  • Page 1 TSA300 R ACTIVE POWERED BASSREFLEX SUBWOOFER SYSTEM...
  • Page 2 INHALTSVERZEICHNIS TABLE OF CONTENT TABLE DES MATIÈRES SOMMARIO INDICE BEDIENUNGSANLEITUNG USER’S MANUAL MODE D’EMPLOI MANUALE D´USO MANUAL DE USO...

  • Page 3: Technische Daten

    Bitte lesen Sie die Bedienungsanleitung vollständig durch, bevor Sie mit der Instal- lation beginnen und den Verstärker in Betrieb nehmen. TECHNISCHE DATEN TSA300R Subwoofer 30 cm (12“) Ausgangsleistung RMS 1 x 300 W Ausgangsleistung Max. 1 x 600 W Tiefpassfilter 50 –...
  • Page 4 +12V – 45 x 14 mm 45 x 14 mm 45 x 14 mm ZEUS ZX 82 A TITAN TDA 200 R TITAN TDA 250 R POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION HIGH EFFICIENCY CLASS D AMPLIFIER...
  • Page 5 4 mm 45 x 14 mm 45 x 14 mm LEVEL PROTECT POWER ZX 82 A FUSE TITAN TDA 200 R TITAN TDA 250 R OOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION 50Hz 150Hz ASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER 400 WATTS MAX.
  • Page 6 +12V BASS BOOST +12V – – 45 x 14 mm 45 x 14 mm 12dB TITAN TDA 200 R TITAN TDA 250 R AUDIO INPUT SCHUTZSCHALTUNG POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER Die PROTECT LED [ 17 ] leuchtet rot auf, wenn das Gerät überhitzt ist, oder ein Kurzschluss anliegt.

  • Page 7: Fehlerbehebung

    FEHLERBEHEBUNG Falls Sie nach dem Einbau Probleme haben, befolgen Sie die nachfolgenden Punkte zur Fehlerbehebung: Punkt 1: Den Verstärker auf ordnungsgemäße Anschlüsse überprüfen. Prüfen Sie, ob die POWER aufleuchtet. Ist dies der Fall, fahren Sie mit Schritt 3 fort, falls nicht, fahren Sie hier fort. 1.

  • Page 8: Specifications

    Please read the user‘s manual carefully before the installation and the first operation of the amplifier. SPECIFICATIONS TSA300R Subwoofer 30 cm (12“) Output Power RMS 1 x 300 W Output Power Max 1 x 600 W Lowpass Filter 50 – 150 Hz @ 12/18dB/Octave Subsonic Filter Fixed at 15 Hz Phase Shift...

  • Page 9: Important Notes Prior To Installation

    +12V – 45 x 14 mm 45 x 14 mm 45 x 14 mm ZEUS ZX 82 A TITAN TDA 200 R TITAN TDA 250 R POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION HIGH EFFICIENCY CLASS D AMPLIFIER...

  • Page 10: Input Sensitivity

    4 mm 45 x 14 mm 45 x 14 mm LEVEL PROTECT POWER ZX 82 A FUSE TITAN TDA 200 R TITAN TDA 250 R OOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION 50Hz 150Hz ASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER 400 WATTS MAX.
  • Page 11 45 x 14 mm 45 x 14 mm 12dB AUDIO INPUT TITAN TDA 200 R TITAN TDA 250 R PROTECTION CIRCUIT POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION The PROTECT LED [ 17 ] lights up red, when the amplifier is overheated, or a short circuit occurs respective...

  • Page 12: Troubleshooting

    TROUBLESHOOTING If you are having problems after installation follow the Troubleshooting procedures below. Procedure 1: Check Amplifier for proper connections. Verify that POWER LED lights up green. If this is the case, skip to Step 3, if not continue. 1. Check in-line fuse on battery positive cable. Replace if necessary. 2.

  • Page 13: Caractéristiques

    Veuillez s’il vous plaît lire attentivement toutes les instructions d’installation avant que vous installiez l’amplificateur et le fassiez fonctionner. CARACTÉRISTIQUES TSA300R Subwoofer 30 cm (12“) Puissance de sortie RMS 1 x 300 W Puissance de sortie Max. 1 x 600 W Filtre passe-bas 50 –...
  • Page 14 RECOMMANDATIONS AVANT L’INSTALLATION - Cet appareil convient exclusivement au branchement à un système de 12 volt à masse négative. - La chaleur provenant de l’utilisation nécessite un espace de montage avec une circulation de l’air suffisante. Il est important que les canaux de refroidissement de l’appareil de refroidissement ne soient pas en contact avec une tôle ou une surface, qui pourraient causer une réduction de la circulation de l’air.
  • Page 15 4 mm 45 x 14 mm 45 x 14 mm LEVEL PROTECT POWER ZX 82 A FUSE TITAN TDA 200 R TITAN TDA 250 R 50Hz 150Hz OOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION ASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER 400 WATTS MAX.

