General Safety Information & Replacement Parts

TABLE OF CONTENTS

General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Air Compressor and Air Tool Safety . . . . . . . . . . . . . . . . . . . 2-3
Tool Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance / Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
WARNING: Risk of injury to persons. Read and
understand operation instructions. Always become familiar
with all the instructions and warnings before operating any
pneumatic tool.
1"Super Duty Impact Wrench
: This product contains lead, a chemical known to
WARNING
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
: This product contains chemicals known to
WARNING
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
FP-793B
IMPACTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP-793B and is the answer not in the manual?

Questions and answers

Related Manuals for Florida Pneumatic FP-793B

Summary of Contents for Florida Pneumatic FP-793B

  • Page 1 FP-793B 1”Super Duty Impact Wrench IMPACTS General Safety Information & Replacement Parts TABLE OF CONTENTS General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2...
