Hughes 9211 and 9202M
User Guide
3500988-0001
Revision D
12 October 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hughes 9211 and is the answer not in the manual?

Questions and answers

Related Manuals for EchoStar Hughes 9211

Summary of Contents for EchoStar Hughes 9211

  • Page 1 Hughes 9211 and 9202M User Guide 3500988-0001 Revision D 12 October 2017...
  • Page 2 Copyright © 2014 - 2017 Hughes Network Systems, LLC All rights reserved. This publication and its contents are proprietary to Hughes Network Systems, LLC. No part of this publication may be reproduced in any form or by any means without the written permission of Hughes Network Systems, LLC, 11717 Exploration Lane, Germantown, Maryland 20876.

  • Page 3: Table Of Contents

    Contents Messages concerning personal injury ...................... vii Messages concerning property damage ....................vii Introduction ..........................1 Overview ..............................1 About this User Guide ..........................2 9211 Package Contents ..........................3 9202M Package Contents .......................... 5 Minimum System Requirements for Laptop/PC ..................5 Getting Started ............................
  • Page 4 Power Icon ............................24 GPS Icon .............................. 24 Satellite Icons ............................25 Wireless LAN Icon ..........................25 Wireless LAN Lock Icon ........................25 Globe ICON ............................25 SIM PIN entry ............................26 Multiple Users ............................26 Information Messages ..........................26 Using the Web UI ........................
  • Page 5 Troubleshooting ........................66 Technology Overview ......................69 GPS ................................69 Obtaining a GPS Fix ..........................69 GPS and BGAN Registration ....................... 70 Dialing and Numbering ........................70 PDP Context............................. 70 Technical Specifications ......................72 9211 EU Declaration of Conformity ..................73 FCC Compliance ............................
  • Page 6 Tables Table 1: Status Messages ......................... 21 Table 2: LCD Menu Structure ......................... 23 Table 3: Quick-text Status Message Descriptions ................... 27  Tables 3500988-0001 Revision D...

  • Page 7: Messages Concerning Personal Injury

    Understanding safety alert messages Safety alert messages call attention to potential safety hazards and tell you how to avoid them. These messages are identified by the signal words DANGER, WARNING, CAUTION, or NOTICE, as illustrated below. To avoid possible property damage, personal injury or in some cases possible death;...
  • Page 8 Safety symbols The generic safety alert symbol calls attention to a potential personal injury hazard. It appears next to the DANGER, WARNING, and CAUTION signal words as part of the signal word label. Other symbols may appear next to DANGER, WARNING, or CAUTION to indicate a specific type of hazard (for example, fire or electric shock).
  • Page 9 Changes or modifications to the Terminal not expressly approved by Hughes Network Systems could void your authority to operate this equipment. Only use a soft damp cloth to clean the Terminal. To avoid impaired Terminal performance, please ensure the unit’s antenna is not damaged or covered with foreign material like paint or labeling.
  • Page 10 Pacemakers The various brands and models of cardiac pacemakers available exhibit a wide range of immunity levels to radio signals. Therefore, people who wear a cardiac pacemaker and who want to use a Satellite Terminal should seek the advice of their cardiologist. If, as a pacemaker user, you are still concerned about interaction with the Satellite Terminal, we suggest you follow these guidelines:...

  • Page 11: Introduction

    Introduction Overview The Hughes 9211 and 9202M Land Portable Terminals provide reliable satellite connectivity over the Inmarsat BGAN satellite network.  The Hughes 9211 comes in a small, portable package, and it allows the user to take advantage of the High- Data-Rate (HDR) bearers in the Inmarsat network.

  • Page 12: About This User Guide

    It is focused on the specific information needed to operate the Hughes 9211 and 9202M Land Portable Terminals. For information on using LaunchPad, please refer to the Inmarsat website where a copy of the ‘Inmarsat LaunchPad Guide’...

