Planar LA1500R Specifications

SPECIFICATIONS
Planar Part Number
Touchscreen Type
Touch Screen Interface
Transmissivity
Contrast Ratio
Response Time
Horizontal Scan
Viewing Angle
Brightness
(w/o touchscreen)
Pixel Pitch
Refresh Rate
Power Consumption
Input Options
Power Requirements
External Connections
Audio Compatability
Features
Power Supply
Display Active Area
Native Resolution
PLANAR SYSTEMS, INC.
1195 NW Compton Drive
Beaverton, Oregon 97006-1992 USA
1-866-752-6271 (1-866-PLANAR1)
Dimensions
E-mail: ResellerSupport@planar.com
bids@planar.com
Weight
(display and brackets)
Approvals
Operating Temperature
© 2005, Planar Systems, Inc. Planar is a
Service and Support/Warranty
registered trademark of Planar Systems, Inc.
All other trademarks are property of their
respective owners. Technical information in
Mounting Options
this document is subject to change without
notice. Please consult your account manager
for up to date and/or custom configurations.
www.planar.com
LC_0405
PLANAR AMLCD OPEN-FRAME MONITORS
Display Innovation You Depend On
Touch
LA1500RTC - 15" Capacitive and LA1710RTC - 17" Capacitive and
LA 1500RTR - 15" Resistive LA1710RTR - 17" Resistive
LA1500RTC 997-2930-00 LA1710RTC 997-2931-00
LA1500RTR 997-2807-00 LA1710RTR 997-2809-00
7-wire resistive 7-wire resistive
(LA1500RTR)
3M Capacitive 3M Capacitive
(LA1500RTC)
USB touch screen driver USB touch screen driver
(Windows® 95/98/2000/ME/XP. (Windows® 95/98/2000/ME/XP.
Contact Fujitsu for Linux Contact Fujitsu for Linux
support.) support.)
78% 78%
(LA1500RTR)
Up to 88% Up to 88%
(LA1500RTC)
400:1 450:1
(typical)
4 ms rise, 12 ms fall 4 ms rise, 12 ms fall
(typical)
31.5 - 60 KHz 31.5 - 80 KHz
(typical) 150º H, 125º V (+50/-75)* 160º H, V*
350 cd/m 2 260 cd/m
(LA1500RTC)
250 cd/m 2
(LA1500RTR)
.297 mm 0.264 mm
56-75 Hz 56-75 Hz
(operational) 30W (5W standby) 40W (5W standby)
Analog Analog/DVI-D
100-240 VAC, 50/60Hz 100-240 VAC, 50/60Hz
D-sub, 15 pin D-sub, 15 pin, DVI-D
USB (touch screen option) USB (touch screen option)
On-board electronics On-board electronics
support external speakers support external speakers
Anti-glare coating Anti-glare coating
Multi-language support Multi-language support
On screen display (OSD) On screen display (OSD)
External Module with IEC 320 External Module with IEC 320
Connector, USA, Cord-set, Connector, USA, Cord-set,
UL1950 certified. UL1950 certified.
304mm x 228mm ( 338mm x 270mm
15" diagonal)
XGA (1024 x 768) native. SXGA (1280 x 1024) native.
Supports IBM VGA; VESA VGA, Supports IBM VGA; VESA VGA,
SVGA, XGA; and Apple® SVGA, XGA, SXGA; and Apple®
Mac modes Mac modes
14.2"x10.6"x1.9" 14.6"x11.8"x1.8"
W x H x D
(360mm x 270mm x 47mm) (371mm x 299mm x 46mm)
9.2 lbs (4.2 kg) 11.2 lbs (5.1 kg)
Resistive
9.4 lbs (4.3 kg) Capacitive 11.4 lbs (5.2 kg)
CSA, FCC-B, CE, TUV CSA, FCC-B, CE, TUV
0 - 50°C 0 - 50°C
1 year. Extended warranty 1 year. Extended warranty
package available. package available.
Part number 990-0068-00. Part number 990-0068-00.
Adjustable rear panel Adjustable rear panel
mounting brackets included. mounting brackets included.
VESA 75 mm compatible. VESA 100 mm compatible.
Page 6 : Effective April 15, 2005
LA1910RTC - 19" Capacitive
LA1910RTC 997-2811-00
3M Capacitive
(LA1710RTR)
(LA1710RTC)
USB touch screen driver
(Windows® 95/98/2000/ME/XP.
Contact Fujitsu for Linux
support.)
