Samsung LW15E33C Service Manual

Tft-lcd monitor
Hide thumbs Also See for LW15E33C:

Advertisement

Quick Links

Download this manual
SERVICE
TFT-LCD MONITOR
TFT-LCD MONITOR
Chassis
Model
AS15E*
LW15E33C
AS17E*
LW17E34C
Manual
CONTENTS
4. Alignment & Adjustments
6. Exploded View & Parts List
7. Electrical Parts List
10. PCB Layout
12. Panel Description

Advertisement

loading
Need help?

Need help?

Do you have a question about the LW15E33C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung LW15E33C

Summary of Contents for Samsung LW15E33C

  • Page 1: Table Of Contents

    TFT-LCD MONITOR Chassis Model AS15E* LW15E33C AS17E* LW17E34C SERVICE Manual TFT-LCD MONITOR CONTENTS 1. Precautions 2. Product Specifications 3. Disassembly & Reassembly 4. Alignment & Adjustments 5. Troubleshooting 6. Exploded View & Parts List 7. Electrical Parts List 8. Block Diagram 9.

  • Page 2: Precautions

    A substitute replacement that does not have the same safety characteristics as the recommended replacement part might create shock, fire and/or other hazards. Product safety is under review continuously and new instructions are issued whenever appropriate. LW15E33C/LW17E34C...
  • Page 3 Use only an anti-static solder removal device. Some brushing clothes together, or lifting your foot from solder removal devices not classified as “anti-static” a carpeted floor can generate enough static can generate electrical charges sufficient to damage electricity to damage an ESD. ESDs. LW15E33C/LW17E34C...

  • Page 4: Product Specifications

    2 Product Specifications 2-1 Specifications Description Item LW15E33C LW17E34C LCD Panel TFT-LCD panel, RGB vertical stripe, normaly TFT-LCD panel, RGB vertical stripe, normaly white, 15-Inch viewable, 0.297 mm pixel pitch white, 17-Inch viewable, 0.264 mm pixel pitch Scanning Frequency Horizontal : 30 kHz ~ 69 kHz (Automatic)
  • Page 5 Not Used Not Used DDC Clock DDC Clock DDC Clock Sync Type DTV 15pin connector Pin No. Red , Y Green , Pb Blue , Pr GND-Red GND-Green GND-Blue No Connection No Connection Horizontal sync. Vertical sync. No Connection LW15E33C/LW17E34C...
  • Page 6 B : Horizontal sync width O : Frame time total P : Vertical sync width C : Back porch D : Active time Q : Back porch R : Active time E : Front porch S : Front porch LW15E33C/LW17E34C...

  • Page 7: Disassembly & Reassembly

    3 Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LW15E33C/LW17E34C monitor. WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components. 3-1 Disassembly Cautions : 1. Disconnect the monitor from the power source before disassembly.
  • Page 8 TV and pull the rear cover by pressing a hand. 2. Remove power cable on the hand and signal cable on the driver. 3. Remove 2 screws on the rear cover and remove the rear cover by using opening jig. LW15E33C/LW17E34C...
  • Page 9 6. Remove 6 screws from the shield. (see illustrations) 7. Remove IR PCB cable from the shield and lift up the shield. (see illustrations) 8. Remove LVDS cable from the main shield and lift up the panel. (see illustrations) 9. Remove the panel. LW15E33C/LW17E34C...
  • Page 10 3 Disassembly and Reassembly 3-2 Reassembly Reassembly procedures are in the reverse order of dissasembly procedures. LW15E33C/LW17E34C...
  • Page 11 6. Do not attempt to connect or disconnect any wire while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts. 7. To protect aganist shock hazard, use an isolation transformer. LW15E33C/LW17E34C...
  • Page 12 2. TV Auto Color : Used to adjust TV image color. 3. Reset : Used after all adjustments. 4. Other functions shown are not service related. 4-2-3 Adjustment Sequence for ROM change only EEPROM Clear TV auto color PC auto color RESET (For ROM change only) LW15E33C/LW17E34C...

