FX-401
Fire Alarm Control Panel
All MGC MIX-4000 Series Detectors are not FM Approved
LT-6670 Rev 2
Installation and Operation Manual
Nov 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIX-4000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Microm MIX-4000 Series

Summary of Contents for Microm MIX-4000 Series

  • Page 1 FX-401 Fire Alarm Control Panel All MGC MIX-4000 Series Detectors are not FM Approved LT-6670 Rev 2 Installation and Operation Manual Nov 2022...

  • Page 3: Table Of Contents

    Table of Contents Industry Canada and FCC Notice Notice for all FX-400 Series Built-In UDACTs Sold in Canada ........Industry Canada Notice ....................Notice for all FX-400 Series Built-in UDACTs Sold in the U.S.A........FCC Notice ........................Introduction The FX-401 Addressable Fire Alarm Control Panel ............FX-401 Overview FX-401 Fire Alarm Control Panel Model ................
  • Page 4 LCD Display ........................Common LED Indicators and Control Buttons ............... Wiring Wiring Tables ......................... Wire Routing ........................Addressable Loop Wiring ....................NAC Circuit Wiring ......................TS1 SPECIAL APPLICATION Power Source ..............Module and Devices Wiring ................... Power Supply Wiring ...................... Placement of Ferrites for FCC Standard ................
  • Page 5 List of Figures Figure 1 FX-401 with DOX-1024DSR ..................Figure 2 UB-1024DS Backbox Installation Instructions and Dimensions ........Figure 3 Port and Jumper Locations on Main Board ..............Figure 4 Jumper on back of display ..................... Figure 5 Main Board with all Adder Modules Installed ..............Figure 6 Installing the PR-300 Polarity Reversal and City Tie Module ........
  • Page 6 List of Tables Table 1 FX-401 System Components ..................Table 2 MIX-4000 MGC Addressable Devices ................Table 3 Main Board Connectors and Jumpers ................Table 4 Core Board Jumpers ...................... Table 5 PR-300 Polarity Reversal and City Tie Module Connectors and Jumpers ..... Table 6 ALC-480 Dual Loop Adder Connector ................

  • Page 7: Industry Canada And Fcc Notice

    Industry Canada and FCC Notice Notice for all FX-400 Series Built-In UDACTs Sold in Canada Mircom's FX-400 SERIES BUILT-IN UDACT Communicator described in this manual is listed by Underwriters Laboratories Canada (ULC) for use in slave application under Standard ULC- S527 (Standard for Control Units for Fire Alarm Systems) and ULC-S559 (Equipment for Fire Signal Receiving Centres and Systems).

  • Page 8: Fcc Notice

    FCC Notice This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the telco transformer of this equipment is a label that contains, among other information, a product identifier in the format US:1M8AL01BFX3500. If requested, this number must be provided to the telephone company.

  • Page 9: Introduction

    The FX-401 Addressable Fire Alarm Control Panel Mircom's FX-401 Addressable Fire Alarm Control Panel provides the following: • MGC Protocol with up to three addressable (SLC) loops with a maximum of 720 MGC devices (MIX-4000 series), 240 per loop. • Compatible with MGC devices (MIX-4000). •...
  • Page 10 General Notes Circuits Refers to a physical electrical interface for the analog loop, indicating signals or relays, and common alarm, supervisory, and trouble relay outputs. Zone/Group Is a logical concept for a Fire Alarm Protected Area, and will consist of at least one Circuit. The FX-401 uses Groups extensively to facilitate annunciation of multiple input and output points on the RAX-1048TZDS (up to 96 points) and to facilitate the indication of bypass points.

  • Page 11: Fx-401 Overview

    All MGC MIX-4000 Series Detectors are not FM Approved FX-401 Overview This chapter lists all the possible components of an FX-401 system. FX-401 Fire Alarm Control Panel Model The FX-401 Fire Alarm Control Panel has the following features: • Main Board, Power Supply and Backbox.

