  • Page 1 65BDL3052T V1.01 www.philips.com/welcome User Manual (English)
  • Page 2 65BDL3052T Safety Instructions TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. Warnings and Precautions The Socket-outlet should be installed near the apparatus and be easily KNOW THESE SAFETY SYMBOLS accessible.
  • Page 3 65BDL3052T Important Safety Instructions WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation 1. Read these instructions. instructions. 2. Keep these instructions. WARNING: The Class I apparatus shall be connected to a mains socket 3.
  • Page 4 65BDL3052T IMPORTANT INFORMATION Federal Communications Commission (FCC) Notice (U.S. Only) If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, Note: This equipment has been tested and found to can be avoided by taking simple precautions such as: comply with the limits for a Class A digital • Using cabinets or stands recommended by the manufacturer of the device, pursuant to part 15 of the FCC Rules.
  • Page 5 65BDL3052T Information for U.K. only WARNING – THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: 1. Remove fuse cover and fuse. Electric, Magnetic and Electronmagnetic Fields 2.
  • Page 6 65BDL3052T China RoHS 警告 此为 A 级产品。在生活环境中，该产品可能会造成无线电干扰。 根据中国大陆 《电子电气产品有害物质限制使用标识要求》 ， 以下部分 在这种情况下，可能需要用户对干扰采取切实可行的措施。 列出了本产品中可能包含的有害物质的名称和含量。 有害物质 六价铬 多溴 多溴二 零部件名称 仅适用于非热带气候条件下安全使用 : 铅 汞 镉 联苯 苯醚 (Pb) (Hg) (Cd) (VI)) (PBB) (PBDE) 汉 文 仅适用于非热带气候条件下安全使用。 塑料外框 蒙古文 后壳 藏 文 CCFL 维...
  • Page 7 Please find out about the local regulations on how to dispose of your old responsibility to dispose of your waste equipment display from your local philips dealer. by handing it over to a designated collection point for the recycling of waste electrical and electronic (For customers in Canada and U.S.A.)
  • Page 8 65BDL3052T Helpline number: 1800-425-6396 (Monday to Saturday, 9 a.m. to 5:30 pm) Centralized E-waste collection center Address: TPV Technology India Private Limited, 59, Maheswari Nagar, 1st Main Road, Mahadevapura Post, Whitefield Road Bangalore, Karnataka, PIN: 560048, Tel: 080-3023-1000 E-mail: india.callcentre@tpv-tech.com Batteries For EU: The crossed-out wheeled bin implies that used batteries should not be put to the...

  • Page 9: Table Of Contents

    65BDL3052T Table Of Contents 5.14. Supplementary ................40 OSD Menu ................42 Unpacking and Installation ............1 6.1. Navigating the OSD Menu ..........42 6.2. OSD Menu Overview ............42 1.1. Unpacking ..................1 1.2. Package Contents ................1 Supported Media Formats ............ 48 1.3. Installation Notes .................1 Input Mode ................50 1.4.

  • Page 10: Unpacking And Installation

    65BDL3052T Unpacking and Installation 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Due to the size and weight of this display it is recommended for two people to move it. •...

  • Page 11: Mounting On A Wall

    65BDL3052T 1.4. Mounting on a Wall To mount this display to a wall, you will have to obtain a standard wall-mounting kit (commercially available). We recommend using a mounting interface that complies with TUV-GS and/or UL1678 standard in North America. Protective Sheet VESA Grid Table...

  • Page 12: Parts And Functions

    65BDL3052T Parts and Functions 2.1. Control Panel MUTE INPUT MENU [ ] button Remote control sensor and power status indicator Use this button to turn the display on or put the display to standby. • Receives command signals from the remote control. •...

  • Page 13: Input/Output Terminals

    65BDL3052T 2.2. Input/Output Terminals RS232 RS232 100-240V TOUCH USB DP IN 50-60Hz 2.5A HDMI 1 IN HDMI 2 IN RJ45 AC IN AUDIO OUT AC power input from the wall outlet. Audio output to external AV device. MAIN POWER SWITCH USB 2.0 PORT/ USB 3.0 PORT Switch the main power on/off.
  • Page 14 65BDL3052T 2.2.1. Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace batteries: 1. Press and then slide the cover to open it. 2. Align the batteries according to the (+) and (–) indications inside the battery compartment.

