LG 27BQ70QC-S.AUB Owner's Manual
LG 27BQ70QC-S.AUB Owner's Manual

LG 27BQ70QC-S.AUB Owner's Manual

Led lcd monitor

Advertisement

Quick Links

Owner's Manual
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
27BQ70QC
27MQ70QC
www.lg.com
Copyright 2022 LG Electronics Inc. All Rights Reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 27BQ70QC-S.AUB and is the answer not in the manual?

Questions and answers

Summary of Contents for LG 27BQ70QC-S.AUB

  • Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27BQ70QC 27MQ70QC www.lg.com Copyright 2022 LG Electronics Inc. All Rights Reserved.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE ..................... 3 OPEN SOURCE SOFTWARE NOTICE INFORMATION ......4 ASSEMBLING AND PREPARING ............4 USING THE MONITOR ............... 13 USER SETTINGS ................16 TROUBLESHOOTING ................ 21 PRODUCT SPECIFICATION ..............22...
  • Page 3: License

    LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
  • Page 4: Open Source Software Notice Information

    It is recommended that use the supplied components. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing • Illustrations in this document represent typical procedures, so they may look different from the actual such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.
  • Page 5 • The power cord provided may differ depending upon the region. Supported Software You can download and install the latest version from the LGE website (www.lg.com). • Monitor Driver/ OnScreen Control/ Dual Controller Button...
  • Page 6 Moving and Lifting the Monitor CAUTION • Avoid touching the monitor screen as much as possible. When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or - This may result in damage to the screen or some of the pixels used to create images. damaged and to ensure safe transportation, regardless of its shape or size.
  • Page 7 Installing on a Table CAUTION After folding the stand to secure it, lift the monitor and place it on the table in an upright position. • Make sure the table on which the product is installed is stable and solid. A table made of fragile materials such as glass may be damaged.
  • Page 8 Adjusting the Angle Using the Kensington Lock The angle of the screen can be adjusted forward or backward from -5° to 10° for a comfortable viewing For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website experience.
  • Page 9 Installing on the Wall NOTE • Secure at least a certain amount of vertical flat space in the partition to be installed. The stand can be unfolded by pushing the button on the back of the product. In addition, ensure that it is strong and sturdy enough to hold and use the product. B-Type C-Type B-Type...
  • Page 10 NOTE CAUTION • The partition in which the product is installed must be sufficiently rigid. If it is made of fragile material such as glass, this may result in damage to the product. • If the partition surface is uneven or tilted, the product may tilt. •...
  • Page 11 Webcam Installation When Installing on a Partition Insert the webcam according to the direction in which you wish the camera to shoot, and use it after connecting it to the monitor. When Installing on a Table CAUTION • Do not mount the webcam on the bottom of the monitor.
  • Page 12 NOTE Adjusting the Angle • The USB-C port on the side of the monitor and the USB-C port on the PC must be connected with a USB-C The angle of the webcam can be adjusted from -15° to 10° (or 15°) front and back for comfortable use. cable in order for the webcam to function.
  • Page 13: Using The Monitor

    (Menu) button on the side of the monitor and select the corresponding input from the [Input] menu. CAUTION • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Do not press the screen for a prolonged time. This may cause image distortion. •...
  • Page 14 Connecting to a PC USB-C connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the feature. NOTE : A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers.
  • Page 15 Connecting AV Devices Connecting Peripherals HDMI Connection Headset Connection HDMI transmits digital video and audio signals from your AV device to the monitor. Connect peripherals to the monitor via the headset port. CAUTION NOTE • • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. Peripheral devices are sold separately.
  • Page 16: User Settings

    USER SETTINGS [Quick Settings] • [Brightness]: Adjusts the brightness of the screen. • [Contrast]: Adjusts the contrast of the screen. NOTE • [Volume]: Adjusts the volume level. • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. •...
  • Page 17 [Input] [Picture] • [Input List]: Selects the input mode. [Picture] > [Picture Mode] • [Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide], • [Custom]: Allows the user to adjust each element. [Original], and [Just Scan] options at the recommended resolution (2560 x 1440).
  • Page 18 [Picture] > [Picture Adjust] [Picture] > [Game Adjust] • • [Brightness]: Adjusts the brightness of the screen. [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is •...
  • Page 19 [Picture] > [Color Adjust] [Picture] > [Picture Reset] • • [Gamma] Returns picture and color to the default settings. - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the [Sound] lower the gamma value, the lighter the image becomes. •...
  • Page 20 [General] • [Deep Sleep Mode]: When [Deep Sleep Mode] is [On], power consumption is minimized while the monitor is in standby mode. • [Language]: Sets the menu screen to the desired language. - [On]: Enables [Deep Sleep Mode]. • [SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm. - [Off]: Disables [Deep Sleep Mode].
  • Page 21: Troubleshooting

