Lex System 3I370DW Manual

Intel® coffee lake-s core™ i processor + intel q370, ddr4 lan / dp / hdmi / usb / pcie / m.2
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Intel® Coffee Lake-S Core™ I processor + Intel Q370,
DDR4 LAN / DP / HDMI / USB / PCIe / M.2
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
NO. 3I370DW
Release date: May 26th. 2020
3I370DW
9 / 8th gen. Intel Coffee Lake-S Core™ I CPU
HDMI, DP, eDP, PCIe, PCIe mini card, M.2,
Multi-LAN, COM, Audio, SATA, USB
Wide Range DC-input
All in One

Advertisement

Table of Contents
loading

Related Manuals for Lex System 3I370DW

Summary of Contents for Lex System 3I370DW

  • Page 1 HDMI, DP, eDP, PCIe, PCIe mini card, M.2, Multi-LAN, COM, Audio, SATA, USB Wide Range DC-input CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS NO. 3I370DW Release date: May 26th. 2020...

  • Page 2: Table Of Contents

    1-5 INSTALLING THE MINI PCI-e CARD (FULL SIZE) .............. 1-6 DIRECTIONS FOR INSTALLING THE M.2B KEY MINI CARD ..........CHAPTER 2 HARDWARE INSTALLATION ................2-1 DIMENSION-3I370DW ......................2-2 LAYOUT-3I370DW-FUNCTION MAP-TOP ................2-2-1 LAYOUT-3I370DW-FUNCTION MAP-BOT ............... 2-3 FUNCTION MAP-3I370DW ....................2-4 CONNECTOR MAP-3I370DW-TOP ..................
  • Page 3 3-10 CO1: I2C BUS 4 PIN (1.25MM) WAFER ................3-11 CPI1: MOTHERBOARD DC POWER INPUT (ATX 2x3 PIN 2.54MM WAFER) ....3-12 CPO1: +12V / +5V DC VOLTAGE OUTPUT WAFER CONNECTOR (BLACK) ....3-13 CPS1: EXTERNAL POWER-ON SYNC CONTROL ............3-14 USB 3.0 AND USB 2.0 ......................
  • Page 4 4-10 SAVE & EXIT ........................4-11 HOW TO UPDATE INSYDE BIOS ..................APPENDIX B: RESOLUTION LIST ....................
  • Page 5 Copyright This manual is copyrighted and all rights are reserved. It does not allow any non authorization in copied, photocopied, translated or reproduced to any electronic or machine readable form in whole or in part without prior written consent from the manufacturer.

  • Page 6: Warning

    Warning ! 1. Battery Batteries on board are consumables. The life time of them are not guaranteed. 2. Fanless solution with HDD The specifi cation & limitation of HDD should be considered carefully when the fanless solution is implemented. We will not give further notifi cation in case of changes of product information and manual.

  • Page 7: Hardware Notice Guide

    Hardware Notice Guide 1. Before linking power supply with the motherboard, please attach DC-in adapter to the motherboard fi rst. Then plug the adapter power to AC outlet. Always shut down the computer normally before you move the system unit or remove the power supply from the motherboard.
  • Page 8 Photo 1 Insert Unplug...

  • Page 9: Chapter 1 General Information

    Intel LAN chipset, it is perfect control board for networking devices. The 3I370DW SBC equipped with a variety of interfaces: 5 x LAN, 4 x RS232 / RS422 / 485 serial ports, 4 x USB3.1, 4 x USB2.0, DP, HDMI & eDP) and expansion slots such as PCIe / mPCIe / M.2 slots for I/O modules (Digital I/O, WiFi, 3G / 4G, LoRA, Bluetooth)

  • Page 10: Major Feature

    1-1 Major Feature 1. The Desktop Coff ee Lake-Platform processor includes Integrated Display Engine, GPU and Integrated Memory Controller. The processor is designed be off ered in a LGA1151 package. 2. Intel Q370 Chipset Family Platform Controller Hub (PCH) 3. Supports Two Channels of DDR4 SO-DIMM SDRAM, Max. 32GB, data transfer rates of 2400MT/s and 2666 MT/s 4.