  • Page 12: Fx-401 System Components

    FX-401 System Components The following table describes the components of the FX-401. Table 1 FX-401 System Components Model Description Model FX-401, black backbox, red door enclosure FX-401 comes complete with main board, power supply, transformer and main display. MAM-3500 Main Display Visual Indicator Test DOX-1024DS...
  • Page 13 Table 1 FX-401 System Components (Continued) Model Description RAM-3500-LCD Remote Annunciator with 4-line LCD Display. PR-300 Polarity Reversal and City Tie Module. Power Supply Interface Board use for powering PCS-100 3G4010 or 3G4010CF Universal Wireless Alarm Communicator. Smart Relay Module with White Enclosure. SRM-312W Can support up to 12 relays.
  • Page 14 Table 1 FX-401 System Components (Continued) Model Description 48 Point adder annunciator display with 48 Trouble RAX-1048TZDS LEDs. MGD-32 Graphic Annunciator. RAX-LCD-LITE Remote Annunciator with 4-line LCD Display. AGD-048 Graphic Annunciator Adder Driver Board. Common Remote Trouble Indicator, Buzzer and RTI-1 LED.
  • Page 15 Table 1 FX-401 System Components (Continued) Model Description BB-1002D White Enclosure for two annunciators. BB-1002DR Red Enclosure for two annunciators. BB-1002DS Enclosure for two annunciators with stainless steel door. BB-1002WPA White enclosure for two annunciators rated for outdoor environment, wet location. BB-1002WPRA Red enclosure for two annunciators rated for outdoor environment, wet location.

  • Page 16: Table 2 Mix-4000 Mgc Addressable Devices

    All MGC MIX-4000 Series Detectors are not FM Approved 3.2.1 Devices The following tables lists all the devices available for the FX-401. Table 2 MIX-4000 MGC Addressable Devices MGC Addressable Detectors and Control Modules MGC Addressable Detectors MIX-4010 Photoelectric Smoke Sensor...

  • Page 17: Installation

    Installation This chapter describes the installation of the FX-401. UB-1024DS Mechanical Installation The UB-1024DS is a black backbox suitable for flush or surface mounting with a built-in trim ring. The DOX-1024DS is the front door of this backbox, which is available in white and red, DOX-1024DSR.

  • Page 18: Installation Tips

    Installation Tips 1. Group the incoming wires through the top of the enclosure. For easy identification and neatness use a wire tie to group wires. 2. Be sure to connect a solid Earth Ground (from building system ground / to a cold water pipe) to the Chassis Earth Ground Mounting Lug, and to connect the Earth Ground Wire Lugs from the Main Chassis to the ground screw on the Backbox.

  • Page 19: Connections And Jumpers

    Connections and Jumpers JW11 Main Board JW10 Core Board Buzzer JW12 JW14 Figure 3 Port and Jumper Locations on Main Board...

  • Page 20: Table 3 Main Board Connectors And Jumpers

    Table 3 Main Board Connectors and Jumpers Connector/ Description Jumper To Power Supply To Power Supply Ribbon Cable connects to P4 of front display To PC Configurator Factory Use Only To PR-300 To Printer To ALC-480 Loop Adder Factory Use Only USB Port to PC Configurator Future Use Must be ON (default) - Allows Configuration Connection...

  • Page 21: Installing Adder Modules

    4.3.1 Jumper on Display The jumper on the back of the display is factory installed on the middle 2 pins. P2 - Ribbon cable P4 - Ribbon cable connecting to adder connecting to main panel annunciator board Jumper on the middle 2 pins by default Figure 4...

  • Page 22: Figure 5 Main Board With All Adder Modules Installed

    See the following diagrams for adder module installation locations. For Jumper or DIP Switch settings refer to Table 3 and for Wiring Specifications see 7.1 Wiring Tables. TR-063A Transformer Barrier Terminal Block FX-401 Main Board Rectifier Bridge ALC-480 Dual Loop Adder MD-1011 Power Supply Board PR-300 Polarity Reversal And City Tie Module...

  • Page 23: Figure 6 Installing The Pr-300 Polarity Reversal And City Tie Module

    The Trouble Transmit signal to the PR-300 can be programmed to delay AC power fail 0, 1, 2, or 3 hours if this is the only system trouble. Mounting hole for #6-32 screws Mounting hole for #6-32 screws PR-300 Reverse polarity and city tie module PR-300.