    TROUBLESHOOTING Screen display is unstable and shaky. / Images displayed on the monitor leave shadow trails. • Did you select the appropriate resolution? - If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the resolution to 1080p or the recommended resolution.
  • Page 22: Product Specification

    • 10-bit color is supported. • Have you installed the display driver? - Be sure to install the display driver from our web site: https://www.lg.com. Resolution • Max Resolution: 2560 x 1440 @ 60 Hz - Make sure to check if the graphics card supports function.
  • Page 23 AC/DC Adapter Power Sources • • Model: ADS-150KL-19N-3 190140E Power Rating: 19 V 7.0 A Manufacturer: Shenzhen Honor Electronic Co.,Ltd. • Power Consumption • - Operating Mode: 38 W (Typical)* Input: 100-240 V~ 50/60 Hz 2.0 A • Output: 19 V 7.37 A - Sleep Mode (Standby Mode): ≤ 0.5 W - Off Mode: ≤...
  • Page 24 Support Mode (Preset Mode, USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702 59.810 1280 x 1024...
  • Page 25 (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702 59.810 1280 x 1024...
  • Page 26 HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480p 31.5 720p 1080p 67.5 2160p 67.5...
  • Page 27 Beep Guide Menu Location Menu Location Picture - Picture Mode - Custom 3 1 1 Picture - Game Adjust - Response Time - Fast 3 3 1 2 Picture - Picture Mode - Vivid 3 1 2 Picture - Game Adjust - Response Time - Normal 3 3 1 3 Menu Location...
  • Page 28 Menu Location Menu Location Menu Location Picture - Color Adjust - Six Color - Green Hue 3 4 6 3 1 Slider General - Language - English 5 1 1 General - DisplayPort Version Picture - Color Adjust - Six Color - Green Saturation 3 4 6 4 General - Language - German 5 1 2...
  • Page 29 Supplier's Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632 E-mail lg.environmental@lge.com (27BQ70QC only) The model and serial number of the product are located on the back and on one side of the product.
  • Page 30 » If loosely connected, the poor connection may cause a fire or electric shock. Be sure to use power cords and AC adapters provided or approved by LG Electronics, Inc. » The use of non-approved products may cause a fire or electric shock.
  • Page 31 » If you continue to use without taking proper measures, electrical shock or fire can occur. If you dropped the product or the case is broken, turn off the product and unplug the power cord. » If you continue to use without taking proper measures, electrical shock or fire can occur. Contact LG Customer Service.
  • Page 32 Do not attempt to disassemble, repair or modify the product yourself. » Fire or electric shock can occur. » Contact LG Customer Service for repair. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 33 Assurez-vous d’enfoncer complètement la fiche du cordon dans l’adaptateur c.a. » Un branchement desserré pourrait causer un incendie ou une décharge électrique. Assurez-vous d’utiliser les cordons d’alimentation et adaptateurs c.a. fournis ou approuvés par LG Electronics, Inc. » L’utilisation de produits non approuvés pourrait entraîner un incendie ou une décharge électrique.
  • Page 34 Si une odeur de fumée ou toute autre odeur se dégage du moniteur ou si vous entendez un son étrange en provenance du moniteur, débranchez le cordon d’alimentation et contactez le service à la clientèle de LG. » Si vous continuez à utiliser l’appareil sans prendre de mesures appropriées, il y a un risque de décharge électrique ou d’incendie.
