Summary of Contents for Fulgor Milano F4GK24 1 Series
- Page 1 Use & Care Manual Manuel d’utilisation et d’entretien Manual de uso & Mantenimiento F4GK24*1 F4GK30*1 F4GK36*1 F4GK42*1...
-
Page 3: Table Of Contents
Use & Care Manual ENGLISH Table of Contents Pay attention to these symbols present in this manual: Page Safety Instructions..........4 WARNING Cooktop Safety ............4 This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or Personal Safety ............ -
Page 4: Safety Instructions
Use & Care Manual ENGLISH IMPORTANT Safety Instructions Please read all instructions before using this appliance. Cooktop Safety To reduce the risk of burn injuries during cooktop use, observe the following: NEVER use this appliance as a space heater to WARNING heat or warm the room. -
Page 5: Warnings For Gas And Electric Installation
Use & Care Manual ENGLISH Do not clean the cooktop while it is still hot. Some cleaners produce noxious fumes when WARNING applied to a hot surface. Installation and service must be performed by a CAUTION qualified installer, service agency or the gas DO not allow aluminium foil, plastic, paper or cloth to supplier. -
Page 6: Models And Part Identification
Use & Care Manual ENGLISH Models and Part Identification 24” 30” 1. DOUBLE CROWNS (700 to 18000 Btu/h burner & control 1. DOUBLE CROWNS (700 to 18000 Btu/h burner & control knob) knob) 2. SR (1,300 to 6,300 Btu/h burner & control knob) 2. AUX (1,000 to 4,000 Btu/h burner & control knob) 3. R (2,200 to 12,000 Btu/h burner & control knob) 3. R (2,200 to 12,000 Btu/h burner & control knob) 4. AUX (1,000 to 4,000 Btu/h burner & control knob) 4. SR (1,300 to 9,000 Btu/h burner & control knob) 5. SR (1,300 to 6,300 Btu/h burner & control knob) 36” 42” 1. SR (1,300 to 6,300 Btu/h burner & control knob) 1. DOUBLE CROWNS (700 to 18000 Btu/h burner & control 2. SR (1,300 to 9,000 Btu/h burner & control knob) knob) 3. DOUBLE CROWNS (700 to 18000 Btu/h burner & control 2. AUX (1,000 to 4,000 Btu/h burner & control knob) knob) 3. SR (1,300 to 9,000 Btu/h burner & control knob) 4. R (2,200 to 12,000 Btu/h burner & control knob) 4. R (2,700 to 15,000 Btu/h burner & control knob) 5. AUX (1,000 to 4,000 Btu/h burner & control knob) Appliance installed over 2,000 feet (610mt) De-rate effect Nominal values Elevation Elevation Elevation Elevation Cook top... -
Page 7: Gas Cooktop Operation
Use & Care Manual ENGLISH Gas Cooktop Operation Gas Control Knob Setting WARNING Electric gas ignition Do not operate a burner using empty The gas burner use an electric ignition device located cookware or without cookware on the grate. near each burner that by means a spark igniters Do not touch the burner when the igniters are ensure its surface light automatically. - Page 8 Use & Care Manual ENGLISH Burners with two rings flame This special burner has two separate flame rings to provide a real full heat regulation from high power to simmering. To set : 1. Push and turn counter clockwise the knob between HI-LO main flame ,when the burner is turned on, the main flame and the Simmer flame will always light and stay on.
-
Page 9: Burner Use Suggestions
Use & Care Manual ENGLISH Burner Use Suggestions Be sure when lighting the burner: Gas spreader pin is properly aligned with burner Use the right front, right rear or left rear burners for base slot. simmering, or for cooking smaller quantities of food Cap pin is properly aligned with gas spreader slot. -
Page 10: Cookware
Use & Care Manual ENGLISH Cookware IMPORTANT: Never leave empty cookware on a hot Match Pan Diameter to Flame Size surface cooking area, element or surface burner. The flame should be the same size as the bottom of Ideal cookware should have a flat bottom, straight the pan or smaller. - Page 11 Use & Care Manual ENGLISH Use a simmering plate: For simmering stews and soups, or melting chocolate, use the "FULGOR" simmer plate accessory. The simmer plate distributes the heat evenly and gently. Canners and pressure cookers must meet the same requirements as described above. After bringing contents to a boil, use lowest heat setting possible to maintain a boil or pressure (for pressure canners/cookers).
-
Page 12: Cleaning The Cooktop
Use & Care Manual ENGLISH Cleaning the Cooktop The entire Cooktop can be safe�y cleaned by wiping with a soapy sponge, then rinsing and drying. If stubborn soil remains, follow the recommended cleaning methods below. CAUTION: Before cleaning, be certain the burners are turned off and the grates are cool. - Page 13 Use & Care Manual ENGLISH Parts and materials Suggested cleaners Suggestions/Reminders Exterior finish • Hot sudsy water: rinse and dry • Acidic and sugar-laden spills deteriorate thoroughly. the porcelain enamel. Remove soil (Porcelain enamel) immediately. • Non abrasive cleansers: Ammonia, Fantastic®, Formula 409®.
-
Page 14: Troubleshooting
Use & Care Manual ENGLISH Troubleshooting Try the solutions suggested here first �n order to Surface burner makes popping noises avoid the cost of an unnecessary service call. Is the burner wet? Let it dry. Ignition will not operate Is the cap and gas spreader positioned Is the power supply cord unplugged? correctly? Plug into a grounded 3 prong outlet. -
Page 15: Fulgor Warranty For Home Appliances
Use & Care Manual ENGLISH Fulgor Milano WARRANTY for Home Appliances Duration of warranty: Fulgor Milano grants for the Continental U.S and Canada a 24 month full warranty from the date of purchase indicated on the invoice. During this period Fulgor Milano will pay the cost for replaced parts and labor needed to repair the appliance.