  • Page 24: Installing The Alc-480 Dual Loop Adder

    Installing the ALC-480 Dual Loop Adder Mount the ALC-480 Dual Loop Adder as shown in Figure 7. The ALC-480 provides two addressable loops (SLC). Each loop can accommodate 240 MIX- 4000 Series devices. ALC-480 Mounted on hex spacer with four screws provided Figure 7 Installing the ALC-480 Dual Loop Adder Table 6 ALC-480 Dual Loop Adder Connector...

  • Page 25: Operation

    Operation This chapter describes the operational capabilities of the FX-401. Table 7 Settings Permitted in UL864 NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES This product incorporates field-programmable software. In order for the product to comply with the requirements in the Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be limited to specific values or not used at all as indicated below.

  • Page 26: Figure 8 Mgc-400 Configurator Date And Time Settings

    Alarm conditions are determined by interrupt which uses thresholds for alarm conditions stored in the device. MGC detectors (MIX-4000 series) send an interrupt request to the panel, indicating the Alarm condition. The system is polling the interrupt group to determine the devices in Alarm. The Alarm conditions are confirmed by device status flag and comparing reported value against the threshold.

  • Page 27: Configurable Input Types

    The panel can provide up to 280mA of current to the devices on the loop at normal standby. For device currents see Appendix E - Battery Calculations on page 86. For further information refer to the device Installation Instructions and other documentation provided with the addressable devices, bases, and isolators.
  • Page 28 Table 9 Configurable Input Types (Continued) Device Types Dual Input Module Description Mini Dual Input Module As listed in located in Conventional Zone Input Type Configurator Section number Detectors Module Buzzer Silence Buzz Sil 5.2.7 Signal Silence Signal Silence 5.2.7 Acknowledge General Ack GA 5.2.7...
  • Page 29 • Supervisory input activations display as the second highest priority on the shared display in the common queue. • Devices configured as supervisory inputs display as supervisory conditions on the shared display and on the supervisory zone status indicator. • Restoring the non-latching supervisory input returns all outputs correlated to the input, that are not correlated to another active input, to normal.
  • Page 30 • May also be programmed to relay, signal, and strobe outputs. Note: Trouble conditions initiated as a result of a trouble-only input activating is separate from the circuit or device supervision trouble. 5.2.6 Waterflow Alarm Input Waterflow inputs are sampled every second. 10 samples in alarm in any given 15 second period confirms the alarm condition.

  • Page 31: Output Types

    5.2.10 Manual Day/Night Configures (mini) dual input modules for manual day/night alarm thresholds. For more information on alarm thresholds see 5.1.3 Alarm Conditions. 5.2.11 Auto Day/Night Configures (mini) dual input modules for auto day/night alarm thresholds. For more information on alarm thresholds see 5.1.3 Alarm Conditions. 5.2.12 Verified Alarm Input Un-bypassed verified alarm inputs entering into alarm are verified over a period of time to...

  • Page 32: Table 10 Configurable Output Types

    Table 10 Configurable Output Types Device Types Description As listed in located in Supervised Output Output Type Configurator Section number Dual Relay Module Module Relay Relay 5.3.3 Signal Signal 5.3.1 Strobe Strobe 5.3.2 Additional Operation Features • The panel can synchronize strobes directly without the use of the synchronous module. •...

  • Page 33: Nac Circuit Operation

    NAC Circuit Operation NAC Circuits can be configured as • Signal Output • Strobe Output • Relay Output For more information on Outputs see 5.3 Output Types. Powered output circuits are supervised while they are not active for both open circuits and shorts.

  • Page 34: Two-Stage Operation

    • Activates non-disconnected strobes associated with the input. • Activates non-disconnected signals associated with the input at the evacuation rate. Subsequent alarms when the panel is already in alarm, cause the following: • The alert buzzer sounds steady. • Resounds silenced signals, turns off the Signal Silence LED, and restarts the Auto Signal Silence timer (if configured).

