varithek

acs 1100d3

varithek

acs 600 ec

acs

varithek

air-cleaning-system acs



With integrated side extraction and circulating-air cleaning for food delivery



With electronic fan control

The illustrations show configuration examples, which do not necessarily have to be included in the scope of delivery.

Observe the operating instructions

Translation of the Original Operating Instructions

DOWNLOAD: USER MANUAL

QR code on type plate

Issue: 2019-03-22

varithek

acs 1500d3

varithek

acs 1000 ec

Table of Contents

Need help?

Do you have a question about the varithek acs 1500d3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rieber varithek acs 1500d3

Page 1 ® ® varithek acs 1100d3 varithek acs 1500d3 ® ® varithek acs 600 ec varithek acs 1000 ec ® varithek air-cleaning-system acs  With integrated side extraction and circulating-air cleaning for food delivery  With electronic fan control The illustrations show configuration examples, which do not necessarily have to be included in the scope of delivery. Observe the operating instructions Translation of the Original Operating Instructions DOWNLOAD: USER MANUAL...
Page 2: Table Of Contents
Ensure undisturbed extraction of steam and vapours ..................27 Freshly prepare food on the cutting board ...................... 28 Switch appliance on and off electrically ......................28 Electronic fan control (option) ......................... 29 Clean the appliance after use ......................... 32 Rieber GmbH & Co. KG...
Page 3: Revision Index
Potential equalisation system, damaged supply line 2014-04-11 Index 2015-06-15 General modification, adaptation to acs 1600 O , ISO 82079, VDE requirement, electronic fan control 2016-08-05 New Rieber active carbon filter, plus electronic control 2018-06-07 Entfall 800 ec; Absaugung 2019-03-22_f1 Designations Rieber GmbH & Co. KG...
Page 4: Important Information
Select " Customer Service" at the top of the display list.  The Rieber price guide provides further information about a wide variety of accessories. www.rieber.de At the top of the display list, select: Search  price guide Or: Contact the manufacturer, Rieber, or your dealer ...
Page 5: Representation Conventions In The Text
Failure to follow these warning instructions may cause serious bodily injury or even death. CAUTION indicates a potentially harmful situation. Failure to follow these warnings may cause minor bodily injury. Rieber GmbH & Co. KG...
Page 6: General Safety Instructions
Make sure the appliance cannot be switched on unintentionally. Double check that the main switch is in the "OFF" position before inserting the plug in the socket. Connecting the appliance to the power supply while it is switched on can cause an accident. Rieber GmbH & Co. KG...
Page 7: Operator's Obligations
In addition, the operator must train the personnel and inform them of the hazards involved at regular intervals.  The operator must provide the personnel with the necessary protective equipment and make sure that they wear it. Rieber GmbH & Co. KG...
Page 8: Personnel Qualification Requirements
Ensure that the personnel wear the personal protective equipment appropriate to the relevant situation.  Wear safety shoes to prevent injuries when transporting or moving the appliance.  Wear protective gloves to prevent burns to hands and arms when using the cooking accessories. Rieber GmbH & Co. KG...
Page 9: Appliance-Specific Safety Instructions
The unit's extraction and circulating-air cleaning is not a replacement for an air-conditioning system. Always ensure an adequate supply of fresh air. Risks due to human error when  using the Rieber active carbon filter for odour and contaminant absorption and odour elimination using plasma technology...
Page 10  Mobile appliances may only be moved manually. Machine-aided transport, e.g. using fork lift trucks or lift trucks, is not permissible. Risk of injury and risk of damaging the appliance. Rieber GmbH & Co. KG...
Page 11 For variant with odour elimination using plasma technology:  Pressure sensor monitors the pressure conditions in the technical compartment; in the event of a fault the plasma generator is switched off Rieber GmbH & Co. KG...
