Summary of Contents for Planar XP15SSA
-
Page 2: Table Of Contents
Thank you for your purchase of this product. With this product you can use your computer monitor to watch TV/CATV, VCR, LD, and DVD or play a video game. Without turning on your computer, the system set up is very easy and there is no additional requirement for hardware or software. - Page 3 • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Warning Use only shielded signal cables to connect I/O devices to this equipment.
-
Page 4: Important Notices
3. Unplug this product from AC outlet and remove batteries from remote control when this product is left unused for a long time. 1.3 Product Functions With the advanced video processing technology, the TV composite VIDEO, S-VIDEO signal can be displayed on a PC monitor. Double scan conversion (15.75 KHz to 31.5 Khz). -
Page 5: Viewing Angle Adjustment
1.6 Viewing Angle Adjustment This product is designed to allow users to have a comfortable viewing angle. The viewing angle can be adjusted from -5°to +25°. (See Figure 1-2). When you want to close the base and body to 90°, you need to release a button from 25°. -
Page 6: Chapter 2 Installation
Turn on or off the main body. Open or Close the OSD menu. Select the next lower channel / higher channel (TV/AV mode) ; OSD function for selecting (PC mode). Lower / Raise the sound volume (TV/AV mode) ; OSD function for adjusting (PC mode). -
Page 7: System Installation
2.2 System Installation: Refer to the example closest to your configuration. Turn off the power of all devices before connection. For audio connection, use RCA audio (L+R) connector. For video connection, choose either RCA video connector or s-video connector. For connection to monitor alone omit those connections associated with PC. -
Page 8: Chapter 3 Operation Instruction
Chapter 3 Operation Instruction 3.1 Remote Control... -
Page 9: Advanced Setting
"←, →" (on remote control) button to adjust content. AUDIO: Treble, Bass and Balance. VIDEO: Brightness, Picture, Color, Hue and Sharp. SYSTEM: MTS, Language, Sleep, TV/CATV, Channel search, Channel memory, Fine tune and Recall. C.C. (Closed Caption) V-CHIP: TV, MPAA, Change Pin. - Page 10 3.2.2 PC The OSD shown below displays when you press "MENU"(on main body) or "►" button. (on remote control) Press " " (on main body) or "↑, ↓" (on remote control) button to select item. Then press " " (on main body) or "←, →" (on remote control) button to adjust content.
-
Page 11: Icon Description
3.2.3 PC OSD function description Icon Function Function Description This function increases or decreases the brightness of the image. Brightness This function increases or decreases the difference between the dark and light Contrast color. H-Position This function shifts the entire display image left or right. This function shifts the entire display image up or down. -
Page 12: Chapter 4 Technical Information
Chapter 4 Technical Information 4.1 Specifications LCD Panel Size Display Type Resolution Display Dot Display Area (mm) Brightness Contrast Ratio Response Time Lamp Voltage Lamp Current Viewing Angle Display colors Video Input Signal Input Impedance Polarity Amplitude Multi-mode Supported Speaker Control Power switch (hard and soft types) On/Off switch with LED indicator OSD (On Screen Display) - Page 13 Power Management Mode Power Consumption* 60W maximum 5W maximum Soft switch off 5W maximum Disconnected 5W maximum * Meeting VESA DPMS requirements measured from AC Input end of AC power cord. Sync Input Signal Polarity Plug & Play External Connection Power Input (AC input) Video Cable Audio Cable...
-
Page 14: Standard Timing Table
4.2 Standard Timing Table If the selected timing is NOT included in table below, this LCD monitor will use the most suitable available timing. Mode Resolution 640x480@60Hz 640x480@72Hz 640x480@75Hz 800x600@56Hz 800x600@60Hz SVGA 800x600@72Hz 800x600@75Hz 1024x768@60Hz 1024x768@70Hz 1024x768@75Hz DOS* 720x400@70Hz 640x350@70Hz Chapter 5 Other Information 5.1 Specifications POWER IN... -
Page 15: Chapter 6 Troubleshooting
Chapter 6 Troubleshooting This LCD Monitor was pre-adjusted using factory standard VGA timings. Due to the output timing differences among various VGA cards in the market, users may initially experience an unstable or unclear display whenever a new display mode or new VGA card is selected. Attention This LCD Monitor Supports Multiple VGA Modes.
