- Page 1 L i - H V S y s t e m S o l i n t e g E B S - 5 1 5 0 User Manual ENGLISH VERSION...
-
Page 3: Table Of Contents
About This Manual ……………………………………… 1.1 How To Use This Manual ………………………………………………………… 4 1.2 Target Groups …………………………………………………………………… 4 Safety Instructions ……………………………………… 2.1 Safety Notes ……………………………………………………………………… 5 2.2 Important Safety Matters ……………………………………………………… 5 2.1 Environmental Conditions ……………………………………………………… 7 2.2 Statement ………………………………………………………………………… 8 Product Description ………………………………………... -
Page 4: About This Manual
The products, services or features purchased are subject to the commercial contracts and terms of Solinteg Power Co., Ltd. All or part of the products, services or features described in this document may not be within purchased. This document serves only as a guide to use, and all statements, information and recommendations in this document do not consti- tute any express or implied guarantee. -
Page 5: Safety Instructions
Solinteg certified installers. Solinteg assumes no liability for injury or prop- erty damage due to repairs attempted by unqualified individuals or a failure to properly follow these instructions. - Page 6 User Manual EBS-5150 series Do not attempt to open, disassemble, repair, tamper with, or modify EBS Battery. EBS Battery is not user serviceable. LFP Cells in EBS Battery are not replaceable. WARNING Contact the EBS Authorized Reseller who sold the EBS Battery for any repairs.
-
Page 7: Environmental Conditions
EBS parts or accessories, or parts or accessories not CAUTION purchased directly from Solinteg or a Solinteg -certified party. Do not place EBS Battery in a storage condition for more than one (1) month, or permit the electrical feed on the EBS Battery to be severed for more than one (1) CAUTION month. -
Page 8: Statement
User Manual EBS-5150 series 2.4 Statement Solinteg Power Co., Ltd. has the right not to undertake quality assurance in any of the fol- lowing circumstances: ① Damages caused by improper transportation. ② Damages caused by incorrect storage, installation or use. -
Page 9: Product Description
User Manual EBS-5150 series Product Description 3.1 Models The EBS series battery includes 7 models which are listed below: EBS-5150-5, EBS-5150-7, EBS-5150-10, EBS-5150-12, EBS-5150-15, EBS-5150-17, EBS-5150-20. 3.2 Appearance Introduction 3.2.1 BMS Module 5 6 7 Figure 3-1 EBS-5150-BMS Item Terminal... -
Page 10: Indicator
User Manual EBS-5150 series 3.2.2 Battery Module and Base Figure 3-2 Battery Module (EBS-5150-BAT) Figure 3-3 Base (EBS-5150-BAS) 3.3 Indicator Figure 3-4 Battery indicator... - Page 11 User Manual EBS-5150 series Power Indicator Status Description Battery power off. Battery power on. Run and Alarm Indicator Indicator Status and Color Description RUN (Green) Alarm (Red) Power off Slow Flashing Normal Waiting Status Slow Flashing Quick Flashing Alarm Normal...
-
Page 12: Packing List
User Manual EBS-5150 series 3.4 Packing List The package of the battery includes the following accessories. Please check whether the accessories in the packing box are complete when receiving the goods. User Manual Figure 3-5 Packing list... - Page 13 User Manual EBS-5150 series Item Name Quantity BMS Module (EBS-5150-BMS) Battery Module (EBS-5150-BAT) Base (EBS-5150-BAS) Fixings Expansion Battery Terminal Fixed Bolt PE Terminal User Guide...
-
Page 14: Installation
User Manual EBS-5150 series Installation 4.1 Location ① The area is completely water proof. The floor is flat and level. ② There are no flammable or explosive materials. ③ The ambient temperature is within the range from 0 to 50℃. - Page 15 User Manual EBS-5150 series ③ Distance between base and wall is 20mm~120mm. 20mm~120mm Wall Figure 4-2 Distance between base and wall 4.2.2 Install the Module ① After the base is installed, remove the protective film of the terminals, and the remaining battery module and BMS module are then placed in turn.
- Page 16 User Manual EBS-5150 series ② Install the fixings on both sides of the BMS module. Figure 4-5 Install the fixings ③ Use the fixings as the template to mark the position of 4 holes on the wall. Figure 4-6 Mark the position ④...