  • Page 35 Ne tentez pas de désassembler, de réparer ou de modifier l’appareil vous-même. » Il existe un risque d’incendie ou de décharge électrique. » Contactez le service à la clientèle de LG pour le faire réparer. Pour nettoyer l’appareil, débranchez le cordon d’alimentation et frottez doucement avec un chiffon doux pour prévenir toute éraflure.
  • Page 36 DDC(Display Data Channel) ENGLISH DEUTSCH DDC (Display Data Channel) DDC (Display Data Channel) DDC ist ein Kommunikationskanal, über DDC is a communication channel over which weiche Sie von lhrem Monitor automatisch the monitor automatically informs the host über das verbundene System (PC) und seine system (PC) about its capabilities.
  • Page 37 DDC(Display Data Channel) FRANÇAIS ITALIANO DDC (Display Data Channel) DDC (Display Data Channel) DDC est une chaine de communication par Il DDC è un canale di comunicazione attraverso le biais de laquelle le moniteur prévient il quale il monitor informa automaticamente il automatiquement le systéme central (PC) de sistema ospite (PC) circa le proprie capacità.
  • Page 38 DDC(Display Data Channel) ESPAÑOL PORTUGUÊS DDC (Canal de despliegue de DDC (Display Data Channel) información) DDC es un canal de comunicacion sobre el DDC é um canal de comunicação através cual el monitor automáticamente informa al do qual o monitor informa ao computador sistema anfitrión (PC) sobre sus capacidades.
  • Page 39 DDC(Display Data Channel) NEDERLANDS РУССКИЙ DDC (Display Data Channel) Канал обмена данных между монитором и компьютером DDC. DDC is een communicatiekanaal waarmee de DDC-канал связи, по которому монитор monitor het hostsysteem (PC) automatisch автоматически информирует компьютер о informeert over zijn mogelijkheden. своих...
  • Page 40 DDC(Display Data Channel) 日本語 한국어 DDC( 디스플레이 데이터 채널 ) DDC(ディスプレイ • データ • チャンネル) DDC 는 모니터의 기능에 관한 정보를 자동으로 호스 DDC は、 モニターがその状態をホスト • システム (P C)へ自動的に通知する通信チャンネルです。 트 시스템 (PC) 에 제공하는 통신 채널입니다 DDC protocol DDC プロトコル ①...
  • Page 41 DDC(Display Data Channel) ‫العربية‬ (‫ )قناة بيانات الشاشة‬DDC ‫ هي قناة تواصل ت ُ علم الشاشة من خاللها النظام المضيف‬DDC .‫)الكمبيوتر( تلقائيا ً حول قدراتها‬ DDC ‫بروتوكول‬ DDC2B/DDC1 ① .‫قناة تواصل أحادية االتجاه‬ 2AB/DDC2B+/DDC2Bi DDC ② .‫قناة تواصل ثنائية االتجاه‬ ‫مالحظة‬...
  • Page 42 Energy saving Design ENGLISH PORTUGUÊS Energy Saving Design Programa de economia de energia This program is designed to have computer Este programa foi elaborado com a finalidade equipment manufacturers build circuitry into de estimular os fabricantes de equipamentos their products to reduce power consumption para computadores a construírem em seus when it is not in operation.
  • Page 43 Energy saving Design DEUTSCH 한국어 Energiespar-Design 절전디자인 Dieses Programm wurde konzipiert, um 이 프로그램은 컴퓨터 장비 제조업체가 해당 제품에 die Hersteller von Computergeräten zu 회로를 내장하여 , 사용하지 않는 기간에 전력 소비를 veranlassen, Schaltungen in ihre Produkte 줄일 수 있도록 만들어졌습니다 . einzubauen, die zu einem geringeren Stromverbrauch führen, wenn das Gerät nicht 이...
  • Page 44 Energy saving Design MAGYAR BAHASA INDONESIA Energiatakarékos kialakítás Desain Hemat Energi E program célja, hogy a számítógéptartozék- Program ini dirancang agar produsen peralatan gyártók azon termékei, amelyek rendelkeznek komputer membangun sistem sirkuit ke dalam az ehhez szükséges áramkörrel, alacsony produk mereka untuk mengurangi konsumsi fogyasztással üzemeljenek akkor, amikor daya saat peralatan sedang tidak beroperasi.