  • Page 13: Troubleshooting

    Check IC11. appear at Pin 1 of IC11? Does proper DC 3.3 V appear at Check IC14. Pin 3 of IC14? Does proper DC 2.5 V appear at Check IC109 and IC17. Pin 4 of IC109 and IC17? Check IC23. LW15E33C/LW17E34C...
  • Page 14 X21? Does the clock pulse appear at output of <RA35~RA39, RA310>15” Check related circuit of IC32. <RA35~RA39, RA310, RA313~318>17”? Does the clock pulse appear at Replace <R611~R620>15” output of <R611~R620>15” <R611~R620, R61~R69, R610>17”. <R611~R620, R61~R69, R610>17”? Replace LCD panel. LW15E33C/LW17E34C...
  • Page 15 Check IC401 (VSP9407) RA33, RA34, RA311, RA312? and related circuit. Does signal appear at <RA35~RA39, RA310>15” Check IC32 and related circuit . <RA35~RA39, RA310, RA313~RA318>17” of related IC32? Check IC61, 62 and <R611, R612, ~R620>15” <R611, R612, ~R620, R61~R69, R610>17”. LW15E33C/LW17E34C...
  • Page 16 CN26 (VCR connector). (VCR sound) of IC53 (MSP3421G)? Does the signal appear at Pin 27, Check IC32 and related circuit. 28 of IC53 (MSP3421G)? Does the signal appear Check IC55 (Audio amp) and related circuit. at L53~L56? Replace the speaker. LW15E33C/LW17E34C...
  • Page 17 7 Electrical Parts List You can search for updated part codes through CMS web site. URL : http://ecms. samsungelectronics. com/ 7-1-1 LW15E33C Main PCB Parts Loc. No. Code No. Description Specification Remarks BN94-00456E ASSY PCB MAIN-EW AS15EO C115 2401-002286 C-AL 470uF,20%,16V,WT,TP,10x12.5,5...
  • Page 18 C148 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, 2402-001044 C-AL,SMD 100UF,20%,25V,GP,TP,8.3X8.3X6.3MM C150 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C154 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C155 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C156 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C157 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C158 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C159 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C160 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 LW15E33C/LW17E34C...
  • Page 19 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3300 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C331 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C332 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C333 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C334 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C335 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C336 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C337 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C338 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, LW15E33C/LW17E34C...
  • Page 20 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C414 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C415 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C416 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C417 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C418 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C419 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C420 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C427 2203-000236 C-CERAMIC,CHIP 0.1NF,5%,50V,C0G,TP,1608 C428 2203-000236 C-CERAMIC,CHIP 0.1NF,5%,50V,C0G,TP,1608 LW15E33C/LW17E34C...
  • Page 21 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5255 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5256 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5257 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5258 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5259 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C526 2203-000903 C-CERAMIC,CHIP 0.0047NF,0.25PF,50V,C0G,TP,1608 C5260 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5261 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5262 2203-000440 C-CERAMIC,CHIP 1nF,10%,50V,X7R,TP,1608,- LW15E33C/LW17E34C...