  • Page 11: Specification

    1-2 Specifi cation CPU: Desktop Coff ee Lake Platform processor. The processor is designed be off ered in a LGA1151 package. Memory: Two SO-DIMM slots for DDR4 SDRAM, Max. 32GB, data transfer rates of 2400MT/s and 2666 MT/s Graphics: Intel 9th generation (Gen 9) LP graphics and media encode / decode engine supports OpenGL x 4.5, OpenCL x 2.1, Direct3D x 2015, Direct3D 11.2, Direct2D eDP 1.4 2 Lanes up to 1920 x 1080, DP 1.2 4096 x 2160, HDMI 1.4 up to 3840 x 2160...

  • Page 12: Installing The Cpu / North Bridge Chip Heatsink. (Socket Version)

    1-3 Installing the CPU / North Bridge Chip Heatsink. (Socket Version) 2. Open of CPU pin anti- crash cover 1. Put the "CPU Under Bracket" with the CPU location at the back side of motherboard 4. Screw the CPU mounting bracket via 3.

  • Page 13: Installing The So-Dimm

    1-4 Installing the SO-DIMM 1. Align the SO-DIMM with the connector at a 45 degree angle. 2. Press the SO-DIMM into the connector until you hear a click.
  • Page 14 Notices: 1.The connectors are designed to ensure the correct insertion. If you feel resistance, check t h e connectors & golden fi nger direction, and realign the card. 2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of the card fi...

  • Page 15: Removing The So-Dimm

    1-4-1 Removing the SO-DIMM 1. Release the SO-DIMM by pulling outward the two retaining clips and the SO-DIMM pops up slightly. 2. Lift the SO-DIMM out of its connector carefully.

  • Page 16: Installing The Mini Pci-E Card (Full Size)

    1-5 Installing the Mini PCI-e Card (Full Size) 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 17: Directions For Installing The M.2B Key Mini Card

    1-6 Directions for installing the M.2B Key Mini Card 1. Unscrew the screw on the board 2. Plug in the Mini Card in a 45 angle 3. Gently push down the Mini Card and screw the screw back.

  • Page 18: Chapter 2 Hardware Installation

    Chapter-2 2-1 Dimension-3I370DW...

  • Page 19: Layout-3I370Dw-Function Map-Top

    2-2 Layout-3I170DW-Function Map HDD LED, Full Size, mini card M.2 B KEY 3042 PWR LED, (PCIe/mSATA/ Line Out (PCIe x2/mSATA/ LAN LED, USB 3.0/2.0) Line In USB 3.0/2.0) Power LED, Mic In Reset Button COM1 LAN5 COM2 COM3 or 4DI/4DO COM4 or 4DI/4DO COM5 or 4DI/4DO LAN4...

  • Page 20: Layout-3I370Dw-Function Map-Bot

    2-2-1 Layout-3I170DW-Function Map Nano SIM USB 3.0 USB 3.0 USB 3.0 USB 3.0...

  • Page 21: Function Map-3I370Dw

    2-3 Function Map-3I370DW Full SIZE, mini card M.2 B Key 3042 (PCIe/mSATA/USB 3.0/2.0) (PCIe x2/mSATA Line Out HDD LED, PWR LED, /USB 3.0/2.0) Line In/Mic In LAN LED, Power On, Reset Button SMBus COM2 COM1 COM6 or 4DI/4DO COM5 or 4DI/4DO...

  • Page 22: Connector Map-3I370Dw-Top

    2-4 Connector MAP-3I370DW NGFF1 MPCE1 CLPC1 CFP1 CCIO1 CCIO2 JSB2 CCIO3 JSB1 CCIO4 CBT1 CPO1 CU11 SATA3 CU10 SATA2 CPU FAN1 JVL1 CDH1 CPI1 CPS1...