  • Page 16: Circuit De Protection

    BASS LEVEL BASS BOOST +12V – – 45 x 14 mm 45 x 14 mm 12dB TITAN TDA 200 R TITAN TDA 250 R AUDIO INPUT CIRCUIT DE PROTECTION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER La PROTECT LED [ 17 ] s´éclaire en rouge quand l´ampli est en surchauffe, ou lorsqu’un un court circuit est...

  • Page 17: Dépannage

    DÉPANNAGE Si vous éprouvez des difficultés après l’installation,appliquez les procédures de dépannage ci-dessous. Procédure 1: Vérifiez que les connexions de l’ampli sont bien mises. Vérifiez que le POWER LED est allumé en vert. Si c‘est le cas e, passez à l‘étape 3, sinon poursuivez. 1.

  • Page 18: Dati Tecnici

    Per favore leggere le istruzioni per il montaggio integralmente, prima di montare l’amplificatore e di metterlo in funzione. DATI TECNICI TSA300R Subwoofer 30 cm (12“) Potenza di uscita RMS 1 x 300 W Potenza di uscita Max. 1 x 600 W Filtro passa basso 50 –...
  • Page 19 INDICAZIONI IMPORTANTI PRIMA DEL MONTAGGIO - Questo apparecchio e adatto unicamente ad essere collegato con un sistema elettrico a 12 Volt con massa negativa. - Il calore irradiato durante l’erogazione di potenza richiede un posizionamento con una sufficiente circolazione d’aria. E molto importante che le alette di raffreddamento del dissipatore non siano adiacenti ad una paratia che possa limitare la circolazione d´aria.
  • Page 20 4 mm 45 x 14 mm 45 x 14 mm X-OVER SLOPE 180° PROTECT POWER LEVEL ZX 82 A TITAN TDA 200 R TITAN TDA 250 R FUSE 50Hz 150Hz OOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION ASS D AMPLIFIER...
  • Page 21 +12V +12V BASS BOOST – – 45 x 14 mm 45 x 14 mm 12dB TITAN TDA 200 R TITAN TDA 250 R AUDIO INPUT CIRCUITI DI PROTEZIONE POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER Il PROTECT LED [ 17 ] si accende in rosso quando l´amplificatore è...

  • Page 22: Risoluzione Dei Problemi

    RISOLUZIONE DEI PROBLEMI Se incontraste dei problemi dopo l’installazione,seguite le procedure per la localizzazione e la riparazione dei guasti elencate di sotto. Procedura 1: Controllate che l’amplificatore abbia i collegamenti adeguati. Controllate che la POWER LED sia accesa in verde. Se questo è il caso, passare al numero 3, altrimenti continuare. 1.

  • Page 23: Datos Técnicos

    Lea completamente las instrucciones de montaje antes de proceder a montar el amplificador y ponerlo en funcionamiento. DATOS TÉCNICOS TSA300R Subwoofer 30 cm (12“) Potencia de salida RMS 1 x 300 W Potencia de salida Max. 1 x 600 W Filtro de paso bajo 50 –...
  • Page 24 INDICACIONES IMPORTANTES PREVIAS AL MONTAJE - Este equipo es adecuado sólo para la conexión a un sistema de 12 voltios con tierra negativa. - El calor irradiado hace que sea importante que instale el aparato en un lugar con suficiente circulación de aire.
  • Page 25 LEVEL 4 mm 45 x 14 mm 45 x 14 mm PROTECT POWER FUSE ZX 82 A TITAN TDA 200 R TITAN TDA 250 R 50Hz 150Hz OOFER STATION POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION ASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER...
  • Page 26 +12V BASS LEVEL +12V – – BASS BOOST 45 x 14 mm 45 x 14 mm TITAN TDA 200 R TITAN TDA 250 R 12dB AUDIO INPUT CIRCUITO DE PROTECCIÓN POWERED SUBWOOFER STATION POWERED SUBWOOFER STATION HIGH EFFICIENCY CLASS D AMPLIFIER HIGH EFFICIENCY CLASS D AMPLIFIER El POWER LED [ 17 ] encendido en rojo significa que el Amplificador esta en cortocircuito o sobrecalentado.

  • Page 27: Solución De Problemas

    SOLUCIÓN DE PROBLEMAS Si tiene problemas después de la instalación,siga los procedimientos de solución de problemas descritos a continuación. Procedimiento 1: Verifique que el amplificador esté bien conectado. Compruebe que esté encendida la luz de POWER LED en verde. Si este es el caso, al paso 3, de otra manera, continúe. 1.
  • Page 28 Audio Design GmbH Am Breilingsweg 3 · D-76709 Kronau/Germany Tel. +49 7253 - 9465-0 · Fax +49 7253 - 946510 www.audiodesign.de · www.hifonics.de © Audio Design GmbH, All Rights Reserved...
