Magnet Mounts (Included)
This unit comes included with magnetic mounting brackets pre-attached.
Magnet brackets are adjustable along the length of the aluminum track.
Ensure all four magnets are secured to a flat surface.
Stud Mount (Sold Separately)
Loosen the hardware securing the Magnet Mounts to the Light Bar and
remove the Magnet Mounts from the Light Bar.
Place the main mounting bolt through the Stud Mount.
Use the screws that were securing each Magnet Mount to the Light Bar and
attach the Stud Mount to the Light Bar.
Fully tighten the hardware to secure the Stud Mount to the Light Bar.
NOTE: Not all bolts used to secure Magnet Mounts will be used for securing
Stud Mount as pictured on the right.
Headache Rack Mount (Sold Separately)
Loosen the hardware securing the Magnet Mounts to the Light Bar and
remove the Magnet Mounts from the Light Bar.
Use the screws that were securing each Magnet Mount to the Light Bar and
attach the Headache Rack Bracket to the Light Bar using the two vertical
cutaways on the Headache Rack Mount. This secures the Headache Rack
Mount to the Light Bar.
The Headache Rack Mount may then be directly mounted. Or, by using the
supplied secondary piece, you may "sandwich" the back rack with 2 user
supplied nuts and bolts.
NOTE: Not all bolts used to secure Magnet Mounts will be used for securing
Headache Rack Mount as pictured on the right.
5
K-FORCE
MICRO 14 LINEAR
®
MINI LIGHT BAR
SpeedTech Lights, Inc © 2021
