Quick User Guide: Medstrom Aria PRO

Power:

• Ensure the rocker switch at the side of the control unit is in the ON
position.
• Press the POWER/MUTE/UNLOCK button to switch the control
unit on.
• A green LED will light up when the control unit is in use.

Unlock:

• The control unit will automatically lock out after 3 minutes of
inactivity.
• Press and hold the POWER/MUTE/UNLOCK button for 3
seconds to unlock the control panel.

Constant Immersion:

• The control unit will default to Constant Immersion mode when
switched on.
• Constant immersion is a reactive therapy in which all air cells
maintain constant pressure to maximise contact area and
redistribute pressure.
• A green LED will illuminate on this button when Constant
Immersion is active.

Gradient Immersion:

• Gradient Immersion (or ALP therapy) is an active therapy in
which air cells will alternate to provide off-loading.
• This mode can be selected by pressing this button.
• The cell cycle options of 5, 10 or 15 minutes can also be
changed by pressing this button.
• The chosen cycle time will be visible on the digital display.

Max Inflate:

• Max Inflate (repositioning mode) will rapidly inflate the mattress
to provide a stable surface for nursing procedures or patient
repositioning.
• As a safety feature, Max Inflate will automatically return back to
the previous therapy setting after 20 minutes to avoid the patient
being on peak pressures for long periods.
• An orange LED will be visible on this button when it is active.

Comfort Settings:

• Press the +/- button to adjust the comfort setting from -2 (softest)
to +2 (firmest).
• The control unit will automatically default to 0 (medium).
• All comfort settings are within a therapeutic window and adjusting
the setting will not alter clinical therapy.
• The chosen comfort setting will be visible on the digital display.

Pressure Monitoring:

• This LED detects changes of pressure inside the mattress. If blue,
the pressures are adjusting (e.g. inflating). If green, the pressures
are static.
• Note: When this LED is green on initial inflation, it can be a useful
indication that the mattress is fully inflated and ready for patient use.
For clinical and technical support 24/7/365, call Medstrom:
UK: 0845 371 1717
IRE: 01 686 9487
DO NOT REMOVE FROM MATTRESS
Max. Patient Weight: 250kg

Control Unit Functions

SM547_REV3_0121
!
