Philips QT4020 User Manual

5 Close the cutting unit by pushing it back onto the
ENGLISH
appliance until you hear a click (fig. 12).
Important The appliance does not need any lubrication.
.
Read these instructions for use carefully before using the
Replacing the cutting unit
appliance and save them for future reference.
A worn or damaged cutting unit should only be replaced
Make sure the appliance, the cord and the
with an original Philips cutting unit, available from
powerplug do not get wet. authorised Philips service centres.
Check if the voltage indicated on the powerplug
1 Open the cutting unit.
corresponds to the local mains voltage before you
connect the appliance. 2 Remove the old cutting unit by pulling it upwards
Only use the powerplug supplied. (fig. 13).
Keep the appliance out of the reach of children.
3 Place the two lugs of the new cutting unit into the
Charge, use and store the appliance at a
guiding slots (fig. 14).
temperature between 15cC and 35cC.
This appliance is only intented for trimming the
4 Push the cutting unit back onto the appliance until
human beard. Do not use it for any other purpose.
you hear a click (fig. 12).
Do not use the appliance when the cutting unit is
Environment
damaged or broken, as this may cause injury.
.
If the powerplug is damaged, always have it replaced
Do not throw the appliance away with the normal
by one of the original type in order to avoid a hazard. household waste at the end of its life, but hand it in at
The powerplug contains a transformer. Do not cut an official collection point for recycling. By doing this
off the powerplug to replace it with another plug, as you will help to preserve the environment (fig. 15).
this will cause a hazardous situation.
The built-in rechargeable battery contains substances that
Noise level Lc = 64 dB[A]
may pollute the environment. Always remove the battery
before discarding the appliance or handing it in at an
Charging
.
official collection point. Dispose of the battery at an
Charge the appliance fully before you start using it for the
official collection point for batteries. If you have trouble
first time.
removing the battery, you can also take the appliance to a
1 Make sure the appliance is switched off (fig. 1). Philips service centre, which will remove the battery for
you and will dispose of it in an environmentally safe way.
2 Insert the appliance plug into the appliance (fig. 2).
1 Disconnect the appliance from the mains and let the
3 Put the powerplug in the wall socket.
appliance run until the motor stops.
The green light on the powerplug will go on to
2 Undo the screw in the housing of the trimmer
indicate that the appliance is charging (fig. 3).
(fig. 16).
It will take approx. 10 hours to fully charge the battery.
3 Separate the 2 housing parts by means of a
Do not charge the appliance for more than 24 hours.
screwdriver (fig. 17).
A fully charged appliance has a cordless trimming time of
4 Insert the screwdriver into the small slot in the
up to 35 minutes.
printed circuit board marked with an arrow. Push
The appliance does not run from the mains.When the screwdriver down until parts of the printed
the battery is empty, charge it as described above. circuit board break off (fig. 18).
5 Remove the battery holder including the
Optimising the lifetime of the battery
rechargeable battery (fig. 19).
When the appliance has been charged for the first time, 6 Separate the rechargeable battery from the battery
we advise you to use it until the battery is completely holder (fig. 20).
empty.
Do not connect the appliance to the mains again
Do not recharge the appliance in between the trimming
after it has been opened!
sessions.
Continue using the appliance until the motor almost
Guarantee & service
.
stops running during a session.Then recharge the battery.
If you need information or if you have a problem, please
Follow this procedure at least twice a year.
visit the Philips Web site at www.philips.com or contact
the Philips Customer Care Centre in your country (you
Trimming
.
will find its phone number in the worldwide guarantee
Always comb the beard and/or moustache with a fine
leaflet). If there is no Customer Care Centre in your
comb before you start trimming.
country, turn to your local Philips dealer or contact the
If you are trimming for the first time, be careful. Service Department of Philips Domestic Appliances and
Do not move the trimmer too fast. Make smooth and
Personal Care BV.
gentle movements.
Trimming with comb attachment
1 Turn the Precision Zoom Lock` to the desired
trimming length setting (see table) (fig. 4).
The setting will appear in the window below the
Precision Zoom Lock`.
B If you are trimming for the first time, start by using the
maximum trimming length setting (9).
2 Switch the appliance on.
3 To trim in the most effective way, move the trimmer
against the direction of hair growth. Make sure the
surface of the comb always stays in contact with the
skin (fig. 5).
4 If a lot of hair has accumulated in the comb, remove
the comb attachment and blow and/or shake the
c
hair out of the comb.The selected trimming length
setting will not change when you do this (fig. 6).
Trimming length settings table
setting resulting beard length
1 1.5 mm
2 2.5 mm
3 4 mm
4 5.5 mm
5 7.5 mm
6 9.5 mm
7 12 mm
8 15 mm
9 18 mm
Trimming with the unique 'stubble look'
setting
Using the minimum setting (1) will result in a
'stubble look' (fig. 7).
Trimming without comb attachment
Full beards and single hairs
1 Remove the comb attachment by pulling it off the
appliance (fig. 8).
Never pull at the flexible top of the comb attachment.
Always pull at the bottom part.
2 Switch the appliance on.
3 Make well-controlled movements.Touch the hair
lightly with the trimmer (fig. 9).
Cleaning
.
Do not use abrasives, scourers or liquids such as alcohol,
petrol or acetone to clean the appliance.
1 Make sure the appliance is switched off and
disconnected from the mains before you start
cleaning it.
2 Remove the comb attachment.
3 Open the cutting unit (fig. 10).
4 Clean the cutting unit and the inside of the appliance
with the brush supplied (fig. 11).
`
.
`
B Pokud přístroj používáte poprvé, začněte s maximálním
nastavením délky střihu (9).
B
c
MAGYAR
c c
Ne használja a készüléket, ha a vágóegység hibás
vagy törött, mert ez sérülést okozhat.
`
`
Mikor első alkalommal vágja szakállát, kezdje a
legnagyobb vágási hosszal (9).
`
`
B Якщо Ви стрижете бороду уперше, почніть із
максимального значення довжини (9).
c c
Trimmer
QT4020
u
www.philips.com
4203 000 55371
1 2 3
CHARGE
4 5 6
9
9
7 8 9
10 11 12
13 14 15
16 17 18
19 20