  • Page 35: Evacuation Codes

    Subsequent First Stage alarms when the panel is already in alarm, cause the following: • The buzzer sounds steady. • Resounds silenced signals, turns off the Signal Silence LED, and restarts the Auto Signal Silence timer (if configured). • If the panel is not already in General Alarm, activates additional non-disconnected signals programmed to the new input with the Alert Code (see 5.3 Output Types on page 31).
  • Page 36 Any of these alarm inputs activating when the panel is not already in alarm causes the following: • Buzzer sounds steady. • Cancels active fire drill. • Common Alarm LED turns ON. • Individual zone LED (if programmed) turns ON. •...

  • Page 37: Remote Annunciator Operation

    How to Enable or disable the Positive Alarm Sequence 1. From the Keypad of the FACP press M to enter the Menu. 2. Using the Up and Down cursor buttons, scroll to Operation. 3. Press Enter. 4. In the Operation Menu scroll to Positive Alarm. 5.
  • Page 38 Table 11 Annunciator Address DIP Switch Settings (Continued) Address SW1-1 SW1-2 SW1-3 5.9.1 Supervision of annunciators (Class B) • The communications with each annunciator is constantly supervised by the panel and the annunciator. • If communications fails, the panel will activate the common trouble sequence. The number of annunciators is set during panel configuration.

  • Page 39: Dialer Operation

    • Relays are bypassed by Auxiliary Bypass • Supervised as one of the (maximum) seven permitted annunciators. 5.10 Dialer Operation The FX-401 is equipped with a built-in dialer. The dialer provides a means to communicate panel status to the remote central monitoring station using two dedicated phone lines. The two standard protocols for communicating with the central monitoring station are supported by this panel are as follows.

  • Page 40: Figure 10 Operation Menu

    • Clearing Logs • Walk Test Function • Bypass Operation • Disconnecting Auxiliary Relays • Testing the Dialer • After Hours Operation • Clearing Verification Counts • Ground Fault Testing - Factory Use Only Complete configuration of the system is done via the software configurator. How to Enter the Operation Menu 1.
  • Page 41 5.11.2 Setting the Password By default, no password is required to press the control buttons and enter the operation menu. Sets the password for all three access levels. The minimum number of digits for a password is 4. For changing a specific level of password the password required is the equivalent level or higher level.
  • Page 42 • Activation of any alarm input or common control which activates the common alarm sequence. • Activation of system reset. • Clearing of the event log (as the first entry). Each entry contains the time and date of the event and a description of what the event was, for example: Nverf alm ipt Active...
  • Page 43 The display shows the loop number, device address, the device type, device status, and the level of alarm, in the following format: Loop 1 Address 2 0001 0000 0096 0032 (0% alarm) 2. Press the Up and Down cursor keys to scroll through all the devices on the loop. 3.
  • Page 44 The maintenance report is shown in the following format. Maint Report Percent dirty :012% Press the Up and Down cursor keys to scroll through all the devices on the loop for which the maintenance report is available. If there are no dirty devices on the loop the following message will be displayed No dirty devices found...
  • Page 45 5.11.4 Clear Logs Clears the logs stored in the flash memory. Press the Up and Down cursor keys to the desired log to be cleared and press the Enter button. Select Log 1. Alarm Log 2. General Log 3. All Logs A message prompts for confirmation.
  • Page 46 While the walk-test is active the following message is displayed on the screen: - Walktest Active - Alarms: nnn Troubles: mmm Press ENTER to end where nnn and mmm are continuously updated counts of the number of alarms and troubles which have been recorded during the test (alarms includes all input circuit types tested).
  • Page 47 After the confirmation, the device is bypassed and the message appears that the device is bypassed. Device /circuit Bypassed If the device is already bypassed the user is prompted to un-bypass the circuit. Device now bypassed Unbypass ?Y/N After the confirmation, the device is un-bypassed and the information message shows that the device is un-bypassed.

