- Page 1 A i r I o n C o u n t e r s AlphaLab, Inc. The AIC3Pro is designed and manufactured in the U.S.A. by AlphaLab, Inc., a trusted source of standard and custom air ion measurement products since 1993.
- Page 3 Overview The Precis-Ion™ Air Ion Counter Model AIC3Pro is a Gerdien condenser air ion meter. During operation, a blower draws air through the top of the meter, and the electrical charge from air ions (charged air molecules) is measured. The air ion count is calculated and displayed. The Static Shield: Do not use plastics, adhesives, Use of this shield is optional.
- Page 4 Grounding the AIC3Pro Air Ions are charged air molecules. These air molecules are measured with respect to earth/ground reference. Thus, the meter must have an earth ground reference either via the hand/body of the operator or a ground cable connected to an outlet ground or other ground connection. At low air ion counts (<20K ions/cc), holding the meter (with the kickstand removed) maintains suffi- cient ground reference, provided that your body doesn’t build up a static charge.
- Page 5 Operating Modes and Displayed Information Single Polarity (Positive or Negative) Operating Mode Temperature °C/°F Humidity Selected Polarity Peak Ion Count Real-Time Ion Count Scale X10³ or X 10⁶ System Warning See page 9 for details. Ion Count Averaging MicroSD Card Installed Scales: X10³...
- Page 6 Key Pad Functions Select Ion Polarity +, -, or Dual Power On/Off Menu Functions, see page 7 for details. Zero Reference Verification and (when needed) Rezeroing Reset of the Peak Ion Count Zero Reference Standby/Zero Display Automatic rezero 10 second with instructions rotating timer...
- Page 7 Measuring Air Ions Ion Count Averaging Air Ion Measurement Examples...
-
Page 8: Recording Data
Recording Data Maximum MicroSD Card Size 32G Maximum File Length: To prevent excessive file sizes, files are Included 8G Card Recording Time: truncated when their duration exceeds the Approximately 150,000 hours can be intervals noted below. A new file is automati- at a one second record interval. - Page 9 AlphaApp Data Streaming, Uploading, and Plotting With the AlphaApp (free PC application), previously recorded data or live streaming data can be saved and graphically plotted. Download the AlphaApp at: https://www.alphalabinc.com/alphaapp Connect (powered) AIC3Pro via USB cable. Bottom right corner of the application Open the Application provides key status information.
- Page 10 Menu Selections and Additional Features Main Menu Press the “Menu(Enter)” button to access the main menu. Use the up and down arrows to highlight the desired settings/functions. Once highlighted, press “Menu (Enter)”. When settings are changed, the new setting becomes the new power-up default.
- Page 11 Additional Menu Selections Menu, Record Settings Menu, System Information Warnings & Error Messages If there are system warnings or errors, the warning icon will appear on the (bottom left) of the main display. The warning icon will also appear in the menu adjacent to the menu Warning group that is related to the error or warning.
- Page 12 Accessories (Included) Deluxe Protective Carrying Case...
-
Page 13: Specifications
Specifications... - Page 14 Frequently Asked Questions about Air Ions...
- Page 15 Frequently Asked Questions about the AIC3Pro...
- Page 16 Calibration, Troubleshooting, Warranty, and Support...
