Operating Instructions & Parts Manual
- Before using this product, read this manual and follow all its Safety Rules and Operating Instructions
Blackhawk Automotive is a Licensed Trade Mark
Vehicle Stands
10939 N. Pomona Ave. Kansas City, MO 64153
"Pin Style"
Model
BH5010
BH5220
sales@blackhawk-automotive.com
Capacity per pair
10 Ton
22 Ton
SFA Companies
Made in PRC
BH5010-M0 rev 01/07
Advertisement
Table of Contents
Related Manuals for Blackhawk Automotive BH5010
Summary of Contents for Blackhawk Automotive BH5010
- Page 1 Blackhawk Automotive is a Licensed Trade Mark “Pin Style” Vehicle Stands Operating Instructions & Parts Manual Model Capacity per pair BH5010 10 Ton BH5220 22 Ton SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 sales@blackhawk-automotive.com - Before using this product, read this manual and follow all its Safety Rules and Operating Instructions...
- Page 2 Blackhawk Automotive authorized service center. It is recommended that an annual inspection be done by qualified personnel. Labels and Operator’s Manuals are available from manufacturer.
- Page 3 9 3/4" x 9 3/4" 12 1/4" 19 7/8" 64 lb. Saddle Height Adjustment Extension Tube Holes Roll Pin Extension Tube Collar Support Bar Lanyard Support Bar Holder Base Section Figure 1 - Model BH5010 Components Figure 2 - Model BH5220 Components...
- Page 4 1. Adjust saddle height by pulling up the extension tube, then insert the tube support bar through the hole on extension tube. 2. For model BH5010: Ensure that support bar is secure before loading. Insert support bar into the extension tube far enough to create equal distance of bar extending from the extension tube on both sides.
