  • Page 1 Mirage G4 2018 OWNER’S MANUAL...
  • Page 2 Table of contents Overview Quick index General information Seat and restraint systems Features and controls Driving safety Comfort controls For emergencies Vehicle care and maintenance Customer assistance/ Reporting Safety Defects Specifications Alphabetical index...
  • Page 3 Instruments and controls Instruments and controls N00100202775 Instrument cluster P.5-63 Hazard warning flasher switch P.5-81 Wiper and washer switch P.5-81 Combination headlights and dimmer switch P.5-78 Turn-signal lever P.5-80 Front fog light switch (if so equipped) P.5-81 Cruise control switches (if so equipped) P.5-54 Engine switch (if so equipped) P.5-13 Ignition switch (if so equipped)
  • Page 4 Instruments and controls Center vents P.7-2 Heater (if so equipped) P.7-4 Supplemental restraint system (SRS)-air- Manual air conditioning (if so bag (for front passenger) P.4-22, 4-28 equipped) P.7-7 DISPLAY AUDIO (if so equipped), Smartphone Link Display Audio (if so equipped), Electric rear window defogger switch Clock (if so equipped) P.5-83...

  • Page 5: Table Of Contents

    Interior Interior N00100302460 Power window lock switch Microphone P.5-29 [Refer to the separate owner’s manual.] Dome light P.5-92, 9-28 Assist grips Power door lock switch (if so Inside rearview mirror P.5-33 equipped) P.5-25 P.5-95 Sun visors P.5-85 Vanity mirror P.5-85 Card holder P.5-85 Power window switch P.5-29 Bottle holders P.5-94...
  • Page 6 Luggage area Luggage area N00100501553 Trunk room light P.9-28 Tools P.8-5 Spare tire P.8-7 Overview...
  • Page 7 Outside Outside N00100602724 Windshield wipers P.5-81 Power window P.5-29 Outside rearview mirrors P.5-35 Fuel tank filler P.3-3 Engine hood P.9-4 F.A.S.T.-key (Free-hand Advanced Security Transmitter) (if so equipped) P.5-9 Keyless entry system (if so equipped) P.5-6 Front fog lights (if so equipped) Locking and unlocking P.5-24 P.5-81, 9-27, 9-30 Side turn signal lights...
  • Page 8 Outside Tire pressure monitoring system (if so equipped) P.5-58 Antenna P.7-19 High-mounted stop light Changing tires P.8-6 P.9-27 Size of tires and wheels P.11-5 Tire inflation pressure P.9-15 Tire rotation P.9-17 Tire chains P.9-18 Rear-view camera (if so equipped) P.5-61 Trunk lid P.5-27 Rear side- marker lights P.5-78, 9-27, 9-31 License plate lights...
  • Page 10 If the light comes on while the engine oil level is normal, have the system checked P. 5-77 at an authorized Mitsubishi Motors dealer or a repair facility of your choice as soon as possible. Oil pressure warning light...
  • Page 11 Idle the engine until the selector lever position indicator stops flashing. P. 5-44 Selector lever position indicator in the If the indicator does not go off, contact an authorized Mitsubishi Motors dealer or a instrument cluster flashes rapidly repair facility of your choice immediately.
  • Page 12  If the indicator does not go out, or if it comes on again, have your vehicle inspected P. 5-53 by an authorized Mitsubishi Motors dealer or a repair facility of your choice as soon as possible. ASC indicator and ASC OFF indicator ...
  • Page 13 Restart the engine and check whether the indicator goes out.  If the indicator does not go out, or if it comes on again, have your vehicle inspected by an authorized Mitsubishi Motors dealer or a repair facility of your choice as soon P. 5-48 as possible.
  • Page 14 If this problem occurs... If this problem occurs... N00200902018 Problem Do this Ref. Page Unable to turn the key. (except for vehicles equipped with the F.A.S.T.-key) From “ACC” to “OFF” Vehicles with continuously variable transmission (CVT): P. 5-37 Check the position of the selector lever. The key cannot be removed unless the selector lever is set to the “P”...
  • Page 15 If this problem occurs... Problem Do this Ref. Page Cannot shift the selector lever from the “P” (PARK) position. Shift the selector lever while pressing the brake pedal. P. 5-41 (for vehicles with continuously Check that the ignition switch or the operation mode is in ON. variable transmission (CVT)) The windows are fogged up.
  • Page 16 The There may be a problem in the CVT. initial movement of the vehicle Have the vehicle inspected by an authorized Mitsubishi Motors dealer or a repair facility of P. 5-44 is slow when the vehicle starts your choice immediately.
  • Page 18 General information Fuel selection ...................3-2 Filling the fuel tank ................3-3 Modifications to and racing of your vehicle ........3-5 Genuine Mitsubishi Motors parts ............3-6 California Perchlorate Materials Requirements .......3-7...

  • Page 19: Fuel Selection

    Mitsubishi Motors Corporation strongly sup- names. Oxygenates are required in some ports the use of reformulated gasoline. Prop- CAUTION areas of the country.

  • Page 20: Filling The Fuel Tank

     Before removing the fuel tank filler cap, Your vehicle may have been designed to sat- Mitsubishi Motors dealer or a repair facility be sure to get rid of your body’s static isfy California’s low-emission regulations of your choice.
  • Page 21 Filling the fuel tank 3. Open the fuel tank filler pipe by slowly Fuel tank capacity WARNING turning the fuel tank filler cap counter-  Since the fuel system may be under pres- clockwise. sure, remove the fuel tank filler cap 9.2 gal (35 L) slowly.

  • Page 22: Modifications To And Racing Of Your Vehicle

    (OBD) system performs a self check.  Failure to use Mitsubishi Motors genuine Always tighten the fuel tank filler cap until 7. To close, turn the fuel tank filler cap parts you hear at least 3 clicks.

  • Page 23: Genuine Mitsubishi Motors Parts

    Also avail-  Tires and wheels which do not meet spec- able from your Mitsubishi Motors dealer are ifications must not be used. a wide variety of accessories to personalize your new vehicle. Each Mitsubishi Motors...

  • Page 24: California Perchlorate Materials Requirements

    California Perchlorate Materials Requirements vehicle has a selection of Mitsubishi Motors authorized accessories to choose from to tai- lor your new vehicle to your own personal preference. Your Mitsubishi Motors dealer’s Parts Manager has information on various audio systems, protection items, as well as interior and exterior accessories available for your specific model.
  • Page 26 Seat and restraint systems Seats ....................4-2 Seats and restraint systems ..............4-2 Front seats ..................4-2 Rear seat ...................4-5 Head restraints .................4-5 Seat belts ..................4-7 Seat belt use during pregnancy ............4-13 Seat belt pre-tensioner and force limiter systems ......4-13 Child restraint systems ..............4-14 Maintenance and inspection of seat belts ........4-22 Supplemental Restraint System (SRS) - airbag ......4-22...

  • Page 27: Seats

    Seats WARNING Seats Seats and restraint systems  Do not place objects under the seats. This N00408401593 N00401601235 could prevent the seat from locking Your vehicle has seat belts and other safety securely, and it could lead to an accident. features that help protect you and your pas- It may also cause damage to the seat or sengers in an accident.
  • Page 28 Front seats WARNING CAUTION To adjust the seatbacks  After adjusting the seat, make sure that  When sliding or reclining the seat rearward, N00402000369 seat is securely locked into position. pay careful attention to the rear seat passen- To adjust the seatback, lean forward slightly, gers.
  • Page 29 Front seats WARNING NOTE  To reduce the risk of serious injury or  Do not stand or sit on the arm rest. It could death in the event of an accident or sud- break. den stop, all seatbacks should be kept in the upright position while the vehicle is in motion.

  • Page 30: Rear Seat

    Rear seat WARNING CAUTION Trunk-through lid  Persons who are unable to feel tempera-  If water or any other liquid is spilled on the N00409001062 Open the lid to gain access to the luggage ture change or skin pain due to age, ill- seat, allow it to dry thoroughly before ness, injury, medication, alcohol use, attempting to use the heater.
  • Page 31 Head restraints upright position and the head restraint to the WARNING Adjustment of the head proper position. Sit back against the seatback restraint height (front seats)  Never place a cushion or similar device on with your head close to the head restraint. the seatback.

  • Page 32: Seat Belts

    Seat belts To remove To install CAUTION  The shape and size of the head restraint dif- Press the lock knob (A) in the direction First check that the head restraint is facing in fers according to the seat. Always use the shown by the arrows.
  • Page 33 Mitsubishi Motors even when you are wearing your seat belt. dealer to determine whether replacement Never place any part of the seat belt you is necessary.
  • Page 34 Seat belts inside the belt retractor is designed to lock the 1. Occupants should always sit back in their WARNING retractor in the event of a sudden change in seats with their backs against the upright  To reduce the risk of serious injury or the vehicle’s motion.
  • Page 35 Seat belts 3. Pull the seat belt out slowly while holding 4. The lap part of the belt must always be WARNING the latch plate. Push the latch plate into worn low and snug across the hips. Pull  Be sure the lap belt portion fits snugly and the buckle until you hear a “click”.
  • Page 36 Seat belts Driver’s seat belt WARNING reminder/warning light  In order to reduce the risk of serious injury or death in an accident, always fas- N00418400384 ten your own seat belt. Do not allow any- A tone and warning light are used to remind one to ride in your vehicle unless he or she the driver to fasten the seat belt.
  • Page 37 Seat belts Adjustable seat belt shoulder WARNING Installation anchor (front seats)  Adjust the shoulder belt anchor only when 1. Unfasten the button (A) of the seat belt the vehicle is not in motion. N00406300357 guide strap. Put the seat belt webbing ...

