ENGLISH Content User Manual for Transett T-SIGN What’s in the box ..................3 About Transett T-SIGN ................3 Set up/ Installation instructions for Transett T-SIGN ......3 Normal operation mode ................3 Installation (refer to the enclosed Quick Guide) .........4 Calibration mode ..................5 Technical data ....................8 Cleaning and maintenance ................9 Repairs ......................9 Waste disposal ....................9... -
Page 3: User Manual For Transett T-Sign What's In The Box
ENGLISH User Manual for Transett T-SIGN What’s in the box 3. DIP - switches 1. Brightness knob Power Input External sensor (optional) 2. Sensitivity knob External sensor input About Transett T-SIGN T-SIGN, the active hearing loop indicator is designed to indicate how a hearing loop functions. -
Page 4: Installation (Refer To The Enclosed Quick Guide)
ENGLISH one flash and program two gives two flashes (see below for program characteristics). Very weak or no signal: T-SIGN is dark Weak signal: Flashes green in a soft manner Normal signal: Steady green light Strong signal: Steady red light Installation (Refer to the enclosed Quick Guide) 1. -
Page 5: Calibration Mode
ENGLISH Calibration Calibration is done in order for T-SIGN to show correct display mode (dark/soft flashing green/steady green/red) in relation to magnetic field strength. It is made to that T-SIGN works well in regard to the SIS 60118-4 standard. When in calibration mode, sensitivity is adjusted so that T-SIGN changes color from green to red when the magnetic field strength at the listening position (most likely NOT at the mounting spot) is 400 mA/m. - Page 6 ENGLISH 8. Adjust T-SIGN sensitivity knob with the supplied screwdriver to that T-SIGN just turns red (or just showing red in peaks if using a pulsating sinus tone, or red in peaks if using a speech signal). 9. If it’s not possible to reach red color shift in the previous step, then T-SIGN won’t be able to indicate correct display (dark/soft flashing green/steady green/red ).
- Page 7 ENGLISH • DIP-sw 3: Change indication of strong signal from a steady red light to flashing red light (off/on). • DIP-sw 4: Program selection 1 & 2 (off/on). Program characteristics program 1: Program 1 is a program where T-SIGN reacts relatively fast to changes in magnetic field strength.
-
Page 8: Technical Data
ENGLISH ENGLISH / NEDERLANDS / NORSK / SVENSKA Program characteristics program 2: Program 2 is the default program where T-SIGN reacts slower to changes in magnetic field strength. This is useful in public venues and where the speaker can’t affect the level of the sound. A normal indication shows that the hearing loop is functional and within correct limits. -
Page 9: Cleaning And Maintenance
ENGLISH Cleaning and maintenance Use a damp cloth to wipe it on the outside. Never use cleaning products or solvents. Repairs If your product malfunctions, it must be repaired by a qualified technician. Do not attempt to open the case of the device since this would invalidate the warranty. -
Page 10: Drilling Template
Drilling template... - Page 12 SVERIGE / SERVICE: INTERNATIONAL INQUIRIES: AB Transistor Sweden AB Transistor Sweden Bergkällavägen 23 Bergkällavägen 23 192 79 Sollentuna SE-192 79 Sollentuna, Sweden Tel: 08-545 536 30 Tel: +46 8 545 536 30 Fax: 08-545 536 39 Fax: +46 8 545 536 39 info@transistor.se...
