Summary of Contents for Lex System TWITTER
- Page 2 Contents Twitter & LEO assembly for SATA HDD Version ... Twitter Exploded Drawing ..........LEO Exploded Drawing ........... LEO / Twitter wall mount kit ..........
-
Page 3: Twitter & Leo Assembly For Sata Hdd Version
Twitter & LEO assembly for SATA HDD Version Twitter (Fig.2) (Fig.1) 1. Remove the round-headed screws (M2.5*8) off the top cover on both sides (Fig.1) (Fig.2) of the chassis. Twitter (Fig.4) (Fig.3) (Fig.3) (Fig.4) 2. Remove the top cover. (Fig.5) (Fig.6) - Page 4 (Fig.7) (Fig.7) 5.Connect the SATA POWER CABLE to the HDD. Twitter (Fig.8) (Fig.9) (Fig.8) (Fig.9) 6. Plug the SATA DATA CABLE on the motherboard. Twitter (Fig.10) (Fig.11) (Fig.10) (Fig.11) 7. Plug the SATA POWER CABLE on the Motherboard.
- Page 5 Twitter (Fig.12) (Fig.13) 8. Screw the HDD KIT on the copper pillars with three flat-headed (M3*4) screws. (Fig.12) (Fig.13) Twitter (Fig.14) (Fig.15) 9. Attach the thermal pad on the HDD and avoid the heat-dissipating holes (Fig.14) (Fig.15) at the same time.
- Page 6 Twitter (Fig.18) (Fig.19) 1. Remove the round-headed screws (M2.5*8) off the top cover on both sides (Fig.18) (Fig.19) of the chassis.
-
Page 7: Twitter Exploded Drawing
Twitter Exploded Drawing Dimension: 55(H) x 210(W) x 125.5(D)mm Name Q'ty Name Q'ty 2_5-SATA-HDD SCREW-BROLLY-M3-10 SCREW-M2_5-6 TWITTER_BACK-COVER SCREW-M2_5-3 TWITTER_BACK-PANEL SCREW-M2_5-4 BOTTOM-COVER THERMAL_PAD-60X47X1_25 FRONT-COVER-A THERMAL_PAD-60X45X0_5 FRONT-PANEL TWITTER_TOP-BRACKET TOP-COVER POWER-LEAD_6G3186-6301-0900 SCREW-BROLLY-M3-4... -
Page 8: Leo Exploded Drawing
LEO Exploded Drawing Dimension: 50(H) x 240(W) x 124(D)mm Name Q'ty Name Q'ty 2.5" SATA-HDD PW010 3I270D_M01 SCREW-BROLLY-M3-4 AUDIO_6G6003-0301-0100 SCREW-BROLLY-M3-10 BRIK_HDD-BRACKET_3V700A-2.5" HDD SCREW-M2_5-10 COPPER_EXTRUED_M3-18_5 SCREW-M2_5-3 D89-327-COMPORT_9P-HOUSING SCREW-M2_5-4 LEO_BACK-COVER SWITCH_RL3-4_ LEO_BACK-PANEL THERMAL_PAD-60X47X1_25 LEO_BOTTOM-COVER THERMAL_PAD_60X45X0_5 LEO_FRONT-COVER-A LEO_TOP-BRACKET LEO_FRONT-PANEL LEO_MODULE-BKT_PW010 WIRELESS LEO_TOP-COVER POWER-LEAD... -
Page 9: Leo / Twitter Wall Mount Kit
1. M 4*8 black flat-head screw x 4 pcs 2. 4*6(B) Pan-head screw x 4pcs ( for 7" Panel PC ) 3. 4*8 Pan-head screw x 4pcs ( for Twitter System ) 4. M 3*4 dome-head screw x 1 pcs Fig. - Page 10 Fig. 4 Fig. 5 3.Secure Wall Mount Kit-B to the wall 4. Slide the Wall Mount Kit-C (whole system ) from ( in advance ) (Fig.4) top to down into Wall Mount Kit-B. (Fig.5) Fig. 6 5. Screw M 3*4 round-head screw to secure Wall Mount Kit-A with Wall Mount Kit-C.
