SB100 Waterproof Speaker Assembly with
Infrared Communication Port
1352 Charwood Road • Suite D • Hanover, MD 21076 • Tel (410) 761-4000 • Fax (410) 761-6274 www.polyplanar.com
4 Screw Holes .125" (3.2mm)
6" (152mm) Leads
Snap fit Cover(s)
4.800" (122mm)
Audio Connector: AMP MATE-N-LOK (or equivalent)
MFG# 1-480699-0 , 2 Pin (Gold Finish)
Infrared Connector: 3.5mm Plug
3 contacts (Gold Plated)
PVC molded w/ strain relief
3.390"
83mm
Advertisement
Table of Contents
Related Manuals for poly-planar SB100
Summary of Contents for poly-planar SB100
- Page 1 SB100 Waterproof Speaker Assembly with Infrared Communication Port Snap fit Cover(s) 3.390” 83mm 4 Screw Holes .125” (3.2mm) 4.800” (122mm) 6” (152mm) Leads Audio Connector: AMP MATE-N-LOK (or equivalent) MFG# 1-480699-0 , 2 Pin (Gold Finish) Infrared Connector: 3.5mm Plug...
- Page 2 2 ½” (63mm) and a 1 ¼” hole on 1 ½” centers. Cut away the corners of the intersecting holes as The SB100 is designed to be used in conjunction with the shown. Test fit the Speaker.