  • Page 38: Curtain Airbags

    Seat belt use during pregnancy 2. Fasten the seat belt and make sure it fits WARNING Seat belt pre-tensioner and snugly across your shoulder.  The extender should only be used if the force limiter systems existing belt is not long enough. Anyone N00417701752 who can use the standard seat belt should The driver’s and front passenger’s seats each...

  • Page 39: Child Restraint Systems

    The ignition switch is in the “ON” or belt pre-tensioner system inspected by an “START” position. authorized Mitsubishi Motors dealer. [Vehicles equipped with the F.A.S.T.-key] The operation mode is in ON. SRS warning light...
  • Page 40 Child restraint systems Child restraint systems specifically designed  Children older than 1 year of age and who WARNING for infants and small children are offered by weigh less than 40 pounds (18 kg) or who  Any child who is too large to use a child several manufacturers.
  • Page 41 Child restraint systems WARNING Airbag  It is important to use an approved rear- facing infant restraint until the infant is one year old (unless the infant outgrows the seat sooner). This allows the infant’s neck and spine to develop enough to sup- port the weight of their head in the event of an accident.
  • Page 42 Child restraint systems NOTE Installing a child restraint sys- Tether anchor locations tem using the LATCH (Lower  Before purchasing a child restraint system, N00418901230 Your vehicle has 3 attachment points on the try installing it in the rear seat to ensure Anchors and Tethers for chil- rear shelf, located behind the top of your rear proper fit.
  • Page 43 Child restraint systems 3. Push the anchor connectors (D) on the Examples of child restraint sys- NOTE child restraint system into the lower tems compatible with the LATCH  In order to secure a child restraint system anchors (C) in accordance with the compatible with the LATCH system, you system instructions provided by the child restraint...
  • Page 44 Child restraint systems 5. Latch the tether strap hook (E) of the child Installing a child restraint sys- WARNING restraint system to the anchor (F) as illus- tem using the seat belt (with  When you install a child restraint system trated below (5) and tighten the top tether using the seat belt, always make sure the emergency/automatic locking...
  • Page 45 Child restraint systems 3. To activate the ALR child restraint instal- WARNING Installation lation function, slowly pull the shoulder  Never remove the buckle (A) for the rear part of the belt all the way out of the 1. Place the child restraint system on the seat center seat from the rubber belt (B).
  • Page 46 Child restraint systems 5. After confirming that the belt is locked, 7. Latch the tether strap hook (A) of the 9. To remove a child restraint system from grab the shoulder part of the belt near the child restraint system to the tether anchor the vehicle and deactivate the ALR mode, buckle and pull up to remove any slack (B) as illustrated below (7) and tighten the...

  • Page 47: Maintenance And Inspection Of Seat Belts

     Children can die from heat stroke if left or front passenger seat belt systems by provid- Mitsubishi Motors dealer. Failure to have trapped inside the vehicle, especially on an authorized Mitsubishi Motors dealer ing those occupants with protection against hot days.
  • Page 48 Supplemental Restraint System (SRS) - airbag the driver and passengers on the front seat WARNING WARNING and rear outboard seat with protection against • Seat belts help keep the driver and pas- • Airbags inflate very quickly and with head injuries by deploying the curtain airbag sengers properly positioned.
  • Page 49 Supplemental Restraint System (SRS) - airbag Airbag WARNING WARNING WARNING  NEVER put REAR-FACING CHILD  Infants and small children should never  FRONT-FACING CHILD RESTRAINT RESTRAINT SYSTEMS or INFANT ride unrestrained, or lean against the SYSTEMS should be used in the rear seat instrument panel.
  • Page 50 Supplemental Restraint System (SRS) - airbag The airbags will operate under the same con- 7- Passenger’s seat occupant classifica- WARNING ditions as the airbag control unit. tion sensor system  Older children should be seated in the 8- Airbag module (Driver’s knee) rear seat with their seat belt properly When the impact sensors detect a sufficient 9- Airbag control unit...
  • Page 51 (e.g., the vehicle inspected by an authorized The main purpose of an EDR is to record, in Mitsubishi Motors dealer as soon as possi- name, gender, age, and crash location) are certain crash or near crash-like situations, ble.
  • Page 52 SRS sensors inspected by child restraint system. In this case, the pas- correctly, observe the following instruc- an authorized Mitsubishi Motors dealer as senger’s airbag off indicator will illuminate. tions. Failure to follow these instructions soon as possible.
  • Page 53 • Even when the ignition switch or the system in your vehicle inspected by an operation mode is in ON, the SRS warn- authorized Mitsubishi Motors dealer as ing light does not come on or it remains soon as possible: •...
  • Page 54 Supplemental Restraint System (SRS) - airbag The front passenger’s airbag is contained in the instrument panel above the glove com- partment. The driver’s airbag and the front passenger’s airbag are designed to deploy at the same time. However, the front passen- ger’s airbag does not deploy when the front passenger seat is not occupied or when the system senses that a child is in the child...
  • Page 55 Supplemental Restraint System (SRS) - airbag Deployment of front airbags N00408001658 The front airbags and driver’s knee airbag ARE DESIGNED TO DEPLOY when … Head-on collision with a solid wall at speeds Moderate to severe frontal impact within the shaded of approx.
  • Page 56 Supplemental Restraint System (SRS) - airbag they cannot provide protection to the occu- The front airbags and driver’s Collision with a utility pole, tree or other narrow pants. knee airbag MAY NOT DEPLOY object Some typical situations are shown in the when …...
  • Page 57 Supplemental Restraint System (SRS) - airbag The front airbags and driver’s Collision with an elevated median/island or knee airbag MAY DEPLOY when curb … The front airbags and driver’s knee airbag may deploy if the underside of the vehicle suffers a moderate to severe impact (under- Vehicle travels over a deep hole/pothole carriage impact).
  • Page 58 Mitsubishi Motors dealer. pants must be properly restrained and seated well back, upright, and in the mid- dle of the seat. Do not lean against the door.
  • Page 59  Do not install seat covers or re-cover seats Mitsubishi Motors dealer. There is a risk that have side airbags. Covers can inter- of a serious injury or death. Improper fere with proper side airbag deployment...
  • Page 60 Supplemental Restraint System (SRS) - airbag The seat belts in your vehicle are your pri- Deployment of side airbag and Side impact in an area away from the passenger mary means of protection in an accident. The curtain airbag compartment SRS side airbags and curtain airbags are designed to provide additional protection.
  • Page 61  If your vehicle has received any damage, Since the side airbags and curtain airbags do you should have the SRS inspected by an authorized Mitsubishi Motors dealer to not protect the occupant in all types of colli- make sure it is in proper working order.
  • Page 62  If you decide to junk or scrap your vehicle, Mitsubishi Motor Sales of Can- we urge you to first take it to an authorized ada, Inc. Mitsubishi Motors dealer so that the SRS can be made safe for disposal. Customer Relations Depart- ...
  • Page 63 Supplemental Restraint System (SRS) - airbag Warning label N00408600383 Occupant restraint warning labels for the SRS are located in the vehicle as shown in the illustration. * - Located in the passenger’s side as well. 4-38 Seat and restraint systems...
  • Page 64 Features and controls Break-in recommendations ..............5-2 Tire pressure monitoring system (if so equipped) ......5-58 Keys ....................5-2 Rear-view camera (if so equipped)..........5-61 Electronic immobilizer (Anti-theft starting system) ......5-3 Instrument cluster ................5-63 Keyless entry system (if so equipped) ..........5-6 Multi-information display .............5-64 Free-hand Advanced Security Transmitter (F.A.S.T.-key) Indicator and warning light package ..........5-74 (if so equipped) ................5-9...

  • Page 65: Break-In Recommendations

    Break-in recommendations Break-in recommendations Keys N00508701382 N00508801703 Advanced automobile manufacturing tech- Type 1 niques permit you to operate your new vehi- cle without requiring a long break-in period of low-speed driving. Two keys are provided. The keys fit all locks. However, you can add to the future perfor- Keep one in a safe place as a spare key.

  • Page 66: Electronic Immobilizer (Anti-Theft Starting System)

    2- Emergency key the vehicle immediately contact an autho- N00509100780 3- Key number plate rized Mitsubishi Motors dealer. [For vehicles equipped with the Free-hand If you notify an authorized Mitsubishi Advanced Security Transmitter (F.A.S.T.- Motors dealer of the key number, they can...
  • Page 67  In cases like the above, move the offending If you lose the key, you can order a key from object(s) away from the key and turn the key your authorized Mitsubishi Motors dealer by back to the “ACC” or “OFF” position. Then referring to the key number.
  • Page 68 Electronic immobilizer (Anti-theft starting system) your vehicle at your Mitsubishi Motors Additional keys NOTE dealer) by doing the following:  When the key registration is completed, the immobilizer indicator will come on within 3 1. Insert the first valid key into the ignition...