  • Page 48: Table 12 List Bypass Special Characters

    Loop number Loop :__ If the loop is not already bypassed the user is then prompted to bypass the loop. Loop 0 not bypassed Bypass ?Y/N After the confirmation, the loop is bypassed and a bypass confirmation message displays. Loop Bypassed If the loop is already bypassed, the user is prompted to un-bypass the loop.
  • Page 49 The following message is displayed to bypass. If the device is already bypassed the message is as follows. If the exclamation is not used, then there will be individual confirmation. At the end of the bypass operation or if the exclamation is used, the message displays: 5.
  • Page 50 5.11.7 Auxiliary Disconnect The auxiliary disconnect operation is performed by the following the steps below. If the auxiliary relays are connected the user is prompted to disconnect the relays. Aux relays connected Disconnect ?Y/N After the confirmation the auxiliary relays are disconnected and the information message is displayed that the auxiliary relays are disconnected.
  • Page 51 Day/night mode updated 5.11.10 Clear Verify Count This operation is used to clear all the verification counts accumulated during the alarm verification process. The user is prompted for confirmation as shown below: Clear all verif Counters ?Y/N After the confirmation the verification count is cleared and the information message is displayed that the counts are cleared.

  • Page 52: Indication & Controls

    Indication & Controls This chapter describes the LED indicators and controls of the FX-401. Indication and Controls FX-401 Display Panel is equipped with the following • 12 Control buttons with associated LEDs • 16 button Numeric Keypad with Cursor buttons Figure 11 displays the LED indicators and the control button on the FX-401 main board.

  • Page 53: Figure 12 Numeric Keypad

    6.2.1 Numeric Keypad and Cursor Buttons Figure 12 Numeric Keypad Description Key 2 (Up cursor) Press this button to move the cursor or scroll up lists in a continuous loop. Key 4 (Left Cursor) Press this button to move the cursor or select options to the left. Key 6 (Right Cursor) Press this button to move the cursor or select options to the right.

  • Page 54: Common Led Indicators And Control Buttons

    Common LED Indicators and Control Buttons For complete descriptions of all LED indicators and control buttons see the following table. Table 13 LED Indicators and Control Buttons LED Indicator and Description Control Buttons AC On Indicator Illuminates steady green when the main AC power is within acceptable levels. The LED turns off when the level falls below the power-fail threshold and the panel is switched to standby (battery) power.
  • Page 55 Table 13 LED Indicators and Control Buttons (Continued) LED Indicator and Description Control Buttons Trouble Queue Button and Indicator Flashes yellow when any trouble condition is detected on the panel. The buzzer sounds at the slow rate. Pressing the Trouble Queue button allows the user to cycle through and review a list of active Troubles from oldest to most recent.
  • Page 56 Table 13 LED Indicators and Control Buttons (Continued) LED Indicator and Description Control Buttons Automatic Alarm Signal Cancel Button and Indicator - Two Stage Automatic Alarm Operation Only Signal Cancel LED and Indicator are active only when the Panel is configured for Two Stage Operation.
  • Page 57 Table 13 LED Indicators and Control Buttons (Continued) LED Indicator and Description Control Buttons Auxiliary Disconnect Button and Indicator Activating the Auxiliary Disconnect button activates the Auxiliary Disconnect function. The Auxiliary Alarm Relay is always disconnected with this button. The Common Alarm Relay, the Common Supervisory relay and all correlated alarm relays may be disconnected as selected through configuration.

  • Page 58: Wiring

    Wiring This chapter describes the proper field wiring for the FX-401. Wiring Tables 7.1.1 Addressable Loop Wiring Maximums MGC Devices • Maximum Loop Current = 350 mA • Maximum Loop Resistance = 40 ohms • Maximum Loop Capacitance = 0.5 F •...

  • Page 59: Table 15 Nac And Auxiliary Power Circuits Wiring Table

    7.1.3 NAC and Auxiliary Power Supply Circuits Table 15 NAC and Auxiliary Power Circuits Wiring Table TOTAL MAXIMUM WIRING RUN TO LAST DEVICE (ELR) MAX. LOOP SIGNAL RESISTANCE 18AWG 16AWG 14AWG 12AWG LOAD Amperes Ohms 0.06 2350 3750 1143 6000 1829 8500 2591...

  • Page 60: Wire Routing

    Wire Routing Notes: All external connections are power limited except for the AC connections to the transformer. Transformer connections must be routed separately from all other external connections using their own conduit. All power limited wiring shall be routed through the remaining knockouts.

  • Page 61: Addressable Loop Wiring

    Addressable Loop Wiring Note: When an SLC device is powered by the AUX output, the supervision of the power pathway shall match the SLC pathway performance requirements. 7.3.1 Addressable Loop Wiring - Class B (DCLB) MULTI-SENSOR DETECTOR OUTPUT MODULE PHOTOELECTRIC SMOKE SENSOR PULL STATION TRI-MODE HEAT DETECTOR...

