Fuse Chart - Two-Rock Sensor 22 Owner's Manual

Parallel/Series Switch - The switch allows the user to choose how the wet and dry
signals interact with each other. With the switch set to Parallel the signal will be split
with one side "wet" running from the preamp to effects to power stage, while the "dry"
signal runs from the preamp to the power stage. This setting is more versatile with
vintage effects that don't have any wet/dry mixing controls. With the switch set to Series
the signal will not be split and will run straight from the preamp through the effects and then
intothe power stage of the amplifier. This setting will be better suited to rack or digital gear
that has onboard mixing controls. With nothing plugged into the loop, the Parallel
setting will yield a fatter and fuller signal.
Footswitch Jack - The footswitch connects here using a ¼" stereo cable. The Expansion and
Lead functions can be activated via the footswitch. The respective front panel Push/ Pull pots must
be in the "off," or "in" position, to enable the footswitch functions.
S/N - Your serial number is located here. We strongly suggest that you record this number and
have it handy in case you need service, or in the event that your amp is lost, stolen, or damaged.
Export 100V:
2A – 22/35 Watt
2.5 - 50 Watt
WARNING! No user serviceable parts inside! Refer to qualified service person only.
LINE CORD- For your safety, connect to grounded A/C receptacle only.

Fuse Chart

All Fuses are 3AG Type 250 Volt, SLO-BLO
Domestic 120V:
2A – 22/35 Watt
2.5 - 50 Watt
FOOTSWITCH
Export 220V, 230V, 240V:
1A-22/35 Watt
1.6 - 50 Watt