  • Page 13: 9211 Package Contents

    9211 Package Contents When you unpack the Hughes 9211 Land Portable Terminal Kit package, you will find the following:  Upper Level o AC/DC power adapter o US, EU and UK power cords o Ethernet cable o Lithium Ion battery ...
  • Page 14 Do not tear the plastic cover on the lower level where the 9211 terminal is housed. Lift the entire lower level up and unfold the side flaps to remove the 9211 terminal. This packaging can be re-used for shipping to other customers if needed. Your Service Provider will supply you with a Subscriber Identification Module (SIM) and its PIN, and Satellite Terminal configuration instructions –...

  • Page 15: 9202M Package Contents

     3.1KHz Audio/Fax 9202M Package Contents When you unpack the Hughes 9202M Land Portable Terminal Kit package, you will find the following:  Hughes 9202M terminal  AC/DC power adapter  US, EU and UK power cords  Ethernet cable ...

  • Page 16: Information For Maintenance

    Information for Maintenance In the event that a Hughes terminal develops a problem, please follow the instructions below. For Users: Please contact the company that you purchased the terminal from so that they can request an RMA from Hughes for your terminal. For Distribution Providers: Should a Hughes terminal need to be returned for repair, an RMA will be required.

  • Page 17: Using The Terminal

    Service Provider in the battery compartment. The SIM card icon on the casting shows the proper way to install the SIM card. Hughes 9211 Hughes 9202M Install the battery in the terminal unit and then fully charge the battery using the supplied AC/DC converter.

  • Page 18: Lcd Quick Start

    LCD Quick Start Press the power button for at least two (2) seconds in order to Power On the terminal. The LCD will display “Hughes 9211” or “Hughes 9202” for about 30 seconds while the terminal is booting up. Since the terminal is a portable device, you must first obtain a GPS fix and then point the terminal to the Inmarsat satellite before setting up a data connection with the network.

  • Page 19: Web Ui Quick Start

    Once the unit has registered and is Circuit Switched (CS) and Packet Switched (PS) attached (“Ready” on the LCD), you can create a data connection from the menu by first pressing the Accept button to enter the menu system, then by scrolling through the various selections and by pressing the Accept button when the LCD says Connection.
  • Page 20  Once you are registered and CS and PS Attached, you can then select the Quality of Service (QoS) for your data connection by choosing either the Standard or Streaming connection.  The screenshot below shows a Full HDR asymmetric data session (9211 only) that has been selected and setup with the network.
  • Page 21  Using the Terminal 3500988-0001 Revision D...

  • Page 22: Connecting The Terminal To The Computer

     WLAN Power: The default is off, which disables the WLAN feature.  SSID (network name): The default is “Hughes 9211” or “Hughes 9202”, but you can change it to whatever you want.  Channel Number: This controls the radio channel number (1 through 11) used by the access point.

  • Page 23: Wlan Security

    Once the WLAN is “Enabled” and configured, any device with a WLAN interface can detect the UT’s WLAN SSID, and connect to it automatically. In PPPoE mode, you can connect to the Web UI via WLAN, but you can’t activate PDP contexts or send data over the spacelink via WLAN –...

  • Page 24: Connecting By Rj11

     MAC Filtering: For added security, check the box to “Enable” MAC Filtering. You can define up to 10 MAC addresses that are allowed to connect to your WLAN. To determine the MAC address of a PC, go to a DOS prompt and type ipconfig/all.

  • Page 25: Dialing And Numbering

    Dialing and Numbering Dialing - As the BGAN numbering system follows the same pattern as the normal telephone system, dialing is carried out in exactly the same manner as making a normal telephone call. The subscriber number is used with the same international and area codes as any other telephone network.

  • Page 26: Coverage Map

    Coverage Map The Inmarsat BGAN service is operated with 4 satellites as shown below. The terminal will perform best in areas where the elevation (or “look”) angle is 20 degrees above horizontal or higher, but the terminal can operate down to 5 degrees of look angle.