  • Page 15: Remote Control

    65BDL3052T 2.3. Remote Control ] LIST button No function. 2.3.1. General functions NAVIGATION buttons Root Menu: Go to Smart picture OSD. Main Menu: Move the highlight bar up to adjust the selected item. IR Daisy Chain Menu: Increase controlled Group ID number. Root Menu: Go to Audio source OSD. Main Menu: Move the highlight bar down to adjust the selected item.
  • Page 16 65BDL3052T 2.3.2. ID Remote Control Press [ID] button. The red LED blinks twice. 1. Press [ID SET] button for more than 1 second to enter the ID You can set the remote control ID when you want to use this remote Mode.
  • Page 17 5. All media or pdf files should be put at the folder, which is named “philips” with sub-folder, under the root directory of the specified storage (internal/USB/SD Card). All sub-folders (video/photo/music/ pdf) are named by media types and shouldn’t be changed.
  • Page 18 65BDL3052T » when zoom in/out has been not performed, [ ] [ ] VOLUME button Adjust volume. The buttons are only controlled by Scalar. Press to go to the next page. Press to go to the previous page. ] button Confirm an entry or selection.

  • Page 19: Usb Cover

    65BDL3052T 2.4. USB Cover • Use the USB cover and screws to hide the USB stick and Micro SD card. USB-1 USB-1 USB-2 USB-2 • Maximum suitable USB sticker size: USB-1: 20(W)x8(H)x60(L) mm USB-2: 20(W)x8(H)x30(L) mm...

  • Page 20: Connecting External Equipment

    65BDL3052T Connecting External Equipment 3.1. Connecting External Equipment (DVD/VCR/VCD) 3.1.1. Using HDMI video input DVD / VCR / VCD HDMI Out [HDMI IN] HDMI 1 IN HDMI 2 IN 3.2. Connecting a PC 3.2.1. Using VGA input [VGA AUDIO IN] Audio Out [VGA IN] VGA Out...

  • Page 21: Connecting Audio Equipment

    65BDL3052T 3.2.3. Using DisplayPort input DisplayPort Out RS232 DP IN HDMI 1 IN HDMI 2 IN [DisplayPort IN] 3.3. Connecting Audio Equipment 3.3.1. Connecting an external audio device [AUDIO OUT] Audio In Stereo Amplifier 3.4. Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a menu board.

  • Page 22: Ir Connection

    65BDL3052T DISPLAY 1 DISPLAY 2 [RJ-45] [RJ-45] [RS-232C OUT] [RS-232C IN] 3.5. IR connection External IR Receiver DISPLAY 1 DISPLAY 2 [IR IN] [IR IN] [IR OUT] DISPLAY 1 DISPLAY 2 [RS-232C OUT] [RS-232C IN] NOTE: 1. This display’s remote control sensor will stop working if the [IR IN] is connected. 2.

  • Page 23: Ir Pass-Through Connection

    65BDL3052T 3.6. IR Pass-through Connection [IR OUT] DVD / VCR / VCD [IR IN] (DVD / VCR / VCD) Remote Control...

  • Page 24: Touch Operation

    65BDL3052T 3.7. Touch Operation Zoom in This display is equipped with a touch-sensitive screen and supports Touch the target on the screen with two fingertips holded together and the Windows Touch features either by singletouch or multitouch move them apart to zoom in (magnify) the screen image. operation.
  • Page 25 RJ45 5. SDK, enclosed in the website www.philips.com/signagesolutions-support, for 20-point touch application development is for Windows and Linux. 6. For Mac OS 10.10, it is recommended using the tool “TouchService” to re-define the touch position and simulate mouse operation(single touch).

  • Page 26: Operation

    65BDL3052T Operation • Admin mode will show five icons: “Settings”, “Apps”, “Network” “Storage” and “Help”. NOTE: The control button described in this section is mainly on the • When you leave admin mode, system will return to last source. remote control unless specified otherwise. 1)Home page of admin mode, this page has five items: “Settings”, “Apps”, “Network”...

