Summary of Contents for Inmotion controls 342 Series
-
Page 2: Table Of Contents
Contents Warning and Caution…………………………………. 2 Warranty……………………………………………… 3 Important Information Before You Start……………... 4 Precautions……………………………………………. 5 Emergency Procedures………………………….…….. 5 Specification…………………………………………... 6 Transmitter Overview…………………………….…… 7 Receiver Overview……………………………………. 8 General Operation…………………………………….. 9 Getting Started…………………………………. 9 Transmitter LED Indicator…………………….. 10 Changing Receiver Input Voltage……………... 11 Frequency Chart………………………………………. -
Page 3: Warning And Caution
Warning and Caution The following symbols may be found on the product or throughout the documentation. Symbol Description Refer to Manual Refer to the user manual for additional information when marked with this sign. Dangerous Voltage Indicates the presence hazardous voltage. Unsafe practice could result in severe personal injury. -
Page 4: Warranty
Under proper installation, it should work as expected. However, INMOTION Controls, Inc. does not guarantee that operation of the 342 Series Radio Control System is error-free or without interruption. This equipment is warranted against defects in materials and workmanship for a period of one year from the date of shipment. -
Page 5: Important Information Before You Start
Important Information Before You Start 1. Read this manual carefully before operating and installation. 2. Due to the complex nature of equipment, it is necessary to read the entire manual prior to installation. 3. Never allow any unauthorized personnel to dismantle equipment as this may cause damage to the equipment. -
Page 6: Precautions
Precautions 1. Press EMO (Emergency Off) button and switch off main power of crane and receiver after operation. Then remove transmitter rotary key and keep in a safe place. 2. The following situations may cause a receiver response delay. You should stop operation immediately if these situations occur. -
Page 7: Specification
Specification General Specification ID Code…………………………….. Over 1 Million Sets Channel Space……………………… 25 KHz Hamming Distance…………………. > 4 Structure……………………………. Enhanced Glass-Fiber Operating Environment…………….. -40°F ~ +185°F Operating Distance…………………. Up to 300 Feet Transmitter Power……………………………. (4) AA Alkaline Batteries Emission Power…………………. <10mW Dimensions………………………... -
Page 8: Transmitter Overview
Transmitter Overview Inmotion Series 342 Transmitter Overview... -
Page 9: Receiver Overview
Receiver Overview Inmotion Series 342 Receiver Overview... -
Page 10: General Operation
General Operation Getting Started 1. Install 4 new AA-size batteries in the battery compartment (make sure batteries are correctly installed according to “Positive” & “Negative”) and close the battery cover firmly. 2. Insert rotary key into transmitter unit and switch to “ON” position. -
Page 11: Transmitter Led Indicator
Transmitter LED Indicator Green (Full Power) Operate as usual. Yellow (Mid Power) Unload the article as soon as possible and stop operation until old batteries are replaced with fresh batteries. Red (Low Power) An EMS signal will be sent to the receiver automatically to turn off receiver. -
Page 12: Changing Receiver Input Voltage
Receiver Voltage Selection There are two types of power voltages (DC and AC) available for the Series 342. 1) DC Type: Input Voltage: 12~24 VDC Relay Contact: 6.7A-36 VDC 2) AC Type: Three different AC transformers: 48/110/220V, 48/220/380V, 110/220/380V. Please disconnect the Receiver’s power, select the proper voltage, and plug in the connector. -
Page 13: Frequency Chart
FREQUENCY CHART Freq. MHz Freq. MHz Freq. MHz Freq. MHz 433.050 433.550 434.050 433.550 433.075 433.575 434.075 433.575 433.100 433.600 434.100 433.600 433.125 433.625 434.125 433.625 433.150 433.650 434.150 433.650 433.175 433.675 434.175 433.675 433.200 433.700 434.200 433.700 433.225 433.725 434.225 433.725 433.250... -
Page 14: Installation Notes
Installation Notes... -
Page 15: Receiver Wiring Diagram
Receiver Wiring Diagram...
