Page 2
CONTENTS 1) IMPORTANT SAFETY INFORMATION 2) CE DECLARATION OF CONFORMITY DISPOSAL POWER REQUIREMENTS 3) INTRODUCTION 4) OVERVIEW 5) UNPACKING AND INSTALLATION 12) CONNECTION 12) OPERATION 14) WARRANTY INFORMATION 15) CONTACT INFORMATION...
! IMPORTANT SAFETY INFORMATION ! RISK OF SHOCK OR ELECTROCUTION! INTERNAL OPERATING VOLTAGES ARE LETHAL! Do not remove top cover, unless specifically instructed to do so in the user manual. This unit contains fuses and other safety components in accordance with BS60065 requirements.
BS EN 60065 in accordance with the regulations 73/23/EEC, 89/336/EEC (from 1 January 1997) CE 94 Peter Qvortrup, Director Audio Note (UK) Limited Viscount House Star Road, Star Trading Estate Partridge Green West Sussex RH13 8RA...
Page 5
INTRODUCTION Thank you for purchasing this Audio Note (UK) product. With the correct care it should give you many years of pleasure and enjoyment. Please take the time to read all of the information in this manual before connecting your new component to an electrical supply or your system, to ensure both your safety and satisfaction.
Page 6
TT has been hand made in the same Austrian factory as our loudspeakers, and by the same skilled artisans. The internal power supply is equipped with Audio Note (UK) custom copper foil capacitors, the same as are used in our amplifiers and preamplifiers. These components have a surprising and audible effect on the sound quality of the turntable, and this is why we chose to use them for the Deluxe TT.
UNPACKING AND INSTALLATION Please take care when unpacking your Deluxe TT. Choose a clean, clear location to unpack your unit. Be aware that the turntable is surprisingly heavy; before attempting to unpack or lift the unit, check the weight and if necessary use more than one person so that it can be moved safely and easily.
Page 9
UNPACKING AND INSTALLATION continued… Sub-platter Turntable Platter...
Page 10
UNPACKING AND INSTALLATION continued… Once the main unpacking procedure, described above, has been competed, assembly of the turntable can begin. Set the lid and platter to one side, and place the turntable on a suitably level, stable, and vibration free surface. Before installing the sub-platter and platter, it is advisable to perform the initial tonearm installation.
Page 11
UNPACKING AND INSTALLATION continued… As is stated on the label, the bearing has already been fully charged with oil, so no extra oil needs to be added. (The additional syringe of oil supplied with the turntable is for occasional re- lubrication purposes.
Page 12
UNPACKING AND INSTALLATION continued… Remove the transit screw that is located to the right of the bearing / motor aperture (shown above). This releases the suspension. Install the belt; place it around the sub-platter and then the motor pulley(s). You will notice that there are two grooves on the pulley(s);...
Page 13
UNPACKING AND INSTALLATION continued… Using the supplied 4mm Allen key, adjust each bolt so that the underside of the platter sits 5mm above the surface of the plinth. Turn the bolts clockwise to raise the platter / increase the gap between platter and plinth, and anti-clockwise to lower the platter / reduce the gap between platter and plinth.
Special Note – Make sure that all connections are tight and clean. For best results use good quality audio interconnects and mains cables. For best results and performance, we recommend our own Audio Note (UK) range of power, interconnects and loudspeaker cables. For further information, please consult your nearest Audio Note (UK) dealer, or alternatively please feel free to contact us directly.
Page 15
OPERATION continued… Bedding in Your new turntable requires roughly 100 hours of initial use (called “bedding in”) before optimum performance is realized. Cleaning No special maintenance is required for the Deluxe TT. Use a soft, clean lint free cloth to remove any surface marks from the plinth, platter and lid.
Audio Note (UK) warrants this product to be free from defects in materials and workmanship for two years from the original date of purchase from an appointed Audio Note (UK) dealer, and agrees to covers the cost of parts and associated labour required to correct such defects, subject to terms & conditions.
CONTACT INFORMATION If in the future your Audio Note (UK) product requires servicing, or if you require technical support or have any questions regarding this or any of our other products, please contact your local Audio Note (UK) dealer. Alternatively, please feel free to contact us directly: -...