  • Page 23: Connector Map-3I370Dw-Bot

    2-4-1 Connector MAP-3I370DW SIM1...

  • Page 24: Diagram-3I370Dw-Top

    2-5 Diagram- 3I370DW NGFF1 MPCE1 CLPC1 CFP1 CCIO1 CCIO2 JSB2 CCIO3 JSB1 CCIO4 CBT1 CPO1 CU11 SATA3 CU10 SATA2 CPU FAN1 JVL1 CDH1 CPI1 CPS1...

  • Page 25: Diagram-3I370Dw-Bot

    2-5-1 Diagram- 3I370DW SIM1...

  • Page 26: List Of Jumpers

    2-6 List of Jumpers JSB1: CMOS DATA Clear JSB2: ME DATA Clear JVL1: eDP panel power select 2-7 Jumper Setting Description A jumper is ON as a closed circuit with a plastic cap covering two pins. A jumper is OFF as an open circuit without the plastic cap.

  • Page 27: Jsb1: Cmos Data Clear

    2-8 JSB1: CMOS DATA Clear A battery must be used to retain the motherboard confi guration in CMOS RAM. Close Pin1 and pin 2 of JSB2 to store the CMOS data. To clear the CMOS, follow the procedures below: 1. Turn off the system and unplug the AC power 2.

  • Page 28: Jsb2: Me Data Clear

    2-9 JSB2: ME DATA Clear JSB2 DESCRIPTION *1-x Normal Set ME data clear JSB2 *Normal 2-10 JVL1: eDP panel power select JVL1 DESCRIPTION *2-3 +3.3V JVL1 *+3.3V...

  • Page 29: Chapter 3 Connection

    Chapter-3 Connection This chapter provides all necessary information of the peripheral's connections, switches and indicators. Always power off the board before you install the peripherals. 3-1 List of Connectors CBT1: CMOS battery 1x2 pin (1.25mm) wafer CA1: Line-out / Line-in / Mic-in / SPDIF-out 2x5 pin (2.0mm) Wafer CC1: COM port1 2x5 pin (2.0mm) wafer.

  • Page 30: Cbt1: Cmos Battery 1X2 Pin (1.25Mm) Wafer

    CU10: USB 2.0 port 4 pin (1.25mm) Wafer CU11: USB 2.0 port 4 pin (1.25mm) Wafer EDP1: eDP 2x10 pin (1.25mm) connector SATA2: SATA port 2 connector 7pin SATA3: SATA port 3 connector 7pin SIM1: Nano push-push SIM socket. SODIMM1: DDR4 Channel 0 SODIMM SODIMM2: DDR4 Channel 1 SODIMM...

  • Page 31: Ca1: Line-Out / Line-In / Mic-In 2X5 Pin (2.0Mm) Wafer

    3-3 CA1: Line-out / Line-in / Mic-in 2x5 pin (2.0mm) Wafer PIN NO. DESCRIPTION PIN NO. DESCRIPTION Line-out-R MIC-IN Line-in-R Line-in-L Line-out-L MIC-IN pin1...

  • Page 32: Cc1 / Cc2 Com Port1 / 2 2X5 Pin (2.0Mm) Wafer

    3-4 CC1 / CC2 COM port1 / 2 2x5 pin (2.0mm) wafer. RS232 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION RS485 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION Data- Data+ RS422 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION Note: 1. Pin 9 RI has +12V or +5V voltage, but default is RI, voltage for OEM.

  • Page 33: Ccio1 / Ccio2 / Ccio3 / Ccio4 Com Port3 / Port4 / Port5 / Port6 And Di/Do 2X5 Pin (2.0Mm) Wafer

    3-5 CCIO1 / CCIO2 / CCIO3 / CCIO4 COM port3 / port4 / port5 / port6 and DI/DO 2x5 pin (2.0mm) wafer. 3-5-1 For COM 3 / 4 / 5 / 6: RS232 Mode PIN NO. DESCRIPTION PIN NO. DESCRIPTION RS485 Mode PIN NO.