  • Page 27: Operation In The Russian Federation

    Operation in the Russian Federation In the Territory and National Waters of the Russian Federation covered by the three Regional I-4 MEAS Beams shown below, end-users must select MEAS rather than Alphasat (EMEA) or I-4 Asia Pacific (APAC), even if one of these satellites is closer.

  • Page 28: Using The Lcd And Keypad

    Using the LCD and Keypad LCD Display and Keypad The terminal has an LCD display that provides status information about the terminal. It has a four button keypad that allows you to control the operational features of the terminal without the need of a PC or a browser. It also includes control of an audible pointing aid integrated into the terminal.

  • Page 29: Lcd Status Display

    A “long press” is any keystroke that is two seconds or greater. An “extra long press” of more than five seconds of the power button will cause a hardware enforced power down. Any button press starts or restarts the (configurable) backlight time period, even if it has no function in the current context.

  • Page 30: Exit Pointing And Registering With The Network

    Exit Pointing and Registering with the network Once you have accurately pointed the unit to the satellite, exit pointing by a long press of the Back/Cancel button. This will cause the unit to attempt to register with the BGAN network (note: if audible pointing tones were enabled during pointing, they will automatically turn off once you attempt to register).

  • Page 31: Status Messages

    Status messages The upper line of the LCD is used for status messages and menu items. Status messages are listed below. Display Description HUGHES 9211 On screen during power up HUGHES 9202 Initializing Powering Off Displayed while the UT is powering down Too Hot Unit is too hot;...

  • Page 32: Menu Navigation

    Examples: Menu Navigation From the status display, a short press of the Accept button takes the display to menu mode and displays the first of a circular list of menu items. The menu structure is shown in Table 2 below. Use the Scroll button to scroll between options and the Accept button to select options.
  • Page 33 Level 1 Level 2 Level 3 Level 4 Comment Connection Starts display with the Standard current setting. 32 Kbps 64 Kbps 128 Kbps X-Stream and HDR for the X-Stream 9211 only; 256 Kbps 1/2 HDR possible with C10 external antenna Disconnect Information # New Msgs or...

  • Page 34: Display Icons

    Display Icons Battery Icon The battery icon displays the estimated life of the battery while under battery power. The battery icon also displays the charging state while under external power. Three segments: 75% to full Two segments: 50% to 74% One segment: 25% to 49% Zero segments: 10% to 24% Zero segments, flashing: 0% to 9%...

  • Page 35: Satellite Icons

    Satellite Icons The satellite icons, located next to the GPS icon, indicate the status of the GPS receiver in the terminal and the number of visible satellites. The icons are off when the GPS receiver is off. The icons are active when the GPS receiver is on, either flashing or steady state.

  • Page 36: Sim Pin Entry

    SIM PIN entry If the SIM PIN is enabled, the PIN must be entered before the UT can be used. This can be entered via the Web UI, LaunchPad, or the front-panel keypad. The upper row of the LCD displays “Enter PIN” while the lower row is used for PIN entry.
  • Page 37 When setting up contexts from the menu, these messages are possible: MustDeact1st There is already a context up for this TE, deactivate it before setting up a new one Deact;TryAgn UT is in the process of deactivating a context, try setting up the context a short time later NotPSAttachd UT is currently not PS attached, context setup is not possible...

  • Page 38: Using The Web Ui

    Using the Web UI Accessing the Web UI The UT includes its own internal Web User Interface (Web UI). To access the Web UI, open your favorite Web Browser and type in the internal IP address of the UT, e.g. http://192.168.128.100.

  • Page 39: Home Page

    Home page The Home “tab”/page shows the current terminal status and allows you to setup your initial data connection. On the left side of the page is the Status bar. These items are updated automatically when the status of any item changes. 1.
  • Page 40 connections use the drop down box to select the data rate for the stream. Connect using APN field allows you to control the APN used for the connection. Details show the status of the connection for this TE. Visible Satellites shows the satellites visible from your current location and the pointing information.