  • Page 27: Media Player Introduction

    65BDL3052T 4.4. Media Player introduction: 4 ） Ethernet page 1. Home page of Media Player, this page has three items: “Play”, “Compose” and “Settings”. Play : select playlist to play. Compose: edit playlist. Settings: setting play properties. 5) Wi-Fi (Optional) 2.
  • Page 28 7. If you choose “Sort” in the slide bar, you can change the order of media source. files one by one. All media files should be placed in /philips/ of root directory. For example, videos: {root dir of storage}/philips/video/ photos: {root dir of storage}/philips/photo/ music : {root dir of storage}/philips/music/ 8.
  • Page 29 Note : if playlist file contains video and music, when the pd plays music file, the screen will be black. Step 2. Copy mpplaylistX.txt to “philips” folder of internal storage. You may use FTP to do this. File path : /storage/emulated/legacy/philips Ex.

  • Page 30: Browser Manual

    65BDL3052T 4.5. Browser manual 4. Press “Option” then left side will pop up a list Import : Import url list file 1. Home page of Browser app, this page has one item: “Settings”. Export : Export url list file Press Settings then enter next page. Delete all : Delete all url record on right side Back : left side list will be closed.
  • Page 31 65BDL3052T • Import file and url will show on list • Dialog shows path file will be saved and file’s name. Press “save” button then urls on list will be saved. • File format for import Format should be like below with file extension “txt” 5.

  • Page 32: Pdf Reader Play

    FILE 1 and FILE 7. The pencil icon means the playlist is non-empty. Step 2. Copy bookmarklist.txt to “philips” folder of internal storage. You may use FTP to do this. File path : /storage/emulated/legacy/philips (for DL, PL) Ex.
  • Page 33 65BDL3052T 4. If an empty playlist is chosen, the app will guide you to select the media source. All media files should be placed in /philips/ of root directory. For example, pdfs : {root dir of storage}/philips/pdf/ 7. If you choose “Sort” in the slide bar, you can change the order of files one by one.

  • Page 34: Cmnd & Play

    Setup CMND & Play server address Ex. /storage/emulated/legacy/philips/pdfplaylist1.txt 2) Account Setup CMND & Play account Step 3. Prepare pdf files to “pdf ” folder under “philips” folder, 3) PIN Code internal storage only. Setup CMND & Play PIN code Ex. /storage/emulated/legacy/philips/pdf/xxx.pdf (4) Version /storage/emulated/legacy/philips/pdf/yyy.pdf...
  • Page 35 65BDL3052T 4.8.1. OSD Menu operation: If customer installed apk,user can select customer installed apk in list • Case 1: Not set up Custom App case. RCU: Source -> Custom Customer app will show up and focus on first item automatically. If set up customer APK, PD will open customer app when switch source to Customer mode.

  • Page 36: Signage Display

    65BDL3052T Signage display F. Gateway (2) Mac Address Ethernet 5.1. Setting Main Switch Disable Main items: Enable To see available networks, turn Ethernet on. (1) WI-Fi (Show up when plug in Wi-Fi dongle) Ethernet Configuration Connection Type (2) Ethernet Static IP Mac Address 00:24:67:21:57:ea (3) Proxy...