Page 12  Only connect varithek appliances with the same voltage, i.e. 400 V or 230 V. Product identification in technical compartment for all appliance types ‘ WARNING  Unplug mains plug before removing the fan device.’ Rieber GmbH & Co. KG...
Page 13: Information About Regulations To Be Followed
General Safety Instructions Product identification in technical compartment for  variant with Rieber active carbon filter for odour and contaminant absorption and odour elimination using plasma technology WARNING Health risks, respiratory disorders ► Only use Rieber active carbon filter, install correctly.
Page 14: Instructions On Behaviour In An Emergency
Breathing difficulties, lacrimal irritation, mucosal irritations in throat, neck and lungs, headache, strong tickle in the throat, cannot be excluded in the case of human error. ► Only use with Rieber active carbon filters, which are correctly mounted. Replace active carbon filters after at least 500 operating hours. ►...
Page 15  Only use with original filter components, which are correctly mounted. ®  Only Use correctly sized cooking units, such as the cooking modules in the Rieber varithek range.  Provide the unit with electrical fuse connection on site. ...
Page 16: Description Of The Equipment
Splash guard; removable for cleaning → option Sneeze guard attachment, including shelf for serving food → option Operating elements, power connections for cooking units The electrical connection with cable and plug is located at the back of the product. Rieber GmbH & Co. KG...
Page 17 The electrical connection with cable and plug is located at the back of the product. 5.1.3 Cooking units User tip Only use correctly sized cooking units. ® ► Use cooking modules from the Rieber varithek range. Baking, grilling, cooking, wok cooking and frying. Rieber GmbH & Co. KG...
Page 18 A wet active carbon filter is unusable. Never dry a wet Rieber active carbon filter in the oven or dryer, as there is a risk of fire. Let the active carbon filter dry in dry ambient air.
Page 19: Technical Data
(separation efficiency approx. 95%), Grease drip trays. In addition Version A: Rieber active carbon filter Model type B: Rieber active carbon filter for odour and contaminant absorption and odour elimination using plasma technology Rieber GmbH & Co. KG...
Page 20 Approx. 3 m cable / CEE plug 3x 16 A / L1 / L2 / L3 / N / PE For detailed information on dimensions, order number, accessories, circuit diagrams, spare and wearing parts: see type plate, catalogue, brochure Complete with splash guard Rieber GmbH & Co. KG...
Page 21: Before First Use
Lift / deposit a heavy load evenly with your knees bent and your upper body straight and upright. Your feet should be at least hip-width apart and your abdominal muscles braced. Breathe out. Do not twist your spine. Rieber GmbH & Co. KG...
Page 22 Dispose of the disposable packaging with respect for the environment. 6.1.5 Clean the appliance  Clean the appliance thoroughly before using for the first time. Clean with a damp cloth and rub dry with a clean cloth. See ‘Cleaning, Maintenance and Care’, page 33 Rieber GmbH & Co. KG...
Page 23: Observe When Commissioning/Recommissioning
 The socket outlet must be easily accessible so that the unit can be disconnected from power supply at anytime. Equipotential bonding must be carried out by a qualified electrician. Rieber GmbH & Co. KG...
Page 24: Use
(RCD) with a tripping current of 30 mA. Never direct a jet of water at electrical components such as heater, controller or ventilation grille. Avoid malfunctions after a power interruption  Disconnect the unit from the mains completely after a power failure. Then switch on the electrical appliances again. Rieber GmbH & Co. KG...
Page 25: Only Equip The Appliances With Suitable Accessories
Only equip the appliances with suitable accessories User tip Only use correctly sized cooking units. ® ► Use cooking modules from the Rieber varithek range. Baking, grilling, cooking, wok cooking and frying. Use ® varithek functional components.
Page 26 Position griddle to the right.  Do not position a ceramic hob next to the griddle, as otherwise odours may develop due to splashes of grease. ‘Ensure undisturbed extraction of steam and vapours’, page 27 Rieber GmbH & Co. KG...
Page 27: Ensure Undisturbed Extraction Of Steam And Vapours