  • Page 41: Connections

    Connections Along the top of all Web UI pages are “tabs”/icons representing the categories of available sub-pages. The Connections icon has three main configuration areas (sub-pages) to select from: Manage Contexts, Automatic Contexts, and Manage APNs. The following section reviews each of these pages. ...

  • Page 42: Manage Contexts

    Manage Contexts The Manage Contexts page under the Connections icon allows the user to setup and configure PDP contexts (data connections) for any TE that is connected to the UT. It also shows you all current Active Connections. Open a New Connection field - To open a new connection, select the row and enter the required data: Owner –...
  • Page 43 APN - The APN is read from the SIM card, but if you have other APNs defined (refer to the Manage APNs page), you can use the down arrow to select a different APN. Username/Password: Some Service Providers require a username and password to be used when setting up a connection.

  • Page 44: Automatic Contexts

    Automatic Contexts This web page allows you to use Automatic Context Activation (ACA) for multiple devices. (The M2M page Always on context can be used if you only require a single context.) The ACA page is not available in NAPT or PPPoE modes. This web page allows you to use Automatic Context Activation (ACA) in two different ways;...
  • Page 45 o “Data”: Select Data if you only want the context to be activated when the TE attempts to send data to the satellite link When using “Data” ACA, if the context is ever deactivated, it will be reactivated when more data is sent. The “On”...
  • Page 46 DHCP Automatic Contexts: This option allows you to set up the UT for dynamic standard ACA. This means that any device connected to the UT via DHCP, whether wired or wirelessly, will automatically receive a standard context. Note: Streaming contexts are not supported with DHCP ACA. For Streaming contexts, you must use Static ACA, described above.

  • Page 47: Manage Apns

    Manage APNs Some SIM cards are provisioned with multiple APNs, so you can use this page to pre-configure those additional APNs if needed. Once an APN is defined, you can select it from drop down lists on other pages without having to put in the username and password every time.
  • Page 48 Add an APN field – Use this field to add an additional APN that you want to use, or to edit an existing APN. For adding a new APN, type in the new APN and username (if required) then select Add New APN. If the APN requires a password, select the “APN Requires Password”...
  • Page 49 and you can then edit it. Click the Save Changes button to save your changes. Make Default. If you wish to change the default APN, select an entry in the list of Defined APNs and then click Make Default. This APN will now be the default APN on the other context control pages.

  • Page 50: Sms

    You can manage SMS text messages from the SMS pages. You must have a valid Service Center number configured in order to send SMS messages – see the SMS Settings Page. Send/Receive The Send/Receive page allows you to view your Inbox messages and Compose a new message.

  • Page 51: Saved Drafts

    Saved Drafts The Saved Drafts page allows you to view previously saved messages. After editing a message you can resave (Save) or send the message (Send). You can also compose a message from this page.  Using the Web UI 3500988-0001 Revision D...

  • Page 52: Sent Messages

    Sent Messages The Sent Messages page allows you to view previously sent messages. Again, you may need to periodically delete messages to prevent the SIM from filling up. You can also compose a new message from this page.  Using the Web UI 3500988-0001 Revision D...

  • Page 53: Sms Settings

    SMS Settings On the SMS Settings page you can configure the default settings for messages. You must have a valid Service Center number configured in order to send SMS messages. The default Service Center number is +870772001799. In the Remote SMS Feature section you can enable the unit to receive and act on special remote control SMS messages.

  • Page 54: Settings Page

    Settings page General Setup This page allows the user to configure various parameters of the UT. A description of each item follows: Terminal Startup – by default, “Bypass Antenna pointing” is not selected, but if the terminal is permanently mounted, you can select this option to bypass antenna pointing on subsequent power-ups.

  • Page 55: Ip Address/Dhcp Settings

    Emergency Call Numbers: Allows the user to add the emergency call number that is applicable in the part of the world where the terminal is being used, if it is not already defined. IP Address/DHCP Settings Terminal Local IP Address: This section allows the user to change the local IP address of the terminal from the default 192.168.128.100 IP address.

