Jinko Solar JKS-6H-EI User Manual

Hide thumbs

page of 50

/ 50
Bookmarks

Quick Links

Download this manual

JKS-6H-EI

JKS-8H-EI

JKS-10H-EI

JKS-12H-EI

JKS-15H-EI

JKS-20H-EI

User MANUAL

Need help?

Do you have a question about the JKS-6H-EI and is the answer not in the manual?

Questions and answers

Summary of Contents for Jinko Solar JKS-6H-EI

Page 1 JKS-6H-EI JKS-8H-EI JKS-10H-EI JKS-12H-EI JKS-15H-EI JKS-20H-EI User MANUAL...
Page 2 Contents 1. Safety Introductions ………………………………………………… 2. Product instructions 01-04 ………………………………………………… 2.1 Product Overview 2.2 Product Size 2.3 Product Features 2.4 Basic System Architecture 3. Installation 05-23 …………………………………………………………… 3.1 Parts list 3.2 Mounting instructions 3.3 Battery connection 3.4 Grid connection and backup load connection 3.5 PV Connection 3.6 Meter Connection 3.7 Earth Connection(mandatory)
Page 3 - 01 -...
Page 4 - 02 -...
Page 5 2.2 Product Size - 03 -...
Page 6 AC cable DC cable WiFI GPRS Cloud services phone Solar Backup Load On-Grid Home Load Grid Battery Smart Load Grid-connected Inverter Generator - 04 -...
Page 7 Three-Phase Smart Meter - 05 -...
Page 8 -40~60 ℃ - 06 -...
Page 9 ≥500mm ≥500mm - 07 -...
Page 10 Blue Blue 6±0.2mm 6±0.2mm 3.75±0.2mm 3.75±0.2mm 5.2±0.2mm 3.97±0.5mm Safety Hint: （mm ） Cable type Range Recommended value - 08 -...
Page 11 - 09 -...
Page 12 Inverter Meter Parallel_1 Parallel_2 BMS1 BMS2 RS485 1 2 3 4 5 6 7 8 9 10 1112 1 2 3 4 5 6 7 8 9 10 1112 SHUT DOWN CT -R CT -S Gen start-up N/O Relay CT -T coil relay open...
Page 13 backup load connec�on Model Wire Size Cable(mm ) Torque value(max) 6/8/10Kw 8AWG 2.5Nm 12/15/20Kw 4AWG 2.5Nm Grid connec�on Model Wire Size Cable(mm ) Torque value(max) 6/8/10Kw 8AWG 2.5Nm 12/15/20Kw 4AWG 2.5Nm Chart 3-3 Recommended Size for AC wires Please follow below steps to implement Grid, load and Gen port connec�on: 1.
Page 14 - 12 -...
Page 15 Inverter Model 10KW 12KW 15KW 20KW Safety Hint: Safety Hint: Safety Hint: Black Black 4.6±0.3mm 4.6±0.3mm 3.05±0.3mm 3.05±0.3mm 5.2±0.2mm 4±0.2mm - 13 -...
Page 16 Safety Hint: （mm ） Cable type Range Recommended value - 14 -...
Page 17 Warning: Warning: - 15 -...
Page 18 GRID Inverter Meter Parallel_1 Parallel_2 Three-Phase Smart Meter RS485A Grid RS485B Three-Phase Smart Meter (1,4,7,10) (3,6,9,10) RS 485 CHNT DTSU666 - 16 -...
Page 19 GRID Inverter Meter Parallel_1 Parallel_2 RS485B RS485A Home Load 1 1 2 1 Three-Phase Smart Meter 3 1 4 1 6 1 7 1 9 1 1 2 4 2 5 2 Grid Note: the arrow direction towards the inverter 3 6 9 101314161719 21 1 1 2 1 Three-Phase Smart Meter...
Page 20 Note: Note: - 18 -...
Page 21 3.9 Wiring System for Inverter - 19 -...
Page 22 3.10 Wiring diagram - 20 -...
Page 23 ③AC Breaker CT1 CT2 Grid ④AC Breaker Home Load ① DC Breaker for battery JKS-6H-EI: 80A DC breaker Backup Load JKS-8H-EI: 80A DC breaker JKS-10H-EI: 80A DC breaker JKS-12H-EI: 80A DC breaker JKS-15H-EI: 80A DC breaker JKS-20H-EI: 80A DC breaker ②...
Page 24 Ground Inverter ①DC Breaker ③AC Breaker Battery pack ① DC Breaker for battery JKS-6H-EI: 80A DC breaker JKS-8H-EI: 80A DC breaker JKS-10H-EI: 80A DC breaker JKS-12H-EI: 80A DC breaker JKS-15H-EI: 80A DC breaker JKS-20H-EI: 80A DC breaker Backup Load ② AC Breaker for backup load...