- Page 17 User Manual EBS-5150 series ⑤ Use an electrical driller with 10mm diameter bit to drill 4 holes in the wall with 80mm depth. Hole depth:80mm Figure 4-8 Drill holes Before drilling, make sure to avoid any buried water tube and electric wires in the wall.
- Page 18 User Manual EBS-5150 series ⑧ Tighten modules with fixed bolt on the left and right side. Figure 4-11 Tighten modules ⑨ Insert the expansion screws into the holes, then fix the fixings onto the wall with expan- sion screws by using a cross screwdriver.
- Page 19 User Manual EBS-5150 series 4.2.3 Ground Connection Proper grounding is good for resisting surge voltage shock and improving EMI performance. Battery must be well-grounded. For a system with only one battery, the PE cable needs to be grounded. NOTICE For a multi-battery paralleling system, the PE. wire or all battery groups need to be connected to the same grounding copper bar to ensure equipotential bonding.
-
Page 20: Electrical Connection
WARNING Do not use other brands or other types of terminals other than the terminals in the accessory package. Solinteg has the right to refuse to held liable of all damages NOTICE caused by the mixed-use of terminals. -
Page 21: Electrical Wiring Diagram
If the conductor core of the battery power cable is too small, which may cause poor contact between the terminal and the cable, please use the cable specified in CAUTION the above table, or contact Solinteg to purchase terminals of other specifications. - Page 22 User Manual EBS-5150 series ② Peel off the battery cable insulation sleeve for 10 mm. 10mm Figure 5-2 ③ Disassemble the connector in the accessory bag. Figure 5-3 ④ Insert the battery cable through the battery connector nut into the metal terminal and press the terminal with a professional crimping plier (pull back the cable with some power to check if the terminal is well connected to the cable).
- Page 23 User Manual EBS-5150 series Open-end W Open-end Wre renc nch h Open-end Wrench Figure 5-5 ① Before making the battery connector, please make sure the polarity of the cable is correct. ② Use a multimeter to measure the voltage of the battery pack and make sure the WARNING voltage is within the inverter limitation and the polarity is correct.
-
Page 24: Communication Cable Connection
User Manual EBS-5150 series 5.3 Communication Cable Connection Please insert one side of the communication cable to the "Inverter COM" port in the BMS module, and refer to the inverter user manual to connect the other side. RJ45 terminal connection sequence and definition as below. -
Page 25: Commissioning
User Manual EBS-5150 series Commissioning 6.1 Start Battery ① Turn on the Breaker on the BMS module left side. Figure 6-1 ② Hold down the POWER button for 5 seconds until the indicator lights up. Figure 6-2 ③ Observe the status indicator, green light flashing indicates the normal output. -
Page 26: Troubleshooting
Restart the battery only after removing the fault that impairs safety performance. Never arbitrarily replace any internal components. For any maintenance support, please contact Solinteg. Otherwise, Solinteg shall NOTICE not be held liable for any damage caused. -
Page 27: Troubleshooting
It is recommended to replace the battery immediately. 7.2 Troubleshooting If any battery fault occurs, record the fault information, shut down the battery according to the shutdown procedure, and contact the distributor or Solinteg. Do not handle the fault by yourself. -
Page 28: Appendix
User Manual EBS-5150 series Appendix 8.1 Technical Parameters Model EBS-5150-5 EBS-5150-7 EBS-5150-10 Nominal Capacity (kWh) 5.12 7.68 10.24 Usable Energy (kWh) Nominal Capacity (Ah) Nominal Voltage (V) 102.4 153.6 204.8 Voltage Range (V) 89.6~115.2 134.4~172.8 179.2~230.4 Maximum Charge/ Discharge Current (A) - Page 29 User Manual EBS-5150 series EBS- EBS- EBS- EBS- Model 5150-12 5150-15 5150-17 5150-20 Nominal Capacity (kWh) 12.8 15.36 17.92 20.48 Usable Energy (kWh) 11.52 13.8 16.13 18.4 Nominal Capacity (Ah) Nominal Voltage (V) 307.2 358.4 409.6 Voltage Range (V) 224~288 268.8~345.6...
-
Page 30: Contact Information
• Serial number of the device • Date of the device • Fault code/name • Brief description of the problem China (HQ) Solinteg Power Co., Ltd. Address: Building H1-1001, No. 6 Jingxian Road, Xinwu District, 214135 Wuxi, Jiangsu Province, China Website: www.solinteg.com Service Mail: service@solinteg.com... - Page 32 www.solinteg.com...