  • Page 37: Proxy

    65BDL3052T 5.4. Proxy Signage Display General settings Browser connect to Proxy server and ask Proxy server to connect Signage Display Name PD_0024672157ea some website on Internet. Boot Logo Screenshot Server settings Enable/Disable to turn on/off Proxy server. Email Notification • Click “Enable”...
  • Page 38 65BDL3052T 2) When boot logo selected, PD will check if there is bootanimation. Case 2 zip under USB and SD card. The users do not settle customized boot logo. PD find bootanimation.zip file under SD and USB. The screen will show bootanimation.zip and select the first file automatically.
  • Page 39 Set up screenshot start time. folder automatically. Note: (2) The picture will save to philips/Screenshot/. (1) If no start time, the screen will show current time automatically (2) Just press Back key to exit dialog for Set up (3) Start time cannot be newer than End time. It will show Error...
  • Page 40 65BDL3052T 6)Purge Screenshots Set up purge timeframe. One day or One week. Send screenshots via email After check this item, it will send screenshot to email of administrator Please refer to 6.2.1 Email notification Note: Please confirm Email setting is done. 5.5.2.
  • Page 41 65BDL3052T Yahoo Email Security Setting English a-z and A-Z II. Number 0-9 If Yahoo Email is not working when setting complete, please confirm “Allow apps that use less secure sign in” item is enabled. 2) Password 2)Manager Email Set up FTP password. Email Note: Set up Receiver mail account...
  • Page 42 65BDL3052T Set up completed screen: 3. Remote Control Via Enable/Disable to Control Remote Control On/Off User can input Server address. If server does not registered, it will ask user for PIN code. Bind status: (1) Will show network is disconnected if not yet connects to network. 3)Storage Path Show default path: Internal storage Note:...
  • Page 43 65BDL3052T 5.5.3. Source Settings (4) Will show Server is binded if Sever binded successfully. 1. Media Player Can Edit Media Player play list and effect settings. (5)Will show Error PIN code if input incorrect PIN code. (1) Open Media Player Player List edit page. 4.
  • Page 44 65BDL3052T Open Browser setting page. 4. PDF Player (1) Open PDF Player Player List edit page. 3. CMND & Play 1) Server (2) Open PDF Player effect edit page. Setup CMND & Play server address 2) Account Setup CMND & Play account 3) PIN Code Setup CMND &...
  • Page 45 65BDL3052T Function introduction After setup, it will show App name (1) Save Case2. Setup Custom App. (there is a checked circle on right) Select App and press Save key to save it. (2) Forget Press Forget key to clean previous stored data (3) Cancel No change, close window directly If no customer installed apk, the list will be blank.

  • Page 46: System Tools

    (2) Only clear Philips folder under Internal storage. Note: (3) Only clear Philips folder under USB storage. If no Philips folder exists in USB or SD card, it will be created automatically. (4) Only clear Philips folder under SD card.

  • Page 47: Clone Media File

    65BDL3052T 5.6.3.2 Import Signage Display Settings Import settings.db from Philips folder under USB or SD card. (1) Import settings.db. Include OSD setting, Android settings but “Signage Display Name” and “Boot Logo” (2) Auto install 3 party apk from Philips/app/ List all available storage (Internal/SD/USB) 5.8.

  • Page 48: Security

    65BDL3052T 5.10. Security 5.12. Developer options (1) Credential storage Android developer options. For more information please visit https://developer.android.com/index.html Control panel of certificates 5.13. About Main info in About: (1) System updates (2) Android version (3) Kernel version (4) Build number 5.11.

  • Page 49: Supplementary

    65BDL3052T 5.14. Supplementary p 1 0 part0 p 0 0 part1 5.14.1. Quick Info a. The first line You can press “Info + 77” to startup quick info. 1920 and 1080 define the width and height of the screen resolution. Quick info will show “Network”...
  • Page 50 2.1 The rest of steps is the same as above. Please note, each model may have different <internal storage path>. (b) Via Adb Shell 1. Make sure that your PC can connect to Philips Android Signage Display using adb. 2. Prepare your apk in a folder(for example, C:\apkfolder) on PC.