Page 25 L wire N wire PE wire Inverter Meter Parallel_1 Parallel_2 BMS1 BMS2 RS485 No.3 (slave) ① Ground Battery pack Inverter Inverter ④ ⑤ No.2 (slave) Ground ② ⑦ Battery pack ⑥ Inverter No.1 (master) Ground ③ ⑨ ⑧ Battery pack CT1 CT2 Grid L1L2L3...
Page 26 4. OPERATION 4.1 Power ON/OFF LED Indicator Messages - 24 -...
Page 27 05/28/2019 15:34:40 8.30 -3.00 -2.00 3.00 - 25-...
Page 28 Solar Page Solar Graph Grid Page Grid Graph Inverter Page Main Screen Battery Page BMS Page Load Page Load Graph Battery Setting System Work Mode Grid Setting System Setup Gen Port Use Basic Setting Advanced Function Device info - 26 -...
Page 29 Solar PV1-V: 286V PV1-I: 5.5A PV1-P: 1559W PV2-V: 286V PV2-I: 5.5A PV2-P: 1559W Today=8.0 KWH Power: 1560W Energy Total =12.00 KWH 1244w -81w 1166w 50Hz 50Hz 222v 0.8w 222v 0.1A 221v 229v 5.0w 230v 0.1A 229v 1166w 229v 0.9w 223v 0.1A 225v INV_P:...
Page 30 Li-BMS Mean Voltage:170.0V Charging Voltage :180.0V Batt Total Current:37.00A Discharging Voltage :160.0V Data Mean Temp :23.5C Charging current :30A Total SOC :38% Discharging current :25A Battery 1 Stand by Dump Energy:57Ah Details Data U:170V I:2.04A Li-BMS Power: 101W Charge Volt Curr Temp Energy...
Page 31 System Setup System Work Mode Battery Setting Gen Port Grid Setting Basic Advanced Device Info. Setting Function Basic Setting Time Syncs Beep Auto Dim Year Month Basic 2019 Hour Minute 24-Hour Factory Reset Lock out all changes PassWord 9999 X--X--X--X 7777 CANCEL - 29 -...
Page 32 Battery Setting Batt Mode Lithium Batt Capacity Batt Mode Use Batt V Max A Charge Use Batt % Max A Discharge No Batt Activate Battery1 Parallel bat1&bat2 Activate Battery2 Battery Setting This is Ba�ery Setup page. ① Start =30%: Percent SOC below 30% system will AutoStart Start a connected generator to charge the ba�ery bank.
Page 33 12/08/2022 15:34:40 This page tells the PV and diesel generator power the load and ba�ery. 0.00 8.61 Signal -8.12 0.00 Generator This page tells generator output voltage, frequency, power. And, how much energy is used from generator. Power: 6000W Today=10 KWH Total =10 KWH P_L1: 2KW V_L1: 230V...
Page 34 (every 30 days 3hr ) System Work Mode 12000 Selling First Max Solar Power Work Zero Export To Load Solar Sell Mode1 Zero Export To CT Solar Sell Max Sell Power Zero-export Power 12000 Energy pattern BattFirst LoadFirst Grid Peak Shaving 8000 Power Solar...
Page 35 Time Of Use Time Power Batt Work 5:00 12000 160V Mode2 9:00 12000 160V 13:00 12000 160V 17:00 12000 160V 17:00 21:00 12000 160V 21:00 01:00 12000 160V Battery Setting Start Batt Set2 ① Grid Charge Gen Charge Gen Signal Grid Signal Gen Max Run Time 24.0 hours...
Page 36 Grid Setting/Grid code selection Grid Mode:General Standard、UL1741 & IEEE1547、 Grid Mode CPUC RULE21、SRD-UL-1741、CEI 0-21、Australia A、 General Standard 0/10 Australia B、Australia C、EN50549_CZ-PPDS(>16A)、 Phase Type Grid Frequency 50HZ Grid NewZealand、VDE4105、OVE-Direc�ve R25. Set1 0/120/240 60HZ Please follow the local grid code and then choose the 0/240/120 corresponding grid standard.