  • Page 22 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C561 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C562 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C563 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C564 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C565 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C566 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C567 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C568 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C569 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- LW15E33C/LW17E34C...
  • Page 23 SS24,40V,2.0A,DO-214AA 0402-000553 DIODE-RECTIFIER SS24,40V,2.0A,DO-214AA 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP 0401-001056 DIODE-SWITCHING MMBD4148SE,75V,200MA,SOT-23,TP 0403-001435 DIODE-ZENER QZX363C5V6,5.32-5.88,200MW,SOT-363,TP D210 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 D211 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 D235 0403-000277 DIODE-ZENER MMBZ5226B,3.3V,5%,225mW,SOT-23 D237 0403-001435 DIODE-ZENER QZX363C5V6,5.32-5.88,200MW,SOT-363,TP D238 0403-001435 DIODE-ZENER QZX363C5V6,5.32-5.88,200MW,SOT-363,TP LW15E33C/LW17E34C...
  • Page 24 IC62 1205-001740 IC-TRANSMITTER DS90C385,TSSOP,56P,240MIL,PLASTIC,4V,1.63W,-10 TO +70C,ST,FPD LINK-85MHZ(LVDS) IC64 1105-001391 IC-DRAM EM638325,2MX32BIT,TSOP(II),86P,400MIL,60NS,3.3V,10%,PLASTIC,0TO+70C,3MA,-,TR 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- L111 BN27-00002A COIL-CHOKE(SMD) 47uH,47uH,20%,12*12*8mm,22.5Ts,SMD,-,-,0.75ohm,-,-,-,TP L113 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm L114 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm L115 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm L116 BN27-20001A COIL-CHOKE -,53.0UH,20%,DR10*5,-,-,-,-,0.18ohm,-,-,-,TRAY L119 2703-001070 INDUCTOR-SMD 100uH,10%,4.5x3.2x3.2mm LW15E33C/LW17E34C...
  • Page 25 2007-000072 R-CHIP 47ohm,5%,1/10W,TP,1608 R113 2007-000132 R-CHIP 180Kohm,5%,1/10W,TP,1608 R114 2007-000132 R-CHIP 180Kohm,5%,1/10W,TP,1608 R115 2007-000132 R-CHIP 180Kohm,5%,1/10W,TP,1608 R116 2007-000092 R-CHIP 15Kohm,5%,1/10W,TP,1608 R117 2007-000092 R-CHIP 15Kohm,5%,1/10W,TP,1608 R118 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R119 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R120 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R121 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C...
  • Page 26 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R226 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R227 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R228 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R229 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R234 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R235 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R236 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R237 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 7-10 LW15E33C/LW17E34C...
  • Page 27 2007-000309 R-CHIP 10ohm,5%,1/10W,TP,1608 R325 2007-000309 R-CHIP 10ohm,5%,1/10W,TP,1608 R326 2007-000309 R-CHIP 10ohm,5%,1/10W,TP,1608 R327 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R328 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R329 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R330 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R331 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R332 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C 7-11...
  • Page 28 R-CHIP 0ohm,5%,1/10W,TP,1608 R416 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R417 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R418 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R419 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R420 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R421 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R433 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R434 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R436 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 7-12 LW15E33C/LW17E34C...