In appliance type ´ec´, the extraction system (push & pull system) is designed in such a way that the vapour created when cooking and roasting is collected by a transversally running air stream and extracted into the side flank. Rieber GmbH & Co. KG...
Page 28: Freshly Prepare Food On The Cutting Board
Green indicator light illuminates. User tip ► We recommend letting the extraction system run for another 10 minutes at the end of the cooking process, so that the vapour caused by residual heat cannot disperse into the environment. Rieber GmbH & Co. KG...
Page 29: Electronic Fan Control (Option)
Increase ventilation intensity, levels 1 to 4 Display LED display LED fan fault, red = alarm LED plasma fault, red = alarm LED filter usage time exceeded, red = alarm 10 LED OK, green = fault-free Rieber GmbH & Co. KG...
Page 30 TURBO is the highest ventilation intensity level. Adjust TURBO  Press the TURBO button (3). ▌ The fan icon and TURBO appear in the display. ▌ After 5 minutes the fan switches back to the last selected ventilation intensity. Rieber GmbH & Co. KG...
Page 31 Is the technical compartment closed?  Are the filters in the technical compartment free from objects?  Are the Rieber active carbon filters correctly inserted? Are the high-performance grease separators, grease drip trays and filter mats  correctly mounted in the air supply area? ...
Page 32: Clean The Appliance After Use
 Replace filter mat if necessary. The time intervals for replacing the Rieber active carbon filters are no more than 500 operating hours. Only use the filter type specified in the display. Replace Rieber active carbon filters ...
Page 33: Cleaning, Maintenance And Care
Have electrical equipment inspected at least every 6 months by a qualified electrician. Risks due to human error when  using the Rieber active carbon filter for odour and contaminant absorption and odour elimination using plasma technology WARNING Breathing difficulties, lacrimal irritation, mucosal irritations in throat, neck and lungs, headache, strong tickle in the throat, cannot be excluded in the case of human error.
Page 34: Cleaning Agents For Stainless Steel
Long-term exposure to sodium hypochlorite can cause damage to the material. It should not be used if possible. Products should be used, which are specified in the list of the German Society of Hygiene and Microbiology (DHGM). Rieber GmbH & Co. KG...
Page 35: Overview Of Maintenance Measures And Intervals
Inspect filter mat Inspect technical compartment; clean if Page 48 Every 7 working days or weekly necessary Replace Rieber active carbon filter Page 48, 51 After at least 500 hours of operation Ensure preservation of the product Page 12, 52...
Page 36: Choose The Correct Cleaning Method
‘Cleaning agents for stainless steel’, page 34 User tip ► We recommend Rieber cleaning agent for stainless steel for cleaning stainless steel. ▌ It is an especially tough yet gentle cleaner, produces a dazzling shine, cleans and protects in one.
Page 37: Clean Casters
If the cutting board is not in place unpleasant odours can develop, as the extraction is interrupted. ► Ensure that the cutting board is in position. Briefly removing the cutting board for cleaning will not interrupt the extraction. Rieber GmbH & Co. KG...
Page 38: Appliance Type 'Ec
↑ High-performance grease separator ↑ Grease drip tray User tip Note the arrangement of the parts. Installation is then easier to carry out. ► Remove the 2x high-performance grease separators. ► Remove the 1x grease drip tray. Rieber GmbH & Co. KG...
Page 39 The illustration shows the right side from the operator's viewpoint, as an example. Right side ‘ec’ ↑ Order no. 61550346 (1 raised point) ↑ Order no. 61550347 (2 raised point) (no further identification available)  Ensure that the parts are completely dry and undamaged prior to assembly. Rieber GmbH & Co. KG...
Page 40: Clean Cooking Area And Splash Guard
User tip. Place an adequately large, soft surface in the cooking area for placing the parts to be cleaned. 8.9.1 Clean air ducts Example ‘d3’ The cover of the air ducts is fixed with pins at the bottom left and clipped in at the top. Rieber GmbH & Co. KG...