  • Page 69: Keyless Entry System (If So Equipped)

    Keyless entry system (if so equipped) General information NOTE Keyless entry system (if so  If you press the LOCK button (1) twice the N00562300097 equipped) horn will sound once. Your electronic immobilizer operates on a N00509002057 radio frequency subject to Federal Communi- Press the remote control transmitter buttons cations Commission (FCC) Rules (For vehi- to lock or unlock the doors.
  • Page 70 Turn signal lights deactiva- can order a remote control transmitter from tion/reactivation  The answerback function will not operate if your authorized Mitsubishi Motors dealer by any of the doors are open. referring to the key number. The turn signal lights answerback function To prevent vehicle theft, the ID code for the can be changed.
  • Page 71 Keyless entry system (if so equipped) tions Commission (FCC) Rules (For vehicles NOTE sold in U.S.A.) and Industry Canada Rules  Be sure to perform the procedure with the (For vehicles sold in Canada). This device Mitsubishi mark facing you. complies with Part 15 of FCC Rules and Mitsubishi mark is not facing you when you Industry Canada licence-exempt RSS stan-...

  • Page 72: Free-Hand Advanced Security Transmitter (F.a.s.t.-Key) (If So Equipped)

    F.A.S.T.-key and then lock B- Internal transmitter  You may purchase a replacement battery at the vehicle. an electric appliance store.  An authorized Mitsubishi Motors dealer can replace the battery for you if you prefer. Features and controls...
  • Page 73 Refer to “To operate without using the details, contact authorized F.A.S.T.-key” on page 5-19. Mitsubishi Motors dealer.  The F.A.S.T.-key is constantly performing • Enabling only the locking and unlocking reception operations in its communication of the doors and the opening of the trunk with the vehicle.
  • Page 74 Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) Operating range for locking and NOTE NOTE unlocking the doors and opening  If the F.A.S.T.-key is within the operating  Even if the F.A.S.T.-key is within the operat- range, even a person not carrying the ing range, it may not be possible to start the the trunk lid F.A.S.T.-key can lock and unlock the doors...
  • Page 75 While carrying the F.A.S.T.-key within the driver’s door switch once. operating range, you can unlock the doors by See an authorized Mitsubishi Motors dealer using the F.A.S.T.-key. for details. The dome light will turn on for 30 seconds.
  • Page 76 Operation mode of the engine  Functions settings can be modified as stated below. switch and its function See an authorized Mitsubishi Motors dealer for details. • Activating the operation confirmation func- tion (blinking of the turn signal lights) only...
  • Page 77 For details, we recommend you to consult an tionary, you can change the operation mode necting the battery, the memorized mode is authorized Mitsubishi Motors dealer. selected automatically. Before disconnect- in the order of OFF, ACC, ON, OFF. ing the battery for repair or replacement, make sure to put the operation mode in OFF.
  • Page 78 This setting can be changed. Please contact an authorized See an authorized Mitsubishi Motors dealer Refer to “Key lock-in preven- Mitsubishi Motors dealer. for details. tion system” on page 5-15.
  • Page 79 Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) When the operation mode is in OFF, the the driver’s door switch, the warning light The engine is warmed up enough for driv- F.A.S.T.-key is left in the passenger compart- blinks and the buzzer sounds for about 3 sec- ing when the low coolant temperature ment, all the doors are closed, and someone onds as a warning, and the doors cannot be...
  • Page 80 (Neutral) position. dures. If the engine still will not start, con- On vehicles equipped with continuously tact your local Mitsubishi Motors dealer 1. Make sure that all electric devices, such variable transmission (CVT), make sure or a repair facility of your choice for as lights, air conditioning blower and rear the selector lever is in the “P”...
  • Page 81 Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) When the ambient temperature is -4 °F (-20 NOTE If the F.A.S.T.-key is not operat- °C) or lower, it may not be possible to start ing properly  If you have to bring the engine to an emer- from a standstill even with the selector lever gency stop while driving, press and hold the in the “D”...
  • Page 82 Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) be used to lock and unlock the passenger’s NOTE door.  Remove the object or additional key from the F.A.S.T.-key before inserting the key into the To use the emergency key (A), unlock the key slot.
  • Page 83 To prevent vehicle theft, take your vehicle Canada) and the remaining F.A.S.T.-keys to an autho- N00561201243 rized Mitsubishi Motors dealer to have the ID You can program new F.A.S.T.-keys to the codes reprogrammed. 4. With the first valid F.A.S.T.-key, press the...
  • Page 84 Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) 7. Release in sequence the LOCK and NOTE To lock UNLOCK buttons within 10 seconds of  It is not possible to register a F.A.S.T.-key if pressing the LOCK button in step 6. The Press the LOCK button (1) to lock all the the immobilizer warning light goes off dur- immobilizer warning light will blink.
  • Page 85 Free-hand Advanced Security Transmitter (F.A.S.T.-key) (if so equipped) The trunk lid must be closed manually after it 3. Press the LOCK button (1) for 4 to 10 sec- Turn signal light deactivation/reactiva- has been opened. onds and press the UNLOCK button (2) tion during this time.
  • Page 86  If you lose your F.A.S.T.-key, please contact WARNING an authorized Mitsubishi Motors dealer for a NOTE replacement.  Changes or modifications not expressly  Be sure to perform the procedure with the ...

  • Page 87: Door Locks

     Never leave a child alone in the vehicle. In  An authorized Mitsubishi Motors dealer can addition to the risk of heat stroke, chil- replace the battery for you if you prefer.

  • Page 88: Power Door Locks

    Power door locks 2. Be sure the keys are not inside the vehi- the lock knob will automatically return to the To lock or unlock the door from cle. Close the door. unlocked position. the inside Operation mode ON reminder Move the lock knob to the lock position to system (vehicles equipped with lock the door.

  • Page 89: Child Safety Locks For Rear Door

    (CVT)}. These functions are not activated when the vehicle is shipped from the factory. To acti- vate or deactivate these functions, please contact your authorized Mitsubishi Motors dealer. Using the selector lever position 1- To lock 2- To release...

  • Page 90: Trunk Lid

    Trunk lid door can be opened using the inside door han- CAUTION Using the remote control transmitter dle. (Vehicles with F.A.S.T.-key)  Do not stand behind the exhaust pipe when loading and unloading luggage. Heat from WARNING Press the trunk button (Vehicles with the exhaust could lead to burns.

  • Page 91: Inside Emergency Trunk Lid Release

    Inside emergency trunk lid release NOTE WARNING Inside emergency trunk lid  The trunk area light comes on when the trunk release  Children should never be left unsuper- lid is opened, and goes out when it is closed. vised in or around vehicles. N00509801188 ...

  • Page 92: Manual Window Control (If So Equipped)

    Manual window control (if so equipped) CAUTION WARNING Power window control  When loading the trunk, place your things so  Never leave the vehicle without carrying N00510800370 that they will not touch the emergency trunk the key. lid release lever when you close the trunk. ...
  • Page 93 Power window control stopped. However, once the driver’s door or Sub switch Type 1 the front passenger’s door is opened, the N00548800098 power windows cannot be operated. Lock switch N00549000169 When this switch is in the lock mode, the pas- senger door switches cannot be used to open or close the door windows, and the main switch will open or close only the driver’s...
  • Page 94 Power window control WARNING CAUTION NOTE  Before driving with a child in the vehicle,  The safety mechanism is deactivated while  If the battery terminals are disconnected or be sure to lock the window switch to make the switch is pulled up. Therefore be espe- the fuse for electric window is replaced, the it inoperative.

  • Page 95: Parking Brake

    Parking brake To apply To deactivate Parking brake N00511400399 To park the vehicle, first bring it to a com- plete stop, fully engage the parking brake, and then move the gearshift lever to 1st (on a uphill) or “R” (Reverse) (on a downhill) posi- tion for vehicles equipped with a manual transaxle, set the selector lever to “P”...

  • Page 96: Inside Rearview Mirror

    Steering wheel height adjustment CAUTION Inside rearview mirror  Before driving, be sure that the parking N00511601402 brake is fully released and brake warning Adjust the inside rearview mirror only after light is off. making any seat adjustments so as to have a If you drive without the parking brake fully clear view to the rear of the vehicle.
  • Page 97 Inside rearview mirror To adjust the vertical mirror To adjust the mirror position To reduce the glare position It is possible to move the mirror up/down and Type 1 left/right to adjust its position. It is possible to move the mirror up and down to adjust its position.

  • Page 98: Outside Rearview Mirrors

    Outside rearview mirrors NOTE To adjust the mirror position Type 2  If you want to stop automatic mode, press N00549100144 When the headlights of the vehicles behind the switch (3) and the indicator (1) will go The outside rearview mirrors can be adjusted you are very bright, the reflection factor of off.