  • Page 29 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R4583 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R4584 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R4585 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R4588 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R4589 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R459 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 R4598 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R464 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C 7-13...
  • Page 30 R546 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R547 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 R548 2007-000981 R-CHIP 5.6Kohm,5%,1/8W,TP,2012 R549 2007-000518 R-CHIP 2.7Kohm,5%,1/8W,TP,2012 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R550 2007-000088 R-CHIP 7.5Kohm,5%,1/10W,TP,1608 R551 2007-000088 R-CHIP 7.5Kohm,5%,1/10W,TP,1608 R552 2007-000093 R-CHIP 20Kohm,5%,1/10W,TP,1608 R553 2007-000093 R-CHIP 20Kohm,5%,1/10W,TP,1608 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 7-14 LW15E33C/LW17E34C...
  • Page 31 1nF,10%,50V,X7R,TP,1608,- U514 2203-000552 C-CERAMIC,CHIP 0.02NF,5%,50V,C0G,TP,1608 U515 2203-000552 C-CERAMIC,CHIP 0.02NF,5%,50V,C0G,TP,1608 U516 2203-000552 C-CERAMIC,CHIP 0.02NF,5%,50V,C0G,TP,1608 U517 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm U518 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- 2801-003667 CRYSTAL-SMD 14.3182MHZ,50PPM,28-AAN,16,50OHM,TP 2801-004004 CRYSTAL-SMD 20.25MHz,20ppm,28-AAN,13pF,25ohm,TP 2801-003843 CRYSTAL-SMD 18.432MHz,30ppm,28-AAN,20pF,50ohm,TP 2801-003773 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP ZD21 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 LW15E33C/LW17E34C 7-15...
  • Page 32 7 Electrical Parts List 7-1-2 LW15E33C Others Loc. No. Code No. Description Specification Remarks BN90-00506E ASSY COVER FRONT AS15EO C/F+C/R 6003-001003 SCREW-TAPTITE BH,+,B,M4,L12,ZPC(BLK),SWRCH18 BN96-00443C ASSY COVER P-FRONT AS15EO,ABS 6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A 6003-000259 SCREW-TAPTITE BH,+,B,M3,L8,ZPC(YEL),SWRCH18A 6003-000276 SCREW-TAPTITE BH,+,B,M3,L10,ZPC(YEL),SWCH10 BN59-00216A PBA SUB...
  • Page 33 BN97-00221F ASSY MICOM AS15EO BN82-00093G A/S MICOM AS15EO IC22 1102-001108 IC-EPROM 27C020,256Kx8Bit,PLCC,32P,495MIL,70nS,5V,10%,PLASTIC,0to+70C,100uA,CMOS,TR BN96-00445B ASSY MISC P-SHIELD COVER ARES15,PAL,SECC T0.8 6502-000131 CABLE CLAMP DAWS-1NA,ID10,-,NTR,NYLON66 BH68-30003B LABEL-HIGH VOLTAGE CKA4217(C),ART,100G,YEL,BLK,W30*L30,CDT-TUBE BN63-00549A GASKET EOS,CONDUCTIVE FABRIC,2.5MM,17MM,160MM,GRAY,71TSSK-17-2.5-160-13,SHIELD FORM BN63-00703B SHIELD-PCB ARES15,SECC,T0.8,PAL BN63-00905A GASKET AS15UO,1.2,10,280 LW15E33C/LW17E34C 7-17...
  • Page 34 XEC,SPANISH,MOJO100,L150,W392,-,- 6801-001018 CARD-REGISTRATION XET,ITALY,MOJO100,L150,W392,-,- 6801-001019 CARD-REGISTRATION XEN,DUTCH,MOJO100,L150,W392,-,- 6801-001020 CARD-REGISTRATION XEP,PORTUGAL,MOJO100,L150,W392,-,- 6902-000110 BAG PE LDPE,T0.05,L356,W240,TRP,28,2,PE MARK BN68-00438D MANUAL USERS LW15E33C,LW17E34C,SAMSNUG,E/F/G/DU/IT/SP/P,W-EUROPE,00 BN92-00740A ASSY P/MATERIAL AS15UO 0203-001100 TAPE-OPP MASKING OPP/W75/CLR,T0.05,W75,L800000,CLR 6902-000520 BAG PE HDPE/NITRON(DOUBLE),T0.015/T0.5(DOUBLE),W700,L700,TRP,28 LANGUAGE,2- P/MATERIAL 6902-000539 BAG SHEET HDPE+NITRON,T0.015+T0.5,W600,L250,-,-,2+ HOLE(40MM) BH69-00457B PACKING-PAD GH15,FOAM,T3.0,930,1000...
  • Page 35 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm BD233 2703-000442 INDUCTOR-SMD 10UH,10%,2X1.25X1.25MM BD24 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm BD25 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm BD26 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm BD27 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm BD28 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm BD29 3301-001163 CORE-FERRITE BEAD AB,80ohm,2x1.25x1mm,300mA,TP,FERRITE,0.08ohm LW15E33C/LW17E34C 7-19...