  • Page 34: For Di/Do

    3-5-2 For DI/DO: PIN NO. DESCRIPTION PIN NO. DESCRIPTION DI-0,4,8,12 DO-3,7,11,15 DI-1,5,9,13 DO-2,6,10,14 DI-2,6,10,14 DO-1,5,9,13 DI-3,7,11,15 DO-0,4,8,12 Note: 1. COM or DI/DO decided by OEM order and BOM controlled 2. UART default is RS232 and RS422 / RS485 by BIOS selected 3.

  • Page 35: Io Device: F81966 Lpc Dio Under Windows

    3-5-2-1 IO Device: F81966 LPC DIO under Windows The Sample code source you can download from Source fi le: F81966_LPC_GPIO_Utility_Src_v1.5.zip Binary fi le: F81966_LPC_GPIO_Utility_Bin_x86_v1.5.zip F81966_LPC_GPIO_Utility_Bin_x64_v1.5.zip F81966 DLL : F81966_DLL_x32_v1.0.zip F81966_DLL_x64_v1.0.zip http://tprd.info/lexwiki/index.php/IO_Device:F81966_LPC_DIO_under_Windows Introduction F81966 DIO Start test Button,Send bits one by one and one by one receive CIO116 mode for CIO116 module use Set time countdown, If the end of the countdown, the trigger signal to reboot Enable loop, Continuously reset the WDT to ensure that when the system is normal, the restart signal will not be triggered...
  • Page 36 F81966_DLL Function F81966_DLL_API bool F81966_LPC_Init(pF81966_status status); F81966_DLL_API BYTE F81966_LPC_Digital_Read_LOW(); F81966_DLL_API void F81966_LPC_Digital_Write_LOW(BYTE byteValue); F81966_DLL_API BYTE F81966_LPC_Digital_Read_HIGH(); F81966_DLL_API void F81966_LPC_Digital_Write_HIGH(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Enable(BYTE byteValue); F81966_DLL_API void F81966_LPC_Set_WDT_Disable(); Digital Input / Ooutput test sample code Set Dout all high F81966_LPC_Digital_Write_LOW(256); set Dout all low F81966_LPC_Digital_Write_LOW(0);...

  • Page 37: Cdh1 Display Port And Hdmi Connector

    3-6 CDH1 Display Port and HDMI Connector Display Port: PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA0+ DATA0- DATA1+ DATA1- DATA2+ DATA2- DATA3+ DATA3- AUX+ AUX- H.P. Detect +3.3V HDMI: PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS DATA2+ TMDS DATA2- TMDS DATA1+ TMDS DATA1- TMDS DATA0+ TMDS DATA0-...

  • Page 38: Cfp1 Front Panel Connector 2X5 Pin (2.0Mm) Wafer

    3-7 CFP1 Front Panel connector 2x5 pin (2.0mm) wafer Display Port: PIN NO. DESCRIPTION PIN NO. DESCRIPTION Power button pin Power button GND Reset pin Reset GND Power LED- Power LED+ HDD LED- HDD LED+ LAN LED- LAN LED+ CFP1 pin1...

  • Page 39: Lan

    3-8 LAN CL1 / CL2 / CL3 / CL4 / CL5: RJ45 LAN1 / LAN2 / LAN3 / LAN4 / LAN5 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION MDI0+ MDI2- MDI0- MDI1- MDI1+ MDI3+ MID2+ MDI3- CL11 / CL21 / CL31 / CL41 / CL51: LAN1 / 2 / 3 / 4 / 5 2x4 pin (2.0mm) wafer (OEM) PIN NO.

