Arable Mark 3
Quick Start Guide
In the box:
Step 1: Pre-deployment
Connect your device to a
charger
Note:
Using 10W+ charger, charging to full
battery can take up to 7 hours from
empty. If using a 5W charger,
charging to full battery can take up
to 14 hours.
www.arable.com ○ support@arable.com ○ 510-992-4095
Mark 3 Device
●
Solar Panel
●
Solar Panel Knob
●
Cellular Antenna
●
BLE Antenna
●
Power Charging Cable (USB to M8 Connector)
●
4" (10cm) Bird Spikes [Qty: 5]
●
2.75" (7cm) Bird Spikes [Qty: 21]
●
8" (20cm) Zip Ties [Qty: 5]
●
Charge until your device's lightning bolt icon turns white by plugging
your charging cord into the provided USB-C converter or directly
into a 10W+ wall charger (not included). The lightning bolt icon will
be green while charging. Reattach the charging cap prior to
deployment.
Pg. 1
Advertisement
Table of Contents
Related Manuals for ARABLE Mark 3
Summary of Contents for ARABLE Mark 3
- Page 1 Reattach the charging cap prior to deployment. Note: Using 10W+ charger, charging to full battery can take up to 7 hours from empty. If using a 5W charger, charging to full battery can take up to 14 hours. www.arable.com ○ support@arable.com ○ 510-992-4095 Pg. 1...
- Page 2 Step 2: First, attach the cable from the panel to the Mark 3 cable. You will hear a snap. Insert the connected cables in the solar panel cavity. Ensure the solar panel is From top→down, slide the groove of the panel down the Mark 3 attached to the Mark 3 casing.
- Page 3 New deployments will appear in the “Unassigned View your data in the Arable Device” list of the Map page in Arable Web. In Arable Mobile a red web or mobile application dot will show up in the “Weather List” menu icon. Find your device by device ID and deployment timestamp in these lists and then name your deployment/site.
- Page 4 Green while charging and white when fully charged. Orientation Your Mark 3 should be deployed 3-4 feet above the maximum expected height of your crop canopy. The “A” in the Arable logo should point +/-90° towards the equator. www.arable.com support@arable.com 510-992-4095 Pg.4...
- Page 5 Internal Sensor Green→ Sensors are all in working condition Red → One or more sensors have failed Connectivity → Device has connected to the Arable system. *Additional Sensors→ Status of additional attached sensors. Amber→ No sensors attached Green → One sensor attached Purple →...
- Page 6 Step 3: Install Mark 3 assembly to the pole Tighten the top knob and mount the Mark 3 to the top of the telescoping pole. Turn the Mark 3 in a position that is facing the equator +/- 90°.
- Page 7 This device complies with Directive 2014/53/EU and UK Radio Equipment Regulations 2017 SI 2017/1206. issued by the Commission of the European Community. Declaration of Conformity Hereby, Arable Labs Inc. declares that the radio equipment type Arable Mark 3 is in compliance with Directive 2014/53/EU and UK Radio Equipment Regulations 2017 SI 2017/1206.