  • Page 62: Nac Circuit Wiring

    7.3.3 Addressable Loop Wiring - Class X (DCLC) MULTI-SENSOR DETECTOR OUTPUT MODULE PHOTOELECTRIC SMOKE SENSOR M500X ISOLATOR TRI-MODE HEAT DETECTOR Figure 16 Addressable Loop Wiring - Class X (DCLC) NAC Circuit Wiring The FX-401 supports up to 4 NAC circuits that can be wired as either: •...

  • Page 63: Figure 17 Nac Circuit - Class B Wiring

    7.4.1 NAC Circuit – Class B Wiring CIRCUIT - 1 + + - - NAC1 NAC CIRCUITS #2, #3 AND #4 ARE NOT SHOWN. WIRE AS SHOWN ABOVE. BELL STROBE HORN EOL-392 Figure 17 NAC Circuit – Class B Wiring 7.4.2 NAC Circuit –...

  • Page 64: Figure 19 Rti-1 Common Remote Trouble Indicator Wiring

    7.4.3 UL 864 Rev. 10 Addressable Supervised Output Module Wiring As per UL864 Rev.10 56.4.3, ensure that a single break, ground or wire-to-wire fault on the installation conductors of a signalling circuit for use with addressable notification appliances or modules shall not affect the operation of more than one notification zone. Exception: Riser conductors installed in accordance with the survivability from attack by fire requirements in National Fire Alarm Code, NFPA 72.

  • Page 65: Ts1 Special Application Power Source

    TS1 SPECIAL APPLICATION Power Source The TS1 SPECIAL APPLICATION power source is located on the bottom right side of the power board (below the transformer and AC wiring). SLC LOOP WIRE MIX-4040 DUAL INPUT MODULE SLC+ SLC- SLC+ − SLC- POWER LINE 24 VDC −...

  • Page 66: Module And Devices Wiring

    Module and Devices Wiring 7.6.1 Dialer Wiring Wire the Dialer to the Public Telephone Switch and premises Telephone as shown in Figure 21. For information on Compatible DACR Receivers see Appendix A - Compatible Receivers on page 76. Public Switch Telephone Wiring RJ31X GREEN BROWN...

  • Page 67: Figure 22 Connecting An Fx-401 Facp To A 3G4010 Interface Device In Canada

    7.6.2 Connecting to a 3G4010 Interface Device in Canada A typical connection is shown in Figure 22. The PCS-100 Passive Communications Interface Board (sold separately) is required. For information on Compatible Receivers see Appendix A - Compatible Receivers on page 76. FX-401 - 3G4010 Connection - Typical Diagram To GSM/GPRS Telephone...

  • Page 68: Figure 23 Connecting A Facp To A 3G4010Cf Interface Device Outside Canada

    7.6.3 Connecting to a 3G4010CF Interface Device outside Canada For information on Compatible Receivers see Appendix A - Compatible Receivers on page 76. A typical connection is shown in Figure 24. The 3G4010CF is powered separately from the PCS-100 and requires 2 DSC RM-2 relays (sold separately). The PCS-100 Passive Communications Interface Board (sold separately) is also required.

  • Page 69: Figure 24 Connecting A Facp To A Sle-Ltev Or Sle-Ltea Interface Device Outside Canada

    7.6.4 Connecting to a NAPCO SLE-LTEV or SLE-LTEA Interface Device outside Canada For information on Compatible Receivers see Appendix A - Compatible Receivers. A typical connection is shown in Figure 24. The SLE-LTEV or SLE-LTEA is powered separately from the PCS-100. The PCS-100 Passive Communications Interface Board (sold separately) is also required.

  • Page 70: Figure 25 Wiring The Pr-300 Polarity Reversal And City Tie Module

    7.6.5 PR-300 Polarity Reversal and City Tie Module Wiring Wire the PR-300 Polarity Reversal and City Tie Module successfully as shown in Figure 25. • Plug PR-300 ribbon cable P1 into connector P8 on the Main Fire Alarm Board. • Remove jumper plug from JW7 on the Main Fire Alarm Board.