  • Page 36 C155 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C156 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C157 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C158 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C159 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C160 2203-000257 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,1608 C162 2203-000236 C-CERAMIC,CHIP 0.1NF,5%,50V,C0G,TP,1608 C163 2203-000236 C-CERAMIC,CHIP 0.1NF,5%,50V,C0G,TP,1608 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm 7-20 LW15E33C/LW17E34C...
  • Page 37 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C332 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C333 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C334 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C335 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C336 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C337 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C338 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C339 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3390 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 LW15E33C/LW17E34C 7-21...
  • Page 38 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C414 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C415 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C416 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C417 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C418 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C419 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C420 2203-005065 C-CERAMIC,CHIP 1000nF,+80-20%,10V,Y5V,TP,1608 C427 2203-000236 C-CERAMIC,CHIP 0.1NF,5%,50V,C0G,TP,1608 C428 2203-000236 C-CERAMIC,CHIP 0.1NF,5%,50V,C0G,TP,1608 7-22 LW15E33C/LW17E34C...
  • Page 39 C-CERAMIC,CHIP 0.056nF,5%,50V,NP0,TP,2012 C5253 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5254 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5255 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5256 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5257 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5258 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C5259 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C526 2203-000903 C-CERAMIC,CHIP 0.0047NF,0.25PF,50V,C0G,TP,1608 C5260 2203-000189 C-CERAMIC,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, LW15E33C/LW17E34C 7-23...
  • Page 40 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C558 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C559 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- 2402-000176 C-AL,SMD 10uF,20%,16V,GP,TP,4.3x4.3x5.4 C560 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C561 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C562 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C563 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C564 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- C565 2203-001391 C-CERAMIC,CHIP 150nF,10%,25V,X7R,TP,2012,- 7-24 LW15E33C/LW17E34C...
  • Page 41 C-NETWORK 15PFX4,10%,50V,- CA33 2503-001018 C-NETWORK 15PFX4,10%,50V,- CA330 2503-001018 C-NETWORK 15PFX4,10%,50V,- CA34 2503-001018 C-NETWORK 15PFX4,10%,50V,- CA35 2503-001018 C-NETWORK 15PFX4,10%,50V,- CA36 2503-001018 C-NETWORK 15PFX4,10%,50V,- CN13 3711-002046 CONNECTOR-HEADER BOX,12P,1R,1.25MM,SMD-S,SN,WHT CN21 3711-002127 CONNECTOR-HEADER BOX,8P,1R,1.25mm,SMD-A,SN CN22 3711-002049 CONNECTOR-HEADER BOX,6P,1R,1.25mm,SMD-A,SN CN26 3711-000556 CONNECTOR-HEADER BOX,12P,1R,1.25mm,SMD-A,SN LW15E33C/LW17E34C 7-25...
  • Page 42 32P,PLCC,SN,- IC23 0903-001202 IC-MICROCONTROLLER 80251G2,8Bit,PLCC,44P,653MIL,24MHz,TR,CMOS,PLASTIC,5V,1.5W,0to+70C,1KBYTE,-,24Bi IC24 0803-000117 IC-TTL 74F14,INVERTER,SOP,14P,150MIL, IC25 0801-002268 IC-CMOS LOGIC 74VHC139,DECODER,SOIC,16P,150MIL,DUAL,TP,PLASTIC,TRI-STATE,-,0.36V,-40TO+85C,180 IC26 0801-000411 IC-CMOS LOGIC 74HC32,OR GATE,SOP,14P,150MIL,QUAD,TP,PLASTIC,-,-,0.26V,-40TO+85C,180MW,4.2V,1UA IC27 0801-000411 IC-CMOS LOGIC 74HC32,OR GATE,SOP,14P,150MIL,QUAD,TP,PLASTIC,-,-,0.26V,-40TO+85C,180MW,4.2V,1UA IC28 0802-001108 IC-BICMOS LOGIC 74ABT573,LATCH,TSSOP,20P,173MIL,8,TR,PLASTIC,3-STATE,-,0.55V,-65TO+150C,-,0.8V,5 IC32 1205-002028 IC-LCD CONTROLLER JAGASM,BGA,388P,208MIL,PALATIC,3.45V,2.5W,-40TO+125C,TR,DIGITAL DISPLAY PRO. 7-26 LW15E33C/LW17E34C...