  • Page 99: Ignition Switch

    Ignition switch inside the mirrors, thus clearing away frost or [Except for vehicles equipped with the NOTE condensation. Free-hand Advanced Security Transmit-  After adjusting, return the lever to the “•” The indicator light (A) will illuminate while ter (F.A.S.T.-key)] (OFF) position (C).

  • Page 100: Starting The Engine

    Starting the engine For information on operation for vehicles equipped with the Free-hand Advanced Secu- rity Transmitter (F.A.S.T.-key), refer to The engine runs and all accessories can be “Free-hand Advanced Security Transmitter used. (F.A.S.T.-key): Starting and stopping the engine” on page 5-16. START [Except for vehicles equipped with the Free-hand Advanced Security Transmit-...
  • Page 101 Starting the engine 2. Insert the ignition key. 7. Turn the ignition switch to the “ON” posi- WARNING 3. Make sure the parking brake is applied. tion and make certain that all warning  Never run the engine in a closed or poorly 4.

  • Page 102: Manual Transaxle (If So Equipped)

    If the engine still will not start, contact your  Do not move the gearshift lever into reverse local Mitsubishi Motors dealer or a repair while the vehicle is moving forward; doing facility of your choice for assistance.
  • Page 103 Manual transaxle (if so equipped) conditions (relatively steady speeds) will Avoid downshifting at too high a speed. The NOTE improve your fuel economy. engine may suffer damage.  To shift into reverse from 5th gear, move the To maintain a safe speed and prolong brake gearshift lever to the “N”...

  • Page 104: Continuously Variable Transmission (Cvt) (If So Equipped)

    Continuously variable transmission (CVT) (if so equipped) The CVT selects an optimum ratio automati- Shift Maximum possible driving DRIVING DOWNHILL cally when the selector lever is in the “D” points speed (DRIVE) position, depending on the speed of 2nd gear 53 mph (85 km/h) According to the conditions, the transmission the vehicle and the position of the accelerator...
  • Page 105 4. Depress the brake pedal with the right “jump” forward or backward. Immediately have your vehicle checked by an foot. authorized Mitsubishi Motors dealer or a 5. Insert a screwdriver in the shift-lock NOTE repair facility of your choice. release hole (B). Shift the selector lever to If you need to move the vehicle, shift the the “N”...
  • Page 106 Continuously variable transmission (CVT) (if so equipped) Selector lever position display “R” REVERSE WARNING  To prevent the vehicle from rolling when N00560400078 stopped on a slope, the engine should be Move the lever to this position only after the When the ignition switch is turned to the started in the “P”...
  • Page 107 CVT may be operating in fail- safe mode due to a malfunction.] Have the vehicle inspected at an authorized Mitsubishi Motors dealer or repair facility of your choice immediately. NOTE  The “A” indicator blinks only if the CVT selector lever switch is broken.
  • Page 108 Continuously variable transmission (CVT) (if so equipped) Operation of the CVT CAUTION Waiting  Use the selector lever in the correct shift N00560801095 position in accordance with driving condi- For short waiting periods, such as at traffic CAUTION tions. lights, the vehicle can be left in selector lever Never coast downhill backward in the driv- ...

  • Page 109: Service Brake

    Have your vehicle checked authorized Mitsubishi Motors dealer or a  It is important not to drive the vehicle with at an authorized Mitsubishi Motors dealer or repair facility of your choice immediately. your foot resting on the brake pedal when a repair facility of your choice immediately.

  • Page 110: Hill Start Assist

     When reversing on an uphill slope, place the ficiently depressed, if the vehicle is heavily replaced at an authorized Mitsubishi Motors gearshift lever or selector lever into the “R” loaded, or if the road is very steep or slip- dealer or a repair facility of your choice.

  • Page 111: Brake Assist System

    Brake assist system If the brake pedal is depressed suddenly, the NOTE Warning indicator brakes will be applied with more force than • On vehicles with manual transaxle, the N00562800092 usual. gearshift lever is in the following position. If an abnormal condition occurs in the sys- [When starting an uphill slope forwards.] tem, the following indicator will turn on.

  • Page 112: Anti-Lock Braking System

    (5 km/h). (The standard brake system is functioning normally.) If this happens, take your vehicle to an authorized Mitsubishi Motors dealer or a repair facility of your choice. Features and controls 5-49...

  • Page 113: Electric Power Steering System (Eps)

    Electric power steering sys- Stop the vehicle in a safe place and contact an tem warning light illuminate tem (EPS) authorized MITSUBISHI MOTORS dealer or repair facility of your choice.  Avoid hard braking and high-speed driv- N00568400074 ing. Stop the vehicle in a safe place.

  • Page 114: Active Stability Control (Asc)

    Mitsubishi Motors dealer or a  Be sure to use the same specified type and repair facility of your choice as soon as pos- size of tire on all four wheels.
  • Page 115 Active stability control (ASC) ning excessive, thus helping the vehicle to deactivate the system by pressing down the CAUTION start moving from a stopped condition. It also “ASC OFF” switch for 3 seconds or longer.  Do not install any aftermarket limited slip provides sufficient driving force and steering When the ASC is deactivated, the indica-...
  • Page 116 Mitsubishi Motors dealer or a repair facility activate and the ASC will turn back on. indicator will blink. of your choice as soon as possible.

  • Page 117: Cruise Control (If So Equipped)

    Cruise control (if so equipped) NOTE Cruise control C- RES + switch (if so equipped)  Your speed may increase to more than the set N00518300573 Used to increase the set speed and to return to speed on a steep downhill. You have to use the original set speed.
  • Page 118 Cruise control (if so equipped) To increase your speed in small amounts, NOTE press the RES + switch for less than about 1  When you release the SET - switch, the vehi- second and release it. cle speed will be set. Each time you press the RES + switch, your vehicle will go about 1 mph (1.6 km/h) faster.
  • Page 119 Cruise control (if so equipped) then press the SET - switch (B) and release SET - switch the switch momentarily to set a new desired cruising speed. Press and hold the SET - switch (B) while driving at the set speed, and your speed will slow down gradually.
  • Page 120  [Except for vehicles equipped with the your vehicle inspected by an authorized (15 km/h) or more below the set speed F.A.S.T.-key] Mitsubishi Motors dealer or a repair facility because of a hill, etc. Turn the ignition switch to the “OFF” or of your choice.

  • Page 121: Tire Pressure Monitoring System (If So Equipped)

    When the spare tire is used, the tire pres- sure monitoring system will not work system (if so equipped) properly. See an authorized Mitsubishi Motors N00530201612 dealer as soon as possible to replace or The tire pressure monitoring system uses tire repair the original tire.
  • Page 122 Mitsubishi Motors dealer. the level to trigger illumination of the TPMS In such situations, a malfunctioning of the low tire pressure telltale.
  • Page 123  After inspecting or adjusting the tire pres-  Wheels other than Mitsubishi Motors sure, always reinstall the valve cap on the valve stem. Genuine wheels are being used.

  • Page 124: Rear-View Camera (If So Equipped)

    Mitsubishi Motors dealer, it is not covered by  The rear-view camera is an aid system for ance could void the user’s authority to backing up, but it is not a substitute for your warranty.
  • Page 125 Rear-view camera (if so equipped) Location of rear-view camera Reference lines on the screen CAUTION  The rear-view camera uses a wide-angle The rear-view camera (A) is built-in to the Reference lines and upper surface of the rear lens. As a result, images and distances shown trunk lid.

  • Page 126: Instrument Cluster

    Instrument cluster Instrument cluster Case 2 N00519001428 A- Actual objects B- Objects shown on the screen CAUTION NOTE  The reference lines for distance and vehicle  Mirror image is displayed on the screen. 1- Tachometer  P.5-64 width are intended to indicate the distance to ...

