American Gas Lamp Works CRAFTSMAN 1100 Quick Start Manual

FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, immediately
call gas supplier.
THE LAMP HEAD MUST BE INSTALLED TO CONFORM WITH LOCAL CODES OR IN ABSENCE OF LOCAL CODES
WITH THE NATIONAL FUEL GAS CODE ANSI Z21.42-2013 – LATEST EDITION
THE MINIMUM CLEARANCE FROM COMBUSTIBLE CONSTRUCTION IS 12" TOP BY 6" SIDE
POST INSTALLATION (for standard burial steel or aluminum post)
1. Obtain from your dealer 3" OD post with notches for valve access at top.
2. Install inside post (1/4" OD) gas feed line tubing with ¼" flare nuts at each end. Tubing should be coiled 2 ½ times at top.
3. Tubing should protrude about 5" through the access hole at the bottom of post.
4. If supplied, insert ladder rest through hole and attach ornamental ball to each end.
5. Dig a hole 21" deep X 12" wide.
6. If a pedestal base is being used proceed to step 7, if no base is being used attach the ¼" flare nut from the gas feed line at the
bottom of the post to the main gas supply and secure post in plumb position, pour concrete around the post to just below the level
of the line access hole. Back fill the hole.
7. If using a pedestal base, pour the concrete in the hole, place the pedestal base over the hole and slide the post down through the
center of the base into the concrete leaving the access hole just above the concrete line. Attach the ¼" flare nut from the gas feed
line at the bottom of the post to the main gas supply and secure the post in plumb position. Back fill the hole and push the base
about 1"-2" down in the ground and secure in place using the back fill. If the base is not secured in the ground, the freeze and
thaw of the ground can cause the base to rise and fall causing the finish of the post to scratch.

LAMP INSTALLATION

1. Attach the flare nut from the ¼"OD gas feed line tubing to the gas valve on the lamp. Tighten Well.
2. Lower lamp onto post or stud, aligning valve with the slot in the post or stud. Check! Make sure you have access to your valve.
3. Tighten set screw(s) in collar of lamp so lamp is well secured to post.
4. Install glass by following the attached glass installation instructions. (Install all but one piece)
5. Leaving lamp valve in OFF position, turn on main gas supply and check all connections for leaks using a soapy solution.
NEVER USE AN OPEN FLAME TO CHECK FOR GAS LEAKS! Tighten any leaky connections and recheck for leaks.
6. Follow Lighting Instructions on back.
7. Install last panel of glass.

MAINTENANCE INSTRUCTIONS:

No combustible material, gasoline or other flammable vapors or liquids should be stored near lamp. Nothing should obstruct the flow of
combustion and ventilation air. Occasionally the glass will need to be cleaned with household glass cleaner and the tip of the brass stem on
the burner will need to be cleaned using steel wool and some dental floss to clean the top opening
INSTALLER: Please leave instructions with the appliance for the consumer to retain for future reference.
MODEL 1100
(CRAFTSMAN)
POST MOUNT
FOR OUTDOOR USE ONLY
7" WATER COLUMN FOR NAT GAS
11" WATER COLUMN FOR LP
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other gas appliance.
