IRIS
®
3" DOWNLIGHT ELEMENTS
Shown with white oculus
3" ADJUSTABLE ACCENT ELEMENTS
926
COOPER LIGHTING
E 3 M R
5 0 ° C u t o f f R e f l e c t o r
Add Cone Color and Flange style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E 3 M R B B
5 0 ° C u t o f f B a f f l e
Add Baffle Finish
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E 3 D N P I N
1 1 / 4 " D o w n l i g h t P i n h o l e
Add Flange Style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 1 1/4" (32mm)
E 3 A A
A n g l e C u t R e f l e c t o r - A d j u s t s T o 4 5 °
Add Cone Color and Flange style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E 3 A A 2 0
A n g l e C u t R e f l e c t o r - A d j u s t s T o 2 0 °
Add Cone Color and Flange style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E 3 M R A A B B
A n g l e C u t B a f f l e - A d j u s t s T o 4 5 °
Add Baffle Finish
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E 3 S L O T
S l o t C u t R e f l e c t o r - A d j u s t s T o 4 5 °
Add Cone Color and Flange style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E 3 P I N
1 1 / 4 " A d j u s t a b l e P i n h o l e - A d j u s t s T o 4 5 °
Add Flange Style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 1 1/4" (32mm)
E 3 P I N L A R G E
1 3 / 4 " A d j u s t a b l e P i n h o l e - A d j u s t s T o 4 5 °
Add Flange Style
Lamp:
P3MR, RPN3MR:
P3MR REMOTE, PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 1 3/4" (32mm)
E 3 P I N C L O S E T
1 1 / 4 " A d j u s t a b l e P i n h o l e w / L e n s - A d j u s t s T o 4 5 °
Add Flange Style
Lamp:
P3MR REMOTE, P3MR, RPN3MR:
PN3MR, PN3MR REMOTE:
Dimensions:
OD: 5 1/8" (130mm) Aperture: 1 3/4" (32mm)
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
50W MR16
71W MR16
