BEFORE YOU BEGIN
HOW TO USE THESE INSTRUCTIONS
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
INSTALLER HAZARD NOTIFICATION
WARNING: Risk of injury or water damage.
Contents of reservoir under pressure can cause
severe injury. Do not open or service before reading
installation instructions or service instructions. Turn
off water supply and flush unit to release pressure
before attempting any service.
CAUTION: Risk of product damage. Do not use
any oils or lubricants on the Pressure Lite system.
CAUTION: Risk of product damage. The fittings
in this toilet require no adjustment. The fittings in this
toilet are preset. Any adjustment or modifications of
the product are not normal usage and void the
warranty.
WARNING: Risk of injury or product damage.
Handle vitreous china products very carefully.
Vitreous china can break and chip if you overtighten
bolts and nuts.
NOTICE: If the new toilet is not installed immediately,
temporarily stuff a rag in the closet flange. Follow all
local plumbing and electrical codes.
PRODUCT REQUIREMENTS
S
The supply stop must be 2-5/8" above floor-line and
7-3/4" left of the closet flange centerline.
S
Since all toilets do not have the same supply
rough-in, you may have to change the location of
the supply stop to install this toilet.
S
Closet flange must be 12" on-center from wall.
S
Seat post holes are on 5-1/2" centers.
S
For most satisfactory operation, the toilet requires
20 p.s.i. static pressure at the supply stop.
Maximum static pressure is not to exceed 80 p.s.i.
EA
113363-2- (9532)
R
1 1
RIALTO PRESSURE LITE
VITREOUS CHINA
SIPHON JET TOILET
All information in this manual is based on the latest
product information available at the time of
publication. Kohler Co. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information – please leave for the consumer.
PRODUCT PROPERTIES
S
Vitreous china siphon jet toilet.
S
Pressure Lite system.
S
Water depth from rim is 5-3/4".
S
2-1/4" passageway.
S
For roughing-in and overall dimensions, See
Fig. #3 .
S
Fixture dimensions are nominal and conform to
tolerances by
(A112.19.2).
ORDERING INFORMATION
Toilet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When specified:
3/8" supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NOTE: For service parts ordering information, see separate
Service Parts document enclosed with product.
ANSI/ASME standards
K-3404
K-7637
21401
Copyright E1995 Kohler Co.