  • Page 40: Clpc1: For Lpc Signal 2X5 Pin Wafer (2.0Mm)

    3-9 CLPC1: for LPC signal 2x5 pin wafer (2.0mm). PIN NO. DESCRIPTION PIN NO. DESCRIPTION FRAME RESET SERIAL IRQ +3.3V CLPC1 pin1 3-10 CO1: I2C Bus 4 pin (1.25mm) Wafer PIN NO. DESCRIPTION +3.3V I2C Clock I2C DATA pin1...

  • Page 41: Cpi1: Motherboard Dc Power Input (Atx 2X3 Pin 2.54Mm Wafer)

    3-11 CPI1: Motherboard DC Power input (ATX 2x3 pin 2.54mm Wafer) PIN NO DESCRIPTION 1,3,5 DC-IN 2,4,6 CPI1 pin1 3-12 CPO1: +12V / +5V DC voltage output wafer connector (Black) (1x4 pin 2.0mm) PIN NO. DESCRIPTION +12V* * Note: Attention! Check Device Power in spec CPO1 pin1...

  • Page 42: Cps1: External Power-On Sync Control

    3-13 CPS1: External Power-On Sync control. PIN NO. DESCRIPTION PS_ON_N *Note: The sync signal is Low active. When Motherboard powered on that is Low, Power-off is high. The signal is +3.3V tolerance. It can be used for gold fi nger power to sync motherboard power sequence. CPS1 pin1...

  • Page 43: Usb 3.0 And Usb 2.0

    3-14 USB 3.0 and USB 2.0 CU1 / CU2 / CU3 / CU4: USB 3.0 Port 1 / 2 / 3 / 4 Type A Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VBUS SS_RX- SS_RX+ SS_TX- SS_TX+ Note: the power supply 0.9A for each USB 3.0 respect specifi cation. CU8 / CU9 / CU10 / CU11 USB 2.0 port (1x4 pin 1.25mm Wafer) PIN NO.

  • Page 44: Edp1: Edp Interface (2X10 Pin 1.25Mm Wafer)

    3-15 EDP1: eDP interface (2x10 pin 1.25mm wafer) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Lane-0-DATA- +12V Lane-0-DATA+ +12V Lane-1-DATA- Lane-1-DATA+ Backlight Enable PWM dimming I2C Clock +LCD (5V or 3.3V) I2C Data +LCD (5V or 3.3V) eDP Aux+ +LCD (5V or 3.3V) eDP Aux- EDP_HPD Note:...

  • Page 45: Sata2 / 3: Sata Port 1X7 Pin Connector

    3-16 SATA2 / 3: SATA port 1x7 pin Connector PIN NO. DESCRIPTION Note: 1. CPO1 provide SATA HDD power +12V, GND, +5V SATA2 SATA3 3-17 SIM1: Nano Push-Push SIM socket. PIN NO. DESCRIPTION Power Reset Clock Data SIM detect Note: 1. The SIM signal comes from M.2 module. SIM1 NANO SIM...

  • Page 46: Sodimm1 / 2 Socket

    3-18 SODIMM1 / 2 socket Note: SODIM1 / SODIM2: SO-DIMM DDR4 1.2V DRAM Socket Only Support un-buff er type module Only suport Raw card type A.C.E. SODIMM1 SODIMM2...

  • Page 47: Mpce1 Pci Express Mini Card

    3-19 MPCE1 PCI Express Mini card PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +1.5V PCIe-CLK- PCIe-CLK+ WAKEUP_LTE W_DISABLE_N Reset PCIe-RX- / mSATA-RX+ +3.3V PCIe-RX+ / mSATA-RX- MPCE1 +1.5V pin1 SMB-CLK PCIe-TX- / mSATA-TX- SMB-DATA pin52 PCIe-TX+ / mSATA-TX+ USB-DATA- USB-DATA+ +3.3V +3.3V +1.5V...