  • Page 56: Nat Mode

    Subnet Mask Range: (release 6.0.0.5) only used in PPPoE mode. If two BGAN terminals are connected to the NSD, set to 255.255.255.128 Default route IP address: (release 6.0.0.5) only used in PPPoE mode. Use with the NSD when the TE local subnet is different from the UT subnet.

  • Page 57: Relay Mode

    Relay Mode In Relay mode, the UT will supply the global IP address to the TE when the context is established. Relay mode is a single user mode, as it only supports a single connected TE. In Relay mode, DHCP is required to provide the global IP address to the TE.
  • Page 58 With the NSD you typically set the UT IP address to 192.168.0.1 on the IP settings page. If two BGAN terminals are connected to the NSD, set the subnet mask to 255.255.255.128 on both UTs and set the IP address of the second UT to 192.168.0.129. If the TEs use a subnet other than the directly connected interface range, configure a default route on the IP Settings page so that the WebUI can be accessed.

  • Page 59: Port Forwarding Page

    Port Forwarding Page The Port Forwarding page is only available in NAPT mode. It includes:  DMZ – if enabled, all packets received from the space link that are not routed to other addresses will be forwarded to the DMZ host address. ...

  • Page 60: Wireless Lan

    Enable Wireless LAN Interface: Turns the Wireless LAN interface on/off. The default is off (unchecked). Network Name (SSID): The default is “Hughes 9211” or “Hughes 9202”, but you can change it to whatever you want. You can “hide”/prevent the SSID broadcast on the WLAN Security page Network Region: There is only one region for all countries.

  • Page 61: Wireless Lan Security

    Network Channel: This controls the radio channel number (1 through 11) used by the access point. To meet FCC regulations, channels 12 to 14 are not supported. If performance issues occur over the WLAN interface, changing the Channel may help. Wireless LAN Security This page allows the user to configure WPA or WPA2 Security for use when the terminal is communicating wirelessly to TEs.
  • Page 62 MAC Address Filtering Check the box to Enable MAC Address Filtering If any TE is already connected to the terminal wirelessly, the MAC address of that TE will be detected and show up in the Add a Detected Device field. To add the detected MAC address, click on the address to highlight it and then click Add.

  • Page 63: Telephony

    Telephony Telephony Settings: Analog Power Savings: This field turns off the 48V POTS supply voltage between calls in order to save power. If you do not get a dial tone a few seconds after you take your analog handset off hook, try changing this field to “Disable (Always on)”.

  • Page 64: Security

    To receive incoming calls on line 1, change the Route incoming 3.1KHz/fax calls parameter on the Telephony Settings page to “RJ14 Line 1” using the drop down menu. General Telephony Settings: Call Progress Tones: Two options are provided for call progress tones.
  • Page 65 entered before any settings can be changed. See screenshots below. The Enter Administrator Password pop down screen appears the first time the user tries to edit a parameter if the Administrator password is enabled.  Using the Web UI 3500988-0001 Revision D...

  • Page 66: Features

    Features You can enable special features from this page if there are any available. SMS Remote Management is “Active” by default (and cannot be deactivated). It allows the unit to receive and act on special remote control SMS messages. It is fully compatible with Remote terminal Manager (RTM) and supports over-air upgrades.

  • Page 67: M2M Page

    M2M Page New in release 6.0.0.4, the M2M page includes the following configurable parameters: Ping Configuration:  Context Watchdog - On/Off  Primary Ping Address  Secondary Ping Address  Tertiary Ping Address  Time between Pings  Ping required - Yes/No. If set to “No”, the system will not try to ping on timer expiration if data was transmitted within the watchdog period.
  • Page 68  Always on static IP address. If the TE has a known static IP address or never ARPs, enter this address. Alternatively, leave the IP address blank (0.0.0.0) and the UT will set up a context for the first device it detects through ARP during startup.

  • Page 69: Usage Page

    Usage Page This web page provides an estimate of the amount of Packet Switched data that was sent and received, along with time spent on streaming connections and CS calls. The data is broken up into two types: Trip Usage Statistics: The trip counter is similar to the trip odometer on your vehicle.