  • Page 45 Energy saving Design ESPAÑOL 日本語 Diseño de ahorro de energía 省エネ設計 (省エネルギー設計、節電設計) Este programa está diseñado para que los fabricantes de equipos informáticos incorporen 本プログラムはコンピュータ機器メーカーが製造す sistemas de circuitos a sus productos con el る製品がその非使用時 ( 非動作時 ) は消費電力 fin de reducir el consumo de energía cuando を抑える回路構成を持つことを目的に策定されま...
  • Page 46 Energy saving Design NEDERLANDS ҚАЗАҚША Energiebesparend ontwerp Энергия үнемдейтін дизайн Dit programma stimuleert fabrikanten van Бұл бағдарлама компьютер жабдықтарын computerapparatuur om schakelingen in өндірушілерге жұмыс істемей тұрғанда, producten te bouwen die het stroomverbruik қуаттың тұтынылуын азайту мақсатымен verminderen als de apparatuur niet wordt өнімдеріне...
  • Page 47 Energy saving Design FRANÇAIS ΕΛΛΗΝΙΚΆ Design d’économie d’énergie Σχεδίαση εξοικονόμησης ενέργειας Ce programme est conçu pour obtenir Το πρόγραμμα αυτό έχει σχεδιαστεί ώστε οι l’installation de circuits par les fabricants κατασκευαστές εξοπλισμού ηλεκτρονικών d’équipements informatiques dans leurs υπολογιστών να δημιουργούν τη διάταξη των produits afin de réduire la consommation en κυκλωμάτων...
  • Page 48 Energy saving Design УКРАЇНСЬКА ITALIANO Programma di risparmio energetico Програма енергозбереження Ця програма має на меті стимулювати Questo programma è stato messo a punto виробників комп'ютерного обладнання affinché i produttori di computer producano до впровадження у своїх виробах засобів circuiti per i loro prodotti in grado di limitare зменшення...
  • Page 49 Energy saving Design РУССКИЙ POLSKI Функция сохранения энергии Oszczędzanie energii Эта программа разработана для создания и Ten program został stworzony, aby producenci внедрения производителями компьютерного sprzętu komputerowego mieli możliwość оборудования схем, позволяющих снизить wbudowania do swoich produktów zespołów потребление электроэнергии, когда obwodów elektrycznych redukujących pobór компьютер...
  • Page 50 Energy saving Design ‫العربية‬ 繁體中文 節能設計 ‫تصميم موفر للطاقة‬ ‫تم إعداد هذا البرنامج بحيث تتمكن شركات تصنيع أجهزة الكمبيوتر‬ 此程式用於幫助電腦設備製造廠商在他們的產 ‫من إدماج مجموعة دارات إلكترونية في منتجاتها للحد من استهالك‬ 品中建立電路,藉此降低產品處於非作業狀態 .‫الطاقة عند عدم تشغيل المنتج‬ 時的功率 消耗量。 ‫فعند استخدام هذه الشاشة مع جهاز كمبيوتر عليه برنامج الشاشة‬ 本顯示器與已安裝符合...
  • Page 51 Service DEUTSCH ENGLISH Service Wartun Bei folgenden Fehlerbedingungen ist der Unplug the monitor from the wall outlet and Netzstecker des Monitors zu ziehen und der refer servicing to qualified service personnel Kundendienst zu benachrichtigen: when : Wenn der Netzstecker beschadigt oder das The power cord or plug is damaged or Netzkabel ausgefranst ist.
  • Page 52 Service ITALIANO FRANÇAIS Manutenzione Maintenance du Moniteur Débranchez le moniteur (prise murale) Staccare il monitor dalla presa elettrica et contactez un technicien qualifié de e consultare il personale addetto alla maintenance de ce type d’équipement dans manutenzione quando: les cas suivants: Il cavo elettrico o la spina sono danneggiati Le cordon d’alimentation ou la prise est o consumati.
  • Page 53 Service ESPAÑOL PORTUGUÊS Servicio Manutenção Desconecte el monitor del tomacorriente de Desligue o monitor da tomada e procure por la pared y refiera el servicio a personal de serviço autorizado, quando: servicio calificado cuando: O cabo de força ou plugue estiver danificado El cable o enchufe de energía está...