  • Page 48: Ngff1: B Key Size

    3-20 NGFF1: B Key size PIN NO. DESCRIPTION PIN NO. DESCRIPTION CONFIG_3 +3.3V or +3.7V +3.3V or +3.7V Full_Card_Power_OFF_N USB-DATA- W_DISABLE_1_N USB-DATA+ LED# CONFIG_0 W_DISABLE_2_N NGFF1 PCIe-RX- PCIe-RX+ PCIe-TX- PCIe-TX+ RESET# PCIe-CLK- PCIe-CLK+ LTE_RESET_N CONFIG_1 +3.3V or +3.7V +3.3V or +3.7V +3.3V or +3.7V CONFIG_2 Note:...

  • Page 49: Connector Wafer Of Compatible Brand And Part Number List

    3-21 Connector wafer of Compatible Brand and part number list Location CKTS PITCH Brand Name Mating connector Cable housing CBT1 1x2 2 Pin 1.25mm MOLEX 53047-0210 51021-0200 2x5 10 Pin 2.00mm B10B-PHDSS PHDR-10VS 2x5 10 Pin 2.00mm B10B-PHDSS PHDR-10VS 2x5 10 Pin 2.00mm B10B-PHDSS PHDR-10VS...

  • Page 50: Introduction Of Bios

    Chapter-4 Introduction of BIOS The BIOS is a program located in the Flash Memory on the motherboard. This program is a bridge between motherboard and operating system. When you start the computer, the BIOS program gains control. The BIOS first operates an auto-diagnostic test called POST (Power on Self Test) for all the necessary hardware, it detects the entire hardware devices and configures the parameters of the hardware synchronization.

  • Page 51: Bios Menu Screen & Function Keys

    4-2 BIOS Menu Screen & Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us fi rst see a short description of the function keys you may use here: ●...

  • Page 52: General Help

    4-3 General Help Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press <Esc>. 4-4 Menu Bars There are six menu bars on top of BIOS screen: Main To change system basic confi...

  • Page 53: Main

    4-5 Main Main menu screen includes some basic system information. Highlight the item and then use the <+> or <-> and numerical keyboard keys to select the value you want in each item. System Date Set the Date. Please use [Tab] to switch between data elements. System Time Set the Time.

  • Page 54: Advanced

    4-6 Advanced PCH-FW Confi guration Please refer section 4-6-1 Trusted Computing Please refer section 4-6-2 F81966 Super IO Confi guration Please refer section 4-6-3 Hardware Monitor Please refer section 4-6-4 Intel TXT Information Please refer section 4-6-5 USB Confi guration Please refer section 4-6-6 Network Stack Confi...

  • Page 55: Pch-Fw Configuration

    4-6-1 PCH-FW Confi guration 4-6-2 Trusted Computing This page for TPM Device only. (For Option Model)
  • Page 56 4-6-3 F81966 Super IO Confi guration Serial Port 1 Confi guration Please refer section 4-6-3-1 Serial Port 2 Confi guration Please refer section 4-6-3-2 Serial Port 3 Confi guration Please refer section 4-6-3-3 Serial Port 4 Confi guration Please refer section 4-6-3-4 Power Failure Please refer section 4-6-3-5...

  • Page 57: Serial Port 1 Configuration

    4-6-3-1 ► Serial Port 1 Confi guration To Enable Serial port or not, default is Enabled. Change Settings, default is Auto.
  • Page 58 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 59: Serial Port 2 Configuration

    4-6-3-2 ► Serial Port 2 Confi guration To Enable Serial port or not, default is Enabled. Change Settings, default is Auto.
  • Page 60 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 61: Serial Port 3 Configuration

    4-6-3-3 ► Serial Port 3 Confi guration To Enable Serial port or not, default is Enabled. Change Settings, default is Auto.
  • Page 62 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 63: Serial Port 4 Configuration

    4-6-3-4 ► Serial Port 4 Confi guration To Enable Serial port or not, default is Enabled. Change Settings, default is Auto.
  • Page 64 To select the Serial port to RS232 / RS422 / RS485, default is RS232.

  • Page 65: Power Failure

    4-6-3-5 ► Power Failure To select the power behavior after power fail, default is Keep last state.

