Table of Contents 1. Unpacking Inspection 2. Packing List 3. Safety Precautions 4. Product Composition 5. Intended Use / Instructions for Use 6. Contraindication 7. Product Parts 8. 3-color Backlit Indicator 9. Preparation:Type-C Charging 10. Function Setting 11. How to Take Proper Measurements 12.
Thank you for purchasing the Arm Blood Pressure Monitor. The device uses the oscillometric method of blood pressure measurement. It is intended for professional and domestic use in monitoring diastolic and systolic blood pressure and pulse rate. The device is suitable for use at home, at work, and on vacation.
Comply with local regulations Consult the instructions for use Keep dry Low voltage prompt Keep out of the sun Vertical upward The device is protected against splashing water. Water splashed against the enclosure from any direction shall have no harmful effects. RoHS mark CE mark Manufacturer...
5. Intended Use / Instructions for Use The Arm Blood Pressure Monitor is intended to measure the systolic pressure and diastolic pressure, as well as the pulse rate of adult person via non-invasive oscillometric technique at medical facilities or at home. 6.
Hierarchical Systolic Blood Diastolic Blood Color of Relationship Pressure(mmHg) Pressure(mmHg) Reading ≥160 ≥100 and (or) 140-159 90-99 and (or) Yellow 90-139 60- 89 and (or) Green <90 <60 Yellow 9. Preparation:Type-C Charging Please check the device's power before using it. When the battery runs out, please use the manufacturer-provided Type-C Charging Cable to charge the device till the “...
Page 8
month year hour date minute (3) Voice On/Off Setting (for voice version only, optional function) After the time setting is finished, it will automatically enter the voice setting (the screen will display "SP"). Press " " button to turn on or turn off the sound. "ON" means turn on the sound, "OFF"...
11. How to Take Proper Measurements (1) Preparation before measurement --Always measure in the same arm (generally the left arm). --Remain still and keep quiet during measurement. --Relax as much as possible and do not talk during measurement. --Measure your blood pressure at about the same time every day.
Page 10
2)Make sure that the device's screen is positioned on your inner arm as illustrated in the diagram. The bottom edge of the cuff should be 0.79-1.18 inches (2 to 3 cm) above the inside elbow. 0.79-1.18 inches (2 to 3 cm) Bottom edge 3)Tighten the cuff around your arm, so it can not move around your arm.
Page 11
• Please use only the manufacturer-provided cuff, as it has passed all required clinical trials. Any replacement of the original components with materials not specified or provided by the manufacturer may result in measurement errors. (4) Taking a measurement Press the " "...
Page 12
(5) Memory function 1)Each measured value is stored automatically under the appropriate “User” group. This device can store up to 120 sets of measurements for each user. (Note: There is no memory for “Guest”.) Once the memory log is full, old values are refreshed with new ones.
12. Contraindications, Precautions, Warnings and Prompt Instructions •No maintenance or servicing when using. •Do not operate when charging. •Dispose of the monitor when its service life is reached. Follow local regulations regarding the disposal of such products. •Maintenance should be done by the operator as suggested •Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30cm (12 inches) to any part...
Page 14
tomography (CT) scanners. This may result in incorrect operation of the monitor and/or cause an inaccurate reading. •Consult with your physician before using this monitor if you have common arrhythmias such as atrial or ventricular premature beats or atrial fibrillation, arterial sclerosis, poor Perfusion, diabetes, pregnancy, pre-eclampsia or renal disease.
•DO NOT drop or place this monitor to strong shocks or vibrations. •DO NOT use this monitor in places with high/low humidity and temperatures. •Use of this equipment adjacent to or stacked with other equipment should be avoided because it could result in improper operation.
● The cuff is not tight enough. If the cuff is loose, the compression force might fail to transmit to the artery, causing the blood pressure value to be much higher than it is. Therefore, re-adjust and tighten the cuff further. ●...
Page 17
*Troubleshooting Anomaly Inspection Items Countermeasures There is no display after Recharge the device till The battery is the " " indicator the power depleted. stops flashing. switch is pressed Whether the arm is Keep your arm and Unable to moved when body still measure pressurization...
15. Cleaning and Disinfection 15.1 Cleaning The device can be cleaned with a soft, clean cloth dampened with a small amount of neutral detergent or water. Do not use corrosive cleaning agents, and take care not to o immerse any part of the monitor in any fluid. It is suggested to clean once every week.
-No maintenance or maintenance required when using the device. Do not allow w ater or other liquids to flow into the host. 17. Specifications Model AOJ-33A Display LED Screen Measuring Oscillometric Method Measuring...
Page 20
Pneumatic Pressure 0~295 mmHg (0~39.3 kPa) Measuring Range Maximum Pressure 295 mmHg (39.3 kPa) Protection SYS: 57-255 mmHg Blood (7.6-33.4 kPa); Pressure Measurement DIA: 25-195 mmHg Value Range (3.33-26 kPa); Pulse Rate 40-199 bpm Blood Pressure ±3 mmHg (±0.4 kPa) Accuracy Value Pulse Rate...
Protection Against Internally powered supply Electric Shock If stored or Temperature 5℃-40℃ used beyond Condition the designated Humidity 15%-90% temperature Operating Condition and humidity Environment range, it will Atmospheric 70kPa- not be used Condition 106kPa properly. Avoid strong impact, direct impact, exposure or rain during transportation.
Page 22
Guidance and manufacturer's declaration - Electromagnetic immunity The Arm Blood Pressure Monitor is intended for use in the electromagnetic environment specified below. The customer or the user of Arm Blood Pressure Monitor should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level...
Page 23
Guidance and manufacturer’s declaration - electromagnetic Immunity The Arm Blood Pressure Monitor is intended for use in the electromagnetic environment specified below. The customer or the user of the Arm Blood Pressure Monitor should assure that it is used in such an environment. Radiate Test Modula...
Page 24
— Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. Shenzhen AOJ Medical Technology Co., Ltd. Room 301&4F, Block A, Building A, Jingfa Intelligent Manufacturing Park, Xiaweiyuan, Gushu Community, Xixiang Street, Bao'an District, 518126 Shenzhen, CHINA Email: info@aojmedical.com...