  • Page 43 R-CHIP 0ohm,5%,1/10W,TP,1608 R1008 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R1009 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R1010 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R1011 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R1012 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R1013 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R1014 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R1015 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R1016 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C 7-27...
  • Page 44 R149 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 R150 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 R151 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R209 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R210 2007-000077 R-CHIP 470ohm,5%,1/10W,TP,1608 7-28 LW15E33C/LW17E34C...
  • Page 45 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 R2556 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R2557 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R2558 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R256 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R257 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R2570 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R258 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R2584 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C 7-29...
  • Page 46 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R359 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R360 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R361 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R362 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R363 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R364 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R365 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 R366 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 7-30 LW15E33C/LW17E34C...
  • Page 47 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 R4553 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 R4555 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 R4556 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 R4557 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 R4558 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 R4559 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R4560 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 R4561 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 R4563 2007-000616 R-CHIP 24Kohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C 7-31...
  • Page 48 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 2007-000097 R-CHIP 47Kohm,5%,1/10W,TP,1608 R520 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R521 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R522 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R523 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R524 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R525 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R526 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R527 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 7-32 LW15E33C/LW17E34C...
  • Page 49 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R625 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R626 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R627 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R628 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R629 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 2007-000072 R-CHIP 47ohm,5%,1/10W,TP,1608 R630 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R631 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R632 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 LW15E33C/LW17E34C 7-33...
