Summary of Contents for Marmitek IPTV PLC 650
- Page 1 IPTV PLC 650 ™ IPTV PLC 650 USER MANUAL 20608/ 20131201 • IPTV PLC 650 ™ ALL RIGHTS RESERVED MARMITEK ©...
- Page 2 © MARMITEK...
-
Page 3: Safety Warnings
1. INTRODUCTION Congratulations on your purchase of the IPTV PLC 650™. Use your existing power network to turn every wall socket in your home (for example those near your AV cabinet) into a network connection for your home network (IP/Internet). -
Page 4: Operation
With built-in filter to prevent interference by your AV equipment and keep your network clean. Status LED: visual display on the Powerline adapters, including signal quality, making set-up and use easy, without any IP or networking knowledge. © MARMITEK... -
Page 5: Product Features
Off: no device is connected to the adapter or it is disabled. 4. Security button : Button to configure your Powerline network's security (see section 6). 5. Reset button: Press this button for 3 seconds with a pointed object to restore the adapter to factory settings. IPTV PLC 650™... -
Page 6: Installation
Please note: The IPTV PLC 650 adapters automatically go into standby mode if no LAN/Ethernet signal is detected on the Ethernet port (1) for 60 seconds. - Page 7 Security button on both adapters is 120 seconds. The Powerline adapter is added to your network and can be used. Repeat steps 1 through 3 for each Powerline adapter you want to add to your network. IPTV PLC 650™...
-
Page 8: Frequently Asked Questions
Try to avoid potential noise sources such as phone chargers, halogen lights, energy saving lamps and vacuum cleaners near the Powerline adapters, as far as possible, as these may seriously weaken the signal. Have any questions that are not answered here? Then please check out www.marmitek.com. © MARMITEK... -
Page 9: Technical Information
8. TECHNICAL INFORMATION IPTV PLC 650™ Adapter Power Network: 100 ~ 240VAC @ 50/60Hz Max. load of power outlet:16A Range: max. 300 metres with Smartlink max. 200 metres without SmartLink Network connection: 10/100/1000Mbps (Gigabit Ethernet) Status indicator LED: Power/Standby, Signal Quality, LAN/Ethernet... -
Page 10: Optionally Available
9. OPTIONALLY AVAILABLE Additional IPTV PLC 650™ adapter (art. no. 08208/08209) Create additional Powerline connections (IP/Internet) at several places in your home (living room, bedroom, home office, loft) through your power network. You may connect up to 64 Powerline adapters to your network. - Page 11 Copyrights Marmitek is a trademark of Pattitude B.V. IPTV PLC 650™ is a trademark of Marmitek B.V. All rights reserved. Copyright and all other proprietary rights in the content (including but not limited to model numbers, software, audio, video, text and photographs) rests with Marmitek B.V.
-
Page 12: Declaration Of Conformity
à la consommation d’électricité hors charge et au rendement moyen en mode actif des sources d’alimentation externs Marmitek BV declara que este IPTV PLC 650™ cumple con las exigencias esenciales y con las demás reglas relevantes de la directriz:... - Page 13 Con ciò, Marmitek BV, dichiara che il IPTV PLC 650™ è conforme ai requisiti essenziali ed alter disposizioni relative alla Direttiva: Direttiva 2004/108/ce del parlamento europeo e del consiglio del 15 dicembre 2004 concernente il ravvicinamento delle legislazioni degli Stati membri relative alla compatibilità...
- Page 14 © MARMITEK...
- Page 15 IPTV PLC 650™...
