TABLE OF CONTENTS
General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Air Compressor and Air Tool Safety . . . . . . . . . . . . . . . . . . . 2-3
Tool Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance / Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
WARNING: Risk of injury to persons. Read and
understand operation instructions. Always become familiar
with all the instructions and warnings before operating any
pneumatic tool.
UT8150P-2 (Pin Retainer)
UT8150R-2 (Ring Retainer)
1/2" Pistol Impact Wrench
: This product contains lead, a chemical known to
WARNING
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
: This product contains chemicals known to
WARNING
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
IMPACTS
Advertisement
Table of Contents
Related Manuals for Florida Pneumatic Universal Tool UT8150P-2
Summary of Contents for Florida Pneumatic Universal Tool UT8150P-2
-
Page 1: Table Of Contents
UT8150P-2 (Pin Retainer) Universal Tool UT8150R-2 (Ring Retainer) 1/2" Pistol Impact Wrench ™ IMPACTS General Safety Information & Replacement Parts TABLE OF CONTENTS General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 : This product contains lead, a chemical known to WARNING Air Compressor and Air Tool Safety . -
Page 2: General Safety Information
Safety Information • If the pneumatic tool is used in a dust filled environment exhaust 7.2.2.3 GENERAL SAFETY RULES air can cause a dust hazard • Multiple hazards. Read and understand the safety instructions before • Dusts and fumes generated when using power tools can cause installing, operating, repairing, maintaining, changing accessories on, ill health (for example: cancer, birth defects, asthma and/or der- or working near the power tool. Failure to do so can result in serious matitis); risk assessment of these hazards and implementation of bodily injury. appropriate controls of is essential. • Only qualified and trained operators should install, adjust or use the • Risk assessment should include dust created by the use of the tool power tool. and the potential for disturbing existing dust. • Do not modify this power tool. Modifications may reduce the effec- • Operate and maintain the power tool as recommended in these tiveness of safety measures and increase the risks to the operator. instructions, to minimize dust or fume emissions • Do not discard the safety instructions – give them to the operator. • Direct the exhaust so as to minimized disturbance of dust in a dust • Do not use a tool if the tool has been damaged. filled environment • Warnings shall be given against the risk of explosion or fire due to the • Where dusts or fumes are created, the priority shall be to control material being processed;... -
Page 3: Air Compressor And Air Tool Safety
Safety Information (continued) AIR COMPRESSOR AND AIR TOOL SAFETY WARNING: Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains 1. Risk of Bursting. Do not adjust the regulator to result in output chemicals known to cause cancer, birth defects or other pressure greater than the marked maximum pressure of this air reproductive harm. -
Page 4: Installation
Installation Cleaning the air hose □ A 3/8" air hose is required, with a maximum length of 25 ft. □ Clean the air hose of accumulated dust and moisture before connecting it to the air supply. NOTE: If a longer air hose is required, connect a 1/2" air hose to the 3/8"... -
Page 5: Troubleshooting
Troubleshooting Problem Possible Cause Solution The tool runs slowly or will not There is grit or gum in the tool. Flush the tool with air tool oil or gum solvent. operate. The tool is out of oil. Lubricate the tool according to the lubrication instructions in this manual. -
Page 6: Service Parts
UT8150P-2 (Pin Retainer) Service Parts / Exploded View Drawing Part Number Description Part Number Description Qty . 900-0104 Cap Screw 9305-009B Rear End Plate 900-1806 Spring Washer 900-2305 Ball Bearing 9303R-002 Hammer Case w/Bushing 9303R-020 Rear Gasket 9303R-019B Front Gasket 900-4311 Insert Recoil 9305F-XI-010... - Page 7 UT8150R-2 (Ring Retainer) Service Parts / Exploded View Drawing Part Number Description Part Number Description Qty . 900-0104 Cap Screw 9303R-020 Rear Gasket 900-1806 Spring Washer 900-4311 Insert Recoil 9303R-002 Hammer Case w/Bushing 9303D-001 Motor Housing 9303R-019B Front Gasket 900-41108 O-Ring 9305F-XI-010 Anvil Bushing...