  • Page 71: Power Supply Wiring

    Power Supply Wiring 7.7.1 Main Power Supply Wiring Wire the Power Supply as shown in Figure 26 and adhere to the following: • Ensure that the AC supply is disconnected before wiring the power to the panel. • Wire the AC power to the AC wiring terminals as shown in Figure 26 using the proper wire gauge with 600 volt insulation and proper over current circuit protection that complies with local codes.

  • Page 72: Figure 26 Main Power Supply Wiring And Connections

    White/Blue Stripe Blue Black Brown FX-401 Main Board 240VAC 50Hz 120VAC 60Hz Ribbon Cable Ground Green Black Power Connector – BRIDGE MD-1011 Power Supply Board P5 P6 BLACK BLACK BATTERY BATTERY Figure 26 Main Power Supply Wiring and Connections 7.7.2 Supervision (Class B) of Auxiliary Supplies Aux 2 Resettable Auxiliary Power (supervised, regulated) The AUX 2 resettable auxiliary power supply is supervised for shorts.

  • Page 73: Figure 27 Supervision Of Auxiliary Supplies

    This filtered circuit is supervised for shorts. A short will: • Disconnect the power until the “RESET” button is pressed. • Generate a trouble signal The circuit must be supervised for opens utilizing the End of Line Relay Model EOLR-1(A) as shown in Figure 15.

  • Page 74: Placement Of Ferrites For Fcc Standard

    Placement of Ferrites for FCC Standard 7.8.1 Ferrite Locations Two ferrites are required to be mounted on the wires coming from the loop terminals and the auxiliary power terminals. Refer to picture below, of the FX-401 main fire alarm board. Ferrite labeled FER-002 is used to loop Aux 1 and Aux 2 wires if used.

  • Page 75: System Checkout

    System Checkout The following are the recommended steps before and during the powering up of the FX-401. 7.9.1 Before Turning The Power ON 1. To prevent sparking, DO NOT connect the batteries first. Connecting the batteries is only to be done after the system has been powered from the main AC Supply. 2.

  • Page 76: Appendix A - Compatible Receivers

    Appendix A - Compatible Receivers The dialers that are built into select models of the FX-401 Fire Alarm Control Panels are compatible with the following Digital Alarm Communicator Receivers (DACR) listed: Table 18 Compatible DACR Receivers DACR Receiver Model Protocols SurGard MLR2 Multi-Line Receiver (ULC, ULI Approved) SIA Format Protocol and SIA Contact ID SurGard SLR Single-Line Receiver (ULC, ULI Approved)

  • Page 77: Appendix B - Manual Panel Configuration

    Appendix B - Manual Panel Configuration COMMAND MENU The command menu is the first menu displayed for command mode. The command menu is divided into four main sub menu categories, the configuration allows full front panel configuration of the system and the operation menu performs certain operations which may not be possible using the common control switches and indicators on the front panel.
  • Page 78 Panel Configuration/Features/Waterflow Retard Waterflow retard [ ] Enabled If disabled, all the initiating circuits configured as waterflow act as non-verified alarms. If enabled, retard operation is performed for initiating circuits configured as waterflow. Panel Configuration/Features/Auxiliary disconnect, disconnects alarm and supervisory relay Aux Dis Alm&Sv [ ] Enabled If enabled the auxiliary disconnect operation, disconnects alarm and supervisory relays disabled the...
  • Page 79 Panel Configuration/Features/Common supervisory relay Com. supv. rly [ ] Enabled This feature is used to make the common supervisory relay acts as a common alarm relay if enabled. Default is disabled Panel Configuration/Features/Signal silence isolator Sig. isolators [ ] Enabled This feature makes the system aware that the isolators are present on the main panel powered output circuits if enabled.
  • Page 80 Panel Configuration/Features/Class-A loop Loop ClassA [ ] Enabled This feature configures all addressable loops as Class A if enabled. Panel Configuration/Features/Auto after hours Auto afthrs. [ ] Enabled This feature allows the daytime/nighttime mode to be set automatically if enabled. Panel Configuration/Features/General alarm timer Gen.alm tmr [x] Disabled...
  • Page 81 PANEL CONFIGURATION/4. USER MESSAGE Allows you to edit (change) the FACP Front Panel Message, i.e. “Welcome to Mircom”. PANEL CONFIGURATION/5. LANGUAGE Allows you to select the language of the LCD display. English is the default. To change the language to French, select French in the panel configuration menu, then exit the configuration and then re-enter and select auto default.