  • Page 66: Hardware Monitor

    4-6-4 Hardware Monitor Press [Enter] to view PC health status. This section shows the status of your CPU, Fan, and overall system. This is only available when there is Hardware Monitor function onboard.

  • Page 67: Intel Txt Information

    4-6-5 Intel TXT Information Press [Enter] to view Intel TXT Information.

  • Page 68: Usb Configuration

    4-6-6 USB Confi guration Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. Disable option will keep USB devices available only for EFI applications. The optional settings are: Enabled (default), Disabled, Auto. XHCI Hand-off...

  • Page 69: Network Stack Configuration

    4-6-7 Network Stack Confi guration To enable the UEFI Network stack or not, default is Disabled. 4-6-8 NVMe Confi guration To detect NVMe storage automatically.

  • Page 70: Chipset

    4-7 Chipset System Agent (SA) Confi guration. Please refer section 4-7-1 PCH-IO Confi guration. Please refer section 4-7-2...

  • Page 71: System Agent (Sa) Configuration

    4-7-1 System Agent (SA) Confi guration Graphics Confi guration. Please refer section 4-7-1-1 PEG Port Confi guration. Please refer section 4-7-1-2...

  • Page 72: Graphics Configuration

    4-7-1-1 ► Graphics Confi guration Primary Display To select which of IGFX / PEG Graphics device should be Primary Display Or select SG for Switchable Gfx. The optional settings are: Auto, IGFX (default), PEG, PCI. Internal Graphics Keep IGFX enabled based on the setup options. The optional settings are: Auto, Enabled (default), Disabled.

  • Page 73: Peg Port Configuration

    4-7-1-2 ► PEG Port Confi guration Enable Root Port To enable the Root Port or not. The optional settings are: Auto (default), Enabled, Disabled. Max Link Speed Confi gure PEG Port Max Speed. The optional settings are: Auto (default), Gen1, Gen2, Gne3.

  • Page 74: Pch-Io Configuration

    4-7-2 PCH-IO Confi guration PCI Express Confi guration. Please refer section 4-7-2-1 SATA And RST Confi guration. Please refer section 4-7-2-2...

  • Page 75: Pci Express Configuration

    4-7-2-1 ► PCI Express Confi guration PCI Express Root Port 14 (MPCE1 / SATA1) The optional settings are: Enabled (default), Disabled. PCI Speed To select PCI Express port speed. The optional settings are: Auto (default), Gen1, Gen2, Gen3...

  • Page 76: Sata And Rst Configuration

    4-7-2-2 ► SATA And RST Confi guration SATA Controller Use this item to Enable or Disable SATA Device. SATA Mode Selection Determines how SATA controller(s) operate. The optional settings are: AHCI, Intel RST Premium.

  • Page 77: Security

    4-8 Security Administrator Password User Password To set up an Administrator or an User password.

  • Page 78: Boot

    4-9 Boot Bootup NumLock State To select Power-on state for NumLock, default is <On> Quiet Boot The optional settings are: Enabled (default), Disabled. Wake-Up From USB The optional settings are: Enabled, Disabled (default).
  • Page 79 4-10 Save & Exit Save Change and Reset Save confi guration and reset Discard Changes and Reset Reset without saving the changes Restore Defaults To restore the optimal default for all the setup options...
  • Page 80 STEP 2. Copy utility program and latest BIOS to your bootable disc. You may download it from our website. STEP 3. Here take 3I370DW as an example, insert your bootable disc into X: (X could be C:, A: or others.
  • Page 81 Appendix B: Resolution list 640 x 480 x ( 256 / 16bit / 32bit ) 800 x 600 x ( 256 / 16bit / 32bit ) 1024 x 768 x ( 256 / 16bit / 32bit ) 1152 x 864 x ( 256 / 16bit / 32bit ) 1280 x 600 x ( 256 / 16bit / 32bit ) 1280 x 720 x ( 256 / 16bit / 32bit ) 1280 x 768 x ( 256 / 16bit / 32bit )