  • Page 50 1nF,10%,50V,X7R,TP,1608,- U514 2203-000552 C-CERAMIC,CHIP 0.02NF,5%,50V,C0G,TP,1608 U515 2203-000552 C-CERAMIC,CHIP 0.02NF,5%,50V,C0G,TP,1608 U516 2203-000552 C-CERAMIC,CHIP 0.02NF,5%,50V,C0G,TP,1608 U517 2402-001042 C-AL,SMD 100uF,20%,16V,GP,TP,6.6x6.6x5.4mm U519 3301-001145 CORE-FERRITE BEAD AB,4.5x1.6x1.6mm,-,- 2801-003667 CRYSTAL-SMD 14.3182MHZ,50PPM,28-AAN,16,50OHM,TP 2801-004004 CRYSTAL-SMD 20.25MHz,20ppm,28-AAN,13pF,25ohm,TP 2801-003843 CRYSTAL-SMD 18.432MHz,30ppm,28-AAN,20pF,50ohm,TP 2801-003773 CRYSTAL-SMD 12MHZ,30PPM,28-AAN,20PF,50OHM,TP ZD21 0403-000579 DIODE-ZENER BZX84C5V1,5.1V,5%,200mW,SOT-23 7-34 LW15E33C/LW17E34C...
  • Page 51 BN91-00591B ASSY MISC-ADAPTOR RT17NS,,, BN44-00075A ADAPTOR AP04914-UV,LCDTM,90 ~264V,47-63HZ,+14VDC,+3.5A,49W,0 TO +40,120*55*31 BN91-00639F ASSY CHASSIS-S5 AS17EO BN83-00081A CKD-C-CERAMIC,CHIP 2203-000206,GH17ASPS/XAZ,SEDA BN83-00086A CKD-C-CERAMIC,CHIP 2203-002793,GH17ASPS/XAZ,SEDA BN83-00288A CKD-C-CERAMIC,CHIP 2203-002494,GH17ASPS/XAZ,SEDA BN83-00082A CKD-C-CERAMIC,CHIP 2203-001458,GH17ASPS/XAZ,SEDA BN83-00083A CKD-C-CERAMIC,CHIP 2203-000455,GH17ASPS/XAZ,SEDA BN83-00289A CKD-C-FILM,PPF 2301-001359,GH17ASPS/XAZ,SEDA BN83-00287A CKD-C-CERAMIC,DISC 2201-002115,GH17ASPS/XAZ,SEDA BN83-00287A CKD-C-CERAMIC,DISC 2201-002115,GH17ASPS/XAZ,SEDA LW15E33C/LW17E34C 7-35...
  • Page 52 0504-000129,GH17ASPS/XAZ,SEDA BN83-00070A CKD-TR-DIGITAL 0504-000129,GH17ASPS/XAZ,SEDA BN83-00070A CKD-TR-DIGITAL 0504-000129,GH17ASPS/XAZ,SEDA BN83-00069A CKD-TR-SMALL SIGNAL 0501-000457,GH17ASPS/XAZ,SEDA BN83-00266A CKD-FET-SILICON 0505-001220,GH17ASPS/XAZ,SEDA BN83-00265A CKD-TR-SMALL SIGNAL 0501-002218,GH17ASPS/XAZ,SEDA BN83-00265A CKD-TR-SMALL SIGNAL 0501-002218,GH17ASPS/XAZ,SEDA BN83-00070A CKD-TR-DIGITAL 0504-000129,GH17ASPS/XAZ,SEDA BN83-00070A CKD-TR-DIGITAL 0504-000129,GH17ASPS/XAZ,SEDA BN83-00070A CKD-TR-DIGITAL 0504-000129,GH17ASPS/XAZ,SEDA BN83-00068A CKD-TR-DIGITAL 0504-000158,GH17ASPS/XAZ,SEDA BN83-00071A CKD-TR-SMALL SIGNAL 0501-000462,GH17ASPS/XAZ,SEDA 7-36 LW15E33C/LW17E34C...
  • Page 53 CKD-CHIP 2007-001241,GH17ASPS/XAZ,SEDA BN83-00284A CKD-CHIP 2007-001241,GH17ASPS/XAZ,SEDA BN83-00284A CKD-CHIP 2007-001241,GH17ASPS/XAZ,SEDA BN83-00284A CKD-CHIP 2007-001241,GH17ASPS/XAZ,SEDA BN83-00284A CKD-CHIP 2007-001241,GH17ASPS/XAZ,SEDA BN83-00284A CKD-CHIP 2007-001241,GH17ASPS/XAZ,SEDA BN83-00278A CKD-R-CHIP 2007-000793,GH17ASPS/XAZ,SEDA BN83-00278A CKD-R-CHIP 2007-000793,GH17ASPS/XAZ,SEDA BN83-00282A CKD-R-CHIP 2007-001039,GH17ASPS/XAZ,SEDA BN83-00275A CKD-R-CHIP 2007-000615,GH17ASPS/XAZ,SEDA BN83-00282A CKD-R-CHIP 2007-001039,GH17ASPS/XAZ,SEDA BN83-00277A CKD-R-CHIP 2007-000703,GH17ASPS/XAZ,SEDA BN83-00285A CKD-R-CHIP 2007-001710,GH17ASPS/XAZ,SEDA LW15E33C/LW17E34C 7-37...
  • Page 54 ARES17,PAL,SECC T0.8 6003-000117 SCREW-TAPTITE BH,+,B,M3,L6,ZPC(YEL),SWRCH18A 6502-000131 CABLE CLAMP DAWS-1NA,ID10,-,NTR,NYLON66 BH68-30003B LABEL-HIGH VOLTAGE CKA4217(C),ART,100G,YEL,BLK,W30*L30,CDT-TUBE BN63-00697B SHIELD-PCB ARES17,SECC,T0.8,PAL BN63-00698A SHIELD-SUB PCB ARES17,SPTE,T0.3,,,, BN71-00022A EARTH PLATE RB15AS,SUS,T0.15 BN71-00024A EARTH-PLATE GH17LS,SUS,T0.15 BN91-00640F ASSY SHIELD AS17EO C/F+AV/JACK 6003-000277 SCREW-TAPTITE BH,+,B,M3,L12,ZPC(YEL),SWRCH18 C/F+BRKT/SUPPO 6003-000277 SCREW-TAPTITE BH,+,B,M3,L12,ZPC(YEL),SWRCH18 7-38 LW15E33C/LW17E34C...
  • Page 55 CARD-REGISTRATION XEC,SPANISH,MOJO100,L150,W392,-,- 6801-001018 CARD-REGISTRATION XET,ITALY,MOJO100,L150,W392,-,- 6801-001019 CARD-REGISTRATION XEN,DUTCH,MOJO100,L150,W392,-,- 6801-001020 CARD-REGISTRATION XEP,PORTUGAL,MOJO100,L150,W392,-,- 6902-000110 BAG PE LDPE,T0.05,L356,W240,TRP,28,2,PE MARK BN68-00438D MANUAL USERS LW15E33C,LW17E34C,SAMSNUG,E/F/G/DU/IT/SP/P,W-EUROPE,00 BN92-00740B ASSY P/MATERIAL AS17UO 0203-001100 TAPE-OPP MASKING OPP/W75/CLR,T0.05,W75,L800000,CLR BH69-40379A PACKING-WRAP LDPE,W500*T0.02,-,- 6902-000520 BAG PE HDPE/NITRON(DOUBLE),T0.015/T0.5(DOUBLE),W700,L700,TRP,28 LANGUAGE,2- BH69-00256A PAD-PACKING-EDGE MV540,B400,200,2170,-,-,YEL,-,- BH69-00457A PACKING-PAD GH17,FOAM,T3.0,1180,1130...

