- Page 1 Air conditioner User manual AR**NV3X*** / AR**NV5X*** • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Display Remote Control Overview Inserting batteries Remote Control Operation Operation modes • Controlling temperature • Controlling fan speed • Controlling air flow direction Power Smart Features Cooling Operation Cool mode • 2-Step cooling function • Wind-Free Cooling function Dehumidifying Operation Dry mode Quick Smart Features... - Page 3 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or contact our Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864).
-
Page 4: Safety Information
Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. If you have any questions, call your nearest contact centre or find help and information online at www.samsung.com. WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 5 • This may result in electric shock or fire. Never install the outdoor unit in a location such as on a high external wall where it could fall. • If the outdoor unit falls, it may result in injury, death or property damage. This appliance must be properly grounded.
- Page 6 FOR USING WARNING If the appliance is flooded, please contact your nearest service centre. • Failing to do so may result in electric shock or fire. If the appliance generates a strange noise, a burning smell or smoke, cut off the power supply immediately and contact the nearest service centre.
- Page 7 Do not place an object near the outdoor unit that allows children to climb onto the machine. • This may result in children seriously injuring themselves. Do not use this air conditioner for long periods of time in badly ventilated locations or near infirm people.
- Page 8 Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or for any other unusual purposes. • This may result in property damage. Avoid directly exposing humans, animals or plants to the air flow from the air conditioner for long periods of time.
-
Page 9: At A Glance
Indoor Unit Overview The actual product may differ slightly from the image depicted below. 01 Air intake 05 Room temperature sensor 02 Air filter 06 Wind-Free panel 03 Air flow blade (up and down) 07 Display 04 Air flow blade (left and right) 08 Power button /Remote control receiver Display Temperature indicator... -
Page 10: Remote Control Overview
Remote Control Overview Set temperature indicator Timer option indicator Operation mode indicator Options indicator Low battery indicator Transmit indicator Fan speed indicator Ionizer indicator Wind-Free indicator Vertical air swing indicator Horizontal air swing indicator Power button Temperature button Timer button Fan speed button Direction button / Selection button... -
Page 11: Remote Control Operation
Remote Control Operation You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan speed, and air direction. Operation modes You can change the current mode between Auto, Cool, Dry, and Fan by pressing the button. - Page 12 Controlling fan speed You can select the following fan speeds in each mode: Mode Available fan speeds Auto/Dry (Auto) (Auto), (Low), (Med), (High), Cool (Turbo) (Low), (Med), (High), (Turbo) Controlling air flow direction For AR**NV3X*** model Vertical air flow Keep the vertical air flow in a constant direction by stopping the movements of the vertical air flow blade.
- Page 13 Controlling air flow direction For AR**NV5X*** model Keep the air flow in a constant direction by stopping the movements of the vertical and horizontal air flow blades. ► In operation NOTE • If you adjust the vertical air flow blade manually, it may not close completely when you turn off the air conditioner.
-
Page 14: Power Smart Features
Cooling Operation The smart and powerful cooling functions of the Samsung air conditioner keep an enclosed space cool and comfortable. Cool mode Use the Cool mode to stay cool in hot weather. ► ► Select Cool. NOTE • For comfort, keep the temperature difference between the indoor and outdoor air within 5 °C in the Cool mode. - Page 15 Wind-Free Cooling function Use the Wind-Free Cooling function to enjoy mild cool breeze exuding from fine holes on the Wind-Free panel with the air flow blade closed, instead of getting cool wind directly. The automated control of the temperature and fan speed according to the indoor temperatures keeps your room cool and pleasant.
-
Page 16: Dehumidifying Operation
Dehumidifying Operation The dehumidifying function of the Samsung air conditioner keeps an enclosed space dry and comfortable. Dry mode Use the Dry mode in rainy or humid weather. ► ► Select Dry. NOTE • The lower the set temperature is, the greater the dehumidifying capacity is. -
Page 17: Quick Smart Features
Quick Smart Features There is a variety of extra functionality provided by the Samsung air conditioner. Auto mode Use the Auto mode when you want the air conditioner to automatically control the operation. The air conditioner will provide the most comfortable atmosphere that it can. - Page 18 NOTE • If you select the Fast function while such functions as 2-Step cooling, Wind-Free Cooling, Comfort, Single user, Quiet, or good'sleep are running, these functions are cancelled. • You can change the air flow direction. • You cannot change the set temperature and the fan speed. Comfort function Use the Comfort function when you feel the current cooling effect is too strong.
- Page 19 Quiet function Use the Quiet function to reduce operating noise. You can select this function in the Cool mode. ► ► ► In the Cool mode ► Select Quiet. NOTE • You can change the set temperature and the air flow direction. •...
-
Page 20: Energy-Saving Features
Energy-Saving Operation The smart energy-saving functions of the Samsung air conditioner reduce electricity consumption. Electricity consumption check Use the Usage function to check the amount of electricity consumed by using the air conditioner. The amount consumed is displayed on the indoor unit display for a few seconds, and the set indoor temperature appears. - Page 21 NOTE • If you select the Single user while such function as 2-Step cooling, Wind-free Cooling, Fast, Comfort, Quiet, or good'sleep are running, these modes are cancelled. • You can also start the Single user function by pressing the Options ) button.
- Page 22 good’sleep function Use the good'sleep function to get a good sleep at night and to save energy. You can select this function in the Cool mode. (Select among On, Off, ► ► In the Cool mode ► (Set the operation time.) •...
-
Page 23: Cleaning And Maintenance
Cleaning at a Glance Running Auto clean Method 1 : Press the button for The Auto clean function 3 seconds or more. is activated. Select Method 2 : When operation is off, [Clean] auto clean starts for 10 min. The indoor unit display shows : ●... - Page 24 CAUTION • Do not clean the display by using alkaline detergent. • Do not use sulphuric acid, hydrochloric acid, or organic solvents (such as thinner, kerosene, and acetone) to clean the surfaces. Do not put any stickers on it as this can damage the surface of the air conditioner. •...
- Page 25 Tip on cleaning the Wind-Free panel Gently push the air flow blade Hold and pull both sides of Remove the dust with a soft with your finger until it is open. the Wind-Free panel until it is brush or vacuum cleaner. detached from the air conditioner.
-
Page 26: Troubleshooting
Troubleshooting If the air conditioner operates abnormally, refer to the following chart to save time and unnecessary expenses. Problem Solution • Check the power status, then operate the air conditioner again. • Switch on the circuit breaker, plug in the power cord, then operate the air conditioner again. - Page 27 Problem Solution The Timed on/off function • Check whether you pressed the SET button on the remote control after does not work. setting the time. The indicator blinks • Press the Power button to turn off the air conditioner or disconnect the continuously.
- Page 28 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT INDIA 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free) www.samsung.com/in/support This product is RoHS compliant DB68-07493A-00...
