Summary of Contents for DEFA Power 715000
- Page 1 DEFA Power Estimated installation time: 8 min Installation Manual defa.com 715986-E03...
-
Page 2: Safety Information
à l’encontre de celles-ci, peut entraîner un choc électrique, un incendie et/ou des blessures graves. Important ! Assurez-vous l’alimentation électrique soit déconnectée avant l’installation et qu’elle le reste tout au long du processus d’installation. defa.com... - Page 3 ADVARSEL Afsnit markeret med dette symbol gør opmærksom på yderligere farer, der kan føre til beskadigelse af selve ledningen eller andre elektriske apparater. Handlinger markeret med dette symbol skal udføres med særlig omhu. VAROITUS Tällä merkillä merkityissä kohdissa on kyseessä muu vaara, joka voi vahingoittaa kaapelia tai muita sähkölaitteita. Tällä merkillä merkityt toimenpiteet tulee suorittaa erityisen huolellisesti. defa.com...
- Page 4 No instalar si la carcasa exterior está No instalar si el cable de carga está No realizar reparaciones físicas en la dañada. defectuoso o parece agrietado, roto o estación de carga. dañado de alguna manera. defa.com...
-
Page 5: What's Included
What's included Charging Unit Wall Bracket Cable clip Locking tool Wood screws (x 4) Washers (x 4) Wall plugs (x 4) Multi grommets (x 2) 3,9 x 32 mm 5,3 x 10 x 1 mm 6 x 30 mm Tx30 defa.com... -
Page 6: Installation Planning
6. The installation site must not be located in areas with an explosive atmosphere. 7. The installation site must offer sufficient air circulation. 8. The product should be installed on an even, solid, and strong surface. The entire rear surface of the Wall Bracket must be in contact with the mounting surface. defa.com... - Page 7 12. The installation site should not be located in a confined space and must be freely accessible. 13. The bottom of the charging station is recommended to be installed at 140-160 cm above the ground. Local regulations may apply. 20cm defa.com...
- Page 8 Tools needed (not included) Wirestripper Wire cutter Pencil Screwdriver Drill Smartphone with Bluetooth Bits: Philips or PZ2 6 mm defa.com...
-
Page 9: Installation And Setup
Accessories For more information about accessories for this product, such as DEFA Balancer, scan the QR code on the cover. Online connection requirements DEFA Power supports Wi-Fi (2.4 or 5GHz), Ethernet and cellular connections. To achieve full functionality of the charging station, connect it to the internet. - Page 10 DEFA Power Ready PN: 714835 2,5Nm T: DEEVC/WB480/22 3x 230/400V 50Hz Design by DEFA AS, Norway Max. 22kW, 32A Manufactured in China by w/cover: IP44, IK10 DEFA Technology (Wuxi) Co., Ltd Adapt the length of the supply cable and strip according to the input route. Make sure terminal wires can be connected without strain.
- Page 11 Pass the wires through the wire guides. Avoid sharp bends on the wires. If more than one Wall Bracket is to be installed, repeat the steps from 1 to 12. NOTICE The Wall Bracket must not be left unprotected, use the Charging Unit or the protective cover to seal it. defa.com...
- Page 12 Attach the RJ45 connector to the LAN cable. Connect the LAN cable into the LAN port. Slide the grommet over the cable and firmly into the LAN port enclosure. The grommet now protects the LAN connection from water and dirt. defa.com...
- Page 13 Slide the charging unit down until you hear a “click”. See the illustration below. Using the included locking tool, turn the lever from the unlocked position to the locked position. CLICK Once the installation has been completed, reconnect the power supply. defa.com...
-
Page 14: Verify Installation
Verify Installation NOTICE Before finalizing the set-up of DEFA Power, the RDC functionality will be tested via DEFA Power Setup App. A self-test of the built-in RDC-DD will be performed in every charging start-up cycle and every 24h. If the built-in RDC-DD is tripped, a clear error message will be displayed on the screen. To reset the built-in RDC-DD, unplug the charging cable from the vehicle and then plug it in again. -
Page 15: Product Specification
The guarantee and warranty is only valid by the legal provision of the country of purchase – the guarantee or warranty is not transferable. DEFA’s warranty obligations will not apply if the product is damaged due to accident, abuse or other external causes, or if any non-authorized modifications have been performed or guidelines have not been followed during the service/repair. -
Page 16: Contact Information
Contact information If you have any questions, contact your local vendor or visit defa.com. If you have any feedback on how the system or support can be improved, feel free to give us your input at defa.com Installed by: Rating of product installed: ___A/___kW...