  • Page 127: Multi-Information Display

    Multi-information display CAUTION Type A Type D  The red zone indicates an engine speed beyond the range of safe operation. Select the correct shift position (manual transaxle) or selector position (CVT) to con- trol the engine speed so that the tachometer indicator does not enter the red zone.
  • Page 128 Multi-information display 1- Information display  P.5-66 2- Frozen road warning (if so equipped)  P.5-69 3- Fuel remaining display  P.5-69 4- Selector lever position display (if so equipped)  P.5-43 NOTE  When the ignition switch or the operation mode is in OFF, the selector lever position display, fuel remaining display and frozen road warning are not displayed.
  • Page 129 Multi-information display Information display N00574801054 Each time you lightly press the multi-information display switch (A), the display switches in the following order. 5- Driving range display  P.5-68 9- Service reminder (month)  P.5-70 1- Odometer  P.5-67 6- Average fuel consumption display  2- Trip odometer ...
  • Page 130 Multi-information display NOTE  When the parking lights are not illuminated, the instrument panel light dimmer control is not displayed even if you operate the multi-information display switch. If trip odometer is displayed, only trip Odometer Bright odometer will be reset. N00574900016 The odometer indicates the total distance the NOTE...
  • Page 131 Multi-information display NOTE NOTE NOTE  The brightness level of the instruments is  The display setting can be changed to the  Average fuel consumption may vary depend stored when the ignition switch is turned to preferred units (miles or km). on the driving conditions (road conditions, the “OFF”...
  • Page 132 Multi-information display turned to the “ON” position or the operation Frozen road warning (if so mode is changed to ON. equipped) When the remaining fuel level runs very low (no segments displayed), the bar graph N00579000041 flashes. If the outside air temperature drops below If the warning display appears, refuel as soon approx.
  • Page 133 1. When you lightly press the multi-informa- arrived. tion is due. Contact an authorized tion display switch a few times, the infor- Mitsubishi Motors dealer or a repair facil- mation display switches to the service ity of your choice to have the system NOTE reminder display.
  • Page 134 5-66.  If you accidentally reset the display, consult 2. Each time you press the multi-information an authorized Mitsubishi Motors dealer for display switch for 1 second or more on assistance. driving range display, you can switch reset mode for average fuel consumption.
  • Page 135 Multi-information display [Except for vehicles equipped with the 3. Press and hold the multi-information dis- NOTE F.A.S.T.-key] play switch to switch in sequence from  The average fuel consumption display can be “km/L”  “L/100 km”  “mpg”  Turn the ignition switch to the “ON” posi- reset separately for the auto reset mode and tion from the “ACC”...
  • Page 136 Multi-information display Distance Fuel consumption (driving range) km/L L/100 km mile (s) Changing the temperature unit so equipped) N00557201183 The temperature display unit can be switched. 1. When you lightly press the multi-informa- tion display switch a few times, the infor- mation display switches to the outside temperature display.

  • Page 137: Indicator And Warning Light Package

    Indicator and warning light package Indicator and warning light package N00519801947 9- Low coolant temperature indicator 17- Cruise control indicator 1- High beam indicator  P.5-75 (green)  P.5-75 equipped)  P.5-54 2- Electric power steering system warning 10- Oil pressure warning light  P.5-77 18- Active stability control (ASC) indica- light ...

  • Page 138: Indicators

    Indicators 24- For details, refer to “Warning activa- Front fog light indicator Warning lights (if so tion” on page 5-14 (if so equipped) equipped) N00520300147 Indicators N00520200175 Brake warning light and buzzer This indicator comes on while the front fog N00519900127 N00520400526 lights are on.
  • Page 139 If a problem is detected in one of Mitsubishi Motors dealer or a repair facility • When the brake warning light stays on these systems, this indicator illuminates or of your choice.
  • Page 140 Mitsubishi Motors dealer or a driven at high speeds or on hilly roads. This repair facility of your choice. illuminating does not necessarily indicate a Charging system warning light problem.

  • Page 141: Combination Headlights And Dimmer Switch

    Combination headlights and dimmer switch The daytime running lights will be illumi- NOTE nated:  When the auto cut-out function of the doom light is been activated, the light goes out The daytime running lights illumi- automatically after about 30 minutes. nated Refer to “Dome light”...
  • Page 142 [When using the F.A.S.T.-key to start the vated. engine] [Except for vehicles equipped with the See your authorized Mitsubishi Motors If the driver’s door is opened with the opera- F.A.S.T.-key] dealer for details. tion mode is put in OFF or ACC, or if the The ignition switch is turned to the “OFF”...

  • Page 143: Turn Signal Lever

    Use the full position (2) Have the system inspected by your autho- when making a normal turn. The lever will rized Mitsubishi Motors dealer or a repair return to the neutral position when the turn is facility of your choice.

  • Page 144: Hazard Warning Flasher Switch

    Hazard warning flasher switch See your authorized Mitsubishi Motors NOTE Front fog light switch (if so dealer for details.  If the light switch is rotated to the “OFF” or equipped) “ ” position while the front fog lights are...
  • Page 145 For further information, please contact your The wipers will wipe automatically several HI- Fast authorized Mitsubishi Motors dealer or a times when the washer fluid is sprayed. repair facility of your choice. To turn off the spray, release the lever.

  • Page 146: Electric Rear Window Defogger Switch

     Replace the wiper blades when they are worn. Use the proper size replacement blades. For further information, please con- NOTE tact your authorized Mitsubishi Motors Type 2  Do not use the wipers when the windshield is dealer. dry. This could scratch the glass and wear the wiper blades prematurely.

  • Page 147: Horn Switch

    Horn switch CAUTION USB input terminal  The rear window defogger is not designed to N00566701171 melt snow. Remove any snow manually You can connect your USB memory device or before using the rear window defogger. iPod* to play music files stored in the USB ...

  • Page 148: Sun Visors

    Sun visors 3. To disconnect the connector cable, per- How to connect a USB memory NOTE form the installation steps in reverse. device  Do not connect the USB memory device to the USB input terminal directly. N00566801172 Sun visors The USB memory device may be damaged.

  • Page 149: 12 V Power Outlets

    12 V power outlets ® 12 V power outlets HomeLink Wireless Con- trol System (if so equipped) N00525001670 CAUTION N00554301040  Be sure to use a “plug-in” type accessory ® HomeLink Wireless Control System is a operating at 12 V and at 120 W or less. registered trademark of Gentex Corporation.

  • Page 150: Homelink® Wireless Control System (If So Equipped)

    HomeLink® Wireless Control System (if so equipped) WARNING Programming a new Home- ® Link  During programming, your garage door or gate may open or close. Make sure that N00584700020 people and objects are clear of the garage ® To program HomeLink to operate a garage door or gate that you are programming.
  • Page 151 HomeLink® Wireless Control System (if so equipped) 2. Position the end of your hand-held trans- • If the device does not operate, continue NOTE mitter (B) 1 to 3 inches (2 to 8 cm) away ® with “Programming a new HomeLink ”...
  • Page 152 HomeLink® Wireless Control System (if so equipped) NOTE NOTE  In the event that there are still programming  If programming a garage door opener or gate difficulties or questions, additional Home- operator, it is advised to unplug the device ®...
  • Page 153 HomeLink® Wireless Control System (if so equipped) 3. Once the door has stopped, press and ® The HomeLink has the capability of listen- release the “Learn” or “Smart” button on ing to these messages at a range up to 820.2 the garage door opener (refer to your feet (250 m) (open line of sight), but range garage door opener owner’s manual for...

  • Page 154: Interior Lights

    Interior lights ® 1. Press and hold the 2 outer HomeLink NOTE CAUTION buttons for at least 10 seconds. The indi-  If you do not complete the programming of a  The transmitter has been tested and complies cator will change from continuous yellow new device to the button, it will revert to the with FCC and IC rules.

  • Page 155: Storage Spaces

    If the light is left switched on with the Also, this function can be deactivated. See ignition switch is in the “OFF” or “ACC” your authorized Mitsubishi Motors dealer for position or the operation mode is in OFF details. or ACC, and a door is opened, it goes off...

  • Page 156: Cup Holders

    Cup holders NOTE For the front seat Cup holders  Do not leave valuables in any storage space N00527301518 The cup holder is located in front of the floor when leaving the vehicle. The cup holder is designed for holding cups console.

  • Page 157: Bottle Holders

    Bottle holders NOTE Bottle holders  Do not store cup or drink can in the bottle N00502801075 holder. WARNING  Make sure all lids are tightly closed when storing beverages that are in plastic bottles,  Do not spray water or spill beverages etc.

  • Page 158: Assist Grips

    Assist grips Assist grips N00559000074 These grips are to support the body by hand while seated in the vehicle. CAUTION  Do not use the assist grips when getting into or out of the vehicle. The assist grips could detach causing you to fall. Features and controls 5-95...
  • Page 160 Driving safety Fuel economy ...................6-2 Driving, alcohol and drugs ..............6-2 Floor mat ..................6-2 Vehicle preparation before driving ..........6-3 Safe driving techniques ..............6-4 Driving during cold weather ............6-4 Braking ....................6-5 Parking .....................6-5 Loading information ................6-6 Cargo loads ..................6-10 Trailer towing ................6-11...

  • Page 161: Fuel Economy

    Fuel economy retaining clip on the driver’s floorboard to Fuel economy Driving, alcohol and drugs secure the floor mat. When used, this clip will help prevent the floor mat from moving for- N00628800178 N00628900049 Fuel economy is dependent on many factors. Drunk driving is one of the most frequent ward and possibly interfering with the opera- Your personal driving habits can have a sig-...

  • Page 162: Vehicle Preparation Before Driving

    For a safer and more enjoyable trip, always another model vehicle even if it is a check for the following: Mitsubishi Motors Genuine floor mat. Check these by selecting the defroster mode,  Before driving, be sure to check the fol- and set the blower switch on high.

  • Page 163: Safe Driving Techniques

    WARNING and the vehicle ahead. Mitsubishi Motors dealer.  Before changing lanes, check your mir-  The battery gives off explosive hydrogen rors, your blind spots, and use your turn- gas.

  • Page 164: Braking

    All parts of the brake system are critical to When driving downhill uously variable transmission safety. Have the vehicle serviced by an autho- rized Mitsubishi Motors dealer or a repair (CVT) facility of your choice at regular intervals It is important to take advantage of the engine braking by downshifting while driving on according to the “WARRANTY AND...

