100, 200, 500, 700, & FMA Series
1. Read these instructions. Follow all instructions. Keep these instructions. Heed all warnings.
2. Use eye protection and protective gloves while unpacking the cabinet.
3. Make sure there are enough people to help safely unload and install the system. Empty rack cabinets alone may weigh up to 200 lbs. Moving rack
cabinets can present dangers to other personnel and the incorporated equipment.
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
Floor-Standing Cabinets
CAUTION
TELEPHONE: (800) 876-3333
FAX: (800) 765-3435
1/12
AtlasSound.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Atlas 100 Series

Summary of Contents for Atlas 100 Series

  • Page 1 1/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets CAUTION 1. Read these instructions. Follow all instructions. Keep these instructions. Heed all warnings. 2. Use eye protection and protective gloves while unpacking the cabinet. 3. Make sure there are enough people to help safely unload and install the system. Empty rack cabinets alone may weigh up to 200 lbs. Moving rack cabinets can present dangers to other personnel and the incorporated equipment.

  • Page 2: Important Safety Instructions

    Final equipment installer must follow individual equipment manufacturer’s installation instructions. b. The 100 Series stand-alone cabinet is the most economical cabinet and features fixed rails. c. The 200 Series is also a stand-alone cabinet; however, the fixed rails are replaced with fully adjustable rails.
  • Page 3 (top left on most models) NOTE: 100 Series cabinets do not require any adjustments; DID YOU KNOW? The Atlas Sound logo plug may be removed and replaced by Atlas Sound M-1A IR NOTE: 100 Series cabinets do not require any adjustments;...
  • Page 4 4/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets 7. Initial Rear Door Setup Initial Door Setup: DID YOU KNOW? The rear flush door (typically supplied with most cabinets) may be hung left or NOTE: The rear flush door (typically supplied with most right-hinged as required by the final installation.
  • Page 5 5/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets g. If required, the rotation and lock position may be changed to suit the user: Open the door. Remove the bolt in the back of the lock. iii. Carefully remove the lock cam and lock washer. iv.

  • Page 6: Side Panel Installation

    6/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets iv. Mount a caster on each caster installation point by using the ¼-20 KEPS nuts to finally attach both the metal stiffener bracket and the caster. e. FMA Series cabinets: Locate the (4) caster installation points on the metal truck bracket.
  • Page 7 7/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets b. FMA-LRPV Series Side Panels for FMA Series cabinets: DID YOU KNOW? The FMA-LRPV series side panels are more like doors than standard lift off panels. They are extremely convenient. Unlock them and open.

  • Page 8: Floor Installation

    Always install cabinet on a level surface, appropriately anchored in all four (4) corners. Consult drawings on AtlasSound.com for dimensions. c. In masonry installations, use a rotary hammer drill with carbide tipped hammer drill bit to create the hole to set a wedge anchor. Atlas Sound recommends using ITW Red Head “Multi-Set II”, “Trubolt”...
  • Page 9 Floor-Standing Cabinets d. If equipment requires rear rack rails, additional rail pairs may be purchased (excluding 100 Series cabinets). In general, any piece of gear heavier than 25 lbs. per rack unit should utilize a rear rack rail. Consult chart below:...
  • Page 10 10/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets Pull-Out Drawers - May be used to provide storage to a rack. Recessed 14" Deep - Can also use Shelf Rear Support Bracket Rack Mount Pencil Drawer and Writing Surface SD2-14 STORAGE DRAWER - RECESSED 2RU W/ 14"...
  • Page 11 11/12 100, 200, 500, 700, & FMA Series Floor-Standing Cabinets Side Panels - Provides closure and protection within multi-rack ganged applications. 500 / 700 Series Cabinets FMA Series Cabinets SPS35-25 SDE PNL 500/700 35RU 61H 25D PR #962 FMA35-25LRPV PNL SD 35RU 25D CR BLK FMA #962 SPS40-25 SDE PNL 500/700 40RU 70H 25D PR #962 FMA44-25LRPV...

  • Page 12: Limited Warranty

    Musician Series stands and related accessories. Additionally, fuses and lamps carry no warranty. Atlas Sound will solely at its discretion, replace at no charge or repair free of charge defective parts or products when the product has been applied and used in accordance with our published operation and installation instructions.