  • Page 70: Support Page

    Support Page This web page allows you to display technical and support information about the terminal and retrieve logs.  Using the Web UI 3500988-0001 Revision D...

  • Page 71: Support And Information

    Support and Information Terminal Information Model: this displays the UT model number: 9211 or 9202M. Class: this indicates the UT Class. IMEI: This displays the IMEI (serial) number of the Software Version: This displays the current version of software that is running on the UT. SIM Information IMSI: This displays the IMSI number of the SIM card in the UT.
  • Page 72 Downloading of the terminal log files uses FTP to retrieve the files from the UT, which can be blocked by some security software such as McAfee. If you encounter problems, check your PC security settings. When extracting files, clear the browser cache on the computer between each download or the browser may use a cached copy rather than downloading the latest version of the file.

  • Page 73: Operation With Tracking Antenna

    Operation with Tracking Antenna Overview The 9211 and 9202M can be used with a Class 10 or 11 external antenna for use on the move. The unit should be connected to a DC supply capable of at least 50W. The internal battery can only operate the external antenna for about an hour.

  • Page 74: Web Ui Changes

    Web UI Changes The Web UI supports external antenna operation:  The lower part of the status bar on the left of the Home page provides information about the antenna.  The Support page shows the UT Class: Class 1 (9211) or 2 (9202M) with the internal antenna, or Class 10 or 11 when operating with an external tracking antenna.

  • Page 75: C10D Antenna Kit For 9211 And 9202M: 3501057-0001

    C10D Antenna Kit for 9211 and 9202M: 3501057-0001 C10 antenna kit includes: 1504876-0001 9504855-0002 3501053-0001 9505964-0001 C10 antenna mag mount set 10m RF cable RF pigtail C11D Antenna Kit for 9211 and 9202M: 3501058-0001 C11 antenna kit includes: 1504875-0001 3501152-0001 3501053-0001 9505964-0001 C11 antenna...

  • Page 76: Troubleshooting

    Troubleshooting Problem Possible Cause Possible Solution Terminal will not turn on Battery not connected properly Check battery is correctly installed Connect AC/DC adapter to Battery not charged charge the battery Cannot get SIM card to lock SIM is not correctly oriented for insertion Ensure the SIM is pressed into position firmly into the SIM slot...
  • Page 77 Problem Possible Cause Possible Solution Handset does not trigger the terminal’s off Disable “analog power Analog handset has no dial tone hook detection circuitry savings” on the Telephony Settings page. None of the above solutions Terminal may have a hardware or software Remove power.
  • Page 78 PDP Context Activation Errors CME error CME Error Text on LCD display or Possible reason number Web UI Problem in PDP context request Invalid index No network service Could be poor signal or signal blockage, or network problem. Implicitly detached (#10) Check attach and registration status.

  • Page 79: Technology Overview

    Technology Overview The Global Positioning System (GPS) uses 24 orbital satellites to determine the position of the Terminal anywhere on the globe. Obtaining a GPS Fix In normal operation, a GPS receiver, such as that built in to the terminal, needs to be able to receive signals from at least four satellites so that it can then calculate a latitude, a longitude and an altitude –...

  • Page 80: Gps And Bgan Registration

    GPS and BGAN Registration BGAN uses the accurate position and timing information obtained from GPS to help ensure efficient registration of a BGAN Terminal with the BGAN network. Dialing and Numbering Dialing - As the BGAN numbering system follows the same pattern as the normal telephone system, dialing is carried out in exactly the same manner as making a normal telephone call.
  • Page 81 3. On receiving the Activate PDP Context message, the Core Network checks the user's subscription record to establish whether the request is valid. If the request is valid, a virtual connection is established between the Terminal and the Core Network, and data transfer can then take place between the Terminal and the external data network, within the scope of the current PDP Context.

