Owner’s Manual (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27GN95R www.lg.com Copyright 2022 LG Electronics Inc. All Rights Reserved.
TABLE OF CONTENTS LICENSE ............3 OPEN SOURCE SOFTWARE NOTICE INFORMATION ..........4 ASSEMBLING AND PREPARING .....4 USING THE MONITOR ........14 USER SETTINGS ...........17 TROUBLESHOOTING ........25 PRODUCT SPECIFICATION ......29...
LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. The SuperSpeed USB Trident logo is a registered trademark of USB Implementers Forum, Inc.
In addition to the source code, all referred license terms, • warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open It is recommended that use the supplied components. source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost •...
Page 5
• The power cord provided may differ depending upon the region. Supported Drivers and Software • You can download and install the latest version from the LGE website (www.lg.com). - Monitor Driver / Joystick Button...
Page 6
Moving and Lifting the Monitor How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or down with your finger.
Page 7
Installing on a Table CAUTION • • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away Avoid touching the monitor screen as much as possible. from the wall to ensure sufficient ventilation. - This may result in damage to the screen or some of the pixels used to create images.
Page 8
Adjusting the Stand Height CAUTION • Unplug the power cord before moving or installing the monitor. There is risk of electric shock. Place the monitor mounted on the stand base in an upright position. • Make sure to use the power cord that is provided in the product package and connect it to a grounded power Handle the monitor with both hands for safety.
Page 9
Pivot Feature WARNING • To avoid injury to the fingers when adjusting the screen, do not hold the lower part of the monitor’ s frame The pivot feature allows the monitor to rotate 90 ° clockwise. as illustrated below. WARNING • Be careful not to touch or press the screen area when adjusting the angle of the monitor.
Page 10
Raise the monitor to the maximum height. Rotate the monitor clockwise as shown in the figure. Adjust the angle of the monitor in the direction of the arrow as shown in the figure. Complete the installation by rotating the monitor 90 ° as shown below.
Page 11
Using the Kensington Lock NOTE • Auto Pivot feature of the display is not supported. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website at http://www.kensington.com. • The screen can be rotated easily using the screen pivot shortcut key provided with your Windows operating system.
Page 12
Installing on the Wall Installing the Wall Mount Plate To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.
Page 13
Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could • The wall mounting bracket is optional. You can obtain optional accessories from your local dealer. lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • •...
Press the joystick button, go to [Settings] > [Input], and then select the input option. CAUTION • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Do not press the screen for a prolonged time. This may cause image distortion.
Page 15
Connecting to a PC DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the * feature. NOTE : A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers.
Page 16
Connecting Peripherals Connecting Headphones Connect peripherals to the monitor via the headphones port. USB Device connection NOTE The USB port on the product functions as a USB hub. • Peripheral devices are sold separately. To use USB 3.0, connect the A-B type USB 3.0 cable of the product to the PC. •...
USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu • Main menu disabled: Enables the main menu. • Main menu enabled: Exits the main menu. (Holding down the button more than 5 seconds to turn off the Press the joystick button on the bottom of the monitor.
Page 18
Main Menu Features Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings]. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
Page 19
[Game Mode] [Game Mode] on HDR signal • [Gamer1]/[Gamer2]: [Gamer1] and [Gamer2] picture modes allow you to save two sets of customized display [Settings] > [Game Mode] settings, including game-related setup options. • [FPS]: This mode is optimized for FPS games. It is suitable for very dark FPS games. [Game Mode] on SDR(Non-HDR) signal •...
Page 20
[Game Adjust] • [Black Stabilizer]: You can control the black contrast to have better visibility in dark scenes. You can easily distinguish objects on dark game screens. [Settings] > [Game Adjust] • [Response Time]: Sets a response time for displayed pictures based on the speed of the screen. •...
Page 21
[Picture Adjust] • [R/G/B]: You can customize the picture color using red, green, and blue colors. • [Six Color]: Meets the user requirements for colors by adjusting the hue and saturation of the six colors (red, [Settings] > [Picture Adjust] green, blue, cyan, magenta, and yellow) and then saving the settings.
Page 22
[Input] [General] [Settings] > [Input] [Settings] > [General] • [Input]: Selects the input mode. • [Waves MaxxAudio ]: Select the sound equipment what you are using. ® • [Ratio]: Adjusts the aspect ratio of the screen. [Over-the-ear] [On-ear] [Ear-buds] The display may look the same for [Full Wide], [Original], and [Just Scan] options at the recommended resolution.
Page 23
• [Power LED]: Turns the power LED on the bottom of the monitor on or off. • [DisplayPort Version] - Please set the [DisplayPort Version] to match the version of the connected external device ([1.4(DSC)], When the Power LED function is turned on, it operates as follows: [1.4], and [1.2]).
Page 24
• [Buzzer]: This feature lets you set the sound generated from Buzzer when your monitor powers on. • [OSD Lock]: This feature disables the configuration and adjustment of menus. All features are disabled except [Brightness], [Contrast] in [Picture Adjust], [Input], [OSD Lock] and [Information] in [General].
TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? - Check if the power cord is correctly plugged into the power outlet. • Is the monitor's adapter plugged in? - Make sure to use the adapter that is provided in the product package. •...
Page 26
Do you see an "Unrecognized monitor, monitor found" message? • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports function.
Page 27
The screen retains an image. • Does image sticking occur even when the monitor is turned off? - Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. - To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
Page 28
The display color is abnormal. • Does the display appear discolored (16 colors)? - Set the color to 24 bit (true color) or higher. In Windows, go to Control Panel > Display > Settings > Color Quality. (The settings may differ depending on the operating system (OS) you use.) •...
PRODUCT SPECIFICATION Environmental Conditions • Operating Conditions - Temperature: 0 °C to 40 °C Specifications are subject to change without notice. - Humidity: Less than 80 % The symbol means alternating current, and the symbol means direct current. • Storing Conditions - Temperature: -20 °C to 60 °C Color Depth: 10-bit color is supported.
Page 30
Supported Mode (Preset Mode, HDMI/DisplayPort) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2560 x 1440 182.996 HDMI only ([ ]: [On]) 3840 x 2160 66.66...
Page 32
The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