Page 41 Clean the casing and air ducts with a hot, mild detergent diluted in water. After cleaning, rub surfaces dry with a soft cloth. 8.9.2 Clean cooking area  Clean the appliance with a hot, mild detergent diluted in water. After cleaning, rub surfaces dry with a soft cloth. Rieber GmbH & Co. KG...
Page 42 Ensure correct positioning and condition of the plastic profiles, replace if necessary; Order no. 37160605 /bulk goods # NOTE  Only re-install the splash guard after cleaning the side edge extraction units. Chapter ‘Insert the parts again’, page 46 Rieber GmbH & Co. KG...
Page 43: Clean High-Performance Grease Separator, Grease Drip Trays
Place the part on the prepared surface. # Remove high- performance grease separator  Grasp the front filter centrally at the handle strip, tilt the part and pull it out vertically upwards.  Repeat with the rear filter. Rieber GmbH & Co. KG...
Page 44  Repeat with the rear grease drip tray. Slide forward around 10 cm first of all. # Remove filter mat  Grasp the filter mat centrally and pull it out. Rieber GmbH & Co. KG...
Page 45 Order no. 91 70 05 15 # Clean inside of appliance Clean with a hot, mild  detergent diluted in water, using a slightly damp cloth.  After cleaning, rub surfaces dry with a soft cloth. Rieber GmbH & Co. KG...
Page 46  Then push it back as far as it will go.  Insert the other grease drip tray at the front. Rieber GmbH & Co. KG...
Page 47  Install the cover. Make sure it is firmly in place. # Re-install side splash guard  Install the side splash guard, left and right. Chapter ‘Remove and clean splash guard ’, page 42 Rieber GmbH & Co. KG...
Page 48: Inspect Technical Compartment; Clean If Necessary
Remove the radial fan if necessary by pulling it out along the guides and place it on a soft surface.  Clean the surfaces in the technical compartment with a hot, mild detergent diluted in water. After cleaning, rub the surfaces dry with a soft cloth. Rieber GmbH & Co. KG...
Page 49 # Notes on inspecting and replacing the active carbon filter User tip The period of use of the Rieber active carbon filter depends on the type of vapour and the amount of grease. The degree of soiling of the active carbon filter cannot be visually assessed.
Page 50 Order no. 37252208, quantity dependent on appliance type  Risk of fire Never dry a wet Rieber active carbon filter in the oven or dryer, as there is a risk of fire. Let the active carbon filter dry in dry ambient air. Rieber GmbH & Co. KG...
Page 51 Rieber active carbon filter.  Risk of fire Never dry a wet Rieber active carbon filter in the oven or dryer, as there is a risk of fire. Let the active carbon filter dry in dry ambient air. User tip The period of use of the Rieber active carbon filter depends on the type of vapour and the amount of grease.
Page 52: Disinfect The Appliance As Required
Disconnect the unit from the mains completely after a power failure. Then switch back on. Any repairs during warranty period may only be carried out by the manufacturer's service department of Rieber. Please contact the manufacturer's service department of Rieber. Rieber GmbH & Co. KG...
Page 53 See below manufacturer is located on the left in the floor of the technical Operating staff compartment.  Clean. Message on display Various of the electronic fan Page 29 control  Operating staff Rieber GmbH & Co. KG...
Page 54: Disposing Of Your Product
Customer service needs information about the type and number of your appliance.  If you have a fault which you cannot remedy yourself, please get in touch with your Rieber specialist dealer or Rieber central customer services. Disposing of your product Your appliance is made of high-quality material which can be reused / recycled.
Page 55: Warranty And Liability
 use non-original spare parts. The "Sales and delivery terms and conditions" of Rieber GmbH & Co. KG shall apply for all warranty claims made against the manufacturer. For instance, any repairs and/or overhaul during the warranty period may only be performed by the manufacturer's service department of Rieber, failing which any claims hereof may be voided.
Page 56: Index
Technical compartment ..10, 12, 16, 17, 37, 48 Grease separator ....12, 18, 19, 38, 39, 53 High-performance grease separator ....45 Manufacturer's address Rieber GmbH & Co. KG Hoffmannstraße 44 D72770 Reutlingen, Germany Phone +49 (0) 7121 518-0...