Page 37 Grid Setting/F(W) FW: this series inverter is able to adjust inverter output power according to grid frequency. F(W) Droop F: percentage of nominal power per Hz Over frequency Droop F %P/Hz For example, “Start freq F＞50.2Hz, Stop freq F＜51.5, Grid Set4 Stop freq F Start freq F...
Page 38 GEN PORT USE Generator input rated power: allowed Max. power from diesel generator. Mode GEN connect to grid input: connect the diesel generator to the Generator Input GEN connect to Grid input grid input port. PORT Rated Power Smart Load Output: This mode u�lizes the Gen input connec�on Set1 8000W as an output which only receives power when the ba�ery SOC...
Page 39 Advanced Function Modbus SN Parallel Master Paral. Set3 Slave EX_Meter For CT Meter Select No Meter CHNT Li-BMS Li-BMS Device Info. Inverter ID: 2102199870 Flash Charge Charge Volt Volt Curr Curr Temp Temp Energy Energy Fault Fault MAIN:Ver2002-1046-1707 HMI: Ver 1001-8010 Volt Volt Curr...
Page 40 AC cable DC cable Solar Backup Load On-Grid Home Load Grid Battery Smart Load On-Grid+AC couple AC cable DC cable Solar Backup Load On-Grid Home Load Grid Battery On-Grid Inverter - 38 -...
Page 41 Error code 1，Check the PV input polarity DC_Inversed_Failure 2，Seek help from us, if can not go back to normal state. 1，The BUS voltage can t be built from PV or battery. DC_START_Failure 2，Restart the inverter, If the fault still exists, please contact us for help 1.
Page 42 Error code BUS over current. 1, Check the PV input current and battery current setting Tz_HV_Overcurr_fault 2. Restart the system 2~3 times. 3. If the fault still exists, please contact us for help. Remotely shutdown Tz_EmergStop_Fault 1, it tells the inverter is remotely controlled. Leakage current fault 1.
Page 43 Error code Grid frequency out of range 1. Check the frequency is in the range of specification or not; AC_OverFreq_Fault 2. Check whether AC cables are firmly and correctly connected; 3. Seek help from us, if can not go back to normal state. Grid frequency out of range 1.
Page 44 ；；；；；；； - 42 -...
Page 45 8. Datasheet Model JKS-6H-EI JKS-8H-EI JKS-10H-EI JKS-12H-EI JKS-15H-EI JKS-20H-EI Number of ba on to BMS 420-850 26+26 30+30 30+30 30+30 39+30 39+30 39+39 AC Output Data Max. AC Output Power(W) 12.2/11.6 15.2/14.5 22.8/21.8 30.4/29.0 Max. AC Current(A) 10/9.6 13.4/12.8 16.7/16 20/19.2...
Page 46 VDE4105,IEC61727/62116,VDE0126,AS4777.2,CEI 0 21,EN50549-1, G98,G99,C10-11,UNE217002,NBR16149/NBR16150 ℃ ℃ ℃ 5 years - 44 -...
Page 47 1 2 3 4 5 6 7 8 RS485 Pin 485_B 485_A GND_485 CAN-H1 CAN-L1 GND_485 485_A 485_B RS485 Pin 485_B 485_A GND_485 CAN-H2 CAN-L2 GND_485 485_A 485_B Meter-485 Pin 1 2 3 4 5 6 7 8 METER-485_B METER-485_A GND_COM METER-485_B METER-485_A...
Page 48 1 2 3 4 5 6 7 8 RS485 Pin Modbus-485_B Modbus-485_A GND_485 GND_485 Modbus-485_A Modbus-485_B WIFI/RS232 D-GND 12Vdc 5 4 3 2 1 9 8 7 6 WIFI/RS232 - 46 -...
Page 49 User Manual JKS-6-20H-EI A2, 2023-01-02 - 47 -...
Page 50 Jinko Solar Co., Ltd No.1, Jinko Road, Shangrao Economic Development Zone Shangrao City, Jiangxi Province, 334100, P.R. China www.jinkosolar.com...