  • Page 82: Technical Specifications

    Technical Specifications 1626.5 – 1660.5 MHz and 1668 – 1675 MHz Satellite TX Frequency 1518 – 1559 MHz Satellite RX Frequency 1574.42 – 1576.42 MHz GPS Frequency Continuous transmit on HDR stream Up to 2 hours Continuous receive Up to 4 hours Standby Time Up to 36 hours 9211 Weight...

  • Page 83: 9211 Eu Declaration Of Conformity

    9211 EU Declaration of Conformity Hughes Network Systems, LLC 9605 Scranton Road, Suite 500, San Diego, CA 92121, USA declare under our sole responsibility that the product Model 9211 Land Portable Satellite Terminal to which this declaration relates, is in conformity with the following standards and/or other normative documents.

  • Page 84: Fcc Compliance

    FCC Compliance  This device conforms to the FCC rules. Any changes or modifications to Hughes Network Systems’ equipment, not expressly approved by Hughes Network Systems, could void the user's authority to operate the equipment.  To comply with FCC RF exposure requirements, this device must be operated with a minimum separation distance of one meter from the front of the satellite terminal’s antenna to a person's body.

  • Page 85: Eu Rohs-2 (Restriction Of Hazardous Substances) Directive

    EU RoHS-2 (Restriction of Hazardous Substances) Directive The European Union (EU) Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU restrict the use of certain hazardous substances in electrical and electronic equipment. Unless otherwise noted, all products, assemblies, and sub- assemblies manufactured by Hughes and its sub-contractors are compliant with this directive.

  • Page 86: Glossary

    Glossary APN: An Access Point Name (APN) provides access to an external network. By default, the SIM Card in your terminal is configured with the APN of your Service Provider. You may want to configure further APNs if you have arranged with your Service Provider to use more than one SIM Card.
  • Page 87 HDR: High Data Rate. The HDR streaming options in the 9211 use higher modulation techniques to achieve higher throughput in the uplink. They are asymmetric services and the downlink is a regular 64kbps stream. These services are optimized for applications requiring high speed transmission, such as real-time video.
  • Page 88 Flow Template allows multiple PDP Contexts to be associated with the same PDP address. UT (User Terminal): The user terminal is the BGAN modem device, i.e. the Hughes 9211 or 9202M. SIM Card: Your BGAN Service Provider supplies you with a Universal Mobile Telecommunications System Subscriber SIM (SIM) Card.

  • Page 89: Application Note - Phone/Fax

    Application Note – Phone/Fax Line 1 Telephone 2 line splitter Hughes 9211 Line 2 or 9202M Fax/Modem 1. The UT RJ14 port allows the connection of both a telephone and a fax or modem at the same time (BGAN circuit switched network restrictions mandate that only one is in use at any given time).
  • Page 90 Hughes suggests one of the following splitters for applications requiring both voice and fax/modem. No splitter is needed when accessing the RJ11 connector for voice services only. Two line splitter “70-489” from Calradstore http://store.calradstore.com/ Omnicron Electronics MTJ-S2 http://www.omnicronelectronics.com/digital/mtj-s2.htm  Appendices 3500988-0001 Revision D...

  • Page 91: Application Note - Battery

    Application Note – Battery The UT battery is a high capacity lithium-ion battery pack. When using the 9211-HDR terminal in extremely hot environments with an HDR PDP context active, you may receive a “Battery Too Hot” error message after about an hour of usage. To get rid of this error, you can connect an external power source.

  • Page 92: Application Note - Battery Safety

    (20 C +/- 5 Charging a. Only charge batteries with a Hughes 9211 or 9202M b. The Hughes 9211/9202M charges with a constant- voltage, constant current battery charger circuit with the following parameters: ...

  • Page 93: Disposal

    1. Nominal charge voltages : 8.40 VDC (Maximum charge voltage: 8.50 VDC) 2. Nominal charge current : 3200 mA (Maximum charge current: 3250 mA) 3. Charge temperature range: 0 C to +40 Disposal a. Dispose of used battery promptly. Keep away from children.