Up to 88%
(LA1710RTR)
(LA1710RTC)
500:1
15 ms rise, 10 ms fall
31.5 - 80 KHz
160º H, V
2 250 cd/m 2
0.294 mm
56-75 Hz
60W (5W standby)
Analog/DVI-D
100-240 VAC, 50/60Hz
D-sub, 15 pin, DVI-D
USB (touch screen option)
On-board electronics
support external speakers
Anti-glare coating
Multi-language support
On screen display (OSD)
External Module with IEC 320
Connector, USA, Cord-set,
UL1950 certified.
376mm x .301mm
(17" diagonal) (19" diagonal)
SXGA (1280 x 1024) native.
Supports IBM VGA; VESA VGA,
SVGA, XGA, SXGA; and Apple®
Mac modes
17.2"x14.3"x3.2"
(436mm x 363mm x 81mm)
15.2 lbs (6.9 kg)
Resistive
Capacitive
CSA, FCC-B, CE, TUV
0 - 50°C
1 year. Extended warranty
package available.
Part number 990-0068-00.
Adjustable rear panel
mounting brackets included.
VESA 75/100 mm compatible.
Non-Touch
LA1500R - 15" LA1710R - 17"
LA1500R 997-2806-00 LA1710R 997-2808-00
400:1 450:1
4 ms rise, 12 ms fall 4 ms rise, 12 ms fall
31.5 - 60 KHz 31.5 - 80 KHz
150º H, 125º V (+50/-75)* 160º H, V*
350 cd/m 2 260 cd/m 2
.297 mm 0.264 mm
56-75 Hz 56-75 Hz
30W (5W standby) 40W (5W standby)
Analog Analog/DVI-D
100-240 VAC, 50/60Hz 100-240 VAC, 50/60Hz
D-sub, 15 pin D-sub, 15 pin, DVI-D
USB (touch screen option) USB (touch screen option)
On-board electronics On-board electronics
support external speakers support external speakers
Anti-glare coating Anti-glare coating
Multi-language support Multi-language support
On screen display (OSD) On screen display (OSD)
External Module with IEC External Module with IEC
320 Connector, USA, Cord- 320 Connector, USA, Cord-
set, UL1950 certified. set, UL1950 certified.
304mm x 228mm 338mm x 270mm
(
15" diagonal) (17" diagonal)
XGA (1024 x 768) native. SXGA (1280 x 1024) native.
Supports IBM VGA; VESA Supports IBM VGA; VESA
VGA, SVGA, XGA; and VGA, SVGA, XGA, SXGA;
Apple® Mac modes and Apple® Mac modes
14.2"x10.6"x1.9" 14.6"x11.8"x1.8"
(360mm x 270mm x 47mm) (371mm x 299mm x 46mm)
7.9 lbs (3.6 kg) 10.1 lbs (4.6 kg)
CSA, FCC-B, CE, TUV CSA, FCC-B, CE, TUV
0 - 50°C 0 - 50°C
1 year. Extended warranty 1 year. Extended warranty
package available. package available.
Part number 990-0068-00. Part number 990-0068-00.
Adjustable rear panel Adjustable rear panel
mounting brackets mounting brackets
included. VESA 75 mm included. VESA 100 mm
compatible. compatible.
*Specified at CR>5:1. All other LCDs specified at CR>10:1.
Display Innovation You Depend On
LA1910R - 19"
LA1910R 997-2810-00
500:1
15 ms rise, 10 ms fall
31.5 - 80 KHz
170º H, V
250 cd/m 2
0.294 mm
56-75 Hz
60W (5W standby)
Analog/DVI-D
100-240 VAC, 50/60Hz
D-sub, 15 pin, DVI-D
USB (touch screen option)
On-board electronics
support external speakers
Anti-glare coating
Multi-language support
On screen display (OSD)
External Module with IEC
320 Connector, USA, Cord-
set, UL1950 certified.
376mm x .301mm
(19" diagonal)
SXGA (1280 x 1024) native.
Supports IBM VGA; VESA
VGA, SVGA, XGA, SXGA;
and Apple® Mac modes
17.2"x14.3"x3.2"
(436mm x 363mm x 81mm)
12.5 lbs (5.7 kg)
CSA, FCC-B, CE, TUV
0 - 50°C
1 year. Extended warranty
package available.
Part number 990-0068-00.
Adjustable rear panel
mounting brackets
included. VESA 75/100 mm
compatible.