  • Page 82: Appendix C - Reporting

    10.0 Appendix C - Reporting 10.1 Ademco Contact-ID FX-400 Series Event Codes Table 19 Contact-ID Event Codes Event Description Event Qualifier Code Group # Contact # Family Phone Line #1 trouble detected Trouble New event 1 351 Phone Line #2 trouble detected Trouble New event 1 352...

  • Page 83: Security Industries Association Sia Format Protocol Fx-400 Series Event Codes

    10.2 Security Industries Association SIA Format Protocol FX-400 Series Event Codes SIA Format Protocol does not define indicating zone troubles, but lists it as Untyped Zone Trouble/Restore. Table 20 SIA-DCS Event Codes Event Description Event Family Qualifier SIA Event Code Parameter Phone Line #1 trouble detected Trouble New event...

  • Page 84: Appendix D - Specifications And Features

    11.0 Appendix D - Specifications And Features 11.1 FX-401 Fire Alarm Control Panel Table 21 lists specifications for the FX-401 panel: Table 21 FX-401 Specifications FX-401 Fire Alarm Control Panel General Digital signal processor based design, fully configurable from front panel with password protection Electrical ratings AC line voltage...

  • Page 85: Fx-401 System Module And Annunciator Specifications

    Table 21 FX-401 Specifications (Continued) FX-401 Fire Alarm Control Panel Unfiltered supply Power limited / 24V FWR special application / 1.7A max at 49C List of Compatible Devices: RAM-1032TZDS, RAM-3500-LCD, RAX-LCD-LITE Auxiliary relays Common Alarm/ Must be connected to a listed power limited source of Supv./Trouble/ supply Form C/28VDC/1A max Auxiliary Alarm...

  • Page 86: Appendix E - Battery Calculations

    12.0 Appendix E - Battery Calculations IMPORTANT NOTICE The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power without provision of any disconnect devices. Use #12 AWG wire with 600-volt insulation and proper over-current circuit protection that complies with the local codes.

  • Page 87: Table 23 Recommended Batteries

    Battery Capacity Requirement Battery (AH) = (Standby Current Total x Discharge Time) + (Alarm Current Total x Alarm Time) ([STANDBY (A) ______ ] X [(24 Hours) ___ ]) + ([ALARM (B) ______ ] X [Alarm in Hr.] _____) = (C) ______AH Total Alarm Current must be 10 amperes or less.

  • Page 88: Warranty And Warning Information

    13.0 Warranty and Warning Information WARNING! Please read this document CAREFULLY, as it contains important warnings, life-safety, and practical information about all products manufactured by the Mircom Group of Companies, including Mircom and Secutron branded products, which shall include without limitation all fire alarm, nurse call, building automation and access control and card access products (hereinafter individually or collectively, as applicable, referred to as “Mircom System”).
  • Page 89 The testing should include all sensing devices, keypads, consoles, alarm indicating devices and any other operational devices that are part of the system. NOTE TO USERS: All Mircom Systems have been carefully designed to be as effective as possible. However, there are circumstances where they may not provide protection.
  • Page 90 13. Wireless Devices Placement Proximity. Moreover all wireless devices must be a minimum and maximum distance away from large metal objects, such as refrigerators. You are required to consult the specific Mircom System manual and application guide for any maximum distances required between devices and suggested placement of wireless devices for optimal functioning.
  • Page 91 CANADA - Main Office U.S.A © Mircom 2021 25 Interchange Way 4575 Witmer Industrial Estates Printed in Canada Vaughan, ON L4K 5W3 Subject to change without prior notice Niagara Falls, NY 14305 Tel: (905) 660-4655 Tel: (905) 660-4655 www.mircom.com (888) 660-4655 (888) 660-4655 Fax: (905) 660-4113 Fax: (905) 660-4113...