  • Page 54 Service NEDERLANDS РУССКИЙ Onderhoud Ремонт и Обслуживание In de volgende gevallen haalt u de stekker van В нижеперечисленных случаях отключите de monitor uit het stopcontact en roept u de монитор от сети и обратитесь в пункты hulp in van een gekwalificeerde technicus: сервисного...
  • Page 55 Service ‫العربية‬ ‫الخدمة‬ Maintenance Tel :‫افصل الشاشة عن مأخذ الحائط واتصل بفريق خدمة محترف‬ Dammam 8339561 . ٍ ‫إن سلك الطاقة أو المقبس تالف أو بال‬ • .‫انسكب سائل على الشاشة‬ • Khobar 8942694 .‫تعرضت الشاشة للمطر أو الماء‬ • ‫ال...
  • Page 56 Service 日本語 한국어 保守および修理 수리 次のような保守になったら、モニタ-の電源プラグ 다음과 같은 경우에는 벽면 콘센트에서 모니터의 플러그 をコンセントから抜き、修理センターにご相談くださ 를 뺀 다음 자격이 있는 수리 담당자에게 의뢰하십시오 . い。 전원코드 또는 플러그가 손상되거나 낡았습니다 . 電源コードまたはプラグが破損した、または擦り 액체가 엎질러져서 모니터에 흘러들어갔습니다 . 모니터가 비 또는 물에 노출되었습니다 . 切れた。...
  • Page 57 REGULATORY INFORMATION Please read this manual carefully before operating your set and retain it for future reference. P/No. : SAC37093516 (2108-REV00) Copyright ⓒ 2021 LG Electronics Inc. All Rights Reserved. www.lg.com...
  • Page 58 Deutsch ENVIRONMENTAL PRESERVATION Informationen zur Erhaltung der Umwelt Im Jahr 1994 verkündete LGE die ‘LG Declaration for a Cleaner Environment’ English (LG Erklärung für eine sauberere Umwelt). Seitdem dient dieses Ideal als führendes Prinzip des Unternehmens. Diese Erklärung war die Basis für die Durchführung von umweltfreundlichen Aktivitäten, wobei wirtschaftliche,...
  • Page 59 “verte” , rendez visite à notre site : http://www.lg.com/global/sustainability/environment/take-back-recycling.jsp Noi della LG impostiamo la nostra visione e le nostre politiche a favore di un mondo più pulito ponendo la questione dell’ambiente dal punto di vista globale come una mansione rivolta al miglioramento della nostra azienda. Vi invitiamo a visitare il nostro sito internet per ulteriori informazioni sulla nostra politica “verde”...
  • Page 60 A LGE. anunciou a ‘LG Declaration for a Cleaner Environment’ (Declaração da y este ideal ha servido para guiar nuestros principios empresariales desde LG para um ambiente mais limpo) em 1994 e esse ideal tem servido desde entonces. La Declaración es la base que nos ha permitido llevar a cabo tareas então como um princípio administrativo de orientação.
  • Page 61 В 1994 году корпорация LGE опубликовала «Декларацию LG по охране окружающей среды», которая с тех пор служит основным принципом LGE. publiceerde in 1994 de ‘LG Declaration for a Cleaner Environment’ (de управления. На основе этой декларации мы смогли предпринять LG-verklaring met betrekking tot een schoner milieu). Deze verklaring en действия, обеспечивающие...
  • Page 62 본사의 재활용 프로그램에 대한 자세한 정보는 각 지역의 LG공급업체나 LG 기업 대표부에 문의하시기 바랍니다. Disposal of your appliance LG전자는 기업 개선 정책의 하나로 지구 환경 문제를 채택함으로써 보다 나은 The symbol indicating separate collection for 환경을 만들어 나가기 위한 비전과 정책을 수립했습니다. 본사의 친환경 정책에...
  • Page 63 SYMBOLS Language Refers to alternating Refers to direct Refers to class II Refer to “ON” Refers to dangerous English Refers to stand-by. current(AC). current(DC). equipment. (power). voltage. Gäller växelström Gäller utrustning i Svenska Gäller likström (DC). Gäller stand-by. Gäller ”PÅ” (ström). Gäller farlig spänning.
  • Page 64 Language “AÇIK” Alternatif Doğru Sınıf II Tehlikeli Beklemeyi (güç) Türkçe akımı (AC) akımı (DC) donanımı voltajı niteler. durumunu niteler. niteler. niteler. niteler. niteler. Se refiere a la Se refiere a Español Se refiere a la Se refiere a los Se refiere al modo Se refiere a voltaje corriente continua "ENCENDIDO"...

This manual is also suitable for:

27mq70qc27bq70qc