  • Page 165: Loading Information

    Loading information transaxle. When this happens, it is difficult to ard located on the driver’s door sill of your WARNING move the selector lever out of the “P” vehicle will show how much weight it may  Do not park your vehicle in areas where (PARK) position.
  • Page 166 Loading information  Curb weight: the weight of a motor vehi- *: 150 lbs (68 kg) is the weight of one per- cle with standard equipment including the son as defined by U.S.A. and Canadian maximum capacity of fuel, oil, and cool- regulations.
  • Page 167 Loading information Determine the combined weight Steps for Determining Correct of luggage and cargo being loaded Load Limit on the vehicle. That weight may N00630201277 not safely exceed the available Locate the statement “The com- cargo and luggage load capacity bined weight of occupants and calculated in Step 4.
  • Page 168 Loading information NOTE  The following table shows examples on how to calculate total cargo/load capacity of your vehicle with varying seating configurations and number and size of occupants. This table is for illustration purposes only and may not be accurate for the seating and load capacity of your vehicle. ...

  • Page 169: Cargo Loads

    Cargo loads WARNING WARNING Cargo loads  To reduce the risk of serious injury or  Make sure that the weight of luggage and N00629700435 death, the combined weights of the driver, the roof carrier do not exceed the maxi- passengers and cargo and must never mum roof load, 110 lb (50 kg).

  • Page 170: Trailer Towing

    Trailer towing CAUTION Trailer towing  Before driving and after traveling a short dis- N00629801358 tance, always check the load to make sure it is securely fastened to the roof carrier. Stop the vehicle periodically and check that the load remains secure. If the load is not secure, it could fall from the vehicle and damage your vehicle, another vehicle or cre- ate a road hazard.
  • Page 172 Comfort controls Vents ....................7-2 Heater without air conditioning function (if so equipped) ....7-4 Manual air conditioning (if so equipped) .........7-7 Automatic air conditioning (if so equipped)........7-12 Important air conditioning operating tips ........7-18 Air purifier (if so equipped)............7-19 Antenna ..................7-19 General information about your radio ...........7-20...

  • Page 173: Vents

    Vents Vents N00729901305 1- Open 2- Close Side vents 1- Center vents 2- Side vents NOTE When the dimple (A) is pressed, the vents  On rare occasions, air from the vents of an open. air-conditioned vehicle may be foggy. This is To close the vents, press the dimple on the Air flow and direction adjust- only moist air cooling suddenly and does not...
  • Page 174 Vents 7-14, “Defogger switch” on page 7-14.) These symbols are used in the next several illustrations to demonstrate the quantity of air coming from the vents. : Small amount of air from the vents : Medium amount of air from the vents : Large amount of air from the vents Face position Air flows only to the upper part of the passen-...

  • Page 175: Heater Without Air Conditioning Function (If So Equipped)

    Heater without air conditioning function (if so equipped) 3- Electric rear window defogger switch NOTE Heater without air condi-  P. 5-83  With the mode selection dial between the tioning function (if so equipped) 4- Mode selection dial “ ”...
  • Page 176 Heater without air conditioning function (if so equipped) Temperature control dial Mode selection dial N00738001067 N00738101084 Turn the temperature control dial clockwise To change air flow direction, turn the mode to make the air warmer. Turn it counterclock- selection dial. Refer to “Changing the mode wise to make the air cooler.
  • Page 177 Heater without air conditioning function (if so equipped) Operating the system Combination of unheated air and Defrosting or defogging (wind- heated air shield, door windows) N00738301099 N00738401045 N00738501091 Heating Set the mode selection dial to the positions CAUTION shown in the illustration and set the air selec- tion lever to the outside air position.

  • Page 178: Manual Air Conditioning (If So Equipped)

    Manual air conditioning (if so equipped) 2. Set the air selection lever to the outside air 4- Electric rear window defogger Manual air conditioning (if so position. switch P.5-83 equipped) 3. Select your desired blower speed by turn- 5- Mode selection dial ing the blower speed selection dial.
  • Page 179 Manual air conditioning (if so equipped) Temperature control dial Mode selection dial Air selection lever N00736601258 N00736701246 N00736801423 Turn the temperature control dial clockwise To change air flow direction, turn the mode Normally, use the outside air position to keep to make the air warmer.
  • Page 180 Manual air conditioning (if so equipped) CAUTION Operating the air conditioning Cooling system  Using recirculated air for a long time may N00731201406 cause the windows to fog up. N00731101304 Heating Air conditioning switch N00731001488 Set the mode selection dial to the “ ”...
  • Page 181 Manual air conditioning (if so equipped) 2. Set the air selection lever to the outside air Combination of unheated air and Defrosting or defogging (wind- position. heated air shield, door windows) 3. Select your desired blower speed by turn- N00731301292 N00731401596 ing the blower speed selection dial.
  • Page 182 Manual air conditioning (if so equipped) NOTE  When defrosting, do not set the temperature control dial near the maximum cool position. This would blow cool air on the window glass and fog it up. Comfort controls 7-11...

  • Page 183: Automatic Air Conditioning (If So Equipped)

    Automatic air conditioning (if so equipped) Automatic air conditioning (if so equipped) N00731501438 The air conditioning can only be used while the engine is running. CAUTION  The engine speed may increase when the air conditioning is operating. With an increased engine speed, a CVT vehicle will creep to a greater degree than with a lower engine speed. Fully depress the brake pedal to prevent the vehicle from creeping.
  • Page 184 Automatic air conditioning (if so equipped) The selected blower speed will be shown in 9- OFF switch Temperature control switch the display (A). 10- Temperature display N00737001406 11- Mode selection display Press of the temperature control 12- Air selection indicator switch to the desired temperature.
  • Page 185 Defogger switch quickly remove fog or frost from the wind- Contact your Mitsubishi Motors dealer or a N00703400015 shield. repair facility of your choice for assistance. When this switch is pressed, the mode Refer to “Personalizing the air conditioning...
  • Page 186 Automatic air conditioning (if so equipped) To change the air selection, simply press the and then to keep the windows from fogging Press the air selection switch for about 10 air selection switch. seconds or longer. The selected position will be shown in the When the setting has changed, the system display (A).
  • Page 187 Automatic air conditioning (if so equipped) When the AUTO switch is pressed, or Air conditioning switch NOTE when the temperature control switch has  When the defogger switch is pressed, the air N00737301409 been set to the minimum temperature, the Push the switch, and the air conditioning conditioning will run automatically, even if air conditioning switch is automatically...
  • Page 188 Automatic air conditioning (if so equipped) In normal conditions, use the system in the OFF switch Defrosting or defogging (wind- AUTO mode and follow these procedures: shield, door windows) N00703600017 Push the switch to turn off the air condition- 1. Push the AUTO switch. N00732401522 ing system.

  • Page 189: Important Air Conditioning Operating Tips

    Have the system inspected by your authorized N00733700336 1. Park the vehicle in the shade whenever Mitsubishi Motors dealer or a repair facility possible. Parking in the hot sun makes the of your choice. vehicle interior extremely hot which then requires more time to cool.

  • Page 190: Air Purifier (If So Equipped)

    During a long period of disuse windshield or windows start to fog up easily, replace the air filter. Contact your Mitsubishi Motors dealer or a To install The air conditioning should be operated for at repair facility of your choice for assistance.

  • Page 191: General Information About Your Radio

    General information about your radio NOTE Signal transmission Reflection • When driving into a structure that has a low FM signals do not follow the earth surface The reason why one can hear FM but not AM ceiling nor are they reflected by the upper atmo- in parking garages, under bridges etc., is that sphere.
  • Page 192 General information about your radio Cross modulation Causes of disturbances If one listens to a weak station and is in the FM reception is affected by the electrical sys- vicinity of another strong station, both sta- tems of vehicles in the vicinity, especially tions might be received simultaneously.
  • Page 194 For emergencies If the vehicle breaks down ...............8-2 Jump-starting the engine ..............8-2 Engine overheating ................8-4 Jack and tools ...................8-5 How to change a tire ................8-6 Towing ...................8-12 Operation under adverse driving conditions ........8-13 Fuel Pump Shut-off System ............8-15...

  • Page 195: If The Vehicle Breaks Down

    If the vehicle breaks down CAUTION If the vehicle breaks down Jump-starting the engine  Check the other vehicle. It must have a 12- N00836300233 N00836401837 volt battery. If the other system isn’t 12-volt, If your vehicle breaks down on the road, If the engine cannot be started because the both systems can be damaged.
  • Page 196 Jump-starting the engine 8. Start the engine in the vehicle providing 6. Connect one end of one jumper cable NOTE the boost. Let the engine idle a few min- to the positive (+) terminal of the dis-  Use the proper cables suitable for the battery utes, then start the engine in the vehicle charged battery (A), and then connect the size.

  • Page 197: Engine Overheating

    Be gles when working near the battery. Mitsubishi Motors dealer or a repair facil- careful as components will be hot. Any  Keep the battery out of the reach of chil- ity of your choice for assistance.

  • Page 198: Seat

    11. Have the system inspected by your autho- The tools are stored beneath the floor board rized Mitsubishi Motors dealer or a repair of the cargo area. The jack is stored under the facility of your choice.

