________________ 100 watts
• Main Cone Size _____________________________ 5-1/4" (133.4mm)
• Dimensions ________________________ Length - 6-1/8" (155.5mm)
POLY-PLANAR • PO Box 409 • Hanover, MD 21076 • (410)761-4000
MA-9020
www.polyplanar.com
Width - 10-1/2" (266.7mm)
Depth - 5-1/4" (133.4mm)
