PEARL DRUM PEDAL
P-1030R / P-1030
Instruction Manual
Congratulations on your purchase!
To get optimum performance of your "P-1030R / P-1030" Drum Pedal,
please read this Instruction Manual before playing.
Beater Setting Stopper
Beater Holder Link
Control Core Quad Beater
Key Bolt (for Beater
Key Bolt
Angle Adjustment)
(for Beater Setting)
Gauge
Dual Chain
Beater Angle Cam
Spring
Adjustment Knob
(for Hoop Clamp)
Footboard
Upper Nut
Lower Nut
Click Lock
Key Bolt
(for PowerShifter)
Anchor Screw
Wing Bolt (for Hoop Clamp)
Heel Plate
Power Plate
DuoBeat Beater
P-1030R
P-1030
Advertisement
Related Manuals for Pearl P-1030R
Summary of Contents for Pearl P-1030R
- Page 1 PEARL DRUM PEDAL P-1030R / P-1030 Instruction Manual Congratulations on your purchase! To get optimum performance of your "P-1030R / P-1030" Drum Pedal, please read this Instruction Manual before playing. Beater Setting Stopper Beater Holder Link Control Core Quad Beater Key Bolt (for Beater...
- Page 2 Beater Setting Beater Angle Adjustment Insert the Control Core Quad Beater into the Beater Holder Depending on your preference, the Beater can be Link with the desired face toward the bass drum head until positioned closer or farther away from the Bass Drum Head. it stops against the Beater Setting Stopper.
- Page 3 Hoop Clamp system To attach your pedal to the bass drum, slide the bass drum The P-1030R / P-1030 Pedal features our patented Click hoop between the Hoop Clamp and the bottom lip of the Lock spring tension retention system. To adjust the spring pedal.
- Page 4 Rubber Mats To maximize traction of the rubber mats underneath the Power Plate keep them clean and dust free using a damp cotton towel. CAUTION Periodically check all Allen Screws for tightness and tighten them with the provided hexagonal wrench as needed.
