Introduction

1.1 DUPLEX DC-24II

Thank you for buying the JETI Duplex DC-24II transmitter. This is a
High-End transmitter that will surely satisfy all users. Duplex is a JETI
model remote control system with maximum reliability and safety.
The DUPLEX DC-24II transmitters were developed and produced
with the cooperation of professional engineers and world champion
pilots. It's a modernized version of the proven DC-24 transmitters.
The design goals were maximum utility, durability, and reliablity of
their mechanical parts along with simple handling. The metal case,
with its chemically resistant finish, provides maximum protection for
the interior components. The straightforward case shape makes
servicing easy. The all-metal, ball bearing equipped, control gimbals
with their magnetic Hall sensors are another revolutionary design
concept used to make the DC/DS among the world's most advanced
R/C systems.
The large LCD display located on the top of the transmitter offers
perfect readability in any lighting conditions and a wide viewing
angle. The new graphical software gives the user a simplified and
intuitive setting not only of the transmitter, but also of other
supported connected devices in the model. Internal WiFi and
Bluetooth communication modules extend the transmitter with
new functions and options. In the products of the DUPLEX EX series,
full telemetry, data transfer and their processing to LCD transmitters,
as well as analysis in a PC, are already integrated as standard. The
transmitter allows the setup of voice notifications, both preinstalled
and user created, which can be related to telemetric values, user set
alarms, or signals which have been assigned to conditions of various
control elements.

1.2 Features

Duplex 2.4GHz – the DC/DS transmitters feature the Duplex
2.4GHz, frequency hopping, digital, data stream system, originally
developed by JETI model in the Czech Republic. For higher security,
the transmitter is equipped with two separate RF modules for the 2.4
GHz band. This system has been reliably used for many years.
Duplex 900MHz NG (Next Generation) - transmitters have a backup
RF module working in the 900 Mhz band. Doubled two-band data
transmission in this way ensures unparalleled security and reliability
of the system.
Bluetooth module - connection to wireless headphones for audio
transmission or to mobile phones and tablets to display telemetry.
Wi-Fi module - extending the connectivity of the transmitter by the
access to the Internet (this function will be gradually released and
updated through free updates).
Integrated telemetry - DUPLEX transmitters are developed to
display and use telemetry for model control. Transmitters display all
telemetry and also offer the possibility to use telemetry data for
control of any functions in the model.
Precise Gimbals – the transmitter gimbals are equipped with Hall
sensors and ball bearings for precision movement with an almost
unlimited lifespan.
LCD Display – color 4" LCD display with 480 x 480 resolution which is
highly visible under any light conditions.
