- Page 1 Doc. No.KQ*-OMY0032-A Product Name FDA compliant Stainless Steel 316 One-touch Fittings Model / Series / Product Number Series KQG2-F...
-
Page 2: Table Of Contents
Contents 1. Safety Instructions 2 to 3 2. Specific Product Precautions 4 to 9 3. Specifications 10 to 11 4. Troubleshooting 5. Construction 12 to 13... -
Page 3: Safety Instructions
FDA compliant Stainless steel 316 One-touch Fittings Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 FDA compliant Stainless steel 316 One-touch Fittings Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
-
Page 5: Specific Product Precautions
2. Specific Product Precautions (1) (3)Do not use fluids other than listed in the Design/Selection specifications. Applicable fluids are air, water and steam. Warning Please consult with SMC if using other fluids. (4)When it is used with water, the fittings or (1)Check the specifications. - Page 6 2. Specific Product Precautions (2) (8)When performing the piping work, turn the tightening tool in the horizontal direction to Mounting/Piping the hex. across flats of the stud so that any moment is not applied to the body. If the tool is in contact with the body, this may Caution cause the stud to come off.
- Page 7 and antistatic tubing (Series TA) are recommended. 2．Specific Product Precautions (3) (6)Do not use the ordinary fittings and tubing in (3)Drain flushing locations where spatter is generated. If condensation in the drain bowl is not emptied Spattering may result in a fire hazard. In such a on a regular basis, the bowl will overflow and place, use of flame resistant fittings (Series allow the condensation to enter the compressed...
- Page 8 5. Pull the tubing back gently to make sure it has a positive seal. Insufficient installation may 2．Specific Product Precautions (4) cause air to leak or the tubing to release. Caution As a guide for checking the tubing is not pulled out, refer to the following table.
- Page 9 Chamfer Dimension for Female Thread 2．Specific Product Precautions (5) Caution Connection Thread Tightening Method (1) Chamfer dimension for female thread of the Caution connection thread Confirming to ISO 16030 (air pressure fluid (1) Connection thread: M5 and 10-32UNF dynamics – connection – ports and stud ends), Screw tightening torque is 1 to 1.5Nm.
- Page 10 2．Specific Product Precautions (6) Precautions for use with non-SMC tubing Recommended Piping Conditions Caution (1) When connecting piping to the One-touch (1)When used with tubing other than those from fitting, use pipe length with sufficient margin, SMC, due to their properties, series KQG2-F in accordance with the piping conditions are not subject to warranty.
-
Page 11: Specifications
3. Specifications Applicable Tubing Note) Tubing material FEP, PFA, Nylon, Soft nylon, Polyurethane, Polyolefin ø 3.2, ø 4, ø 6, ø 8, ø 10, ø 12, ø 16 Tubing O.D. ø 1/8", ø 5/32", ø 1/4", ø 5/16", ø 3/8", ø 1/2" Note: Considering the product application, FDA compliant products are recommended. -
Page 12: Troubleshooting
Cross Reference Table of the Inner Sleeve (Inch size) Tubing material Applicable inner sleeve Tubing O.D. TH/TIH TL/TIL Part no. Length (FEP) (Super PFA) TH0402 TJG-0402 ø 5/32" TH0425 TJG-0425 TL0403 TJG-0403 TIHB07 TIL07 TJG-0604 ø 1/4" TIHA07 TJG-0746 ø 5/16" TH0806 TL0806 TJG-0806... -
Page 13: Construction
5. Construction Connection thread: R,NPT Male elbow Male connector Connection thread: G Male elbow Male connector Description Material Release button Stainless steel 316 Guide 1 Stainless steel 316 Guide 2 Stainless steel 316 Chuck Stainless steel 316 FDA Compliant FKM (NSF H1 grease) Seal Male connector body Stainless steel 316... - Page 14 Stainless steel Metal exists in nature as ore (like oxide or sulfide). This means that oxide or sulfide is more stable than pure metal. Accordingly, metallic material chemically oxidizes (metallic constituent becomes ion and melts out). It corrodes in the natural environment. Even though corrosion of metal easily occurs in an environment where oxidizing tendency is stronger, some kinds of metal have a characteristic for which corrosion never happens if the level of oxidizing goes higher than...
- Page 15 Revision history A: Cleaning added 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
