5.1.4 Ratchet Tension Adjustment
Whether you prefer smooth throttle feel or ratchet throttle feel, you
can adjust the transmitter either way you like allowing you to fully
customize your transmitter's feel. Each tension is set by a different
screw.
1. Switch off the transmitter and remove the 10 screws that secure
the radio back cover. Next, remove the radio back cover.
Be sure to disconnect the transmitter battery pack
connector.
2. For ratchet tension adjustment use the machine screw "A".
Turn slowly (counter-clockwise) until you achieve the desired
ratchet tension. For smooth tension adjustment, use the
machine screw "B". Turn slowly (clockwise) until you achieve the
desired smooth tension.
3. Reconnect transmitter battery pack and reinstall radio back
cover and cover screws.
B A
5.1.5

Throttle stick travel adjustment

The throttle stick travel is adjustable to suit your flying style.
1. Switch off the transmitter and remove the 10 screws that secure
the radio back cover. Next, remove the radio back cover.
Be sure to disconnect the transmitter battery pack
connector.
2. Use indicated machine adjustment screws to limit the throttle
stick travel. By turning the screw clockwise, you will shorten the
throttle stick travel.
3. Reconnect transmitter battery pack and reinstall radio back
cover and cover screws.
After making a limit the throttle stick travel you must recalibrate the
transmitter stick in the software menu, see section „Calibration of
Proportional Controls".