  • Page 199: How To Change A Tire

    How to change a tire On vehicles equipped with continuously To remove WARNING variable transmission (CVT), move the  After storing the jack in place, make sure selector lever to the “P” (PARK) position, the jack is securely fixed in the holder. Turn the shaft end of the jack in the direction and stop the engine.
  • Page 200 Have the tire replaced or repaired at an authorized the installation clamp (A) by turning it Mitsubishi Motors dealer or a repair facility counterclockwise. The compact spare tire is stowed beneath the of your choice as soon as possible.
  • Page 201 How to change a tire 2. Place the jack under one of the jacking NOTE NOTE points (A) shown in the illustration. Use  The flat tire with a normal size wheel cannot  Put the spare wheel under the vehicle body the jacking point closest to the tire you be stored beneath the floor board.
  • Page 202 How to change a tire 4. Insert the bar (D) into the wheel nut WARNING WARNING wrench (E). Then put the end of the bar  No one should be in your vehicle when  Mount the spare wheel with the valve stem into the shaft’s jack end, as shown in the using the jack.
  • Page 203 How to change a tire 7. Install the wheel nuts with their tapered 9. Tighten the nuts in the order shown in the 11. Check the tire inflation pressure. The rec- ends facing inward, then tighten by hand illustration until each nut has been tight- ommended tire pressure for your vehicle until the wheel is no longer loose.
  • Page 204 How to change a tire CAUTION Wheel cover (if so equipped) CAUTION  If the steering wheel vibrates when driving  Trying to remove the wheel cover with only N00849401248 after changing the tire, have the tire checked your bare hands can seriously injure your for balance at an authorized Mitsubishi To remove fingers.

  • Page 205: Towing

    Towing 1. Align the tire air valve (C) and the wheel 4. Gently tap around the circumference of CAUTION cover notch (D). the wheel cover at the top (H), then push  Do not attempt to be towed by another vehi- the wheel cover into place.

  • Page 206: Operation Under Adverse Driving Conditions

    Operation under adverse driving conditions CAUTION Towing with rear wheels off the ground (Type B - M/T vehicles  Do not tow continuously variable transmis- sion (CVT) vehicles with the driving wheels only) on the ground (Type B) as illustrated. If the vehicle is towed like this, the continuously Set the gearshift lever to the “N”...
  • Page 207 Operation under adverse driving conditions Do not rev the engine or spin the wheels.  Your vehicle is equipped with an anti-lock CAUTION Constant efforts to free a stuck vehicle can braking system (ABS). Hold the brake  When driving in rain, a layer of water may cause overheating and transaxle failure.

  • Page 208: Fuel Pump Shut-Off System

    If a fuel leak is found or a fuel odor is detected, do not restart the engine.  Mitsubishi Motors recommends that your vehicle be inspected by an authorized Mit- subishi Motors dealer after any collision.
  • Page 210 Vehicle care and maintenance Service precautions ................9-2 Catalytic converter ................9-3 Engine hood ..................9-4 View of the engine compartment .............9-5 Engine oil and oil filter ..............9-5 Engine coolant .................9-7 Air cleaner filter ................9-8 Manual transaxle oil (if so equipped) ..........9-9 Continuously variable transmission (CVT) fluid (if so equipped) ................9-9 Washer fluid ..................9-9 Brake fluid ..................9-10...

  • Page 211: Service Precautions

     Do not smoke or allow open flames around Have you purchased the Mitsubishi Motors Mitsubishi Motors dealer or a repair facility fuel or the battery. The fumes are flamma- Diamond Care Protection Plan? The Plan of your choice.

  • Page 212: Catalytic Converter

    Catalytic converter If your vehicle is raised with a WARNING WARNING garage jack  Do not use the jack on a tilted or soft sur-  Do not park or run your vehicle in areas face. where combustible materials such as dry Otherwise, the jack might slip and cause grass or leaves can come in contact with a Only use the designated positions shown in...

  • Page 213: Engine Hood

    Engine hood  Stop driving the vehicle if you think the Pull the lever toward you to release the NOTE performance is noticeably low, or the engine hood latch.  To prevent damage to the engine hood and engine has a malfunction such as with the wipers, make sure the wipers are at resting ignition, etc.

  • Page 214: View Of The Engine Compartment

    View of the engine compartment To close NOTE Engine oil and oil filter  If this does not close the engine hood prop- N00937702011 Unlatch the prop from the engine hood and erly, drop it again from a slightly higher put it back in its retainer.
  • Page 215 Engine oil identification mark CAUTION  Overfilling will cause oil aeration and loss of Mitsubishi Motors recommends using only 1- The upper part indicates the quality of oil pressure, which could damage the engine. engine oils with the ILSAC certification sym- the oil.

  • Page 216: Engine Coolant

    Take your vehicle to Synthetic Engine Oil should be used at the antifreeze coolant. an authorized Mitsubishi Motors dealer or a next oil change to maintain optimum fuel repair facility of your choice for testing. economy and cold weather starting.

  • Page 217: Air Cleaner Filter

    You can check the concentration level with a gauge from an automotive supply store, or your vehicle to an authorized Mitsubishi your authorized Mitsubishi Motors dealer or Motors dealer or a repair facility of your service station can check it for you.

  • Page 218: Manual Transaxle Oil (If So Equipped)

    Continuously variable Washer fluid NOTE transmission (CVT) fluid  Genuine Mitsubishi Motors Parts are recom- N00938601371 mended when replacing the air cleaner filter. The windshield washer fluid reservoir is in so equipped)  After replacing the air cleaner filter, make the engine compartment.

  • Page 219: Brake Fluid

    Check the washer fluid level at regular inter- If this occurs, have the vehicle checked by an Brake fluid vals and add washer fluid to reservoir if nec- authorized Mitsubishi Motors dealer or a essary. repair facility of your choice. N00938701314...

  • Page 220: Battery

    It is recommended that you have your battery and charging system checked by an autho- rized Mitsubishi Motors dealer or a repair Vehicle care and maintenance 9-11...

  • Page 221: Tires

    Tires WARNING WARNING Tires  Never disconnect the battery while the  If you are quick-charging your battery, N00939201635 engine is running, or you could damage first disconnect the battery cables. WARNING the vehicle’s electrical parts.  In order to prevent a short-circuit, be sure ...
  • Page 222 Tires  Recommended inflation pressure: the  Sidewall: portion of a tire between the Tire Markings inflation pressure for optimum tire perfor- tread and bead. mance.  Section width: the linear distance between  Intended outboard sidewall: the exteriors of the sidewalls of an •...
  • Page 223 Tires Aspect ratio in percent (%) Service Description WARNING Ratio of section height to section  Overloading of your tire is dangerous. width of tire. Overloading can cause tire failure, affect EXAMPLE: 95H vehicle handling, and increase your stop- Construction code Load index ping distance.
  • Page 224 Tires vehicle. The wrong tire pressure will cause Code representing the tire manu- Traction problems in three major areas: facturing location. (2 digits) The traction grades, from highest to lowest, Code representing the tire size. (2  Safety are AA, A, B and C. Those grades represent digits) Too little pressure increases flexing in the the tire’s ability to stop on wet pavement as...
  • Page 225 Tires The recommended inflation pressures under specified cold pressure, or your tires will be CAUTION normal driving conditions should be used for too low.  If your vehicle is equipped with a tire pres- the tires listed below. Check your tires each time you refuel. If one sure monitoring system, only Mitsubishi tire looks lower than the others, check the Motors Genuine wheels should be used.
  • Page 226 N00939901557 To even out the wear on your tires and make Front them last longer, Mitsubishi Motors Corpora- tion recommends that you rotate your tires at the mileage listed in the “WARRANTY AND Tires that have arrows showing rotation direc- MAINTENANCE MANUAL”.

  • Page 227: Clutch Pedal Free Play (If So Equipped)

    Clutch pedal free play (if so equipped) CAUTION Snow tires Clutch pedal free play (if so  If the tires have arrows (A) indicating the N00940001444 equipped) correct direction of rotation, swap the front In some areas of the country, snow tires are N00940200090 and rear tires on the left-hand side of the required for winter driving.

  • Page 228: Brake Pedal Free Play

    Brake pedal free play WARNING Brake pedal free play Parking brake  Continued operation of the vehicle with N00940300336 N00940400252 the parking brake lever out of adjustment To check the brake pedal free play (A), turn may result in the vehicle moving when off the engine and press the brake pedal sev- Parking brake lever stroke unattended.

  • Page 229: Emission-Control System Maintenance

    Have the valve clearance checked at an maintained by an authorized Mitsubishi N00940900228 authorized Mitsubishi Motors dealer at the Motors dealer or a repair facility of your Spark plugs must fire properly for good mileage specified in the “WARRANTY AND choice.

  • Page 230: General Maintenance

    Have the system checked at an authorized for: the engine exhaust system properly serviced. Mitsubishi Motors dealer at the mileage spec- Have a competent mechanic inspect the com- ified in the “WARRANTY AND MAINTE-  Severe surface cracking, scuffing or worn plete exhaust system and nearby body areas NANCE MANUAL”.