  • Page 51: Osd Menu

    65BDL3052T OSD Menu 6.2. OSD Menu Overview An overall view of the On-Screen Display (OSD) structure is shown 6.2.1. Picture menu below. You can use it as a reference for further adjusting your display. 6.1. Navigating the OSD Menu Picture Brightness Screen Contrast...
  • Page 52 65BDL3052T Color control Zoom mode The color levels of red, green, and blue are adjusted by the color bars. HDMI, DP, VGA, OPS: {Full} / {4:3} / {Real} / {21:9}/ {Custom}. Playing media in Media Player : {Full} / {4:3} / {Real} / {21:9} R: Red gain, G: Green gain, B: Blue gain. There are no function when BROWSER, CMND &...
  • Page 53 65BDL3052T Auto adjust 6.2.4. Configuration1 menu Press “Set” to detect and adjust H position, V position, Clock, Phase automatically. Picture Switch on state Force on NOTE: VGA input only. Screen Panel saving Action Audio RS232 routing RS232 Screen reset Configuration 1 Boot on source Action Reset all settings in the Screen menu to factory preset values.
  • Page 54 Reset all settings in Configuration2 menu to the factory preset values. • {User} 1. If Logo set to ON, both scalar Philips logo and android animation Philips logo will show. 2. If Log set to OFF, neither scalar Philips logo nor android animation...
  • Page 55 65BDL3052T 6.2.6. Advanced option menu • {ACS}: Apply brightness value (backlight) which is adjusted by MIC tool. The default value before adjustment is the same as OSD brightness value, e.g., 70) Picture IR control Unlock • Type: {Off} (Default)/{SW Tool}/{OSD Only} Screen Power LED Light • Source resolution: {Full HD}(Default)/ {4K}...
  • Page 56 65BDL3052T • Schedule list: You can set 7 schedules. Following table is the action for Android board with different power mode. • Enable: Enable/disable schedule. If set start/end time is conflict or empty, input is empty or time conflict with other schedule list, you DC off/on: press power button by RC cannot enable schedule.

  • Page 57: Supported Media Formats

    65BDL3052T Supported Media Formats USB Multimedia Codec Formats Video Decode Type Video Codec Container Decode Encode Channel Remark MPEG program stream (.DAT, .VOB, .MPG, .MPEG) MPEG transport stream (.ts) Max Resolution: 1080P@60fps MPEG1/2 MPEG1/2 MP4 (.mp4) Max Bit Rats : 40Mbps AVI (.avi) MKV (.mkv) MP4 (.mp4)
  • Page 58 65BDL3052T Image Decode Type Image Codec Photo Decode Encode Channel Remark Max Resolution: 7000 x 7000 JPEG JFIF file format 1.02 File Format: JPG, JPEG The limitation of max resolution depends on DRAM Max Resolution: 15360 x 8640 File Format: BMP The limitation of max resolution depends on DRAM Max Resolution: 15360 x 8640...

  • Page 59: Input Mode

    65BDL3052T Input Mode VGA Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz WVGA 70 Hz 33.75 MHz 16:9 Wide Video Graphic Array...

  • Page 60: Pixel Defect Policy

    However, pixel or sub-pixel defects on the PDP / TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any Plasma- & LCD- displays with an unacceptable number of defects will be repaired during the warranty period in line with your local guarantee conditions.

  • Page 61: Dark Dot Defects

    Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips Plasma / LCD- display must have pixel or sub- pixel defects exceeding the tolerances listed in the following table.

  • Page 62: Cleaning And Troubleshooting

    65BDL3052T Cleaning and Troubleshooting 10.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.

  • Page 63: Troubleshooting

    65BDL3052T 10.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back of the 2. Make sure the power switch is switched on. display is not switched on. 3.
  • Page 64 65BDL3052T How to setup the settings in the menu to Daisy chained by RS232 and no IR cable 1. The first display sets as “Primary” on OSD control all the monitors at the same time and (Advanced option/IR control item), others set as individually via RC? “Secondary”. 2. The setup OSD will show on Top-Left of display. (Toggle MENU will show again if it disappear) 3.

  • Page 65: Technical Specifications

    65BDL3052T Technical Specifications Display: Item Specifications Screen Size (Active Area) 163.9 cm / 64.5 inches Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.372 (H) x 0.372 (V) [mm] Displayable colors 10 bits(D), 1.07 Billion colors Brightness (typical) 350 cd/m Contrast ratio (typical)
  • Page 66 65BDL3052T General: Item Specifications Power Input 100 - 240V~, 50 - 60Hz, 5.5A Power Output 100 - 240V~, 50 - 60Hz, 2.5A Power Consumption (Max) 295 W Power Consumption (typ.) 165 W Power Consumption (Standby & Off) <0.5 W Dimensions (Without Stand) [W x H x D] 1475.4 x 850.4 x 101.0 mm Weight (Without Stand) 40.58 Kg...
  • Page 67 2017 © Koninklijke Philips N.V. All rights reserved. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V. Specifications are subject to change without notice.
