Carmelli TRIPLE THREAT NG1022M Assembly Instructions Manual

3-in-1 flip table
Hide thumbs Also See for TRIPLE THREAT NG1022M:

Advertisement

Quick Links

Download this manual
TRIPLE THREAT 3-IN-1 FLIP TABLE
ASSEMBLY INSTRUCTIONS
NG1022M

Advertisement

loading

Related Manuals for Carmelli TRIPLE THREAT NG1022M

Summary of Contents for Carmelli TRIPLE THREAT NG1022M

  • Page 1 TRIPLE THREAT 3-IN-1 FLIP TABLE ASSEMBLY INSTRUCTIONS NG1022M...
  • Page 2 THANK YOU! Thank you for purchasing this product. We work around the clock and around the globe to ensure that our products maintain the highest possible quality. However, in the rare case of issues during assembly or use of this product, please contact our Consumer Hotline at 800-759-0977 for immediate assistance before contacting your retailer.
  • Page 4 Qty. Preassembled Fan NGP58131...

  • Page 5: Assembly Tips

    ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. We recommend that two adults work together to assemble this game. You may want to carefully cut or tear the four corners of the box so that the bottom of the box can be used as your work surface. 2.
  • Page 6 THANK YOU! ASSEMBLY INSTRUCTIONS STEP 1 - ASSEMBLE THE LEGS 1. Select one of the leg pieces (#9 or #10) and lay it flat on the floor. Do not bend the hinge in the leg backwards. Damage to the outer surface will occur. 2.
  • Page 7 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) STEP 2 - ATTACH THE TABLE LOCKS AND CATCH BOX 1. Insert the table locks (#14) into the end panel (#3). Use four screws (#27) to secure each one. 2. Hold the catch box (#4) in position. Insert four screws (#25) from the back side of the end panel.
  • Page 8 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) STEP 4 - ASSEMBLE LEGS TO END PANELS 1. Insert four barrel nuts (#22) into the left and right holes of an end panel (#3). Attach a left leg (#9) and a right leg (#10) to an end panel (#3) using two bolts (#16) per leg. 2.
  • Page 9 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) STEP 6 - ASSEMBLE CABINET (TABLE TOP) TO LEGS All bolts and screws from previous steps must be tight. Two adults are recommended for this step. 1. Engage all four table locks. 2. Locate the two large bolts (#18). Place a washer (#19) onto each bolt. 3.
  • Page 10 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) STEP 7 - ASSEMBLE TOP SIDE PANELS AND SLIDE SCORERS 1. Attach the two top end panels (#6) to the top of the end panels (#3) using eight screws (#25) for each top end panel. 2.
  • Page 11 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) STEP 8 - ADJUST THE LEVELERS 1. With the help of another person, lock the table in position. Turn each leg leveler until the table rests level. 2. Check with a carpenters level placed cross-wise and length wise on the table top. 3.
  • Page 12 THANK YOU! ASSEMBLY INSTRUCTIONS (CONT.) STEP 11 - TABLE TENNIS NET WITH POSTS ASSEMBLY 1. When you want to play table tennis, put the tennis surface (#12) carefully on top of the game table. 2. Insert the table tennis net with posts (#30) into the holes of the table tennis surface (#12). To rotate the table: CAUTION: This should be performed by an adult.

  • Page 13: Care And Use

    CONGRATULATIONS! You have now assembled your Game Table. Please note the Care and Use instructions below to ensure years of trouble free use of your game table. Games This game table includes the equipment and game pieces for Air Hockey, Pool and Table Tennis.
  • Page 14 180-DAY LIMITED WARRANTY This product is warranted to the original purchaser to be free from defects in material or workmanship for a period of 180 days from the date of the original retail purchase. This warranty does not cover defects or damage due to improper installation, alteration, accident or any other event beyond the control of the manufacturer.
  • Page 15 TRIPLE THREAT 3-IN-1 FLIP TABLE - NG1022M Parts List 1,44 PARTS #1 NGP5813 #3 NGP5814 #4 NGP5815 #5 NGP5816 #6 NGP5817 #7 NGP5818 #8 NGP5819 #44 NGP58131 (Pre-installed Fan) NG1022M BALL RETURN BOARD CABINET END PANEL CATCHER BOX TOP END PANEL LEG BRACE LEG PANEL #9 NGP5820...
  • Page 16 HARDWARE PACK - NGP5840 1/4” x 1-3/4” ALLEN 5/16” x 5-1/2” 1/2” PLASTIC 5/16” WASHER ALLEN WRENCH KEY BOLT HEX BOLT 1/2” HEX BOLT 1/2” WASHER WASHER WRENCH F4 x 1” SCREW F3 x 1/2” SCREW 1/4” BARREL NUT 5/16” BARREL NUT T4 x 1/2” SCREW F4 x 2”...