  • Page 231: For Cold And Snowy Weather

    In case of a melted fusible link, see your Check for any of the following authorized Mitsubishi Motors dealer or a The ventilation slots in front of the wind- conditions: repair facility of your choice for inspection shield should be brushed clear after a heavy and replacement.
  • Page 232 Fuses individual circuit is equipped with a fuse. The Passenger compartment fuse loca- fuse blocks are located in the passenger com- tion table partment and in the engine compartment. Type A Passenger compartment Type B The fuse block in the passenger compartment is located in front of the driver’s seat at the position shown in the illustration.
  • Page 233 Fuses  The table above shows the main equip- Sym- Capac- Sym- Capac- Electrical system Electrical system ment corresponding to each fuse. Rear fog light 10 A DC-DC (P/T) 30 A Engine compartment fuse location Door lock 15 A DC-DC (AUDIO) 30 A table Interior light (Dome...
  • Page 234 Fuses 15 A: Cigarette lighter Sym- Capac- Type B Electrical system When using a substitute fuse, replace with a fuse of the correct capacity as soon as possi- Alternator 7.5 A ble. Hazard warning 10 A flasher Identification of fuse Automatic trans- 15 A axle...

  • Page 235: Replacement Of Light Bulbs

    If the glass surface is dirty, clean it with checked by an authorized Mitsubishi Motors alcohol and let it dry completely before dealer or a repair facility of your choice to installing the bulb.
  • Page 236 NOTE these procedures be carried out by an autho- rized Mitsubishi Motors dealer or a repair  It is not possible to repair or replace only the facility of your choice. bulb for the side turn signal light (on fender).
  • Page 237 Wattage N00950401715 or bulb view mirror) uses an LED rather than the type bulb. For repair and replacement, contact an authorized Mitsubishi Motors dealer or a Tail and stop 21/5 W P21/5W repair facility of your choice. light Rear side-marker...
  • Page 238 1. While pressing the tab (A), pull out the N00943200352 connector (B). The alignment of the headlights should be checked by an authorized Mitsubishi Motors dealer or a repair facility of your choice. Front side-marker lights N00917301681 1. Turn the socket (A) counterclockwise to 3.
  • Page 239 Replacement of light bulbs 2. Remove the bulb from the socket by turn- 2. Remove the 3 screws (B) and remove the 3. Depress the tab (D) on the harness con- ing it counterclockwise while pressing in. light unit. nector and pull the harness connector (E) to remove it.
  • Page 240 Replacement of light bulbs 4. Turn the socket counterclockwise to Rear combination lights Type 1 Type 2 remove it. N00943701572 1. Open the trunk lid. 2. Remove the screws (A) that hold the light unit. 6. To install the bulb, perform the removal steps in reverse.

  • Page 241: Vehicle Care Precautions

    N00945200095 corrosives. If you are not sure, contact an After washing the inside of your vehicle with authorized Mitsubishi Motors dealer for help any cleaner, wipe it dry in a shady, well venti- in choosing these materials. lated area.

  • Page 242: Cleaning The Outside Of Your Vehicle

    Cleaning the outside of your vehicle Use a vacuum cleaner and brush to clean Plastic, vinyl leather, fabric and NOTE the seats. If stained, vinyl and synthetic flocked parts  If genuine leather is wet with water, wipe it leather should be cleaned with an appro- with a dry, soft cloth.
  • Page 243 Cleaning the outside of your vehicle Foreign material CAUTION During cold weather  When washing the underside of your vehicle N00945800033 or the wheels, wear a pair of gloves to pro- Salt and other chemicals spread on winter Industrial pollution, road tar, bird droppings, tect your hands.
  • Page 244 Cleaning the outside of your vehicle Use a soft cloth to put a small amount of wax cloth in one direction. After polishing, flush CAUTION on the painted surfaces. After the wax has the compound from the surface and apply a ...
  • Page 245 Cleaning the outside of your vehicle CAUTION Engine compartment  Do not use a brush or other hard implement N00947000071 on the wheels. Never spray or splash water on the electrical  Do not use any cleaner that contains an abra- accessories in the engine compartment.
  • Page 246 Customer assistance/ Reporting Safety Defects Consumer information (For vehicles sold in U.S.A.) ....10-2 Reporting Safety Defects ...............10-2 Important facts to know in case of an accident ......10-4...
  • Page 247 Administration (NHTSA) in addi- ) times as well on the government course heat when tested under controlled conditions tion to notifying Mitsubishi Motors as a tire graded 100. The relative performance on a specified indoor laboratory test wheel. Corporation.
  • Page 248 Canada, Inc. call 1-888-576-4878 or and if it finds that a safety defect write to: To contact Mitsubishi Motors North exists in a group of vehicles, it may America, Inc. call 1-888-648-7820 or Mitsubishi Motor Sales of Can- order a recall and remedy campaign.
  • Page 249 Important facts to know in case of an accident  Ask for genuine Mitsubishi Motors parts. Consumer rights (For vehicles Important facts to know in Many times, to save money, your insur- sold in U.S.A.) case of an accident ance company will recommend imitation...
  • Page 250 Important facts to know in case of an accident Remember to ask for genuine Mitsubishi Motors parts. Customer assistance/Reporting Safety Defects 10-5...
  • Page 252 Specifications Vehicle labeling ................11-2 Vehicle dimensions ................11-3 Vehicle weights ................11-4 Engine specifications ..............11-5 Battery ....................11-5 Tires and wheels ................11-5 Capacity ..................11-6...

  • Page 253: Vehicle Labeling

    Vehicle labeling 1 - Vehicle emission control Chassis number Vehicle labeling information label N01147401895 The chassis number is stamped on the bulk- Keep a record of the chassis number and head as shown in the illustration. vehicle identification number. Such informa- The vehicle emission control information tion will assist police if your vehicle is stolen.

  • Page 254: Vehicle Dimensions

    Vehicle dimensions Engine model/serial number Certification label N01148200242 The engine model and serial number are The certification label is located on the stamped on the cylinder block as shown in driver’s door sill. the illustration. *- Front of the vehicle Vehicle dimensions N01147501652 Tire and loading information...

  • Page 255: Vehicle Weights

    Vehicle weights Vehicle weights N01147602012 Item Manual transaxle Continuously variable transmission (CVT) Gross vehicle weight rating (GVWR) 3,053 lb (1,385 kg) 3,108 lb (1,410 kg) Front 1,609 lb (730 kg) Gross axle weight rating (GAWR) Rear 1,521 lb (690 kg) Vehicle capacity weight 827 lb (375 kg) Seating capacity...

  • Page 256: Engine Specifications

    Pitch Circle Diameter (installation Battery is a 12 volt type. holes) Tires and wheels NOTE N01147901858  Contact an authorized Mitsubishi Motors dealer for details on the combination used on 165/65R14 175/55R15 Tire your vehicle.  These tires satisfy vehicle loading conditions described in this owner’s manual.

  • Page 257: Capacity

    If these oils are not available, an API classification SN or Oil filter .21 qt (0.2 L) higher can be used. Mitsubishi Motors Genuine NEW MULTI GEAR OIL ECO Manual transaxle 1.7 qt (1.6 L) API GL-4 SAE 75W-80 Refer to “Continuously variable transmission (CVT) fluid” on Continuously variable transmission (CVT) 7.4 qt (7.0 L)
  • Page 258 Alphabetical index Disconnection and connection ..9-11 Certification label ....... 11-3 During cold weather ....... 9-11 Charging system warning light ..... 5-77 Specification........11-5 Accessory (installation) ......3-5 Child restraint systems ......4-14 Bottle holders........5-94 Active stability control (ASC) ....5-51 Child safety locks for rear door ....
  • Page 259 Alphabetical index Dimmer (high/low beam change) ..5-80 Engine hood ........9-4 Filling the fuel tank......3-3 Fuel economy........6-2 Disc brake pads ........9-21 Engine switch ........5-13 Fuel hoses........9-20 Dome light Exhaust system ........9-21 Fuel remaining warning display ..5-69 Bulb capacity .........
  • Page 260 Alphabetical index Heater without air conditioning function . 7-4 Manual window control....... 5-29 High beam indicator......5-75 Modifications to and racing of your vehicle .. Jack High coolant temperature warning light 5-77 Garage jack up position..... 9-3 Multi-information display ... 5-63, 5-64 High-mounted stop light Storage..........
  • Page 261 Alphabetical index Power windows ........5-29 Child restraint systems..... 4-14 Sun visors .......... 5-85 Front passenger seat belt warning light..Puncture (Tire changing) ....... 8-6 Supplemental Restraint System .... 4-22 4-11 How the Supplemental Restraint System Maintenance and inspection ..... 4-22 works ..........
  • Page 262 Alphabetical index Turn signal light Wheel Indicators........5-75 Covers........... 8-11 Lever ..........5-80 Specification........11-5 Wiper Switch........... 5-81 Wiper blades........9-19 USB input terminal ......5-84 How to connect a USB memory device ..5-85 How to connect an iPod....5-85 Vanity mirror ........
  • Page 263 How to calculate your gasoline mileage...

Table of Contents