  • Page 56: Block Diagram

    8 Block Diagram LW15E33C/LW17E34C...

  • Page 57: Wiring Diagram

    SPK OUT R- SPK OUT L + CN52 SPK OUT L- INVERTER CN13 AUDIO R IN AUDIO L IN VCR CVBS CN26 LED_GRN CHK_VIDEO LED_RED HP-R CN22 HP-L IRRCVR MODE COM2-Y COM2-PB CN27 COM2-PR COM2-L CN12 CN11 CN51 CN24 CN25 COM2-R LW15E33C/LW17E34C...
  • Page 58 +5V_DEC +5V_TUNER R123 100pF +5V_CPU +5V_SUP +5V_CPU 15" ONLY 17"ONLY IC111 C139 R149 SI9933ADY-T1 R137 100K 4.7K D1_1 R140 D2_1 5 IC18 C138 R148 NM24C17FM8X 100K C113 2SC2412K-Q 100uF 100uF R139 C156 C131 R122 10nF SW_REG_EN R121 2SC2412K-Q LW15E33C/LW17E34C 11-1...

  • Page 59: Schematic Diagrams

    MCA(0) MCA(0) R220 *PSEN EEPROM_CS* SCALER_ALE 14 15 16 17 18 19 20 MCAD(7) C228 MCAD(6) C231 C229 C230 MCAD(0:7) 100pF MCAD(5) 100pF 100pF 100pF MCAD(4) MCAD(3) C232 MCAD(2) C234 C233 100pF MCAD(1) 100pF 100pF MCAD(0) +5V_CPU U509 11-2 LW15E33C/LW17E34C...
  • Page 60 BL_EN FT31 2.5VJA1 AC20 VDDC0 2.5VJP DCLK AC14 VDDC1 VDDC2 C384 KNF21200 3.3VJP 15pF R326 AF21 VDD0 AF16 C3246 C334 VDD1 3.3VJF AF10 VDD2 10uF 100nF C335 100nF 3.3VJF 2.5VJF RA311 RA312 RA33 RA34 MCAD(0:7) MCA(8:15) VYO(0:7) 3.3VJF LW15E33C/LW17E34C 11-3...
  • Page 61 QSS_IF CVBS_TTX 2.2uH +5V_DEC R4560 CVBS_TTX R475 5V_2 U513 3.3UH C5259 R411 U510 18 A_O MONO_IN 100nF R410 R412 GND_0.7 Q201 2SC2412K-Q 100nF 2SC2412K-Q C5260 R4599 GND_0.7 R4570 Scart_vout R209 R4585 RF_CVBS_GND R4563 Tuner_Gnd RF_CVBS R4571 Tuner_Gnd R4572 11-4 LW15E33C/LW17E34C...
  • Page 62 4.7uF BD52 SCR4 Scart_rin C778 SCR1 HB-1M2012-800JT R534 R538 C546 C550 RLZ8.2 100pF 100pF X702 IC705 C518 R535 4.7uF L706 SCL2 COM1_L C547 100pF FT701 C777 4.7uF SCR2 COM1_R R536 C548 100pF C5250 4.7uF Mono MONO_IN C5269 330PF LW15E33C/LW17E34C 11-5...
  • Page 63 PLLGND DABLU(12) TXIN21 PLLVCC DABLU(13) TXIN22 PLLGND1 TXIN23 PWRDWN R627 VCC2 TXCLKIN TXIN24 TXIN26 R628 TXIN25 GND4 R629 R630 DCLK R631 LVDS_EN +3.3V_D +3.3V_D +3.3V_D FT63 FT61 FT62 BLM41P600S BLM41P600S BLM41P600S 10uF 10uF 10uF C635 C637 100nF 100nF 11-6 LW15E33C/LW17E34C...
